49 " Three-sided Electric Fireplace
BEF-49B-3SV (Multi49)
Model #:
OWNER'S MANUAL
Ambe Electric Fire Bay 3 Sided 49"
AC 220-240V 50Hz 1400-1600W
Read and understand this entire owner's manual, including all safety
WARNING
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
Rev_1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multi49 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ambe Multi49

Summary of Contents for ambe Multi49

  • Page 1 49 ” Three-sided Electric Fireplace BEF-49B-3SV (Multi49) Model #: OWNER’S MANUAL Ambe Electric Fire Bay 3 Sided 49" AC 220-240V 50Hz 1400-1600W Read and understand this entire owner’s manual, including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING When using electrical appliances basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read all instructions before using this heater.  This heater is hot when in use. To avoid burning, do not touch hot surface. If provided, use ...

  • Page 3: Parts And Hardware

    Preparation This product includes a GLASS panel! Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts and assembly steps are grouped for free-standing or wall-hanging use.

  • Page 4: Installation For 3 Sided Viewing

    Installation for 3 Sided Viewing 1. The fireplace is fixed with fending bars and panels on the left and right side.
  • Page 5 2. Take off the fending bars and panels if you want to view the fire from three sides. 3. Fix back the fending bars after the panels are removed.
  • Page 6 4. Remove the screws from the fireplace as shown in the picture below. 5. Fix the brackets with the screws in the previous step.
  • Page 7 6. Make an opening for the fireplace with the sizes shown. 7. Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step.
  • Page 8 8. Cover the glass panel with protective plastic bag and install plywood or drywall. 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc.
  • Page 9 Installation for Front and Right Side Viewing 1. To view the fireplace from front and right side, you need to take off the fending panel on the right side and keep the left side close to a wall. 2. Remove the 7 screws on the right side. Take off the fending bar and panel.
  • Page 10 3. Fix back the fending bar after the panel is removed. 4. Remove the screws from the fireplace as shown in the picture below.
  • Page 11 5. Fix the brackets with the screws in the previous step. 6. Make an opening for the fireplace with the sizes shown.
  • Page 12 7. Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step. 8. Cover the glass panel with protective plastic bag and install plywood or drywall.
  • Page 13 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc.
  • Page 14 Installation for Front and Left Side Viewing 1. To view the fireplace from front and left side, you need to take off the fending panel on the left side and keep the right side close to a wall. 2. Remove the 7 screws on the right side. Take off the fending bar and panel.
  • Page 15 3. Fix back the fending bar after the panel is removed. 4. Remove the screws from the fireplace as shown in the picture below.
  • Page 16 5. Fix the brackets with the screws in the previous step. 6. Make an opening for the fireplace with the sizes shown.
  • Page 17 7. Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step. 8. Cover the glass panel with protective plastic bag and install plywood or drywall.
  • Page 18 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc.
  • Page 19 Decorative Crystal & Pebble Ember Installation 1. Use the screw driver to take off the 4 screws. 2. Have two people take out the glass panel and move it to a clean area taking care to avoid scratching.
  • Page 20 3. Place the decorative crystals or pebbles on the media tray. Apply an even layer from side to side. 4. After placing the decorative crystals or pebble, fasten screws back on the glass panel.

  • Page 21: Methods Of Operation

    Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Plug the power cord into an outlet or hard wire the appliance. If you choose to hard wire theappliance, it MUST have a dedicated isolation switch accessible after installation.

  • Page 22: Touch Panel Operation

    Touch Panel Operation BUTTON FUNCTION ACTION & INDICATION Turns the fireplace on/off. POWER Controls flame brightness. ORANGE FLAME Settings: F4-Brightest flame(default) F3-Bright flame F2-Medium flame F1-Small flame BLUE FLAME F0-Flame off Turns the heater and blower on/off. Settings: HO-Heater and blower off bL-Blower on HEATER H1-Low heat...
  • Page 23 Controls the timer. Settings: 30min TIMER Controls the temperature. Settings: 61℉ [16℃] 64℉ [18℃] 70℉ [21℃] 75℉ [24℃] TEMPERATURE 81℉ [27℃] 85℉ [29℃] and OFF Note: To change temperature format from Fahrenheit to Celsius or vice versa, press and hold the Flame button for 5 seconds.

  • Page 24: Remote Control Operation

    Remote Control Operation BUTTON FUNCTION ACTION & INDICATION Turns the fireplace on/off. POWER Controls flame brightness. BLUE FLAME Settings: F4-Brightest flame(default) F3-Bright flame F2-Medium flame ORANGE FLAME F1-Small flame F0-Flame off YELLOW FLAME Turns the heater and blower on/off. Settings: HO-Heater and blower off bL-Blower on HEATER...
  • Page 25 Controls the timer. Settings: 30min TIMER Controls the temperature. Settings: 61℉ [16℃] 64℉ [18℃] 70℉ [21℃] 75℉ [24℃] TEMPERATURE 81℉ [27℃] 85℉ [29℃] and OFF Note: To change temperature format from Fahrenheit to Celsius or vice versa, press and hold the Flame button for 5 seconds.
  • Page 26 Controls ember bed light settings. Settings: 01- Orange (default) 02- Red 03- Blue 04- Yellow 05- Green 06- Purple 07- Azure 08- Carmine 09- White EMBER BED COLOR 10- Pink 11- Salmon pink 12- Chartreuse 13- Warm yellow 14- Auto-cycle through orange, red, blue, yellow, green, purple, azure, carmine, white, pink, salmon pink, chartreuse and warm yellow.
  • Page 27 Controls the top light color settings. Settings: 01- Orange (default) 02- Red 03- Blue 04- Yellow 05- Green 06- Purple 07- Azure 08- Carmine 09- White TOP LIGHT COLOR 10- Pink 11- Salmon pink 12- Chartreuse 13- Warm yellow 14- Auto-cycle through orange, red, blue, yellow, green, purple, azure, carmine, white, pink, salmon pink, chartreuse and warm yellow.

  • Page 28: Temperature Limiting Control

    Temperature Limiting Control This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature, the heater will automatically turn OFF. To reset: 1. Unplug the power cord from the outlet. 2. Turn the ON/OFF switch on the CONTROL PANEL to OFF. Wait 5 minutes. 3.

  • Page 29: Care And Maintenance

    Care and Maintenance Cleaning ALWAYS turn the fireplace OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury.

  • Page 30: Troubleshooting

    Troubleshooting WARNING DISCONNECT THE APPLIANCE COMPLETELY AND LET COOL PRIOR TO ANY SERVICE. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. Problem Possible Cause Solution 1. Reset switch by turning main 1. Fireplace turns off 1. Fireplace has overheated and will not turn on.
  • Page 31 7. Heater does not 1. Thermal switch has been 1. Turn unit off and unplug unit provide heat when tripped. for 10 minutes. Plug back in and turned on. turn unit on. If plug cannot be reached, follow directions for tripped circuit breaker.
