- Page 1 INSTRUCTIONS MODEL AVMP-3-B-N 0 TO -20 VOLTS, 200 ps RISE TIME HIGH PERFORMANCE PULSE GENERATOR WITH IEEE 488.2 AND RS-232 CONTROL SERIAL NUMBER: ____________...
-
Page 2: Warranty
WARRANTY Avtech Electrosystems Ltd. warrants products of its manufacture to be free from defects in material and workmanship under conditions of normal use. If, within one year after delivery to the original owner, and after prepaid return by the original owner, this Avtech product is found to be defective, Avtech shall at its option repair or replace said defective item. -
Page 3: Table Of Contents
TABLE OF CONTENTS WARRANTY__________________________________________________________________2 TECHNICAL SUPPORT________________________________________________________2 TABLE OF CONTENTS_________________________________________________________3 INTRODUCTION______________________________________________________________4 SPECIFICATIONS_____________________________________________________________5 INSTALLATION_______________________________________________________________6 VISUAL CHECK___________________________________________________________________6 PLUGGING IN THE INSTRUMENT__________________________________________________6 FRONT PANEL CONTROLS_____________________________________________________7 REAR PANEL CONTROLS______________________________________________________9 GENERAL INFORMATION____________________________________________________11 BASIC PULSE CONTROL__________________________________________________________11 TRIGGER MODES________________________________________________________________12 GATING MODES_________________________________________________________________13 PULSE WIDTH / AMPLITUDE INTERACTION_______________________________________13 TOP COVER REMOVAL___________________________________________________________13 ELECTROMAGNETIC INTERFERENCE____________________________________________13 RACK MOUNTING________________________________________________________________13 PROTECTING YOUR INSTRUMENT____________________________________________14... -
Page 4: Introduction
8 to 100 ns, and rise time is fixed at less than 200 ps. The AVMP-3-B-N is a highly flexible instrument. Aside from the internal trigger source, it can also be triggered or gated by external TTL-level signals. A front-panel pushbutton or a computer command can also be used to trigger the instrument. -
Page 5: Specifications
SPECIFICATIONS Model: AVMP-3-B-N GPIB and RS-232 control: included Amplitude: (50 Ohm load) 0 to -20 Volts Rise time: 200 ps Fall time: 300 ps Pulse width: 8 to 100 ns PRF: 0 to 1 MHz Polarity: Negative Jitter: (Ext trig in to pulse out) ... -
Page 6: Installation
INSTALLATION VISUAL CHECK After unpacking the instrument, examine to ensure that it has not been damaged in shipment. Visually inspect all connectors, knobs, liquid crystal displays (LCDs), and the handles. Confirm that a power cord and two instrumentation manuals (this manual and the “OP1B Interface Programming Manual”) are with the instrument. -
Page 7: Front Panel Controls
The push button lamp (#382 type) is connected to the internal +15V DC supply. 2. OVERLOAD . The AVMP-3-B-N is protected in its internal software against conflicting or dangerous settings. As an additional protective measure, an automatic overload circuit exists, which controls the front panel overload light. - Page 8 Interface Programming Manual” describes the menus and submenus in detail. 6. KEYPAD . Control Name Function MOVE This moves the arrow pointer on the display. CHANGE This is used to enter the submenu, or to select the operating mode, pointed to by the arrow pointer. If one of the adjustable numeric parameters is displayed, this 10 increases the setting by a factor of ten.
-
Page 9: Rear Panel Controls
REAR PANEL CONTROLS 1. AC POWER INPUT . A three-pronged recessed male connector is provided on the back panel for AC power connection to the instrument. Also contained in this assembly is a slow blow fuse and a removable card that can be removed and repositioned to switch between 120V AC in and 240V AC in. - Page 10 8. GND Connector . This solder terminal is connector to the chassis ground.
-
Page 11: General Information
GENERAL INFORMATION BASIC PULSE CONTROL This instrument can be triggered by its own internal clock or by an external TTL trigger signal. In either case, two output channels respond to the trigger: OUT and SYNC. OUT. This is the main output. The maximum output voltage is -20V. ... -
Page 12: Trigger Modes
The next figure illustrates the relationship between the signal when an external TTL- level trigger is used: >50ns TRIG (external input) TTL LEVELS (0V and 3V-5V) PROPAGATION DELAY (FIXED) SYNC OUT 200ns (generated 3V, FIXED in response to TRIG) DELAY Figure C As before, if the delay is negative, the order of the SYNC and OUT pulses is reversed. -
Page 13: Gating Modes
The pulse width and delay of the output pulse may vary slightly with the amplitude setting, particularly at lower amplitudes. For some demanding applications, it may be desirable to use external attenuators in conjunction with the AVMP-3-B-N, instead of generating a low-amplitude pulse directly. -
Page 14: Protecting Your Instrument
PROTECTING YOUR INSTRUMENT DO NOT EXCEED 1 MHz The output stage may be damaged if triggered by an external signal at a pulse repetition frequency greater than 1 MHz. USE A 50 LOAD The output stage may be damaged if the output is not terminated into a 50 load. -
Page 15: Operational Check
Set the oscilloscope to trigger externally with the vertical setting at 100 mV/div and the horizontal setting at 20 ns/div. 2. Turn on the AVMP-3-B-N. The main menu will appear on the LCD. 3. To set the AVMP-3-B-N to trigger from the internal clock at a PRF of 2 kHz:... - Page 16 a) The arrow pointer should be pointing at the frequency menu item. If it is not, press the MOVE button until it is. b) Press the CHANGE button. The frequency submenu will appear. Rotate the ADJUST knob until the frequency is set at 2 kHz. c) The arrow pointer should be pointing at the “Internal”...
- Page 17 b) Press the CHANGE button. The output submenu will appear. c) Press MOVE until the arrow pointer is pointing at the “ON” choice. d) Press CHANGE to return to the main menu. 8. To change the output amplitude: a) Press the MOVE button until the arrow pointer is pointing at the amplitude menu item.
-
Page 18: Programming Your Pulse Generator
PROGRAMMING YOUR PULSE GENERATOR KEY PROGRAMMING COMMANDS The “OP1B Interface Programming Manual” describes in detail how to connect the pulse generator to your computer, and the programming commands themselves. A large number of commands are available; however, normally you will only need a few of these. -
Page 19: All Programming Commands
ALL PROGRAMMING COMMANDS For more advanced programmers, a complete list of the available commands is given below. These commands are described in detail in the “OP1B Interface Programming Manual”. (Note: this manual also includes some commands that are not implemented in this instrument. - Page 20 :BITS 7 | 8 :ECHO <boolean value> :PARity :[TYPE] EVEN | ODD | NONE :SBITS 1 | 2 :ERRor :[NEXT]? [query only] :COUNT? [query only] :VERSion? [query only] TRIGger: :SOURce INTernal | EXTernal | MANual | HOLD | IMMediate *CLS [no query form] *ESE <numeric value>...
-
Page 21: Performance Checksheet
PERFORMANCE CHECKSHEET...
