LuxenHome WHIF1880 Instruction Manual

PRODUCT NAME : MODERN GRAY PANEL BED HEADBOARD AND FOOTBOARD SET WITH LIGHTS
SKU #: WHIF1880
PRODUCT CARE INFORMATION
1. BEFORE ASSEMBLY, PLEASE DETERMINE THE LOCATION OF THE PRODUCT.
2. PLEASE ENSURE ALL PARTS AND HARDWARE ARE INCLUDED.
3. ALL ASSEMBLY WORK SHOULD PERFORM ON A SOFT SURFACE TO PREVENT DAMAGE.
4. FOLLOW THE ASSEMBLY STEPS, DO NOT SKIP ANY STEP.
5. WHEN MOVING THE PRODUCT, LIFT IT CAREFULLY WITH AT LEAST TWO PEOPLE AND CARRY IT TO
THE NEW LOCATION.
6. NEVER PUSH, DRAG, OR PULL YOUR PRODUCT.
7. PERIODICALLY CHECK THAT ALL THE CONNECTIONS ARE TIGHT. TIGHTEN (SCREW, BOLT, ETC...).
LOOSE CONNECTIONS AS NEEDED. LOOSE CONNECTIONS CAN CAUSE INJURY, PRODUCT DAMAGE, ETC.
8. WIPE THE PRODUCT WITH A CLEAN, DRY CLOTH WEEKLY TO MAINTAIN THE APPEARANCE.
9. TO PREVENT DAMAGE, AVOID DIRECT CONTACT BETWEEN THE PRODUCT AND LIQUIDS.
10. KEEP THIS PRODUCT CARE & ASSEMBLY INSTRUCTIONS FOR FUTURE REFERENCE.
1
2
7
8
4
2
5
PLEASE SAVE THIS MANUAL FOR FUTURE REFERENCE
NO.
A
B
C
D
E
F
G
H
K
6
3
1
INSTRUCTION MANUAL
PART
JCBB SCREW (M8 x 16mm)
JCBC SCREW (M6 x 30mm)
FLAT WASHER (M8 x 18mm)
FLAT WASHER (M6 x 13mm)
SPRING WASHER (M6)
PANHEAD SCREW (M4 x 30mm)
METAL L BRACKET (2H)
CSK SCREW (M3.5 x 16mm)
I ALLEN KEY (M4)
J ALLEN KEY (M5)
PVC NAIL LEG WITH PIN
*TOOLS ABOVE ARE NOT PROVIDED
QTY
8
15
8
15
15
26
5
10
1
1
14
