- Page 1 INSTRUCTIONS MODEL AVMP-3-B-P-OT-ELA-R5 0 TO 20 VOLTS, 200 ps RISE TIME HIGH PERFORMANCE PULSE GENERATOR WITH IEEE 488.2 AND RS-232 CONTROL SERIAL NUMBER: ____________...
-
Page 2: Warranty
WARRANTY Avtech Electrosystems Ltd. warrants products of its manufacture to be free from defects in material and workmanship under conditions of normal use. If, within one year after delivery to the original owner, and after prepaid return by the original owner, this Avtech product is found to be defective, Avtech shall at its option repair or replace said defective item. -
Page 3: Table Of Contents
RACK MOUNTING..........................13 PROTECTING YOUR INSTRUMENT..................14 DO NOT EXCEED 1 MHz........................14 USE A 50 OMH LOAD.........................14 OPERATIONAL CHECK......................15 PROGRAMMING YOUR PULSE GENERATOR..............18 KEY PROGRAMMING COMMANDS....................18 ALL PROGRAMMING COMMANDS....................19 PERFORMANCE CHECKSHEET.....................21 Manual Reference: /fileserver1/officefiles/instructword/avmp/AVMP-3-B-P-OT-ELA-R5,edition2.sxw. Copyright © 2003 Avtech Electrosystems Ltd, All Rights Reserved. -
Page 4: Introduction
The output pulse width is variable from 8 to 100 ns, and rise time is fixed at less than 200 ps. The AVMP-3-B-P-OT-ELA-R5 is a highly flexible instrument. Aside from the internal trigger source, it can also be triggered or gated by external TTL-level signals. A front- panel pushbutton or a computer command can also be used to trigger the instrument. -
Page 5: Specifications
SPECIFICATIONS Model: AVMP-3-B-P-OT-ELA-R5 GPIB and RS-232 included control: Amplitude: 0 to +20 Volts (50 Ohm load) Rise time: 200 ps Fall time: 300 ps Pulse width: 8 to 100 ns PRF: 0 to 1 MHz Polarity: Positive Jitter: ... -
Page 6: Installation
INSTALLATION VISUAL CHECK After unpacking the instrument, examine to ensure that it has not been damaged in shipment. Visually inspect all connectors, knobs, liquid crystal displays (LCDs), and the handles. Confirm that a power cord and two instrumentation manuals (this manual and the “OP1B Interface Programming Manual”) are with the instrument. -
Page 7: Front Panel Controls
FRONT PANEL CONTROLS 1. POWER Switch . This is the main power switch. 2. OVERLOAD . The AVMP-3-B-P-OT-ELA-R5 is protected in its internal software against conflicting or dangerous settings. As an additional protective measure, an automatic overload circuit exists, which controls the front panel overload light. If the... - Page 8 6. KEYPAD . Control Name Function MOVE This moves the arrow pointer on the display. CHANGE This is used to enter the submenu, or to select the operating mode, pointed to by the arrow pointer. If one of the adjustable numeric parameters is displayed, this 10 increases the setting by a factor of ten.
-
Page 9: Rear Panel Controls
REAR PANEL CONTROLS GATE TRIG RS-232 GPIB 1. AC POWER INPUT . A three-pronged recessed male connector is provided on the back panel for AC power connection to the instrument. Also contained in this assembly is a slow blow fuse and a removable card that can be removed and repositioned to switch between 120V AC in and 240V AC in. - Page 10 7. OS Connector . A DC offset may applied to this connector. Internally, it is connected to the output centre conductor via a high quality RF inductor. Do not exceed 50V, 250 mA. For this connector to be active, the OS ON/OFF switch (item 9) must be in the “OFF”...
-
Page 11: General Information
GENERAL INFORMATION BASIC PULSE CONTROL This instrument can be triggered by its own internal clock or by an external TTL trigger signal. In either case, two output channels respond to the trigger: OUT and SYNC. OUT. This is the main output. ... -
Page 12: Trigger Modes
The next figure illustrates the relationship between the signal when an external TTL- level trigger is used: > 50 ns TRIG TTL LEVELS (external input) (0V and 3V-5V) PROPAGATION DELAY (FIXED) 200 ns, FIXED SYNC OUT (generated by the 2 V, FIXED internal oscillator) DELAY... -
Page 13: Gating Modes
The pulse width and delay of the output pulse may vary slightly with the amplitude setting, particularly at lower amplitudes. For some demanding applications, it may be desirable to use external attenuators in conjunction with the AVMP-3-B-P-OT-ELA-R5, instead of generating a low-amplitude pulse directly. -
Page 14: Protecting Your Instrument
PROTECTING YOUR INSTRUMENT DO NOT EXCEED 1 MHz The output stage may be damaged if triggered by an external signal at a pulse repetition frequency greater than 1 MHz. USE A 50 OMH LOAD The output stage may be damaged if the output is not terminated into a 50 load. -
Page 15: Operational Check
Set the oscilloscope to trigger externally with the vertical setting at 100 mV/div and the horizontal setting at 20 ns/div. 2. Turn on the AVMP-3-B-P-OT-ELA-R5. The main menu will appear on the LCD. 3. To set the AVMP-3-B-P-OT-ELA-R5 to trigger from the internal clock at a PRF of 100 kHz:... - Page 16 a) The arrow pointer should be pointing at the frequency menu item. If it is not, press the MOVE button until it is. b) Press the CHANGE button. The frequency submenu will appear. Rotate the ADJUST knob until the frequency is set at 100 kHz. c) The arrow pointer should be pointing at the “Internal”...
- Page 17 c) Press MOVE until the arrow pointer is pointing at the “ON” choice. d) Press CHANGE to return to the main menu. 8. To change the output amplitude: a) Press the MOVE button until the arrow pointer is pointing at the amplitude menu item.
-
Page 18: Programming Your Pulse Generator
PROGRAMMING YOUR PULSE GENERATOR KEY PROGRAMMING COMMANDS The “OP1B Interface Programming Manual” describes in detail how to connect the pulse generator to your computer, and the programming commands themselves. A large number of commands are available; however, normally you will only need a few of these. -
Page 19: All Programming Commands
ALL PROGRAMMING COMMANDS For more advanced programmers, a complete list of the available commands is given below. These commands are described in detail in the “OP1B Interface Programming Manual”. (Note: this manual also includes some commands that are not implemented in this instrument. - Page 20 :PARity :[TYPE] EVEN | ODD | NONE :SBITS 1 | 2 :ERRor :[NEXT]? [query only] :COUNT? [query only] :VERSion? [query only] TRIGger: :SOURce INTernal | EXTernal | MANual | HOLD | IMMediate *CLS [no query form] *ESE <numeric value> *ESR? [query only] *IDN? [query only]...
-
Page 21: Performance Checksheet
PERFORMANCE CHECKSHEET...
