Morrell SW-UNM-8FE1GC-8POE User Manual

8 fast ethernet ports poe + giga combo

Advertisement

Quick Links

SW-UNM-8FE1GC-8POE
8 Fast Ethernet Ports PoE + Giga Combo
User Manual
Version 1.0 | 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-UNM-8FE1GC-8POE and is the answer not in the manual?

Questions and answers

Summary of Contents for Morrell SW-UNM-8FE1GC-8POE

  • Page 1 SW-UNM-8FE1GC-8POE 8 Fast Ethernet Ports PoE + Giga Combo User Manual Version 1.0 | 2017...
  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Product Introduction ....................1 1.1 Product Overview ......................1 2.2 Features ..........................1 3.3 Package Contents ......................1 Chapter 2 External Component Description ................. 2 2.1 Front Panel ........................2 2.2 Rear Panel ........................3 Chapter 3 Installing and Connecting the Switch ..............
  • Page 3: Chapter 1 Product Introduction

    Chapter 1 Product Introduction Congratulations on your purchasing of the 8 Fast Ethernet Port + 1 -Port Gigabit Combo PoE Ethernet Switch. Before you install and use this product, please read this manual carefully for full exploiting the functions of this product. 1.1 Product Overview The Switch provides 8 Fast Ethernet Ports and 1-port Gigabit Combo, support all port forwarding line speed.
  • Page 4: Chapter 2 External Component Description

    Chapter 2 External Component Description 2.1 Front Panel The front panel of the Switch consists of series of LED indicators, 8 Fast Ethernet Port RJ-45 ports, 1 Giga RJ45 port and 1 Giga SFP port shown as below: Figure 1 - Front Panel Fast Ethernet RJ-45 ports (1~8): Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps.
  • Page 5: Rear Panel

    The following chart shows the LED indicators of the Switch along with explanation of each indicator. COLOR STATUS STATUS DESCRIPTION Power On Power Green Power Off A device is connected to the port Green Flashing Sending or receiving data A device is disconnected to the port A Powered Device is connected to the port, which supply power successfully.
  • Page 6: Chapter 3 Installing And Connecting The Switch

    Chapter 3 Installing and Connecting the Switch This part describes how to install your Ethernet Switch and make connections to it. Please read the following topics and perform the procedures in the order being presented. 3.1 Installation Please follow the following instructions in avoid of incorrect installation causing device damage and security threat.
  • Page 7: Power On The Switch

    use the screws provided with the equipment rack to mount the Switch on the rack and tighten it. Figure 5 - Mounting Switch 3.1.3 Power on the Switch The Switch is powered on by the AC 100-240V 50/60Hz internal high-performance power supply.
  • Page 8: Appendix: Technical Specifications

    Appendix: Technical Specifications Specifications IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, Standards IEEE 802.3x, IEEE 802.3af, IEEE 802.3at 10BASE-T: UTP category 3,4,5 cable (maximum 100m) Network Media (Cable) 100BASE-TX: UTP category 5,5e cable (maximum 100m) 1000BASE-T: UTP category 5e,6 cable (maximum 100m) 8 Fast Ethernet Auto-Negotiation ports Number of Ports 1 Giga Auto-Negotiation port...
