Accessing the menu system

NOTE: After you change the settings, press the joystick to save the
changes before exiting or proceeding to another menu.
Icon Menu and
submenu
Brightness/
Contrast
Brightness
Contrast
│
70 Operating the monitor
Adjusts the brightness and the contrast of the display.
Brightness adjusts the luminance of the backlight.
Move the joystick up or down to increase or decrease
the brightness level (min. 0/max. 100).
Adjust the Brightness first, and then adjust the
Contrast only if further adjustment is necessary.
The Contrast function adjusts the degree of difference
between darkness and lightness on the monitor screen.
Move the joystick up or down to increase or decrease
the contrast level (min. 0/max. 100).
Description
