- Page 1 DZ47TRLE User's manual Before installing and using the product, please read the instruction manual carefully and keep it in a safe place for spare parts.
-
Page 2: Safety Advice
Safety advice Before installing, operating, running, maintaining, or checking, be sure to read this manual carefully and install and use the product accurately according to the contents of the manual. Danger: It is strictly prohibited to operate the circuit breaker with wet hands; ... - Page 3 Catalogue 1 Main uses and scope of application .....................1 2 Product characteristics, models and meaning ..................1 1 Normal use, installation and transportation conditions ................1 4 Technical characteristics ........................2 4.1 Classification ...........................2 4.2 Main technical performance parameters .....................2 5 Shape and installation dimensions .......................3 6 Installation and use (maintenance) ......................3 7 Failure analysis ............................
- Page 4 DZ47TRLE leakage circuit breaker is suitable for AC 50Hz, rated voltage 230V/400V, rated current up to 60A and below in the line, used for the indirect contact protection of people, as well as buildings and similar uses of the line for overcurrent protection.
-
Page 5: Technical Characteristics
Instantan off breaking e current circuit breaking number In A wire I △ n eous I△no Capacity Capacity Tripper I △ m A Icn A Type C6-C40 :6000 ＜0.1 C、D DZ47TRLE C50-C60:4500 D6-D60:4500 第 2 页... - Page 6 4.3 Main technical parameters Overcurrent protection characteristics are shown in Table 2 Table 2 Protective characteristics of overcurrent striker Types of base Rated Test current Expected overcurrent currendt starting Test time footnote temper instantaneous results disconnectors state ature In A ——...
-
Page 7: Failure Analysis
Rated current value A 16、20 40、50 Cross-sectional area of conductor mm² e) When the protector product is selected for use, it is installed side by side with small circuit breakers of the same specifications; f) The tightening torque is 2.0N-m. Residual current action circuit breaker working reference temperature of +30 +5 0 ℃, when the ambient temperature change, its rated value needs to be corrected, the temperature correction coefficient is shown in Table 4;... -
Page 8: Unpacking And Inspection
If you have any questions, please contact the dealer or our customer service department. Customer service hotline;400-826-8008 Name ： Residual current operated circuit breaker (RCBO) model number：DZ47TRLE This product is allowed to leave the factory after passing the inspection. Implementation standards：GB/T16917.1 检... - Page 9 浙江省乐清市柳市镇德力西高科技工业园区邮编：325604 电话： （86-577）61778888 传真： （86-577）61778000 客服热线：400-826-8008 www.delixi-electric.com 本说明书自 2019 年 7 月 第 1 版 第 6 页...
