Summary of Contents for AEG OA5PB40WAM
- Page 1 EN User Manual | Oven OA5PB40WAM aeg.com\register...
- Page 2 INSTALLATION (*mm) min. 550 4x25 min. 560 www.youtube.com/electrolux min. 1500 www.youtube.com/aeg How to install your AEG/Electrolux Oven with Hob - Built Under installation H05 V V - F (*mm) min. 550 4x25 min. 578 max. 590 min. 560 www.youtube.com/electrolux min. 1500 www.youtube.com/aeg...
-
Page 3: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................3 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................8 4. CONTROL PANEL..................8 5. -
Page 4: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. -
Page 5: Safety Instructions
• To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. • Do not use a steam cleaner to clean the appliance. •... -
Page 6: Pyrolytic Cleaning
• Fully close the appliance door before you – be careful when you remove or install connect the mains plug to the mains the accessories. socket. • Discoloration of the enamel or stainless • This appliance is supplied with a main steel has no effect on the performance of plug and a main cable. -
Page 7: Internal Lighting
2.6 Internal lighting • Before carrying out the pyrolytic cleaning and initial preheating remove from the oven cavity: WARNING! – any excess food residues, oil or Risk of electric shock. grease spills / deposits. – any removable objects (including • Concerning the lamp(s) inside this product shelves, side rails, etc., provided with and spare part lamps sold separately: the appliance) especially any non-stick... -
Page 8: Product Description
3. PRODUCT DESCRIPTION 3.1 General overview Control knob Heating element Lamp Shelf support, removable Cavity embossment Shelf positions 3.2 Accessories • Wire shelf For cake tins, ovenproof dishes, roast dishes, cookware / dishes. Control panel • Grill- / Roasting pan Knob for the heating functions To bake and roast or as pan to collect fat. -
Page 9: Before First Use
Uptimer is activated. Progress bar - visually indicates when the appliance reaches the set tempera‐ ture or when the cooking time comes to an end. 5. BEFORE FIRST USE 2. Set the function . Set the maximum WARNING! temperature. Let the appliance operate Refer to Safety chapters. -
Page 10: Entering: Menu
2. Turn the knob for the heating functions to Grill select the heating function To grill thin pieces of food and to toast bread. 3. Turn the control knob to set a temperature. Turbo Grilling 4. Preheat the empty appliance for 10 min to To roast large meat joints or poultry with bones on one shelf position. - Page 11 Submenu: Assisted Cooking Legend Legend Weight adjustment available. Shelf level. Refer to "Product description" chapter. Fill the cavity embossment with water for The display shows P and a number of the steam cooking. dish that you can check in the table. Preheat the appliance before you start cooking.
- Page 12 Dish Weight Shelf level / Accessory Pulled pork (slow 1.5 - 2 kg 2; baking tray cooking) Turn the meat after half of the cooking time to get an even browning. Pork loin, fresh 1 - 1.5 kg; 5 - 6 cm 2;...
-
Page 13: Changing Settings
Dish Weight Shelf level / Accessory Brownies 2 kg of dough 3; deep pan Muffins 100 - 150 ml; muffin tray on wire shelf Loaf cake 2; loaf pan on wire shelf Baked potatoes 1 kg 2; baking tray Put the whole potatoes with skin on baking tray. Wedges 1 kg 3;... -
Page 14: Additional Functions
Setting Value Setting Value Key tones 1 - Beep, 2 - Click, Cleaning Reminder On / Off 3 - Sound off Demo mode Activation code: Buzzer volume 1 - 4 2468 Uptimer On / Off Software version Check Light On / Off Reset all settings Yes / No Fast Heat Up... -
Page 15: Using The Accessories
8.4 Setting: Time Delayed Start To set cooking duration. When the tim‐ 1. Turn the knobs to select the heating er ends, the signal sounds and the function and to set the temperature. heating function will automatically turn Cooking off. time 2. -
Page 16: Hints And Tips
Wire shelf Deep pan Push the tray between the guide bars of the shelf support. Insert the shelf between the guide bars of the shelf support. 10. HINTS AND TIPS 10.1 Cooking recommendations Accessory The temperature and cooking times in the tables are for guidance only. -
Page 17: Information For Test Institutes
Moussaka 170 - 190 70 - 95 Lasagne 180 - 200 75 - 90 Cannelloni 180 - 200 70 - 85 Bread pudding 190 - 200 55 - 70 Rice pudding 170 - 190 45 - 60 Apple cake, made of sponge cake mixture 160 - 170 70 - 80 (round cake tin) -
Page 18: Care And Cleaning
Apple pie True Fan Cooking 55 - 65 2 and 4 Wire shelf Preheat the empty appliance. 1 cake tin on each wire shelf. 11. CARE AND CLEANING Use maximum 6% acidity vinegar without WARNING! any additives. 2. Let the vinegar dissolve the limestone Refer to Safety chapters. -
Page 19: Cleaning Reminder
Do not start the function if you did not fully CAUTION! close the oven door. Carefully handle the glass, especially 1. Make sure that the appliance is cold. around the edges of the front panel. The 2. Remove all accessories and removable glass can break. -
Page 20: Replacing The Lamp
not clean the glass panels in the 2. Disconnect the appliance from the mains. dishwasher. 3. Place the cloth on the oven floor. After cleaning, do the above steps in the Top lamp opposite sequence. Install the smaller panel first, then the larger and the door. 1. -
Page 21: Energy Efficiency
13. ENERGY EFFICIENCY 13.1 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations Supplier's name Model identification OA5PB40WAM 944035011 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional mode 1.09 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.69 kWh/cycle... -
Page 22: Environmental Concerns
Use metal cookware and dark, non-reflective When you turn off the appliance, the display tins and containers to improve energy saving. shows the residual heat. Do not preheat the appliance before cooking Keep food warm unless specifically recommended. Choose the lowest possible temperature setting to use residual heat and keep the food Keep breaks between baking as short as warm. - Page 24 867381137-A-162024...
