ambe Multi 65 User Manual

65" built-in electric fireplace
Hide thumbs Also See for Multi 65:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
Multi 65
65" BUILT-IN ELECTRIC FIREPLACE
FULLY RECESSED ELECTRIC FIREPLACE
AC 220V - 240V 50Hz 1400W - 1600W
Model#: Square 30
OWNER'S MANUAL
Dimension
WARNING
READ AND UNDERSTAND THIS ENTIRE OWNER'S MANUAL, INCLUDING ALL SAFETY
INFORMATION, BEFORE PLUGGING IN OR USING THIS PRODUCT. FAILURE TO DO
SO COULD RESULT IN FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY.
25"
24 1/4"
635mm
616mm
CAUTION
KEEP THIS OWNER'S MANUAL FOR FUTURE REFERENCE. IF YOU SELL OR GIVE
THIS PRODUCT AWAY, MAKE SURE THIS MANUAL ACCOMPANIES THIS PRODUCT.
30" Built-in Electric Fireplace
AC 120V 60Hz 1500W
ambefireplaces.com
630677_0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multi 65 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ambe Multi 65

Summary of Contents for ambe Multi 65

  • Page 1 USER MANUAL Multi 65 65" BUILT-IN ELECTRIC FIREPLACE FULLY RECESSED ELECTRIC FIREPLACE AC 220V - 240V 50Hz 1400W - 1600W Model#: Square 30 OWNER’S MANUAL Dimension WARNING READ AND UNDERSTAND THIS ENTIRE OWNER’S MANUAL, INCLUDING ALL SAFETY INFORMATION, BEFORE PLUGGING IN OR USING THIS PRODUCT. FAILURE TO DO SO COULD RESULT IN FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY.

  • Page 2: Important Safety Information

    DO NOT use on soft surfaces, like a bed, bathrooms. where openings may become blocked. - Risk of electric shock- DO NOT OPEN! No user-serviceable parts inside. - DO NOT place clothing or other AMBE USER MANUAL - MULTI 65...
  • Page 3 - This fireplace is tested and listed for - NEVER modify this fireplace. Doing use only with the accessories listed in so could result in personal injury or this manual. Use of other accessories property damage. Modification of this not specifically tested for this appliance fireplace completely voids all warranties.
  • Page 4 For support, inquiries and contact information visit ambehome.com Distributor Address: Escea Ltd 17 Carnforth Street, Green Island, Dunedin 9018, New Zealand...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Dimensions Preparation dware Installation an A d ssembly Installation for 3-Sided Viewing Installation for Front and Right-Sided Viewing Installation for Front and Left-Sided Viewing Decorative Crystal and Pebble Installation Operation Car an d Maintenance Troubleshooting 630677_0...

  • Page 6: Dimensions

    Parts and Hardware E - Decorative Dark Crystals D - Decorative Dark Crystals and assembly steps are grouped for free-standing or wall-hanging use. Check the AMBE USER MANUAL - MULTI 65 A – Fireplace (big) (small) sure nothing is missing. Keep packaging materials out of reach of children and Dis...

  • Page 7: Parts And Hardware

    This product includes a GLASS panel! Always use extreme glass. Failure to do so could result in personal injury or property damag e not toys, and should be kept away from children and infants. materials properly. Plastic bags are not toys, and should be ke Front View glass.

  • Page 8: Installation An A D Ssembly

    Keep packaging materials out of reach of children and Dispose of packaging Plastic bags are not toys, and should be kept away from children and infants. AMBE USER MANUAL - MULTI 65 ever possible. following tools (not included): Phillips screwdriver; stud finder; level; tape...

  • Page 9: Fascia Installation

    relocating. the TWO screws as shown below and take off the black glass fascia with care. warnings about safe nt, safe installation, and e of this product. s Fascia Installation t come in direct al building codes INSTALLATION FOR 3-SIDED VIEWING ass Fascia Installation e the TWO screws as shown below and take off the black glass fascia with care.
  • Page 10 wall opening. Fix the FOUR wall screws in each side of the Fix back the fending bars after the panels are removed. ace into the wall opening. Fix the FOUR wall screws in each side of the 3. Install the fireplace into the wall opening. Fix the FOUR wall screws in each side of the fireplace box.
  • Page 11 6. Make an opening for the fireplace with the sizes shown. Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step. 630677_0...
  • Page 12 8. Cover the glass panel with protective plastic bag and install plywood or drywall. 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc. AMBE USER MANUAL - MULTI 65...

  • Page 13: Installation For Front And Right-Sided Viewing

    ameless Kit Installation Frameless Kit Installation 1. Remove the TWO screws as shown in the below picture and take off the INSTALLATION FOR FRONT AND RIGHT-SIDE VIEWING Frameless Kit Installation black glass fascia with care. To view the fireplace from front and right side, you need to take off the fending panel on 1.
  • Page 14 4. Place the left, right, top, and bottom trims on the appliance and fix the part using the 4. Place the left, right, top, and bottom trims on the appliance and fix the part using the screws provided in the kit. screws provided in the kit. AMBE USER MANUAL - MULTI 65...
  • Page 15 5. Put the appliance into the wall opening and fix it with the screws provided. 5. Put the appliance into the wall opening and fix it with the screws provided. 5. Put the appliance into the wall opening and fix it with the screws provided. Fix the brackets with the screws in the previous step.
  • Page 16 Plug in and check if the fireplace works properly. If so, move on to next step. Cover the glass panel with protective plastic bag and install plywood or drywall. AMBE USER MANUAL - MULTI 65...
  • Page 17 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc. 630677_0...

  • Page 18: Installation For Front And Left-Sided Viewing

    To view the fireplace from front and left side, you need to take off the fending panel on the left side and keep the right side close to a wall. Remove the 7 screws on the left side. Take off the fending bar and panel. AMBE USER MANUAL - MULTI 65...
  • Page 19 Fix back the fending bar after the panel is removed. Remove the screws from the fireplace as shown in the picture below. 630677_0...
  • Page 20 Fix the brackets with the screws in the previous step. Make an opening for the fireplace with the sizes shown. AMBE USER MANUAL - MULTI 65...
  • Page 21 Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step. Cover the glass panel with protective plastic bag and install plywood or drywall.
  • Page 22 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc. AMBE USER MANUAL - MULTI 65...

  • Page 23: Decorative Crystal And Pebble Installation

    FUEL BED MEDIA INSTALLATION 1. Use the screw driver to take off the 4 screws. Have two people take out the glass panel and move it to a clean area taking care to avoid scratching. 630677_0...
  • Page 24 3. Place the fuel bed media on the media tray. Apply an even layer from side to side. After placing the fuel bed media, fasten screws back on the glass panel. AMBE USER MANUAL - MULTI 65...

  • Page 25: Operation

    ” wood drill bit, hammer. ass. Failure to do so could result in personal injury or This product includes a GLA not included): Phillips screwdriver; stud finder; level; tape dware udes a GLASS panel! Always use extreme caution when handling glass.
  • Page 26 H2 - High heat LO - Heater button can be locked or unlocked by holding the Heater button for 5 seconds Controls the timer. Timer Settings: 00 30min 1h 2h 3h 4h 5h 6h 7h 8h AMBE USER MANUAL - MULTI 65...
  • Page 27 BUTTON FUNCTION ACTION & INDICATION Controls the temperature. Temperature Settings: 640F [180C] 760F [240C] 660F [190C] 780F [250C] 680F [200C] 800F [260C] 700F [210C] 820F [270C] 720F [220C] and OFF 740F [230C] Note: To change temperature format from Fahrenheit to Celsius or vice versa, press and hold the temperature button for 5 seconds.
  • Page 28 This remote control uses one CR2025 battery (included). ͳ NEVER DISPOSE OF BATTERIES IN FIRE. FAILURE TO OBSERVE THIS PRECAUTION MAY RESULT IN AN EXPLOSION. DISPOSE OF BATTERIES AT YOUR LOCAL HAZARDOUS MATERIAL PROCESSING CENTER. AMBE USER MANUAL - MULTI 65...

  • Page 29: Care And Maintenance

    CARE AND MAINTENANCE Cleaning ALWAYS TURN THE FIREPLACE OFF AND UNPLUG THE POWER CORD FROM THE OUTLET BEFORE CLEANING, PERFORMING MAINTENANCE, OR MOVING THIS FIREPLACE. FAILURE TO DO SO COULD RESULT IN ELECTRIC SHOCK, FIRE, OR PERSONAL INJURY. NEVER IMMERSE IN WATER OR SPRAY WITH WATER. DOING SO COULD RESULT IN ELECTRIC SHOCK, FIRE, OR PERSONAL INJURY.
  • Page 30 When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposals at least free of charge. AMBE USER MANUAL - MULTI 65...

  • Page 31: Troubleshooting

    TROUBLESHOOTING WARNING DISCONNECT THE APPLIANCE COMPLETELY AND LET COOL PRIOR TO ANY SERVICE. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. PROBLEM POSSIBLE CAUSE SOLUTION 1. Fireplace turns 1. Fireplace has 1. Reset switch by turning main power off and will not overheated and safety switch off and waiting 10 minutes then...
  • Page 32 PLEASE REMEMBER TO ALWAYS HAVE THE UNIT DISCONNECTED PRIOR TO ANY WORK, ALWAYS LAY GLASS AS WELL AS THE UNIT ON A TOWEL OR OTHER MATERIAL NOT TO DAMAGE PARTS/FRAME. THIS ENTIRE PROCESS SHOULD NOT TAKE LONGER THAN 20-30 MINUTES AMBE USER MANUAL - MULTI 65...
  • Page 36 ambefireplaces.com...
