Product Name:
Modern Farmhouse Gray Upholstered Queen Bed Headboard and Wood Footboard Set
SKU #:
WHIF1882
Thank you for purchasing this Luxen Home product. This product has been manufactured with the
highest standards of satety and quality.
PLEASE READ ALL INSTRUCTION CAREFULLY BEFORE ASSEMBLY:
Unpack all parts from the packaging inside the carton to ensure there are no missing or damaged parts.
Place all wooden furniture part on a clean and fat so� surface to prevent scratches. Place all woden
Furniture parts on a clean ,flat, so� surface to prevent scratches. Refer to the steps provided below
for assembly.
Do not a�empt to assemble or use the product if any parts are missing or damaged.
CARTON CONTENTS:
Hardware:
1
M4 Allen Key
x 1
Wood Dowel
5
(10 x 40mm) x 2
9
M6 x 15mm
JCB x 4
13
M6 x 90mm JCB
x 5
2
Center Rail
Bracket x 2
6
Barrel Nut
x 3
10
M6 x 20mm
JCB x 8
Instruc�on Manual
Please save the manual for
3
3
Adjustable
Foot x 3
Spring Washer
7
x14
M6 x 50mm JCB
11
x 6
future reference.
Wood Screw
4
(M4 x 32mm) x 18
M6 Flat Washer
8
x 14
12
M6 x 40mm
JCB x 12
Advertisement
Related Manuals for LuxenHome WHIF1882
Summary of Contents for LuxenHome WHIF1882
- Page 1 Product Name: Modern Farmhouse Gray Upholstered Queen Bed Headboard and Wood Footboard Set SKU #: WHIF1882 Thank you for purchasing this Luxen Home product. This product has been manufactured with the highest standards of satety and quality. PLEASE READ ALL INSTRUCTION CAREFULLY BEFORE ASSEMBLY: Unpack all parts from the packaging inside the carton to ensure there are no missing or damaged parts.
- Page 2 Instruc�on Manual Please save the manual for future reference. Product Name: Modern Farmhouse Gray Upholstered Queen Bed Headboard and Wood Footboard Set SKU #: WHIF1882 Part List Parts in Box A : Post (Left) Footboard Panel Headboard Panel Headboard Support...
- Page 3 Product Name: Modern Farmhouse Gray Upholstered Queen Bed Headboard and Wood Footboard Set SKU #: WHIF1882 Step 2: Fit the Center Rail Bracket (2) to the Headboard Support (C). Assemble Post (D & E) to the Headboard Support (C). Short Tab of Metal Bracket (2) Step 3: Fit the Centre Rail Bracket (2) to the Footboard Panel (B).
- Page 4 Modern Farmhouse Gray Upholstered Queen Bed Headboard and Wood Footboard Set SKU #: WHIF1882 Step 4: Assembled the Post (D & E) to the Headboard (A). Step 5: Assemble the Side Rail (F) to the Post (D & E) & Footboard Panel (B).
- Page 5 Product Name: Modern Farmhouse Gray Upholstered Queen Bed Headboard and Wood Footboard Set SKU #: WHIF1882 Step 6: Bolt the Long Support (G) to the Center Rail Bracket (2) on the Headboard Support (C) & Footboard Panel (B). Step 7: Bolt & Screw the Bed Slats (J) to the Side Rail (F).
