- Page 1 NO GAS/GAS MIG WELDER MODEL NO: MIG145 PART NO: 6014505 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0721 - rev 10...
-
Page 2: Environmental Recycling Policy
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: General Precautions
SAFETY PRECAUTIONS FOR ALL TYPES OF WELDING WARNING: AS WITH ALL MACHINERY, THERE ARE CERTAIN HAZARDS INVOLVED WITH THEIR OPERATION AND USE. EXERCISING RESPECT AND CAUTION WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY. HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED, OR IGNORED, PERSONAL INJURY TO THE OPERATOR MAY RESULT. - Page 4 perchloroethylene vapours to form phosgene. DO NOT WELD or cut where solvent vapours can be drawn into the welding or cutting atmosphere or where the radiant energy can penetrate to atmospheres containing even minute amounts of trichloroethylene or perchloroethylene. C) FIRE AND EXPLOSION PREVENTION Causes of fire and explosion are: 1.
- Page 5 A container with unknown contents should be cleaned (see paragraph above). Do NOT depend on sense of smell or sight to determine if it is safe to weld or cut. Hollow castings or containers must be vented before welding or cutting as they can explode.
-
Page 6: Toxic Fume Prevention
intensity gas-shielded arc) can cause a retinal burn thatmay leave a permanent dark area in the field of vision. Before welding whilst wearing contact lenses, seek advice from your optician. PROTECTION OF NEARBY PERSONNEL For production welding, a separate, well vented room or enclosed bay is best. In open areas,surround the operation with low reflective, non- combustible screens or panels. - Page 7 Examples of conducting objects include, but are not limited to, buildings, electrical tools, work benches, welding power source cases, workpieces, etc. Never touch the electrode and any metal object unless the welding power source is off. When installing, connect the frames of each unit such as welding power source, control, work table, and water circulator to the building earth.
-
Page 8: Preparation Of The Working Area
PREPARATION OF THE WORKING AREA The working area must be sufficiently spacious, not humid, and well-ventilated as to avoid any fumes which develop from the welding process and from incidental material adhering to the pieces to be welded (oils, paints, tars...) which may cause danger to the operator. - Page 9 17. NEVER allow the earth cable or torch hose to become wrapped around the operator or any person in the vicinity. A comprehensive range of CLARKE safety equipment for use when welding is available from your local dealer. the mains supply. Consideration should be given to shielding the supply cable of permanently installed welding equipment, in metallic conduit or equivalent.
-
Page 10: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS FULLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. This product is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. Should the plug need changing, make sure that a plug of identical specification is used. -
Page 11: Safety Symbols
Read instruction manual before use. INVENTORY Any damage or deficiency should be reported to your CLARKE dealer immediately. Some of the components are stored within the machine side compartment. The components include the following: •... - Page 12 OVERVIEW NO DESCRIPTION NO DESCRIPTION Pull Handle Torch Carry Handle Torch Hose Gas Connection Point Earth Clamp Side Panel Wheels Control Panel Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 13: The Control Panel
THE CONTROL PANEL 1. Thermal overload light. If the duty cycle is exceeded as a result of welding too long with a high current, the yellow overload light will illuminate and the welder will turn off. When the welder has cooled down (approx. 5 to 10 minutes), the power will be restored and welding can recommence. -
Page 14: Opening The Side Panel
When replacing the glass panels, only use parts supplied by Clarke International. The dark panel is a certified, specific optical class and should not be exchanged for any other type. 5. The clear glass panel should be replaced when it becomes badly pitted. -
Page 15: Preparation For Use
PREPARATION FOR USE FITTING THE WHEELS 1. Fit two e-clips onto the axle in the positions shown. 2. Slide the axle into the wheel supports. 3. Fit two e-clips onto the opposite end of the axle in the same positions. 4. -
Page 16: Fitting The Handle
MOUNTING THE WELDING WIRE SPOOL Warning: Ensure that the welder is not connected to the mains supply. NOTE: Spools of welding wire are available from your Clarke dealer. 1. Open the side panel, by pushing the latch down and allowing the side panel to drop down. -
Page 17: Setting The Drive Roller Size
SETTING THE DRIVE ROLLER SIZE 1. Loosen the tensioning knob and pivot it towards you. 2. Lift up the arm. 3. Take hold of the triangular knob on the drive roller cover and rotate it 90°anticlockwise to release it. 4. Pull the roller retainer off the drive spindle to reveal the roller. - Page 18 4. Pass the wire through the guide, over the drive roller and into the torch liner. • Push about 10-15 cm into the torch liner. 5. Lower the arm and replace the tensioning knob. • Tighten the tensioning knob sufficiently to hold firmly, but do not fully tighten.
-
Page 19: Mig Welding Principles
The gas is used to prevent oxidation and to shield the arc and the weld from atmospheric contamination. The choice of gas is dependent upon the material being welded, Two types are available from Clarke International. Carbon Dioxide (CO ) For Mild Steel Part No. -
Page 20: Operating The Welder
WELDING WITHOUT GAS 1. If using 0.9mm flux cored wire, connect the terminal as shown. • The earth cable (Thicker Lead) should be connected to the positive (Red) terminal. • The cable from torch (Thinner Lead) should be connected to the Negative (Black) terminal. -
Page 21: Operation
OPERATION CAUTION: THE DUTY CYCLE MUST BE ADHERED IN ORDER TO PREVENT THE THERMAL OVERLOAD PROTECTION FROM ACTIVATING 1. With the welding current set and the wire trimmed, set the wire feed control to 6. 2. Plug the machine into the mains supply and switch on. 3. -
Page 22: Thermal Overload
THERMAL OVERLOAD The ‘Thermal Overload’ shuts off the welder when it becomes too hot, due to the duty cycle being exceeded. This is to prevent any damage to the welder. When this occurs, the warning lamp shown will light up. Allow the welder to cool until the amber light extinguishes before resuming work. -
Page 23: Maintenance
Check the hose for security and damage. As a general rule the power supply should be inspected at least annually. Consult your CLARKE dealer for advice if necessary. Wire feed unit: The feed roller wire guide plays an important part in obtaining consistent results. -
Page 24: Troubleshooting
TROUBLESHOOTING Your CLARKE MIG Welder has been designed to give long and trouble free service. If however, having followed the instructions in this booklet carefully you still encounter problems, the following points should help identify and resolve them. PROBLEM CAUSE... - Page 25 If you have any problems which cannot be resolved by reference to the above, or if you require spare parts for your welder please contact your local Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 26: Rating Plate
RATING PLATE Name and address of manufacturer Load Voltage symbol Model number, part number Energy Input symbol Batch number Rated supply voltage Single phase transformer-rectifier Rated maximum supply current British Standards applied Maximum effective supply current Welding process This symbol indicates that the unit is suitable for carrying out welding operations in an environment which has an increased risk of electric... -
Page 27: Specifications
Rated Max Input Current (A) Welding Capacity (Mild Steel) 4 mm (maximum) CLARKE International reserve the right to change specifications at any time without prior notice DUTY CYCLE The duty cycle determines the machine ‘down time’. i.e 10% means 1 minutes operation followed by 9 minutes of rest. - Page 28 CONSUMABLES The following are some of the accessories available from your CLARKE dealer. Please quote the part numbers shown below: Part Description Part Comment number Welding Wire Flux cored mild steel (mini 8132110 Use for no gas welding Spools spool) 0.9mm Mild steel (mini) - 0.6mm...
-
Page 29: Arc Activated Headshields
ARC ACTIVATED HEADSHIELDS These highly popular headshields activate instantly when the arc is struck and allow you to have both hands free when welding. Model Grinding Solar Fixed Flip Up Part Activated function Powered Shade Number ✔ ✔ ✔ GWH4 6000706 ✔... - Page 30 DECLARATION OF CONFORMITY-UK Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 31: Declaration Of Conformity-Eu
DECLARATION OF CONFORMITY-EU Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
