HiLook THC-B259-LMS User Manual

3k colorvu bullet & turret camera

Advertisement

Quick Links

Bullet & Turret Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type I Camera
Type II Camera
Type III Camera
Type IV Camera
Type V Camera
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Type
3K ColorVu
User Manual
Model
THC-B259-LMS
THC-B159-LPS
THC-B159-LMS
THC-T259-LS
THC-T159-LMS
THC-T159-LPS
01000020241009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THC-B259-LMS and is the answer not in the manual?

Questions and answers

Summary of Contents for HiLook THC-B259-LMS

  • Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model Type I Camera THC-B259-LMS THC-B159-LPS Type II Camera THC-B159-LMS Type III Camera THC-T259-LS Type IV Camera...
  • Page 2: About This Document

    About this Document This Document includes instructions for using and  managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Document is subject  to change, without notice, due to firmware updates or other reasons.
  • Page 3: Regulatory Information

    RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
  • Page 4 This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
  • Page 5 Do not place the camera in extremely hot, cold (the  operating temperature shall be -40°C to 60°C), dusty or damp locations, and do not expose it to high electromagnetic radiation. If cleaning is necessary, use clean cloth with a bit of ...
  • Page 6 1.2.2 Overview of Type II Camera Switch Button Power Cord Video Cable Bracket Microphone Main Body Lens Figure 1-2 Overview of Type II Camera Notes: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS 1.2.3 Overview of Type III Camera Enclosure...
  • Page 7: Installation

    2 Installation Before you start Make sure that the device in the package is in good  condition and all the assembly parts are included. Make sure that all the related equipment is power-off  during the installation. Check the specification of the products for the ...
  • Page 8 2. (Optional) For cement wall, drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs. 3. (Optional) Drill the cable hole, when the cables are routed through the wall. 4. Take apart the junction box. 5.
  • Page 9 Figure 2-6 Install the Camera to Ceiling  For Type IV camera: i. Loosen the set screw. ii. Rotate the camera to align the triangle mark with the screw hole, and dissemble the camera. Figure 2-7 Dissemble the Camera iii. Secure the base to the ceiling with three PA4 × 25 screws (supplied).
  • Page 10 3. (Optional) For cement ceiling, drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs. 4. (Optional) Drill the cable hole, when the cables are routed through the ceiling. 5. Secure the junction box body on the ceiling with three or four PA4 ×...
  • Page 11: Waterproof Measures

     For Type III and Type V camera: i. Use three PM4 screws to fix the installation plate onto the wall mount. Figure 2-13 Fix the Installation Plate  For Type IV camera: i. Refer to Step 3 of Section 2.2.1 to dissemble the camera ii.
  • Page 12: Menu Description

    Figure 3-1 Waterproof Cable 4 Menu Description Please follow the steps below to call the menu. Note: The actual display may vary with your camera model. Steps: 1. Connect the camera with the TVI DVR and the monitor, as shown in figure 4-1. TVI DVR Camera Monitor...
  • Page 13: Video Format

    VIDEO FORMAT EXPOSURE MODE ANTI-BANDING EXPOSURE BACK EXIT SAVE & EXIT LIGHTING MODE IR/WHITE LIGHT SMART IR THRESHOLD LIGHTING SETTINGS Level BACK EXIT SAVE & EXIT IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST VIDEO MAIN MENU SHARPNESS SETTINGS SATURATION BACK EXIT SAVE &...
  • Page 14 4 MP@30 fps 4 MP@25 fps 4 MP@30 fps CVBS NTSC 4.2 EXPOSURE EXPOSURE MODE You can set the EXPOSURE MODE to GLOBAL, BLC, HLC, WDR, or HLS. GLOBAL  GLOBAL refers to the normal exposure mode which adjusts lighting distribution, variations, and non-standard processing.
  • Page 15: White Light

    N D Threshold (Night to Day Threshold)  Night to Day Threshold is used to control the sensitivity of switching the night mode to the day mode. You can set the value from 1 to 9. The larger the value is, the more sensitive the camera is.
  • Page 16: Audio Settings

    BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 9 to darken or brighten the image. The greater the value is, the brighter the image is. CONTRAST This feature enhances the difference in color and light between parts of an image.
