  • Page 1 LC 416 LC 496 With 14A End Blocks Mounting Instructions English (en) 03/2025...

  • Page 2: Table Of Contents

    4.2.2 Removing the shipping brace......................... 4.2.3 Mounting the shipping brace........................Choosing the mounting variant....................Mounting with end blocks......................4.4.1 Variant: cable outlet on the left, equal mounting surfaces (ELG)............ HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 3 Connecting the cable........................5.3.1 Prerequisites and notes........................... 5.3.2 Materials and tools........................... 5.3.3 Connecting the adapter cable to the encoder..................Removal..........................Safety precautions regarding removal..................Removing the encoder........................ HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 4: Basic Information

    Target groups of the Mounting Instructions The Mounting Instructions must be read and observed by every person who performs any of the following tasks: Design Mounting Removal HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 5: Notes On Reading The Documentation

    Would you like any changes, or have you found any errors? We are continuously striving to improve our documentation for you. Please help us by sending your suggestions to the following e-mail address: userdoc@heidenhain.de HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 6: Symbols And Fonts Used For Marking Text

    Tilt the shipping brace to remove it (c) The shipping brace has been removed now Identifies an item of a list Example: Solid contaminants: class 3 Max. pressure dew point: class 4 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 7: Notes In This Documentation

    Unless otherwise specified, the dimensions stated in these Mounting Instructions are given in millimeters. Unless otherwise specified, the tolerances stated in these Mounting Instructions conform to ISO 8015 and ISO 2768 standards. HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 8: Safety

    Do not drop the product or subject it to major vibration Do not expose the product to mechanical stress Do not change the physical structure of the product HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 9 It is essential to observe the safety precautions for handling ESD-sensitive components Never touch connector pins without ensuring proper grounding Wear a grounded ESD wristband when handling the connections of the product HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 10: Items Supplied And Accessories

    Attachment parts Operating Instructions Product placard sticker IIIIIIIIOIIIIIIOIIIIIIIIII IIIIIIIIOIII IIIIIIIIOIII IIIIIIIIOIII IIIIIIIIOIII Quality Inspection Certificate XX xxx Qualitätsprüfbescheinigung Quality Inspection Document ID xxxxxxx-xx SN xxxxxxxx x HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 11: Mounting Accessories

    For encoders of this version, we generally recommend using the mounting spar. With measuring lengths of more than 1240 mm, the encoders must be mounted using a mounting spar. Designation Figure MSL 41 mounting spar 770902-xx To increase vibration resistance HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 12: For Mounting With End Blocks

    6 mm x 1 mm pneumatic hose. The connecting piece has an integrated throttle that ensures flow quantities of 7 l/min at an input pressure of approx. 1*10 Pa (1 bar). HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 13: Mounting

    (ML). S is reached when the arrows are above each other. Move the scanning unit only within the specified measuring length. 0± 0.5  HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 14 To find out whether the clips are required for your mounting variant, please refer to the corresponding chapter in these Mounting Instructions. HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 15: Functional Safety

    15 °C to 35 °C. For more information, refer to the Linear Encoders for Numerically Controlled Machine Tools brochure. www.heidenhain.com/documentation Enter the document ID 571470 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 16: Function And Handling Of The Shipping Brace

    If the bracket is already removed, do not pull the scanning unit, but slide it as shown. 4.2.2 Removing the shipping brace Remove the bracket HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 17: Mounting The Shipping Brace

    Slide the shipping brace into the scanning unit (c) Lock the shipping brace with the hexagon socket tool (d) HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 18 (f) Slide the shipping brace into the scanning unit (g) Attach the bracket of the shipping brace The shipping brace has been mounted. HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 19: Choosing The Mounting Variant

    Mounting | Choosing the mounting variant | Choosing the mounting variant Mounting with encoder end blocks Mounting with a mounting spar MSL 41 (separate accessory) Page 20 Page 29 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 20: Mounting With End Blocks

    Cable outlet on the left Cable outlet on the right ELG variant Page 21 ERG variant Page 23 ELE variant Page 25 ERE variant Page 27 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 21: Variant: Cable Outlet On The Left, Equal Mounting Surfaces (Elg)

    Check the alignment at the indicated ISO 4762 – M4 positions (L) in the center or on the = 2.5 Nm ± 0.2 Nm ridge D 7 .0/4.3 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 22 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 23: Variant: Cable Outlet On The Right, Equal Mounting Surfaces (Erg)

    Further information: "Mounting accessories", Page 11 For further information, refer to the Mounting Instructions Clamping Element LC 400 document. www.heidenhain.com/documentation Enter the document ID 578067 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 24 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 25: Variant: Cable Outlet On The Left, Opposite Mounting Surfaces (Ele)

    Check the alignment at the indicated ISO 4762 – M4 positions (L) in the center or on the = 2.5 Nm ± 0.2 Nm ridge D 7 .0/4.3 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 26 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 27: Variant: Cable Outlet On The Right, Opposite Mounting Surfaces (Ere)

    Further information: "Mounting accessories", Page 11 For further information, refer to the Mounting Instructions Clamping Element LC 400 document. www.heidenhain.com/documentation Enter the document ID 578067 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 28 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 29: Mounting With Mounting Spar

    Mounting with mounting spar The mounting variants in this chapter refer to mounting of the device with a mounting spar. HEIDENHAIN recommends mounting with the cable outlet on the right. This mounting option provides a higher vibration resistance. The mounting variants without a mounting spar (mounting by means of the end blocks) are described on Page 20.

  • Page 30: Mounting Variants

    Cable outlet on the left Cable outlet on the right MLG variant Page 31 MRG variant Page 33 MLE variant Page 35 MRE variant Page 37 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 31: Variant: Cable Outlet On The Left, Equal Mounting Surfaces (Mlg)

    = 1.5 Nm ± 0.1 Nm depending on whether you tighten the screws from above or from below. Torx T8 = 1.5 Nm ± 0.1 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 32 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 33: Variant: Cable Outlet On The Right, Equal Mounting Surfaces (Mrg)

    = 1.5 Nm ± 0.1 Nm depending on whether you tighten the screws from above or from below. Torx T8 = 1.5 Nm ± 0.1 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 34 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 35: Variant: Cable Outlet On The Left, Opposite Mounting Surfaces (Mle)

    = 1.5 Nm ± 0.1 Nm depending on whether you tighten the screws from above or from below. Torx T8 = 1.5 Nm ± 0.1 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 36 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 37: Variant: Cable Outlet On The Right, Opposite Mounting Surfaces (Mre)

    = 1.5 Nm ± 0.1 Nm depending on whether you tighten the screws from above or from below. Torx T8 = 1.5 Nm ± 0.1 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 38 Check the gap (K3)    –               Further information: "Final steps", Page 39 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 39: Final Steps

    < 1    Optionally connect the mounting spar with protective ground   4 mm  M5 = 4 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 40: Using Sealing Air (Optional)

    The encoder has integrated throttles in the connection holes. The throttles ensure the required flow quantity of 7 l/min at an input pressure of 1*10 Pa (1 bar). You can use standard M5 threaded plug connections without throttle as well as HEIDENHAIN connecting pieces with integrated throttle to connect the pressure tubing. Further information: "Accessories for connecting the sealing-air supply", Page 12...
  • Page 41 Screw in the connecting piece at the desired position Tighten the connecting piece with the specified torque Connect the compressed air inlet to SW2.5 the filter system = 1 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 42: Connecting The Cable

    (14 °F) For more information on the cable characteristics and cable routing, refer to the Cables and Connectors brochure. www.heidenhain.com/documentation Enter the document ID 1206103 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 43: Materials And Tools

    Connect the cable to the mating socket of the encoder Pay attention to the correct alignment of the connector. Apply low-strength threadlocker to the coupling ring HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
  • Page 44 Final steps | Connecting the cable | Connecting the adapter cable to the encoder Tighten the coupling ring with the specified torque 1/4" SW10 = 3 Nm = 3 Nm HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...

  • Page 45: Removal

    Disconnect any air connections on the encoder, Page 40 Depending on the mounting variant, release the fastening of the scanning unit and scale unit, Page 19 Attach the shipping brace, Page 17 HEIDENHAIN | LC 416, LC 496 With 14A end blocks | Mounting Instructions | 03/2025...
