- Page 1 INSTRUCTIONS MODEL AVMP-1A-B-P-FOICC 0 TO +5 VOLTS, 5 to 100 ns & 2.5 ns PULSE WIDTHS DUAL CHANNEL HIGH PERFORMANCE PULSE GENERATOR WITH IEEE 488.2 AND RS-232 CONTROL SERIAL NUMBER: ____________...
-
Page 2: Warranty
WARRANTY Avtech Electrosystems Ltd. warrants products of its manufacture to be free from defects in material and workmanship under conditions of normal use. If, within one year after delivery to the original owner, and after prepaid return by the original owner, this Avtech product is found to be defective, Avtech shall at its option repair or replace said defective item. -
Page 3: Table Of Contents
PROTECTING YOUR INSTRUMENT____________________________________________15 DO NOT EXCEED 1 MHz__________________________________________________________15 USE A 50 LOAD_________________________________________________________________15 NEVER APPLY AN EXTERNAL VOLTAGE TO THE OUTPUT_________________________15 OPERATIONAL CHECK_______________________________________________________16 PROGRAMMING YOUR PULSE GENERATOR____________________________________20 KEY PROGRAMMING COMMANDS________________________________________________20 ALL PROGRAMMING COMMANDS________________________________________________21 PERFORMANCE CHECKSHEET_______________________________________________23 Manual Reference: /fileserver1/officefiles/instructword/avmp/AVMP-1A-B-P-FOICC.doc, created October 25, 1999... -
Page 4: Introduction
2.5 ns, and a rise time of 250 ps or less. The AVMP-1A-B-P-FOICC is a highly flexible instrument. Aside from the internal trigger source, it can also be triggered or gated by external TTL-level signals. A front-panel pushbutton or a computer command can also be used to trigger the instrument. -
Page 5: Specifications
SPECIFICATIONS Model: AVMP-1A-B-P-FOICC Channel 1 Channel 2 GPIB and RS-232 control: included Amplitude: (50 Ohm load) 0 to +5 Volts 0 to +5 Volts Rise, fall time: 100 ps 250 ps Pulse width: 5 to 100 ns, variable 2.5 ns, fixed... -
Page 6: Installation
INSTALLATION VISUAL CHECK After unpacking the instrument, examine to ensure that it has not been damaged in shipment. Visually inspect all connectors, knobs, liquid crystal displays (LCDs), and the handles. Confirm that a power cord and two instrumentation manuals (this manual and the “OP1B Interface Programming Manual”) are with the instrument. -
Page 7: Front Panel Controls
FRONT PANEL CONTROLS 1. POWER Switch . The POWER push button switch applies AC prime power to the primaries of the transformer, turning the instrument on. The push button lamp (#382 type) is connected to the internal +15V DC supply. 2. - Page 8 If one of the adjustable numeric parameters is displayed, this 10 decreases the setting by a factor of ten. If one of the adjustable numeric parameters is displayed, and this parameter can be both positive or negative, this changes the sign of the parameter. EXTRA FINE This changes the step size of the ADJUST knob.
-
Page 9: Rear Panel Controls
REAR PANEL CONTROLS 1. AC POWER INPUT . A three-pronged recessed male connector is provided on the back panel for AC power connection to the instrument. Also contained in this assembly is a slow blow fuse and a removable card that can be removed and repositioned to switch between 120V AC in and 240V AC in. - Page 10 8. GND Connector . This solder terminal is connector to the chassis ground.
-
Page 11: General Information
GENERAL INFORMATION BASIC PULSE CONTROL This instrument can be triggered by its own internal clock or by an external TTL trigger signal. In either case, three output channels respond to the trigger: OUT 1. This is the Channel 1 output. The maximum output voltage is +5V. ... - Page 12 Figure B The next figure illustrates the relationship between the signal when an external TTL- level trigger is used: Figure C...
-
Page 13: Trigger Modes
The pulse width and delay of the output pulse may vary slightly with the amplitude setting, particularly at lower amplitudes. For some demanding applications, it may be desirable to use external attenuators in conjunction with the AVMP-1A-B-P-FOICC, instead of generating a low-amplitude pulse directly. -
Page 14: Obtaining Optimum Jitter Performance
OBTAINING OPTIMUM JITTER PERFORMANCE When jitter performance is a priority, it may be necessary to adjust the delay setting within a 5ns range to obtain the lowest jitter, as the jitter has a slight periodic delay dependency. TOP COVER REMOVAL The interior of the instrument may be accessed by removing the four Phillips screws on the top panel. -
Page 15: Protecting Your Instrument
PROTECTING YOUR INSTRUMENT DO NOT EXCEED 1 MHz The output stage may be damaged if triggered by an external signal at a pulse repetition frequency greater than 1 MHz. USE A 50 LOAD The output stage may be damaged if the output is not terminated into a 50 load. NEVER APPLY AN EXTERNAL VOLTAGE TO THE OUTPUT Externally generated potentials must never be applied to the output, with the exception of the OS1 and OS2 offsets (see page 9). -
Page 16: Operational Check
(attenuators, cables, connectors, etc.) should exceed 10 GHz. d) Set the oscilloscope to trigger externally with the vertical setting at 50 mV/div and the horizontal setting at 10 ns/div. 2. Turn on the AVMP-1A-B-P-FOICC. The main menu will appear on the LCD. - Page 17 3. To set the AVMP-1A-B-P-FOICC to trigger from the internal clock at a PRF of 2 kHz: a) The arrow pointer should be pointing at the frequency menu item. If it is not, press the MOVE button until it is.
- Page 18 a) Press the MOVE button until the arrow pointer is pointing at the output menu item. b) Press the CHANGE button. The output submenu will appear. c) Press MOVE until the arrow pointer is pointing at the “ON” choice. d) Press CHANGE to return to the main menu. 8.
- Page 19 oscilloscope. You may also need to adjust the sampling scope controls. d) Rotate the ADJUST knob. The amplitude as seen on the oscilloscope should vary. Return it to +5V. 12. Press CHANGE to return to the main menu. This completes the operational check.
-
Page 20: Programming Your Pulse Generator
PROGRAMMING YOUR PULSE GENERATOR KEY PROGRAMMING COMMANDS The “OP1B Interface Programming Manual” describes in detail how to connect the pulse generator to your computer, and the programming commands themselves. A large number of commands are available; however, normally you will only need a few of these. -
Page 21: All Programming Commands
These commands will satisfy 90% of your programming needs. ALL PROGRAMMING COMMANDS For more advanced programmers, a complete list of the available commands is given below. These commands are described in detail in the “OP1B Interface Programming Manual”. (Note: this manual also includes some commands that are not implemented in this instrument. - Page 22 :GPIB :ADDRess <numeric value> :SERial :CONTrol :RTS ON | IBFull | RFR :[RECeive] :BAUD 1200 | 2400 | 4800 | 9600 :BITS 7 | 8 :ECHO <boolean value> :PARity :[TYPE] EVEN | ODD | NONE :SBITS 1 | 2 :ERRor :[NEXT]? [query only] :COUNT?
-
Page 23: Performance Checksheet
PERFORMANCE CHECKSHEET...
