USER MANUAL
Multi 65
65" BUILT-IN ELECTRIC FIREPLACE
AC 220V - 240V 50Hz 1400W - 1600W
WARNING
READ AND UNDERSTAND THIS ENTIRE OWNER'S MANUAL, INCLUDING ALL SAFETY
INFORMATION, BEFORE PLUGGING IN OR USING THIS PRODUCT. FAILURE TO DO
SO COULD RESULT IN FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY.
CAUTION
KEEP THIS OWNER'S MANUAL FOR FUTURE REFERENCE. IF YOU SELL OR GIVE
THIS PRODUCT AWAY, MAKE SURE THIS MANUAL ACCOMPANIES THIS PRODUCT.
ambehome.com
630677_1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multi 65 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ambe Multi 65

Summary of Contents for ambe Multi 65

  • Page 1 USER MANUAL Multi 65 65" BUILT-IN ELECTRIC FIREPLACE AC 220V - 240V 50Hz 1400W - 1600W WARNING READ AND UNDERSTAND THIS ENTIRE OWNER’S MANUAL, INCLUDING ALL SAFETY INFORMATION, BEFORE PLUGGING IN OR USING THIS PRODUCT. FAILURE TO DO SO COULD RESULT IN FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY.

  • Page 2: Important Safety Information

    This fireplace is not suitable for DO NOT use on soft surfaces, like a bed, bathrooms. where openings may become blocked. Risk of electric shock- DO NOT OPEN! DO NOT place clothing or other No user-serviceable parts inside. AMBE USER MANUAL - MULTI 65...
  • Page 3 - NEVER modify this fireplace. Doing This fireplace is tested and listed for so could result in personal injury or use only with the accessories listed in property damage. Modification of this this manual. Use of other accessories fireplace completely voids all warranties. not specifically tested for this appliance could void the warranty and/or result in - ALWAYS turn this fireplace off before...
  • Page 4 For support, inquiries and contact information visit ambehome.com Distributor Address: Escea Ltd 17 Carnforth Street, Green Island, Dunedin 9018, New Zealand...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Dimensions Preparation Parts and hardware Installation and Assembly Installation for 3-Sided Viewing Installation for Front and Right-Sided Viewing Installation for Front and Left-Sided Viewing Decorative Crystal and Pebble Installation Operation Care and Maintenance Troubleshooting 630677_1...

  • Page 6: Dimensions

    Dispose of packaging materials properly. Plastic bags are not toys, and should be kept away from children and infants. Please recycle whenever possible. You will need the following tools (not included): Phillips screwdriver; stud finder; level; tape measure; electric drill; 1/4” wood drill bit, hammer. AMBE USER MANUAL - MULTI 65...

  • Page 7: Parts And Hardware

    PARTS AND HARDWARE Fireplace Wood Screws Drywall Anchors D. White Pebbles E. Black Acrylic F. Clear Acrylic I. Frameless Trim Kit G. Plastic Tray H. Remote Control J. Metal Brackets 630677_1...

  • Page 8: Installation And Assembly

    BEFORE RELOCATING. FAILURE TO DO SO COULD RESULT IN ELECTRIC SHOCK, FIRE, OR PERSONAL INJURY. CAUTION: ENSURE THAT THE INSTALLATION LOCATION OF THE FIREPLACE WILL NOT COME IN DIRECT CONTACT WITH THE BUILDING’S VAPOR BARRIER OR INSULATION AND MEETS ALL LOCAL BUILDING CODES AMBE USER MANUAL - MULTI 65...

  • Page 9: Installation For 3-Sided Viewing

    INSTALLATION FOR 3-SIDED VIEWING The fireplace is fixed with fending bars and panels on the left and right side. J - Frameless Kit Take off the fending bars and panels if you want to view the fire from three sides. 630677_1...
  • Page 10 Fix back the fending bars after the panels are removed. 4. Remove the screws from the fireplace as shown in the picture below. Fix the brackets with the screws in the previous step.
  • Page 11 6. Make an opening for the fireplace with the sizes shown. Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step. 630677_1...
  • Page 12 8. Cover the glass panel with protective plastic bag and install plywood or drywall. 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc. AMBE USER MANUAL - MULTI 65...

  • Page 13: Installation For Front And Right-Sided Viewing

    I NS T ALLAT I ON FOR FRONT AND RI GHT -SIDE VIEWING To view the fireplace from front and right side, you need to take off the fending panel on the right side and keep the left side close to a wall. Remove the 7 screws on the right side.
  • Page 14 Fix back the fending bar after the panel is removed. Remove the screws from the fireplace as shown in the picture below. AMBE USER MANUAL - MULTI 65...
  • Page 15 Fix the brackets with the screws in the previous step. Make an opening for the fireplace with the sizes shown. 1636mm 630677_1...
  • Page 16 Plug in and check if the fireplace works properly. If so, move on to next step. Cover the glass panel with protective plastic bag and install plywood or drywall. AMBE USER MANUAL - MULTI 65...
  • Page 17 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc. 630677_1...

  • Page 18: Installation For Front And Left-Sided Viewing

    To view the fireplace from front and left side, you need to take off the fending panel on the left side and keep the right side close to a wall. Remove the 7 screws on the left side. Take off the fending bar and panel. AMBE USER MANUAL - MULTI 65...
  • Page 19 Fix back the fending bar after the panel is removed. Remove the screws from the fireplace as shown in the picture below. 630677_1...
  • Page 20 Fix the brackets with the screws in the previous step. Make an opening for the fireplace with the sizes shown. 1636mm AMBE USER MANUAL - MULTI 65...
  • Page 21 Insert the fireplace into the wall opening. Drive the mounting screws into the brackets and the wall studs. Plug in and check if the fireplace works properly. If so, move on to next step. Cover the glass panel with protective plastic bag and install plywood or drywall.
  • Page 22 9. Decorate the plywood or drywall with glazed tile, wallpaper, etc. AMBE USER MANUAL - MULTI 65...

  • Page 23: Decorative Crystal And Pebble Installation

    FUEL BED MEDIA I NS T ALLAT I ON 1. Use the screw driver to take off the 4 screws. Have two people take out the glass panel and move it to a clean area taking care to avoid scratching. 630677_1...
  • Page 24 3. Place the fuel bed media on the media tray. Apply an even layer from side to side. After placing the fuel bed media, fasten screws back on the glass panel. AMBE USER MANUAL - MULTI 65...

  • Page 25: Operation

    OP E RAT I ON READ AND UNDERSTAND THIS ENTIRE OWNER’S MANUAL, INCLUDING ALL SAFETY INFORMATION, BEFORE PLUGGING IN OR USING THIS PRODUCT. FAILURE TO DO SO COULD RESULT IN ELECTRIC SHOCK, FIRE, SERIOUS INJURY, OR DEATH. Power Plug the power cord into an outlet or hard wire the appliance. If you choose to hard wire the appliance, it MUST have a dedicated isolation switch accessible after installation.
  • Page 26 H2 - High heat LO - Heater button can be locked or unlocked by holding the Heater button for 5 seconds Controls the timer. Timer Settings: 00 30min 1h 2h 3h 4h 5h 6h 7h 8h AMBE USER MANUAL - MULTI 65...
  • Page 27 BUTTON FUNCTION ACTION & INDICATION Temperature Controls the temperature. Settings: 64 F [18 C] 76 F [24 C] 66 F [19 C] 78 F [25 C] 68 F [20 C] 80 F [26 C] 70 F [21 C] 82 F [27 C] 72 F [22 C] and OFF 74 F [23 C]...

  • Page 28: Temperature Limiting Control

    This remote control uses one CR2025 battery (included). NEVER DISPOSE OF BATTERIES IN FIRE. FAILURE TO OBSERVE THIS PRECAUTION MAY RESULT IN AN EXPLOSION. DISPOSE OF BATTERIES AT YOUR LOCAL HAZARDOUS MATERIAL PROCESSING CENTER. AMBE USER MANUAL - MULTI 65...

  • Page 29: Care And Maintenance

    CARE AND MAI NT E NANCE Cleaning ALWAYS TURN THE FIREPLACE OFF AND UNPLUG THE POWER CORD FROM THE OUTLET BEFORE CLEANING, PERFORMING MAINTENANCE, OR MOVING THIS FIREPLACE. FAILURE TO DO SO COULD RESULT IN ELECTRIC SHOCK, FIRE, OR PERSONAL INJURY. NEVER IMMERSE IN WATER OR SPRAY WITH WATER.

  • Page 30: Maintenance

    - being. When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposals at least free of charge. AMBE USER MANUAL - MULTI 65...

  • Page 31: Troubleshooting

    T ROUBLE S HOOT I NG WARNING DISCONNECT THE APPLIANCE COMPLETELY AND LET COOL PRIOR TO ANY SERVICE. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. PROBLEM POSSIBLE CAUSE SOLUTION 1. Fireplace turns 1. Fireplace has 1.
  • Page 32 PLEASE REMEMBER TO ALWAYS HAVE THE UNIT DISCONNECTED PRIOR TO ANY WORK, ALWAYS LAY GLASS AS WELL AS THE UNIT ON A TOWEL OR OTHER MATERIAL NOT TO DAMAGE PARTS/FRAME. THIS ENTIRE PROCESS SHOULD NOT TAKE LONGER THAN 20-30 MINUTES AMBE USER MANUAL - MULTI 65...
  • Page 33 ambehome.com...
