INVERTER
CC2
FR-CC2M INSTRUCTION MANUAL
Converter Unit
FR-CC2M-H250K to H560K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-CC2M and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric FR-CC2M

Summary of Contents for Mitsubishi Electric FR-CC2M

  • Page 1 INVERTER FR-CC2M INSTRUCTION MANUAL Converter Unit FR-CC2M-H250K to H560K...

  • Page 2: Table Of Contents

    Safety instructions..............6 Chapter 1 INTRODUCTION .
  • Page 3 Chapter 3 PRECAUTIONS FOR USE OF THE CONVERTER UNIT ......... . . 66 Electro-magnetic interference (EMI) and leakage currents .
  • Page 4 5.3.3 Input phase loss protection selection ..............104 5.3.4 Retry function .
  • Page 5 6.6.7 A breaker trips................. . 176 6.6.8 The converter unit generates abnormal noise.
  • Page 6 UL-certified combinations of converter units and inverters ......207 Major differences from the FR-CC2 series ........207...

  • Page 7: Safety Instructions

    • A person who possesses a certification in regard with electric appliance handling, or person took a proper engineering training. Such training may be available at your local Mitsubishi Electric office. Contact your local sales office for schedules and locations.
  • Page 8 Electric shock prevention WARNING • Do not remove the front cover or the wiring cover while the power of this product is ON, and do not run this product with the front cover or the wiring cover removed as the exposed high voltage terminals or the charging part of the circuitry can be touched.
  • Page 9 CAUTION Transportation and installation • To prevent injury, wear cut-resistant gloves when opening packaging with sharp tools. • Use proper lifting techniques or a trolley when carrying products. Failure to do so may lead to injuries. • Do not stand or place any heavy object on this product. •...

  • Page 10: General Instruction

    CAUTION Usage • Do not repeatedly start or stop the inverter with a magnetic contactor on its input side. Doing so will shorten the life of the inverter and the converter unit. • Use a noise filter or other means to minimize the electromagnetic interference with other electronic equipment used nearby the converter unit.
  • Page 11 MEMO...

  • Page 12: Chapter 1 Introduction

    CHAPTER 1 INTRODUCTION Product checking and accessories .........................13 Component names ..............................14 Related manuals..............................16...

  • Page 13: Harmonic Suppression Guidelines

    Description Operation panel Inverter operation panel (FR-DU08) Converter unit Converter unit FR-CC2M Parameter number (Number assigned to function)  Trademarks • Microsoft and Visual C++ are registered trademarks of Microsoft Corporation in the United States and other countries. • MODBUS is a registered trademark of SCHNEIDER ELECTRIC USA, INC.

  • Page 14: Product Checking And Accessories

    Symbol Year Month Control number indicated by 1 to 9, X (October), Y (November), or Z (December). SERIAL  Accessories • L-shaped conductor (2 pcs): Included with the FR-CC2M-H315K or lower. Installation is required for wiring the main circuit terminals. (Refer to page 43.) 1.

  • Page 15: Component Names

    Component names Component names are as follows. 1. INTRODUCTION 1.2 Component names...
  • Page 16 Symbol Name Description Refer to page Connector for the operation panel (FR-DU08). Also used for the RS-485 PU connector communication. For manufacturer setting. Do not use. — RS-485 terminals Enable RS-485 communication. Terminating resistor selection Select whether or not to use the terminating resistor for RS-485 switch (SW1) communication.

  • Page 17: Related Manuals

    Related manuals Manuals related to this product are as follows. Name Manual number FR-A802M Instruction Manual (Hardware) IB-0600989ENG FR-A800 Instruction Manual (Detailed) IB-0600503ENG 1. INTRODUCTION 1.3 Related manuals...
  • Page 18 CHAPTER 2 INSTALLATION AND WIRING Peripheral devices ..............................18 Removal and reinstallation of the cover........................23 Installation of the converter unit and enclosure design...................27 Terminal connection diagrams..........................32 Main circuit terminals (for 6-phase rectification) .....................35 Main circuit terminals (for 12-phase rectification) ....................48 Control circuit................................52 Communication connectors and terminals......................63...

  • Page 19: Chapter 2 Installation And Wiring

    INSTALLATION AND WIRING This chapter explains the installation and the wiring of this product. Always read the instructions before use. Peripheral devices 2.1.1 Converter unit and peripheral devices (c) Three-phase AC power supply (b) Converter unit (a) Inverter (d) Molded case circuit breaker (MCCB) or earth leakage...
  • Page 20 Incorrect wiring may lead to damage of the inverter and the converter unit. The control signal lines must be kept fully away from the main circuit lines Converter unit (FR-CC2M) to protect them from noise. The built-in EMC filter of the converter unit can reduce the noise.

  • Page 21: Peripheral Devices

    1500 A 1500 A rated product Assumes the use of a Mitsubishi Electric standard 4-pole motor with the power supply voltage of 400 VAC 50 Hz. Select an MCCB according to the power supply capacity. Install one MCCB per converter unit.
  • Page 22 1000 A S-N800 Assumes the use of a Mitsubishi Electric standard 4-pole motor with the power supply voltage of 400 VAC 50 Hz. Select an MCCB according to the power supply capacity. Install one MCCB between the delta/wye connection and the converter unit.
  • Page 23 NOTE • When the converter unit capacity is larger than the motor capacity, select an MCCB and a magnetic contactor according to the converter unit model, and select cables and reactors according to the motor output. • When the breaker on the converter unit's input side trips, check for the wiring fault (short circuit), damage to internal parts of the inverter or the converter unit, etc.

  • Page 24: Removal And Reinstallation Of The Cover

    0.45 N·m)  Removal of the upper main circuit terminal cover (front)  Example: FR-CC2M-H250K to H315K (a) Remove the mounting screws to remove the upper main circuit terminal cover (front). (There are two keyhole slots. The cover can be removed just by loosening the screws in these slots.) 2.
  • Page 25 (b) With the cover removed, the main circuit terminals can be wired.  Removal of the upper main circuit terminal covers (side) and upper main circuit terminal cover (top) Upper main circuit terminal cover (top) Upper main circuit terminal cover (side) (a) Remove the mounting screws to remove the upper main circuit terminal covers (side) and upper main circuit terminal cover (top).
  • Page 26 Loosen Loosen Loosen (c) With the lower cover removed, loosen the mounting screws on the upper cover. (These screws cannot be removed.) (d) While holding the areas around the installation hooks on the sides of the upper front cover, pull out the cover using its upper side as a support.
  • Page 27  Reinstallation of the front cover Tighten Tighten Tighten Tighten Tighten Tighten (a) Clip on the upper front cover as illustrated. Check that it is properly secured. (b) Tighten the screws on the lower part of the cover. (c) Attach the lower front cover using the screws. NOTE •...

  • Page 28: Installation Of The Converter Unit And Enclosure Design

    Installation of the converter unit and enclosure design When designing or manufacturing an enclosure to contain the converter unit, determine the structure, size, and device layout by fully considering the conditions such as heat generation of the contained devices and the operating environment. A converter unit uses many semiconductor devices.
  • Page 29  Humidity Normally operate the converter unit within the ambient air humidity of 45% to 95%. Too high humidity will pose problems of reduced insulation and metal corrosion. On the other hand, too low humidity may cause a spatial electrical breakdown. The humidity conditions for the insulation distance defined in JEM 1103 standard "Insulation Distance from Control Equipment"...

  • Page 30: Cooling System Types For Converter Unit Enclosure

    Especially when impacts are applied repeatedly, caution must be taken because such impacts may break the installation feet. Countermeasure • Provide the enclosure with rubber vibration isolators. • Strengthen the structure to prevent the enclosure from resonance. • Install the enclosure away from the sources of the vibration. 2.3.2 Cooling system types for converter unit enclosure From the enclosure that contains the converter unit, the heat of the converter unit and other equipment (transformers, lamps,...

  • Page 31: Installation Of The Converter Unit

    2.3.3 Installation of the converter unit  Installation of the converter unit Fix the product using six installation screws. • Install the converter unit on a strong surface securely with screws. • Leave enough clearances and take cooling measures. • Avoid places where the converter unit is subjected to direct sunlight, high temperature and high humidity. •...
  • Page 32  Installation orientation of the converter unit Install the converter unit on a wall as specified. Do not mount it horizontally or in any other way.  Above the converter unit Heat is blown up from inside the converter unit by the small fan built in the unit. Any equipment placed above the converter unit should be heat resistant.

  • Page 33: Terminal Connection Diagrams

    Terminal connection diagrams  When the sink logic is selected Sink logic Main circuit terminal Control circuit terminal Inverter MCCB DC reactor Inrush current R/L1 Three-phase limit circuit S/L2 AC power T/L3 supply EMC filter R1/L11 ON/OFF Jumper S1/L21 ∗1 connecter Main circuit Earth...
  • Page 34 NOTE • To prevent a malfunction due to noise, keep the signal cables 10 cm or more away from the power cables. Also, keep the cables of the main circuit for input and output separated. • After wiring, do not leave wire offcuts in the inverter or the converter unit. Wire offcuts can cause a fault, failure, or malfunction.
  • Page 35 To use the RDA signal of the converter unit, select the normally-closed contact input specification for the input logic of the MRS signal or X10 signal of the inverter. To use the RDB signal of the converter unit, select the normally-open contact input specification for the input logic of the MRS signal or X10 signal of the inverter.

  • Page 36: Main Circuit Terminals (For 6-Phase Rectification)

    Main circuit terminals (for 6-phase rectification) 2.5.1 Details on the main circuit terminals Refer to Terminal symbol Terminal name Terminal function description page R/L1, S/L2, T/L3 AC power input Connect these terminals to the commercial power supply. — Connected to the AC power supply terminals R/L1 and S/L2. To retain the fault display and fault output, remove the jumpers across terminals Power supply for the control R/L1 and R1/L11 and across S/L2 and S1/L21, and apply external...

  • Page 37: Terminal Layout Of The Main Circuit Terminals, Wiring Of Power Supply And The Inverter

    2.5.2 Terminal layout of the main circuit terminals, wiring of power supply and the inverter FR-CC2M-H250K to H315K FR-CC2M-H355K to H560K To inverter To inverter Charge lamp Charge lamp Jumper Jumper R/L1 R/L1 S/L2 S/L2 T/L3 T/L3 Power supply Power supply 2.
  • Page 38  Recommended bus bar dimensions (for terminals P/+ and N/-) Refer to the following for bus bars for terminals P/+ and N/-. • FR-CC2M-H250K to H315K (when the FR-A842M-05080(250K) to 06440(315K) (*for the FR-A842M-06440(315K), only when used with the ND rating) are connected to the FR-CC2M): 5×45°...
  • Page 39 • FR-CC2M-H355K (when the FR-A842M-06440(315K) (used with the SLD rating) is connected to the FR-CC2M): Inverter side Converter unit side 27.5 Insulation tube Arrangement of the units Left Right Converter Inverter Clearance between the units + 386 Clearance between the units + 319...
  • Page 40  Preparing the IP20 compatible protective cover When connecting bus bars, the protective cover must be installed to achieve the IP20 compliant protective structure. Prepare the cover referring to the following. • Frame Clearance between the units + 40 4×M4 (Unit: mm) •...
  • Page 41 • The following shows how to connect bus bars to the main circuit terminals. <Example of connecting the FR-CC2M-H450K and the FR-A842M-09080(450K)> Install the protective cover (frame) using the screws and screw holes used for the upper main circuit terminal covers (side) of the converter unit and the inverter.
  • Page 42 Install the bus bar for terminal N/- (rear). Bus bar Install the bus bar for terminal P/+ (front). Bus bar Install the protective cover (lid). M4 screw Protective cover (lid) 2. INSTALLATION AND WIRING 2.5 Main circuit terminals (for 6-phase rectification)
  • Page 43 Units with the protective cover installed Converter unit and inverter with the upper main circuit terminal covers (front) installed NOTE • Ensure the upper main circuit terminal cover (front) is reinstalled before starting operation. 2. INSTALLATION AND WIRING 2.5 Main circuit terminals (for 6-phase rectification)

  • Page 44: Wiring Connection

     Wiring connection <Example: FR-CC2M-H250K to H315K> Remove the upper main circuit terminal cover (front) and the lower main circuit terminal cover (refer to page 23 page 25). Remove the upper main circuit terminal cover (top), the lower wiring covers (front and inner), and the protective bushes.
  • Page 45 Install the included L-shaped conductors to terminals P/+ and N/-. (Tightening torque: 5.49 N·m) L-shaped conductor L-shaped conductor Connect the cables to terminals P/+ and N/-. The upper main circuit terminal cover (top) should remain removed. 2. INSTALLATION AND WIRING 2.5 Main circuit terminals (for 6-phase rectification)
  • Page 46 Connect the cables that are passed through the protective bushes to terminals R/L1, S/L2, and T/L3. Connect the rear cables, then reinstall the bushes. Reinstall the lower wiring cover (inner), connect the front cables, then reinstall the bushes. R/L1 R/L1 S/L2 S/L2 T/L3...

  • Page 47: Recommended Cables

    Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm model screw torque Earthing Earthing R/L1, S/L2, T/ R/L1, S/L2, T/ FR-CC2M-H[] size (N·m) R/L1, S/L2, T/L3 P/+, N/- (grounding) (grounding) cable cable 250K M12 (M10) 47 (26.5) 4×60 2×125...

  • Page 48: Earthing (Grounding) Precautions

    2.5.4 Earthing (grounding) precautions • Always earth (ground) the converter unit.  Purpose of earthing (grounding) Generally, an electrical apparatus has an earth (ground) terminal, which must be connected to the ground before use. An electrical circuit is usually insulated by an insulating material and encased. However, it is impossible to manufacture an insulating material that can shut off a leakage current completely, and actually, a slight current flows into the case.

  • Page 49: Main Circuit Terminals (For 12-Phase Rectification)

    Main circuit terminals (for 12-phase rectification) 2.6.1 Details on the main circuit terminals Refer to Terminal symbol Terminal name Terminal function description page Connect these terminals to the output terminals in the wye connection R/L1, S/L2, T/L3 AC power input of a 12-phase transformer (3-winding transformer).

  • Page 50: Wiring Method

    R/L1, S/L2, and T/L3 of the converter unit. Likewise, connect the output terminals in the delta connection of the transformer with terminals R2/L12, S2/L22, and T2/L32 of the converter unit. <Example: FR-CC2M-H250K12P to H315K12P> To inverter Charge lamp...

  • Page 51: Recommended Cables

    Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm model screw torque R/L1, S/L2, Earthing R/L1, S/L2, R/L1, S/L2, Earthing FR-CC2M-H[]12P size (N·m) T/L3 P/+, N/- (grounding) T/L3 T/L3 (grounding) (per circuit) cable (per circuit) (per circuit) cable 250K M12 (M10) 47 (26.5)

  • Page 52: Earthing (Grounding) Precautions

     Recommended crimp terminals The following table shows recommended crimp terminals when using cables with size indicated in "Connecting cables" (page 50). Converter unit Crimp terminal model R/L1, S/L2, T/L3 P/+, N/- FR-CC2M-H[] 250K R80-12 R150-12 280K R80-12 R150-12 315K R100-12...

  • Page 53: Control Circuit

    • Earthing (grounding) must conform to the requirements of national and local safety regulations and electrical codes (NEC section 250, IEC 61140 class 1 and other applicable standards). A neutral-point earthed (grounded) power supply must be used to be compliant with EN standard. •...

  • Page 54: Output Signal

     Output signal Terminal Type Common Terminal name Terminal function description Rated specification symbol 1 changeover contact output that indicates that the protective function of the converter unit has been Contact capacity: 230 Relay output 1 (fault activated and the outputs are stopped. VAC 0.3 A —...

  • Page 55: Control Logic (Sink/Source) Change

    CAUTION • Do not use the empty terminals (NC) of the control circuit. Doing so may lead to damage of the converter unit and the inverter. • Always connect terminal RDA of the converter unit and terminal MRS (X10) of the inverter, and terminal SE of the converter unit and terminal SD (terminal PC in the source logic) of the inverter.
  • Page 56  Sink logic and source logic • In the sink logic, a signal turns ON when a current exits from the corresponding signal input terminal. Terminal SD is common to the contact input signals. Terminal SE is common to the open collector output signals. •...

  • Page 57: Wiring Of Control Circuit

    2.7.3 Wiring of control circuit  Control circuit terminal layout ∗1 ∗1 NC NC NC NC NC +24 SD NC NC NC NC PC NC NC NC SE SE IPF RSO FAN PC NC NC NC NC NC NC OH SD SD RDI NC NC For manufacturer setting.
  • Page 58 • NICHIFU Co., Ltd. Wire gauge Blade terminal part Crimping tool product Insulation cap part No. number 0.3 to 0.75 BT 0.75-11 VC 0.75 NH 69 Insert the wires into a socket. When using single wire or stranded wire without crimp terminal, push an open/close button all the way down with a flathead screw driver, and insert the wire.

  • Page 59: Signal Inputs By Contactless Switches

    • Terminal SE is a common terminal for the open collector output terminals (RDA, RDB, RSO, IPF, FAN). The contact input circuit is isolated from the internal control circuit by photocoupler.  Signal inputs by contactless switches The contact input terminals of the converter unit (RES, OH, RDI) can be controlled using a transistor instead of a contact switch as shown in the following figure.

  • Page 60: When Using Separate Power Supplies For The Control Circuit And The Main Circuit

    ＜Wiring example＞ Rubber bush （viewed from inside） Make cuts along the lines on the inside with a cutter knife 2.7.5 When using separate power supplies for the control circuit and the main circuit  Cable size for the control circuit power supply (terminals R1/L11 and S1/ L21) •...

  • Page 61: When Supplying 24 V External Power To The Control Circuit

    Connection diagram Converter unit R/L1 S/L2 T/L3 R1/L11 S1/L21 Remove the jumper Power supply terminal block for the control circuit Power supply terminal block for the control circuit R1/L11 S1/L21 (a) Remove the upper screws. (b) Remove the lower screws. (c) Pull the jumper toward you to remove.
  • Page 62  Specification of the applied 24 V external power supply Item Rated specification Input voltage 23 to 25.5 VDC Input current 1.4 A or less Commercially available products (as of April 2023) Model Product overview Manufacturer Specifications: Capacity 50 W, output voltage 24 VDC, output current 2.2 A Installation method: Direct installation, screw type terminal block with cover S8FS-G05024C Input: Single-phase 100 to 240 VAC...
  • Page 63 NOTE • Inrush current equal to or higher than the 24 V external power supply specification may flow at power-ON. Confirm that the power supply and other devices are not affected by the inrush current and the voltage drop caused by it. Depending on the power supply, the inrush current protection may be activated to disable the power supply.

  • Page 64: Communication Connectors And Terminals

    Communication connectors and terminals 2.8.1 PU connector  Mounting the operation panel on the enclosure surface • With a connection cable, you can mount the operation panel on the enclosure surface, and connect it to the converter unit. Use the option FR-CB2[], or connectors and cables available on the market. (To mount the operation panel, the optional connector (FR-ADP) is required.) Securely insert one end of the cable into the PU connector and the other end into the connection connector on the parameter unit or the FR-ADP attached on the operation panel until the stoppers are fixed.

  • Page 65: Terminal Block

    2.8.2 RS-485 terminal block  Communication operation Conforming EIA-485 (RS-485) standard Transmission Multidrop link format Communication Maximum 115200 bps speed Overall length 500 m Connection cable Twisted pair cable (4 pairs) The RS-485 terminals enable communication operation from a personal computer, etc. When the PU connector is used for connection between the converter unit and a personal, FA, or other computer with a communication cable, a user program can run to monitor the converter unit or read and write parameters.
  • Page 66 CHAPTER 3 PRECAUTIONS FOR USE OF THE CONVERTER UNIT Electro-magnetic interference (EMI) and leakage currents ..................66 Power supply harmonics............................72 Installation of a reactor ............................76 Power shutdown and magnetic contactor (MC)......................77 Checklist before starting operation .........................79...

  • Page 67: Electro-Magnetic Interference (Emi) And Leakage Currents

    PRECAUTIONS FOR USE OF THE CONVERTER UNIT This chapter explains the precautions for use of this product. Always read the instructions before use. Electro-magnetic interference (EMI) and leakage currents 3.1.1 Leakage currents and countermeasures Capacitance exists between the I/O cables or other cables of the inverter or the converter unit and earth, and in the motor, through which a leakage current flows.
  • Page 68  Installation and selection of the molded case circuit breaker Install a molded case circuit breaker (MCCB) on the power receiving side to protect the wiring at the input side of the inverter or the converter unit. Select an MCCB according to the inverter input side power factor, which depends on the power supply voltage, output frequency and load.

  • Page 69: Techniques And Measures For Electromagnetic Compatibility (Emc)

    • Leakage currents of the inverter and the converter unit with a 6-phase transformer 400 V class (input power condition: 440 V/60 Hz, power supply imbalance within 3%) Inverter / FR-A802M (Separated FR-A800 (Standard model) Converter unit FR-CC2M converter unit converter type) EMC filter —...
  • Page 70  EMS measures to reduce electromagnetic noises that enter the inverter or the converter unit and cause it to malfunction When devices that generate many electromagnetic noises (which use magnetic contactors, electromagnetic brakes, many relays, for example) are installed near the inverter or the converter and it may malfunction due to electromagnetic noises, the following measures must be taken: •...

  • Page 71: Built-In Emc Filter

    Noise propagation Countermeasure path When a closed loop circuit is formed by connecting the peripheral device wiring to the inverter or the converter unit, leakage currents may flow through the earthing (grounding) cable of the inverter or the converter unit to cause the device to malfunction.
  • Page 72 To enable the EMC filter, fit both of the EMC filter ON/OFF connectors to the "enabled" (ON) position. EMC filter ON/OFF connector OFF ON OFF ON EMC filter OFF EMC filter ON  How to enable or disable the filter •...

  • Page 73: Power Supply Harmonics

    (FR-HAL) factor improving capacitor. unit The converter unit (FR-CC2M) has a built-in DC reactor. NOTE • The power factor improving capacitor and surge suppressor on the inverter output side may be overheated or damaged by the harmonic components of the inverter output. Also, since an excessive current flows in the inverter to activate overcurrent protection, do not provide a capacitor and surge suppressor on the inverter output side when the motor is driven by the inverter.
  • Page 74 All capacity and all models of general-purpose inverter used by specific consumers are now covered by "the Harmonic Suppression Guidelines for Consumers Who Receive High Voltage or Special High Voltage" (hereinafter referred to as "the Specific Consumer Guidelines"). • "Specific Consumer Guidelines" This guideline sets forth the maximum harmonic currents outgoing from a high-voltage or especially high-voltage receiving consumer who will install, add or renew harmonic generating equipment.
  • Page 75  Harmonic contents for 12-phase rectification (values of the fundamental current are 100%) Reactor 11th 13th 17th 19th 23rd 25th Used (DC side)  Calculation of equivalent capacity P0 of harmonic generating equipment "Equivalent capacity" is the capacity of a 6-pulse converter converted from the capacity of consumer's harmonic generating equipment and is calculated by the following equation.
  • Page 76  Harmonic suppression techniques Item Description With the DC reactor equipped on its DC side, the converter unit can suppress the outgoing harmonic current. Reactor installation (FR-HAL) Install an AC reactor (FR-HAL) on the AC side of the inverter to further suppress outgoing harmonic currents. This converter trims the current waveform to be a sine waveform by switching the rectifier circuit (converter High power factor converter module) with transistors.

  • Page 77: Installation Of A Reactor

    Installation of a reactor When the inverter is connected near a large-capacity power transformer (1000 kVA or more) or when a power factor correction capacitor is to be switched over, an excessive peak current may flow in the power input circuit, damaging the converter circuit. To prevent this, always install an AC reactor (FR-HAL), which is available as an option.

  • Page 78: Power Shutdown And Magnetic Contactor (Mc)

    Power shutdown and magnetic contactor (MC)  Converter unit input side magnetic contactor (MC) On the converter unit input side, it is recommended to provide an MC for the following purposes. (Refer to page 20 for selection.) • To disconnect the inverter from the power supply at activation of a protective function or at malfunctioning of the driving system (emergency stop, etc.).
  • Page 79 NOTE • Before wiring or inspection for a PM motor, confirm that the PM motor is stopped. In an application, such as fan and blower, where the motor is driven by the load, a low-voltage manual contactor must be connected at the inverter's output side, and wiring and inspection must be performed while the contactor is open.

  • Page 80: Checklist Before Starting Operation

    Checklist before starting operation This product is a highly reliable product, but incorrect peripheral circuit making or operation/handling method may shorten the product life or damage the product. Before starting operation, always recheck the following points. Refer to Check by Checkpoint Countermeasure page...
  • Page 81 MEMO 3. PRECAUTIONS FOR USE OF THE CONVERTER UNIT 3.5 Checklist before starting operation...

  • Page 82: Chapter 4 Basic Operation

    CHAPTER 4 BASIC OPERATION Operation panel ..............................82 Monitoring the converter unit status........................86...

  • Page 83: Operation Panel

    BASIC OPERATION Operation panel This chapter explains the basic operation of this product. Always read the instructions before use. 4.1.1 Components of the operation panel Install the operation panel of the inverter on the converter unit. To mount the operation panel on the enclosure surface, refer to page Appearance Name...

  • Page 84: Basic Operation Of The Operation Panel

    Appearance Name Description Confirms each selection. When this key is pressed during operation, the monitor item changes. (The monitor item on each screen can be changed according to the settings of Pr.774 to Pr.776.) SET key When the initial setting is set Converter Input Electric thermal relay...

  • Page 85: Parameter Setting Mode

     Parameter setting mode In the parameter setting mode, converter unit functions (parameters) are set. The following table explains the indications in the parameter setting mode. Refer Operation panel indication Function name Description page Under this mode, the set value of the displayed parameter number is read Parameter setting mode or changed.

  • Page 86: Changing The Parameter Setting Value

    4.1.4 Changing the parameter setting value The following shows the procedure to change the setting of Pr.774 Operation panel monitor selection 1. Operating procedure Turning ON the power of the converter unit The operation panel is in the monitor mode. Selecting the parameter setting mode Press to choose the parameter setting mode.

  • Page 87: Monitoring The Converter Unit Status

    Monitoring the converter unit status 4.2.1 Monitoring of converter output voltage and input current • Press on the operation panel in the monitor mode to switch the monitor item between converter output voltage, input current, and electronic thermal relay function load factor. Operating procedure Press to monitor the converter output voltage.

  • Page 88: Chapter 5 Parameters

    CHAPTER 5 PARAMETERS Parameter List ................................88 (E) Environment setting parameters ........................94 (H) Protective function parameter.........................103 (M) Item and output signal for monitoring ......................110 (T) Multi-function input terminal parameters ......................118 (A) Application parameters ...........................120 (N) Communication operation parameters......................124 Parameter clear / All parameter clear ........................155 Parameter copy and parameter verification......................156 5.10 Checking parameters changed from their initial values (initial value change list)..........159...

  • Page 89: Parameter List

    PARAMETERS This chapter explains the function setting for use of this product. Always read the instructions before use. Parameter List 5.1.1 Parameter list (by parameter number) Set the necessary parameters to meet the load and operational specifications. Parameter setting, change, and check can be made on the operation panel.
  • Page 90 Minimum Initial Refer to Customer Name Setting range setting group value page setting increments T700 RDI terminal function selection 9999 T709 OH terminal function selection 7, 62, 84, 9999 T711 RES terminal function selection M400 RDB terminal function selection 2, 8, 11, 17, 25, 26, 64 to 66, 68, 90, 94, 95, 98, 99, M401 RDA terminal function selection...

  • Page 91: The Function Group Number Is Used For The Identification Of Parameters, And Displayed In Alphanumeric Order

    Minimum Initial Refer to Customer Name Setting range setting group value page setting increments Maintenance timer 2 warning E713 0 to 9998, 9999 9999 output set time E714 Maintenance timer 3 0 (1 to 9998) Maintenance timer 3 warning E715 0 to 9998, 9999 9999 output set time...
  • Page 92 Selecting the parameter Turn until " " (Group parameter setting) appears. Press to confirm the selection. The setting " " (initial value) will appear. Selecting the use of the function group number Turn to change the set value to " "...

  • Page 93: Parameter List (By Function Group Number)

    5.1.3 Parameter list (by function group number)  E: Environment setting Refer Pr. group Name to page parameters Emergency drive dedicated H322 retry count Parameters for the converter unit operating environment. Emergency drive dedicated H324 Refer retry waiting time Pr. group Name to page E000...

  • Page 94: A: Application Parameters

     A: Application parameters Parameters for the setting of a specific application. Refer Name group to page A006 Self power management selection A702 Restart selection A730 Power failure stop selection  N: Communication operation parameters Parameters for the setting of communication operation such communication specifications operating...

  • Page 95: E) Environment Setting Parameters

    (E) Environment setting parameters Refer to Purpose Parameter to set page To set the time Simple clock function P.E020 to P.E022 Pr.1006 to Pr.1008 To set a limit for the reset function. Reset selection / P.E100, P.E101, To shut off output if the operation panel disconnected PU detection Pr.75 P.E107...

  • Page 96: Reset Selection / Disconnected Pu Detection / Reset Limit

    5.2.2 Reset selection / disconnected PU detection / reset limit The acceptance of reset command, the operation in the event of detection of the operation panel disconnected, and the reset limit function can be selected. Initial Name Setting range Description value Reset selection/ In the initial setting, the reset command input is always enabled,...

  • Page 97: Buzzer Control

    NOTE • Resetting the converter unit power (turning OFF the control circuit power) clears the accumulated thermal value. • When the retry function is set enabled (Pr.67 Number of retries at fault occurrence ≠ "0"), the reset limit function is disabled. CAUTION •...

  • Page 98: Parameter Write Selection

    • To enable the setting dial and key operation again, press for 2 seconds. NOTE • Even if setting dial and key operations are disabled, the monitor indicator and are enabled. 5.2.6 Parameter write selection Whether or not to enable the writing to various parameters can be selected. Use this function to prevent parameter values from being rewritten by misoperation.
  • Page 99 ○: Enabled, ×: Disabled If the parameter writing is restricted by the Pr.77 Parameter write selection setting, those parameters are unavailable for writing even when "○" is indicated.  Locking parameters with a password (Pr.296, Pr.297) • The procedure of locking parameters with a password is as follows. Set the parameter reading/writing restriction level to enable the password protection.

  • Page 100: Free Parameter

    NOTE • When a password has been set and parameters are locked, Parameter copy cannot be performed using the operation panel. Parameters referred to Pr.77 Parameter write selectionpage 97 5.2.8 Free parameter Any number within the setting range of 0 to 9999 can be input. For example, these numbers can be used: •...
  • Page 101  Life alarm display and signal output (Y90 signal, Pr.255) • Whether or not the parts of the control circuit capacitor, cooling fan, inrush current limit circuit, or internal air circulation fan have reached the life alarm output level can be checked with Pr.255 Life alarm status display and the Life alarm (Y90) signal.

  • Page 102: 5.2.10 Maintenance Timer Alarm

    • Changing the terminal assignment using Pr.190 to Pr.195 (Output terminal function selection) may affect the other functions. Set parameters after confirming the function of each terminal. • For replacement of each part, contact the nearest Mitsubishi Electric FA center.  Life display of internal air circulation fans •...
  • Page 103 First power 9998 Set "0" in Pr.503 (999800h) Maintenance timer 1 Pr.504 (Pr.503) Time Y95 signal MT1 display Operation example of the maintenance timer 1 (Pr.503, Pr.504) (with both MT2 and MT3 OFF) • The cumulative energization time of the converter unit is stored in the EEPROM every hour and displayed in Pr.503 (Pr.686, Pr.688) in 100 hours increments.

  • Page 104: H) Protective Function Parameter

    (H) Protective function parameter Purpose Parameter to set Refer to page To vary the operating level of the Undervoltage level P.H102 Pr.598 undervoltage protective function To initiate an inverter protective Fault initiation P.H103 Pr.997 function To disable the input phase loss Input phase loss protection P.H201 Pr.872...

  • Page 105: Input Phase Loss Protection Selection

    5.3.3 Input phase loss protection selection The input phase loss protective function on the converter unit input side (R/L1, S/L2, T/L3) can be enabled. The IPL (Input phase loss) signal can be output when the power input phase loss is detected. Name Initial value Setting range...
  • Page 106  Retry count check (Pr.69) • Reading the Pr.69 value provides the cumulative number of successful restart times made by retries. The cumulative count in Pr.69 increases by 1 when a retry is successful. Retry is regarded as successful when normal operation continues without a fault for the Pr.68 setting multiplied by four or longer (3.1 seconds at the shortest).

  • Page 107: Emergency Drive (Fire Mode)

    5.3.5 Emergency drive (Fire mode) The converter unit can continue driving the motor in case of emergency such as a fire, since protective functions are not activated even if the converter unit detects a fault. Using this function may damage the motor, the converter unit, or the inverter because driving the motor is given the highest priority.
  • Page 108 NOTE • Settings in the inverter is also required to enable the emergency drive function.  Emergency drive execution sequence • When the X84 signal is ON for three seconds, the emergency drive is activated. • The Y65 signal turns ON during emergency drive operation. •...
  • Page 109 • Writing "0" in Pr.69 clears the cumulative count. Retry success Pr.514×4 Pr.514 Pr.514 Pr.514 Pr.514 (If it is below 3.1s, 3.1s is set.) RDA ON Time Time Second Third First Retry start Success count + 1 retry retry retry Retry failure Fault occurrence (E.RET)
  • Page 110  Emergency drive status monitor • Set "68" in Pr.774 to Pr.776 or Pr.992 to monitor the status of the emergency drive on the operation panel. • Description of the status monitor Operation Description panel Emergency drive setting Emergency drive operating status indication Emergency drive function —...

  • Page 111: M) Item And Output Signal For Monitoring

    (M) Item and output signal for monitoring Purpose Parameter to set Refer to page Operation panel monitor item Pr.170, Pr.268, P.M020 to P.M023, To change the item monitored on the selection, clearing the Pr.290, Pr.563, P.M044, P.M100 to operation panel cumulative value during Pr.774 to Pr.776, P.M104...
  • Page 112 Negative Increment MODBUS Monitor item RS-485 indication Description and unit setting The converter unit input current effective value is *2*3*6 0.1 A 40202 Input current displayed. Converter output 0.1 V 40208 The DC bus voltage value is displayed. voltage Input power 0.1 kW 40213 The power at the converter unit input side is displayed.
  • Page 113  Monitor display for operation panel (Pr.774 to Pr.776) • The monitor displayed at power ON is the first monitor (the converter output voltage monitor in the initial setting). Display the monitor you want to display on the first monitor and hold down for 1 second.
  • Page 114 • Writing "0" in Pr.170 clears the cumulative power monitor. NOTE • When Pr.170 is read just after "0" has been written in Pr.170, the setting "9999" or "10" is displayed.  Monitoring cumulative energization time (Pr.563) • Cumulative energization time monitoring (Pr.774 to Pr.776 = "20") accumulates energization time from shipment of the converter unit every hour.

  • Page 115: Output Terminal Function Selection

    5.4.2 Output terminal function selection Use the following parameters to change the functions of the open collector output terminals and relay output terminals. Initial Name Signal name Setting range value RDB terminal RDB (Inverter operation M400 function selection enable (NC contact)) RDA terminal RDA (Inverter operation M401...
  • Page 116 Setting Refer Signal Related Function Operation Positive Negative name parameter page logic logic Output when the value of Pr.503 reaches the Maintenance timer Pr.503, Pr.504 Pr.504 setting or higher. Output when an alarm (fan alarm, internal fan 116, Alarm alarm, or communication error warning) Pr.121 138, occurs.
  • Page 117  Fan fault output signal (FAN) • A cooling fan operates at power ON of the converter unit. If the fan stops at this time, fan operation is regarded as faulty, Fan alarm (FN) or Internal fan alarm (FN2) is displayed on the operation panel, and the FAN fault output (FAN) and Alarm (LF) signals are output.

  • Page 118: Detection Of Control Circuit Temperature

     Fault signal (ALM/ALM2) • A Fault (ALM/ALM2) signal is output when the converter unit protective function is activated. • The ALM2 signal stays ON during the resetting the product after the Fault occurs. • To use the ALM2 signal, set "94" (positive logic) or "194" (negative logic) in any parameter from Pr.190 to Pr.195 (Output terminal function selection) to assign the function to an output terminal.

  • Page 119: T) Multi-Function Input Terminal Parameters

    (T) Multi-function input terminal parameters Refer to Purpose Parameter to set page Input terminal function P.T700, P.T709, Pr.178, Pr.187, To assign functions to input terminals selection P.T711 Pr.189 To change operation when the OH signal OH input selection P.T723 Pr.876 is input 5.5.1 Input terminal function selection...
  • Page 120  External thermal relay (OH signal, E.OHT) Thermal relay protector Motor Inverter Converter unit External thermal relay input connection diagram • The External thermal relay input (OH) signal is used when using the external thermal relay or the thermal protector built into the motor to protect the motor from overheating.

  • Page 121: Application Parameters

    (A) Application parameters Refer to Purpose Parameter to set page To reduce the standby power Self power management P.A006, P.E300 Pr.30, Pr.248 To restart after instantaneous power Automatic restart after P.A702 Pr.57 failure instantaneous power failure Power failure time To decelerate the motor to a stop at deceleration-to-stop P.A730 Pr.261...
  • Page 122  Operation of the self power management function • This function controls the magnetic contactor (MC) on the input side using the output relay to reduce the standby power. Use separate power supplies for the main circuit and the control circuit by using terminals R1/L11 or S1/L21 (refer to page 59) and 24 V external power supply input (refer to page...

  • Page 123: Operation Selection At Instantaneous Power Failure

    5.6.2 Operation selection at instantaneous power failure When an instantaneous power failure occurs, the converter unit can restart at the power restoration. Initial Setting Name Description value range The converter restarts operation at the power restoration from instantaneous power failure. Restart selection 9999 A702...
  • Page 124  Connection and parameter setting Keep the jumpers between terminals R1/L11 and S1/L21 connected. Converter unit Inverter R/L1 Power supply S/L2 T/L3 Remove the jumper R1/L11 R1/L11 S1/L21 S1/L21 Connect terminals R1/L11 and P/+ MRS(X10) and terminals S1/L21 and N/-. •...

  • Page 125: N) Communication Operation Parameters

    (N) Communication operation parameters Refer Purpose Parameter to set page To start operation via Initial setting of operation via P.N000, P.N001 Pr.549, Pr.342 communication communication Initial setting of computer link To communicate via PU connector P.N020 to P.N028 Pr.117 to Pr.124 communication (PU connector) Initial setting of computer link Pr.331 to Pr.337,...
  • Page 126  Wiring and configuration of PU connector communication system • System configuration Station 0 Station 0 Converter Computer Converter Converter Computer unit unit unit RS-232C Operation FR-DU08 connector panel RS-232C RS-485 connector Maximum connector connector cable interface/ connector 15 m FR-ADP terminals RS-232C-RS-485...

  • Page 127: Wiring And Configuration Of Rs-485 Terminals

    5.7.2 Wiring and configuration of RS-485 terminals  RS-485 terminal layout Terminating resistor switch Initially-set to "OPEN". Set only the terminating resistor switch of the remotest converter unit to the "100 Ω" position. SDA1 SDB1 RDA1 RDB1 (VCC) (GND) (TXD1+) (TXD1-) (RXD1+) (RXD1-)
  • Page 128 • Combination of a computer and multiple converter units (1:n) Station 0 Station 1 Station n Computer Converter Converter Converter unit unit unit RS-485 RS-485 RS-485 RS-485 terminals terminals terminals interface terminals ∗ ∗ ∗ ∗Set only the terminating resistor switch of the remotest converter unit to the "100 Ω"...
  • Page 129 NOTE • For branching, connect the wires as shown in the following table. TXD RXD TXD RXD To computer ground To computer receive To receiving terminal To computer send of the next converter unit To sending terminal of the next converter unit To next converter unit To earth (ground) terminal...

  • Page 130: Initial Setting Of Operation Via Communication

    5.7.3 Initial setting of operation via communication Set the action when the converter unit is performing operation via communication. • Set the RS-485 communication protocol. (Mitsubishi inverter protocol / MODBUS RTU protocol) • Set the action at fault occurrence or at writing of parameters. Setting Name Initial value...

  • Page 131: Initial Settings And Specifications Of Rs-485 Communication

    5.7.4 Initial settings and specifications of RS-485 communication Use the following parameters to perform required settings for RS-485 communication between the converter unit and a personal computer. • Use the PU connector on the converter unit or RS-485 terminals as communication interface. •...
  • Page 132  Parameters related to RS-485 terminal communication Initial Setting Name Description value range 0 to 31 (0 to RS-485 communication Specify the converter unit station number. *1*2 N030 station number (Same specifications as Pr.117) 247) 3, 6, 12, 24, RS-485 communication 48, 96, 192, Select the communication speed.

  • Page 133: Mitsubishi Inverter Protocol (Computer Link Communication)

    5.7.5 Mitsubishi inverter protocol (computer link communication) Parameter setting and monitoring, etc. are possible through communication using the Mitsubishi inverter protocol (computer link communication) via the PU connector or RS-485 terminals on the converter unit.  Communication specifications • The communication specifications are shown in the following table. Related Item Description...
  • Page 134 • Communication operation presence/absence (with/without) and data format type (A to F) are as follows. Special Parameter Converter Parameter Symbol Operation monitor Monitor write reset read write Communication request is sent to the converter unit in accordance with the user program in the computer. Converter unit data processing time With With...

  • Page 135: Data Definitions

    c. Reply data from the converter unit to the computer (No data error detected) Number of characters Format Converter unit Read data Sum check station number Converter unit Read data Sum check station number Converter unit Read data (model information / capacity) Sum check station number Number of characters...
  • Page 136 Specify the delay time (time period between the time when the converter unit receives data from the computer and the time when the converter unit starts transmission of reply data). Set the time delay in accordance with the response time of the computer in the range of 0 to 150 ms in 10 ms increments.
  • Page 137 • Sum check code The sum check code is a 2-digit ASCII (hexadecimal) representing the lower 1 byte (8 bits) of the sum derived from the checked ASCII data. (Example 1) Instruction Station Data check code Computer Converter unit number code Binary code ASCII Code...

  • Page 138: Response Time

     Response time Data sending time (refer to the following formula) Waiting time Data check time Converter unit data processing time Computer (setting 10 ms) (depends on the instruction code ∗3) Converter unit Time Converter unit 10 ms or more necessary Computer Data sending time (refer to the following formula) [Formula for data transmission time]...
  • Page 139  Retry count setting (Pr.121, Pr.335) • Set the permissible number of retries at data receive error occurrence. (Refer to page 136 for data receive error for retry.) • When the data receive errors occur consecutively and the number of retries exceeds the permissible number setting, a communication fault (PU connector communication: E.PUE, RS-485 terminal communication: E.SER) occurs and the inverter output is shut off.

  • Page 140: Programming Instructions

     Programming instructions • When data from the computer has any error, the converter unit does not accept that data. Hence, in the user program, always insert a retry program for data error. • All data communication (for example, monitoring) is started when the computer gives a communication request. The converter unit does not return any data without the computer's request.
  • Page 141 General flowchart Port open Communication setting Time out setting Send data processing ○Data setting ○Sum code calculation ○Data transmission Receive data waiting Receive data processing ○Receive data processing ○Screen display CAUTION • Always set the communication check time interval before starting operation to prevent hazardous conditions. •...
  • Page 142  Setting items and set data • After completion of parameter settings, set the instruction codes and data, then start communication from the computer to allow reading/writing of parameters and monitoring. Number of data Read/ Instruction Item Data description digits write code (format)
  • Page 143 20 digits (B and E3/ Model Read Example) For "FR-CC2M-H": H46, H52, H2D, H43, H43, H32, H4D, H2D, H48, H20, H20...H20 The capacity in the converter model can be read in ASCII code. Data read is displayed in increments of 0.1 kW.

  • Page 144: Modbus Rtu Communication Specification

     Converter status monitor Instruction Item Description Example code length b0: RDB (Inverter operation enable (NC contact)) [Example 1] H01...Inverter operation b1: Fixed to 0 enable signal (NC contact) ON b2: Fixed to 0 Converter b3: RDA (Inverter operation enable status 8 bits (NO contact))
  • Page 145 NOTE • To use the MODBUS RTU protocol, set "1" in Pr.549 Protocol selection. • If MODBUS RTU communication is performed from the master to the address 0 (station number 0), the data is broadcasted, and the converter unit does not send any reply to the master. To obtain replies from the converter unit, set Pr.331 RS-485 communication station number ≠...

  • Page 146: Message Format

     Message format Converter unit response time Query communication (Refer to the following table for the data check time) Programmable controller Query Message (Master) Converter unit (slave) Response Message Data absence time (3.5 bytes or more) Broadcast communication Query Message Programmable controller (Master) No Response...

  • Page 147: Function Code List

    • Details of protocol The following table explains the four message fields. Start Address Function Data CRC check 8 bits 8 bits n × 8 bits 8 bits 8 bits Message field Description "0 to 247" can be set in the single-byte (8-bit) length field. Set "0" when sending broadcast messages (instructions to all addresses), and "1 to 247"...
  • Page 148 • Normal response (Response message) a. Slave address b. Function e. Byte count f. Data CRC check (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (n × 16 bits) (8 bits) (8 bits) • Query message setting Message Description Set the address to send messages to.
  • Page 149 • Content of normal response The contents in the normal response (a to d, including the CRC check) are the same as those in the query messages. In the case of broadcast communication, no response is returned.  Example) Write 114 (H0072) to 41075 (Pr.75) of slave address 5 (H05). Query message Slave address Function...
  • Page 150 • Normal response (Response message) a. Slave address b. Function c. Starting address d. No. of registers CRC check (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) (8 bits) • Query message setting Message Description Slave address Set the address to send messages to.

  • Page 151: Error Response

    • Content of normal response Message Description The start address of the holding register that was successfully accessed is returned. Starting address = start register address (decimal) - 40001 Starting address For example, when starting address 0001 is returned, the holding register address that was successfully accessed is 40002.

  • Page 152: Modbus Register

    Error check items Error item Error description Converter unit operation The data received by the converter unit has different Parity error parity from the specified one (Pr.334 setting). The data received by the converter unit has a different Framing error stop bit length from the specified one (Pr.334 setting).
  • Page 153 Model (7th and 8th characters) Read "H20" (blank code) is set for blank area. 44005 Model (9th and 10th characters) Read Example) For "FR-CC2M-H": 44006 Model (11th and 12th characters) Read H46, H52, H2D, H43, H43, H32, H4D, H2D, H48, H20, 44007...
  • Page 154  Alarm (LF) signal output (communication error warning) • During a communication error, the Alarm (LF) signal is output by open collector output. Assign the terminal to be used using any parameter from Pr.190 to Pr.195 (Output terminal function selection). Master Alarm data Alarm data...
  • Page 155 • The communication check time by query communication includes a no-data time (3.5 bytes). This no-data time differs according to the communication speed, so take this no-data time into consideration when setting the communication check time. Example: RS-485 terminal communication, Pr. 539 = "0.1 to 999.8s" Query communication Query Message1 Query Message2...

  • Page 156: Parameter Clear / All Parameter Clear

    Parameter clear / All parameter clear • Set "1" to Pr.CLR Parameter clear or ALL.CL All parameter clear to initialize all parameters. (Parameters cannot be cleared when Pr.77 Parameter write selection = "1".) • Terminal function selection parameters are not cleared even after Parameter clear has been performed. •...

  • Page 157: Parameter Copy And Parameter Verification

    Parameter copy and parameter verification Pr.CPY setting value Description 0.--- Initial display 1.RD Copy the source parameters to the operation panel. 2.WR The parameters copied to the operation panel can be also copied to the destination converter units. 3.VFY Verify parameters in the converter unit and those in the operation panel. (Refer to page 158.) NOTE...

  • Page 158: Converter Unit

     Copying parameter settings stored in the operation panel to the converter unit Operating procedure Connect the operation panel to the destination converter unit. Selecting the parameter setting mode Press to choose the parameter setting mode. (The parameter number read previously appears.) Selecting the parameter number Turn to "...

  • Page 159: Parameter Verification

    5.9.2 Parameter verification • Whether the parameter settings of converter units are the same or not can be checked. Operating procedure Copy the parameter settings of the verification source converter unit to the operation panel according to the procedure on page 156.

  • Page 160: Checking Parameters Changed From Their Initial Values (Initial Value Change List)

    5.10 Checking parameters changed from their initial values (initial value change list) Parameters changed from their initial values can be displayed. Operating procedure Turning ON the power of the converter unit The operation panel is in the monitor mode. Selecting the parameter setting mode Press to choose the parameter setting mode.
  • Page 161 MEMO 5. PARAMETERS 5.10 Checking parameters changed from their initial values (initial value change list)

  • Page 162: Chapter 6 Protective Functions

    CHAPTER 6 PROTECTIVE FUNCTIONS Converter unit fault and alarm indications ......................162 Reset method for the protective functions ......................163 Check and clear of the fault history ........................164 Fault history and the list of fault displays ......................166 Causes and corrective actions..........................168 Check first when you have a trouble........................175...

  • Page 163: Converter Unit Fault And Alarm Indications

    PROTECTIVE FUNCTIONS This chapter explains the "PROTECTIVE FUNCTIONS" that operate in this product. Always read the instructions before use. Converter unit fault and alarm indications • When the converter unit detects a fault, the operation panel displays an indication such as error message or warning, or a protective function activates to shut off the inverter output in accordance with the fault.

  • Page 164: Reset Method For The Protective Functions

    Reset method for the protective functions Reset the converter unit by performing any of the following operations. Note that the accumulated heat value of the electronic thermal relay function and the number of retries are cleared (erased) by resetting the converter unit. The converter unit recovers about 1 second after the reset is released.

  • Page 165: Check And Clear Of The Fault History

    Check and clear of the fault history The operation panel stores the past eight fault records which appears when a protective function is activated (fault history).  Check for the fault history Monitor mode Parameter setting mode Fault history mode [Operation for displaying fault history] The last eight fault records can be displayed.
  • Page 166  Fault history clearing procedure • Set Err.CL Fault history clear = "1" to clear the fault history. Operating procedure Turning ON the power The operation panel is in the monitor mode. Selecting the parameter setting mode Press to choose the parameter setting mode. (The parameter number read previously appears.) Selecting the parameter number Turn until...

  • Page 167: Error Message

    Fault history and the list of fault displays If the displayed message does not correspond to any of the Operation panel Data Refer following or if you have any other problem, contact your sales Name indication code to page representative. Overvoltage trip (H20) ...
  • Page 168  Others • The fault history and the operation status of the converter unit are displayed. It is not a fault. Operation panel Refer Name indication to page Fault history No fault history 24 V external power supply operation If faults other than the above appear, contact your sales representative.

  • Page 169: Causes And Corrective Actions

    Causes and corrective actions  Error message A message regarding operational troubles is displayed. The inverter output is not shut off. Operation panel HOLD indication Name Operation panel lock Description Operation lock is set. Operation other than is invalid. (Refer to page 96.) Check point...
  • Page 170 Operation panel indication Name Product series error • The series of the source converter unit used to copy or verify parameters is not the same as the target converter unit. Description • The operation panel data was incorrect when attempting to verify parameters or copy parameters from the operation panel to the converter unit.
  • Page 171  Alarm Output is not shut off when a protective function is activated. The Alarm (LF) signal can be output depending on the parameter setting. (Set "98" in Pr.190 to Pr.195 (Output terminal function selection). Refer to page 114.) Operation panel indication Name Fan alarm...
  • Page 172 Operation panel E.FAN indication Name Cooling fan fault Appears when the internal air circulation fan in the converter unit stops due to a fault or slows down to the fault Description level. • Check that the internal air circulation fan is not stopped. Check point •...
  • Page 173 Operation panel E.OHT indication Name External thermal relay operation While "1" (NC contact) or "2" (NO contact) is set in Pr.876 OH input selection to enable the function, the inverter output is shut off if output of the device such as a thermostat is input as the OH signal, and the OH signal turns Description ON (NO contact input) or turns OFF (NC contact input).
  • Page 174 E.CPU E. 5 Operation panel indication E. 6 E. 7 Name CPU fault Description The inverter trips if the communication fault of the built-in CPU occurs. Check point Check for devices producing excess electrical noises around the converter unit. • Take measures against noise if there are devices producing excess electrical noises around the converter unit. Corrective action •...
  • Page 175 E.PBT Operation panel indication E.13 Name Internal circuit fault Description The inverter output is shut off when an internal circuit fault occurs in the converter unit. Corrective action Contact your sales representative. Operation panel indication Name Option fault Description The inverter output is shut off if a plug-in option is disconnected while the converter unit power is ON. •...

  • Page 176: Check First When You Have A Trouble

    Check first when you have a trouble • If the cause is still unknown after every check, it is recommended to initialize the parameters, set the required parameter values and check again. 6.6.1 The converter does not operate properly. Check Refer to Possible cause Countermeasure...

  • Page 177: The Inverter Does Not Run

    6.6.5 The inverter does not run. Refer to Check point Possible cause Countermeasure page Terminals RDA and SE of the converter unit are not connected to terminals MRS Control circuit Check for secure wiring and installation. (X10 signal) and SD of the inverter respectively.

  • Page 178: Chapter 7 Precautions For Maintenance And Inspection

    CHAPTER 7 PRECAUTIONS FOR MAINTENANCE AND INSPECTION Inspection item..............................178 Measurement of main circuit voltages, currents, and powers................189...

  • Page 179: Inspection Item

    PRECAUTIONS FOR MAINTENANCE AND INSPECTION This chapter explains the precautions for maintenance and inspection of this product. Always read the instructions before use. Inspection item The converter unit is a static unit mainly consisting of semiconductor devices. Daily inspection must be performed to prevent any fault from occurring due to the adverse effects of the operating environment, such as temperature, humidity, dust, dirt and vibration, changes in the parts with time, service life, and other factors.

  • Page 180: Checking The Converter Semiconductor Devices

    Inspection Check Area of Inspection Corrective action at fault interval Description inspection item occurrence user Daily Periodic • Check with megger (between main circuit ○ Contact the manufacturer. terminals and earth (ground) terminal). • Check for loose screws and bolts. ○...

  • Page 181: Checking Method

     Checking method Change the polarity of the tester alternately at the converter unit terminals R/L1, S/L2, T/L3, P/+, and N/- and check the electric continuity. NOTE • Before measurement, check that the smoothing capacitor is discharged. • At the time of electric discontinuity, the measured value is almost ∞. When there is an instantaneous electric continuity, due to the smoothing capacitor, the tester may not indicate ∞.
  • Page 182  Removal of the internal air circulation fan • FR-CC2M-H250K to FR-CC2M-H315K Remove the screws attaching the upper main circuit terminal cover (top), and remove the cover. Remove the upper main circuit terminal cover (inner).
  • Page 183 Disconnect the fan connector, and remove the fan bracket together with the internal air circulation fan. Remove the internal air circulation fan from the fan bracket. Fan connector Fan bracket 7. PRECAUTIONS FOR MAINTENANCE AND INSPECTION 7.1 Inspection item...
  • Page 184 • FR-CC2M-H355K to FR-CC2M-H560K Remove the screws attaching the upper main circuit terminal cover (top), and remove the cover. Remove the upper main circuit terminal cover (inner). Upper main circuit terminal cover (inner) Upper main circuit terminal cover (top) 7. PRECAUTIONS FOR MAINTENANCE AND INSPECTION...
  • Page 185 Disconnect the fan connectors, and remove the fan bracket together with the internal air circulation fan. Remove the internal air circulation fan from the fan bracket. Fan connector Fan bracket 7. PRECAUTIONS FOR MAINTENANCE AND INSPECTION 7.1 Inspection item...
  • Page 186  Removal of the cooling fan Remove the screws fixing the bracket, and remove the bracket. Disconnect the fan connector, remove the screws holding the fan block in place, then remove the fan block itself. Remove the fan fixing screws, and remove the fan. Fan connector Fan block Fan connector...

  • Page 187: Smoothing Capacitors

    NOTE • Installing the fan in the opposite direction of air flow may shorten the converter unit life. • Ensure that the cables are not caught when the fan is installed. • Switch OFF the power before starting the fan replacement work. Before starting the replacement, power OFF the converter unit, wait for at least 10 minutes, and then check that the charge lamp is OFF to prevent an electric shock accident as the converter unit circuits are charged with voltage even after power OFF.

  • Page 188: Removal And Reinstallation Of The Control Circuit Terminal Block

    7.1.7 Removal and reinstallation of the control circuit terminal block This product has a removable control circuit terminal block, which can be replaced with a new one.  Removal and reinstallation Loosen the two installation screws at the both sides of the control circuit terminal block. (These screws cannot be removed.) Slide down the control circuit terminal block to remove it.
  • Page 189 NOTE • Do not tilt the terminal block while tightening the screws or removing it from the product. (Otherwise, stress applied to the control circuit terminal block or the control circuit connector may damage the pins.) • After replacing the control circuit terminal block, connect the jumper connector to the correct position in accordance with the control logic of input signals.

  • Page 190: Measurement Of Main Circuit Voltages, Currents, And Powers

    Measurement of main circuit voltages, currents, and powers Since the voltages and currents on the converter unit power supply and output sides include harmonics, measurement data depends on the instruments used and circuits measured. When instruments for commercial frequency are used for measurement, measure the following circuits with the instruments given on the next page.

  • Page 191: Measurement Of Powers

    7.2.1 Measurement of powers Use a digital power meter (for inverter) for the input side of the converter unit. 7.2.2 Measurement of voltages Use a digital power meter (for inverter) for the input side of the converter unit. 7.2.3 Measurement of currents Use a digital power meter (for inverter) for the input side of the converter unit.

  • Page 192: Chapter 8 Specifications

    CHAPTER 8 SPECIFICATIONS Converter unit rating .............................192 Common specifications............................193 Outline dimension drawings..........................194...

  • Page 193: Converter Unit Rating

    SPECIFICATIONS This chapter explains the specifications of this product. Always read the instructions before use. Converter unit rating Model FR-CC2M-H[](12P) 250K 280K 315K 355K 400K 450K 500K 560K Applicable motor capacity (kW) 110% 60 s 150% 60 s Overload current rating...

  • Page 194: Common Specifications

    Common specifications External thermal relay input, converter reset. Input signal (3) The signal to be input can be changed using Pr.178, Pr.187, or Pr.189 (Input terminal function selection). Thermal protection, DC injection brake, automatic restart after instantaneous power failure, retry Operational function function, RS-485 communication, life diagnosis, maintenance timer, 24 V power supply input for control circuit...

  • Page 195: Outline Dimension Drawings

    Outline dimension drawings 8.3.1 Converter unit outline dimension drawings FR-CC2M-H250K(12P), H280K(12P), H315K(12P) 6×φ10 4×φ24 75 75 (45) 6×φ52 2×φ30 (Unit: mm) 8. SPECIFICATIONS 8.3 Outline dimension drawings...
  • Page 196 FR-CC2M-H355K(12P), H400K(12P), H450K(12P), H500K(12P), H560K(12P) 4×φ24 6×φ10 125 125 (40) 14×φ30 (Unit: mm) 8. SPECIFICATIONS 8.3 Outline dimension drawings...
  • Page 197 MEMO 8. SPECIFICATIONS 8.3 Outline dimension drawings...
  • Page 198 CHAPTER 9 APPENDIX Instruction code list ...............................198 Instructions for compliance with the EU Directives....................200 Instructions for UL and cUL ..........................203 Instructions for EAC..............................205 Restricted Use of Hazardous Substances in Electronic and Electrical Products..........206 Referenced Standard (Requirement of Chinese standardized law) ..............207 Compliance with the UK certification scheme.......................207 UL-certified combinations of converter units and inverters...................207 Major differences from the FR-CC2 series ......................207...

  • Page 199: Chapter 9 Appendix

    APPENDIX APPENDIX provides the reference information for use of this product. Refer to APPENDIX as required. Instruction code list Instruction codes are used to read and write parameters in accordance with the Mitsubishi inverter protocol of RS-485 communication. (For RS- 485 communication, refer to page 130.)
  • Page 200 Instruction Instruction Parameter Parameter code code Name Name RS-485 Operation panel ○ ○ ○ ○ ○ ○ communication speed monitor selection 3 RS-485 Input phase loss ○ ○ ○ communication stop bit ○ protection selection ○ ○ length / data length OH input selection ○...

  • Page 201: Instructions For Compliance With The Eu Directives

    CE marking. • The authorized representative in the EU The authorized representative in the EU is shown below. Name: Mitsubishi Electric Europe B.V. Address: Mitsubishi-Electric-Platz 1, 40882 Ratingen, Germany • Note We declare that this converter unit conforms with the EMC Directive in industrial environments and affix the CE marking on the converter unit.
  • Page 202 • The open type converter unit does not provide protection against direct contact with hazardous live parts. The open type converter unit is intended to be installed inside a supplementary enclosure or in a restricted-access area which provides appropriate protection against electric shock. •...
  • Page 203 • To use the system as a TN-C system, earth a neutral point on the output side of the transformer (wye connection) and connect all devices to the protective conductor (PEN). Wiring example 1 Wiring example 2 FR-CC2M FR-CC2M Main power 12-phase rectifier...

  • Page 204: Instructions For Ul And Cul

    à être utilisés avec le variateur de fréquence. Veuillez transmettre les manuels correspondants à l’utilisateur final. Les manuels peuvent également être téléchargés au format PDF sur Mitsubishi Electric FA Global Website. Pour commander des manuels, veuillez contacter votre représentant commercial.

  • Page 205: Short Circuit Ratings

    • 6-phase rectification Converter model Fuse type Model Manufacturer Rating FR-CC2M-H250K 6.9URD32TTF0800 700 V, 800 A FR-CC2M-H280K 6.9URD32TTF0800 700 V, 800 A FR-CC2M-H315K 6.9URD32TTF0900 700 V, 900 A FR-CC2M-H355K 6.9URD32TTF0900 700 V, 900 A Semiconductor fuse Mersen FR-CC2M-H400K 6.9URD33TTF1100 700 V, 1100 A FR-CC2M-H450K 6.9URD33TTF1100...

  • Page 206: Instructions For Eac

    • Authorized sales representative (importer) in the CU area The authorized sales representative (importer) in the CU area is shown below. Name: Mitsubishi Electric Turkey A.S. Head Office Address: Serifali Mahallesi Kale Sokak. No:41 34775 Umraniye, Istanbul, Turkey Phone: +90-216-969-25-00 FAX: +90-216-661-44-47 9.

  • Page 207: Restricted Use Of Hazardous Substances In Electronic And Electrical Products

    Restricted Use of Hazardous Substances in Electronic and Electrical Products The mark of restricted use of hazardous substances in electronic and electrical products is described as follows based on the "Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products" of the People's Republic of China.

  • Page 208: Referenced Standard (Requirement Of Chinese Standardized Law)

    To use converter units with inverters, refer to the "Compatible inverters" section in 2.1.2 Peripheral devices (page 20). Other Mitsubishi Electric inverters are also available. For details, contact the nearest Mitsubishi Electric FA center. Major differences from the FR-CC2 series Item...
  • Page 209 MEMO 9. APPENDIX 9.9 Major differences from the FR-CC2 series...

  • Page 210: Warranty

    (1) Damages caused by any cause found not to be the responsibility of Mitsubishi Electric. (2) Loss in opportunity, lost profits incurred to the user by Failures of Mitsubishi Electric products. (3) Special damages and secondary damages whether foreseeable or not, compensation for accidents, and compensation for damages to products other than Mitsubishi Electric products.
  • Page 211 REVISIONS *The manual number is given on the bottom left of the back cover. Revision date Manual number Revision Feb. 2025 IB(NA)-0600992ENG-A First edition IB(NA)-0600992ENG-A...
  • Page 212 HEAD OFFICE: TOKYO BUILDING 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN IB(NA)-0600992ENG-A(2502)MEE Printed in Japan Specifications subject to change without notice.

This manual is also suitable for:

Cc2Fr-cc2 seriesFr-cc2m-h250kFr-cc2m-h280kFr-cc2m-h315kFr-cc2m-h355k ... Show all

Table of Contents
