- Page 1 Operation Manual Network Speaker Line Checker NSC-1216...
- Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
Important Safety Instructions ....................2 Overview ..........................3 Features ..........................3 Contents and Accessories ....................3 Front Panel ........................4 Rear Panel ........................5 Operation .........................7 Applications ........................8 Block Diagram .........................9 Specifications .........................10 Service Procedures ........................12 Schematic........................12 Parts List.........................12 Variations and Options ....................12 Warranty ........................12 NSC-1216... -
Page 4: Unpacking
NETWORK SPEAKER LINE CHECKER Unpacking Unpacking Although your NSC-1216 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. -
Page 5: Overview
Overview Overview NSC-1216 is a speaker line checker that is controlled through a network in conjunction with our IPC and IPA systems. This is a device that protects the amplifier by automatically blocking the channel when overcurrent occurs due to a short circuit in the line, and informs the operator of the occurrence of an accident. -
Page 6: Front Panel
Network status information (IP Address, Subnet mask, DNS Server, Mac Address information) is displayed through the OLED display. 4. STATUS DISPLAY OLED CONTROL SWITCH You can check the information you want by turning the control switch. 5. POWER LED This LED indicates the power ON/OFF status. NSC-1216... -
Page 7: Rear Panel
- Select the switch when the power is off. 3. AMPLIFIER OUTPUT CONNECTION TERMINAL (AMP IN) This is the terminal to connect the amplifier output of 16 channels. 4. SPEAKER LINE CONNECTION TERMINAL (SPEAKER OUT) This is a terminal to connect a 16-channel 3-wire speaker. NSC-1216... -
Page 8: Reset Switch
※ It is recommended to use the STP cable for the network cable of this product. 6. RESET SWITCH If you press the switch for more than 10 seconds, the settings of the equipment will be reset to factory defaults. NSC-1216... -
Page 9: Operation
NETWORK SPEAKER LINE CHECKER Operation Operation ① ② ③ Network Network Pri. IP 192.168.47.45 RX KB/s NSC-1216 0.1.0.0 MASK 255.255.255.0 0.00 Pri. INS 192.168.12.190 TX KB/s 192.168.1.99 Sec. 0.0.0.0 MAC 00:1d:1d:02:a5:0e 0.00 ④ Recovery ① This is the standby screen of the device. The model name and network information are displayed. -
Page 10: Applications
Applications Network signal Analog signal NETWORK POWER AMPLIFIER MAIN CONTROLLER SPEAKER LINE CHECKER NETWORK SYSTEM REMOTE MIC STATION CD PLAYER SPEAKER ATTENUATOR NETWORK AUDIO INPUT CONVERTER NETWORK EMERGENCY PANEL ATTENUATOR L2 SWITCHING HUB NETWORK GPIO Type R fire receiver NSC-1216... -
Page 11: Block Diagram
NETWORK SPEAKER LINE CHECKER Block Diagram Block Diagram NSC-1216... -
Page 12: Specifications
NETWORK SPEAKER LINE CHECKER Specifications Specifications NSC-1216 Real-time short 0.8A 1.6A 2.4A 3.2A 4.0A check capacity (variable) More than More than More than More than More than Recommended amp capacity 120W 200W 300W 360W 400W Amplifier input channel 16CH speaker output channel... - Page 13 5. In case of fixing by not using the included screws or screws of the same size, or using insufficient number of screws the manufacturer is not responsible for any safety accidents caused by this. Accessories included for fixing the product - Specification: SCREW M5x0.8P, L=12 - Quantity: 4pcs NSC-1216...
-
Page 14: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 16 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
