Quick Installation Guide
EET75KPro-110K - M1
Overview
1.1 Scope of Delivery
2
1
6
5
1.2 Port Description
2
Mechanical Installation
2.1 Installation Requirement
300 mm
150 mm
150 mm
300 mm
Warning
Do not select locations storing flammable material, which may cause fire or explosion!
2.2 Mounting
3
4
Documents
7
1 2 3
45 6 7 8
9
0°- 15°
1) Drill 4 mounting holes of about
4 cm deep with a 10 mm drill bit
2) Insert expansion tubes into
holes
3) Fix the bracket on the wall with
screws
4)Hang up the inverter to the
bracket.
No.
1
2
3
4
5
6
7
2
3
No.
1
DC
PV
Rese-
Name
Switch
Ports
rved
No.
9
AC
Name
Port
1) A minimum 150 mm clearance should be kept
between two inverters and a minimum 300 mm
clearance between inverters and the ground.
2) Install inverter vertically or with a backward tilt
within 15°.
Description
Inverter
Wall Bracket
Expansion Screws
Fastening Screws
DC Connectors
WiFi/GPRS Stick
Documents
7
4
5
6
COM/
Commu-
Wifi/
CT
Meter
nication
GPRS
Port
/DRM
Port 2
Quantity
1
1
4
3
18
Pairs
1
1
8
Ground-
ing Port
