Wired Remote Controller
KSACN1201AAA
For Use With Ductless Systems
NOTE: In order to properly service the wired controller, read this manual carefully prior to operating the
unit. Keep this manual after reading for future reference.
NOTE: Images are for illustration purposes only. Actual models may differ slightly.
OM-KSACN1201AAA-01
Owner's Manual
Specifications subject to change without notice.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KSACN1201AAA and is the answer not in the manual?

Questions and answers

Related Manuals for Carrier KSACN1201AAA

Summary of Contents for Carrier KSACN1201AAA

  • Page 1 Wired Remote Controller KSACN1201AAA For Use With Ductless Systems Owner’s Manual NOTE: In order to properly service the wired controller, read this manual carefully prior to operating the unit. Keep this manual after reading for future reference. NOTE: Images are for illustration purposes only. Actual models may differ slightly.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE SAFETY CONSIDERATIONS...................3 BATTERY INSTALLATION .....................5 BUTTON IDENTIFICATION ON WIRED CONTROLLER ..........9 LCD IDENTIFICATION ON WIRED CONTROLLER ..........10 BASIC FUNCTIONS ......................11 TROUBLESHOOT YOUR WIRED CONTROLLER............20 Specifications subject to change without notice. OM-KSACN1201AAA-01...

  • Page 3: Safety Considerations

    WARNING signifies hazards which could result in personal injury or death. CAUTION is used to identify unsafe practices which may result in minor personal injury or product and property damage. NOTE is used to highlight suggestions which will result in enhanced installation, reliability, or operation. OM-KSACN1201AAA-01 Specifications subject to change without notice.
  • Page 4 Failure to follow this caution may result in equipment damage or improper operation. Do not install the wired controller in an area subjected to excessive steam, oil or sulfide gas. Doing so may damage the controller and/or cause it to fail. Specifications subject to change without notice. OM-KSACN1201AAA-01...

  • Page 5: Battery Installation

    BATTERY INSTALLATION OM-KSACN1201AAA-01 Specifications subject to change without notice.
  • Page 6 Specifications subject to change without notice. OM-KSACN1201AAA-01...
  • Page 7 DO NOT mix old and new batteries, different brands or types of batteries such as alkaline, carbon-zinc, or rechargeable batteries. Remove and immediately recycle or dispose of batteries from equipment not used for an extended period of time according to local regulations. OM-KSACN1201AAA-01 Specifications subject to change without notice.
  • Page 8 Set the time corrected on the first time operation. Batteries in the wired controller can timeout during a power failure which ensures the time is accurate. When the power restores, if the time displayed is not accurate, the battery is dead and must be replaced. Specifications subject to change without notice. OM-KSACN1201AAA-01...

  • Page 9: Button Identification On Wired Controller

    Fig. 2 – Name of Buttons on Wired Controller DO NOT remove the cover or touch the interior parts of the controller. DO NOT use sharp or pointed objects to press the controller buttons. OM-KSACN1201AAA-01 Specifications subject to change without notice.

  • Page 10: Lcd Identification On Wired Controller

    LCD IDENTIFICATION ON WIRED CONTROLLER Fig. 3 – Name on LCD of Wired Controller Specifications subject to change without notice. OM-KSACN1201AAA-01...

  • Page 11: Basic Functions

    BASIC FUNCTIONS The following are instructions for using your air conditioner’s basic functions: OM-KSACN1201AAA-01 Specifications subject to change without notice.

  • Page 12: Auto Function

    2. Set your desired temperature using the Up and DOWN buttons. (In AUTO mode, fan speed cannot be set.) 3. Press the ON/OFF button to start the unit. Fig. 4 – Auto Function Specifications subject to change without notice. OM-KSACN1201AAA-01...
  • Page 13 3. Press the FAN SPEED button to select the fan speed. 4. Press the ON/OFF button to start the unit. NOTE: In FAN mode, the temperature cannot be changed. Fig. 5 – COOL/HEAT/FAN Function OM-KSACN1201AAA-01 Specifications subject to change without notice.
  • Page 14 2. Set your desired temperature using the UP and DOWN buttons. 3. Press the ON/OFF button to start the unit. NOTE: In DRY mode, the FAN SPEED buttons cannot be used. Fig. 6 – DRY Function Specifications subject to change without notice. OM-KSACN1201AAA-01...

  • Page 15: Follow Me Function

    5. Press the FUNC button to enter the setting selection (see Fig. 18). It will scroll through operation functions as follows: The selected symbol will flash on the display. Press the OK button to confirm. Fig. 7 – FUNC Button OM-KSACN1201AAA-01 Specifications subject to change without notice.
  • Page 16 Press it for 2 seconds again to stop. 3. Turn Child Lock on/off Press and hold the function key and the horizontal swing key for 3 seconds. Fig. 8 – Swing Button Specifications subject to change without notice. OM-KSACN1201AAA-01...

  • Page 17: Timer Function

    NOTE: This number indicates the amount of time after the current time you want the unit to turn on. For example, if you set TIMER ON for 2 hours, “2.0 H” will appear on the screen and the unit will turn on after 2 hours. OM-KSACN1201AAA-01 Specifications subject to change without notice.
  • Page 18 10 hours. After 10 hours, it will increase in 1 hour increments up to 24 hours. The timer will revert to zero after 24 hours. You can turn off either function by setting its timer to “0.0 H”. Specifications subject to change without notice. OM-KSACN1201AAA-01...
  • Page 19 HEAT mode and setting temperature of 60/62°F (16/17°C) or 68°F (20°C) (for some models) to activate FP function. Press ON/OFF, SLEEP, MODE, FAN or TEMP button while operating will cancel this function. °C and °F Scale Selection (on some models) OM-KSACN1201AAA-01 Specifications subject to change without notice.

  • Page 20: Troubleshoot Your Wired Controller

    @ 2024 Carrier Company Edition Date: 02/24 Catalog No. OM-KSACN1201AAA-01 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
