- Page 1 User’s Guide Shop online at omega.com e-mail: info@omega.com For latest product manuals: www.omegamanual.info NORWALK, CT UWXL-24-TC/RTD Long Distance Industrial Wireless Thermocouple/RTD Transmitters...
- Page 2 Fax: (203) 359-7700 e-mail: info@omega.com For Other Locations Visit omega.com/worldwide The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
-
Page 3: Table Of Contents
Section 6 Service and Calibration ..............6-1 6.1 Service and Calibration ................6-1 Section 7 Specifications ..................7-1 7.1 UWXL-24-TC & UWXL-24-RTD ............. 7-1 Section 8 Approvals & Regulatory Compliance ..........8-1 8.1 FCC (Domestic Use: USA & Canada) ............. 8-1... - Page 4 UWXL-24-TC/RTD Long Distance Industrial Wireless Thermocouple/RTD Transmitters Table of Figures Figure Description Page Section 1 Introduction IEC Symbols ..................1-1 Transmitter Top Label ............... 1-2 Transmitter Rear Label ..............1-2 System Components ................1-3 Section 3 Transmitter Operation Connecting Your Device ..............3-1 Setup Mode ..................
-
Page 5: Section 1 Introduction
Introduction Section 1 - Introduction Please read this manual completely before installing and operating your wireless connector/transmitter and receiver system. It’s important to read and follow all notes, cautions, warnings and safety precautions before operating this device. “Device” refers to your transmitter or receiver unit. 1.1 Precautions •... -
Page 6: Product Labeling
1) This device may not cause harmful interference; 2) This device must accept any interference received, including interference that may cause undesired operation. omega.com Figure 1-2. Transmitter Top Label Figure 1-3. Transmitter Rear Label 1.4 Statement on FCC and CE Marking 1.4.1 FCC Marking... -
Page 7: General Description & System Components
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions; 1) This device must may not cause harmful interference; 2) This device must accept any interference received, including interference that may cause undesired operation. OMEGA ENGINEERING INC. omega.com Figure 1-4. System Components 1-3... -
Page 8: Section 2 Hardware
Customer Service Department at 1-800-622-2378 or 203-359-1660. We can also be reached on the Internet at omega.com, e-mail: cservice@omega.com. When you receive the shipment, inspect the container and equipment for any signs of damage. Note any evidence of rough handling in transit. -
Page 9: Transmitter Operation
Transmitter Operation Section 3 – Transmitter Operation 3.1 Setup and Configuration 3.1.1 Connecting your device Connect the USB cable to your transmitter unit and also to an available USB port on your computer. See figure below. This cable was provided in the box with your receiver unit. This same cable is used for programming your transmitter units and for running your receiver later. - Page 10 Connector Operation NOTE: If you will be using more than one receiver unit in your area it is important to set the transmitter address numbers to be a corresponding number in your TC-Central software. See Examples below. For the first receiver: Set the channels on your transmitters to 101, 102, 103, 104, etc.
- Page 11 Connector Operation STEP 2. Launch Setup Utility Program. To launch the End Device setup utility program on your PC begin by accessing the “Programs” list under your “Start Menu”. Scroll through the list of to find the “TC-Central” folder, then select the End Device Configuration Program. Figure 3-3. Launch Setup Utility Program STEP 3. Programing your settings into a transmitter. Figure 3-4.
- Page 12 Connector Operation Figure 3-5. Setup The Transmitter Screen If you have not already placed your transmitter into the “Setup” mode you should do this now before continuing. After your unit has been placed into the “Setup” mode click the “Next >” button to proceed and continue setting up your transmitter.
- Page 13 Connector Operation Figure 3-7. Establish A Link Screen After successful communication between your transmitter has been established you can click the “Next >” button to proceed and continue setting up your transmitter. If you did not receive this confirmation of proper communication you should click the “Back” button to try connecting again. If you still do not obtain a good connection visit the “Troubleshooting”...
-
Page 14: Mounting, Installation And Antenna Connection
Connector Operation Figure 3-9. Send Settings To Transmitter Screen Congratulations! You have successfully programmed your transmitter. After your unit has been programmed click the “Finish” button to close the utility program or click the “Start” button to begin setting up a second unit. You can now disconnect your transmitter from the programming cable. - Page 15 Connector Operation 3.2.2 Installation When installing your transmitter it is important to position your device in such a way as to optimize the antenna location within what’s known as the “Fresnel Zone”. The Fresnel Zone can be thought of as a football-shaped invisible tunnel between two locations that provides a path for RF signals between your transmitter and your receiver.
-
Page 16: Thermocouple/Rtd Connection
Connector Operation NOTE: Never use your UWXL transmitter as a portable device. Your unit has been designed to be operated in a permanent installation only. 3.2.4 Antenna Connection Your device has been shipped to you with a standard antenna already attached. In some cases the user may wish to install a remote antenna to maximize transmission range to the receiver. In these instances the UWXL-RAK kit can be used. The kit includes a direction antenna, 8"... -
Page 17: Battery Installation Or Replacement
3.4 Battery Installation or Replacement Your UWXL transmitter is equipped with a “C” size lithium power cell assembly, Omega Part Number: UWTC-BATT-C. To install a replacement battery assembly follow the steps on the next page. - Page 18 Refer to the Omega technical data sheet or this manual for the temperature ranges over which the battery can be operated. Use of the battery outside this temperature range may damage the Transmitter or reduce the performance and life of the battery.
-
Page 19: Section 4 System Operation
System Operation Section 4 - System Operation 4.1 Introduction Compared to wired thermocouple systems, wireless thermocouple systems provide much simpler installation. Based on the physical principle of the propagation of radio waves, certain basic conditions should be observed. The following simple recommendations are provided to insure proper installation and correct operation of your UWXL Series system. -
Page 20: Connector/Transmitter Operation
System Operation 4.4 Connector/Transmitter Operation 4.4.1 Button Operation (1.) “PRESS ON/OFF” The “PRESS ON/OFF” button on the front of your transmitter is used to turn your unit “ON” or “OFF” (2.) “PRESS SETUP” The “PRESS SETUP” button on the front of your transmitter is only used during the setup and configuration of your unit. See Section 3.1.2 for more information. - Page 21 System Operation +TC INPUT NOT USED -TC INPUT Figure 4-3. UWXL Industrial Wireless Transmitter Transmit and Low Battery Lights (1) “SETUP” Button (2) “ON/OFF” Button (3) Transmit Indicator (4) Battery Indicator...
-
Page 22: Environment/Operating Conditions
System Operation 4.5 Environment/Operating Conditions 4.5.1 Environment Omega’s UWXL series transmitters are designed to be fixed mounted and operated in either indoor or outdoor environments; they are also weather and dust-resistant. Care should be taken to prevent the components of your wireless system from being exposed to toxic chemicals and extreme hot or cold temperatures outside the specifications listed in this manual. -
Page 23: Determining And Maximizing Range
System Operation 4.6 Determining and Maximizing Range NOTE: The available maximum range specified for the wireless Series system in this manual is only achievable under optimum installation conditions. Mounting height, obstructions in your “Fresnel Zone” and ambient conditions can cause a decrease in signal strength resulting in a shorter range between your transmitter and receiver unit. - Page 24 System Operation 4.6.1 Operation in Buildings Your transmitter sends wireless data transmissions to a receiver connected to your PC. Radio signals are electromagnetic waves. A radio signal becomes weaker the further it travels. Range is decreased by different types of materials found in the direction of the signals propagation. Radio waves can penetrate most types of wall materials, but they are dampened more than they would be by a direct line-of-sight installation.
-
Page 25: Antenna Basics
Operation is subject to the following two conditions: 1) This device may not cause harmful interference; 2) This device must accept any interference received, including interference that may cause undesired operation. OMEGA ENGINEERING, INC. omega.com Stamford, CT 06907 Made in U.S.A. 9–24 Vdc Figure 4-6. -
Page 26: Factory Preset Values
The slower the 1) This device may not cause harmful interference; 2) This device must accept any interference received, including interference that may cause undesired operation. OMEGA ENGINEERING, INC. omega.com Stamford, CT 06907 Made in U.S.A. 9–24 Vdc transmit rate you set, the longer the battery in your device will last. -
Page 27: Section 5 Troubleshooting
System. If the problems and solutions outlined here do not solve your problem, please contact Omega’s customer service department. Contact information can be found in Section 2 of this manual or by visiting omega.com. 5.1 Transmitter Troubleshooting Problem Solution a. -
Page 28: Section 6 Service And Calibration
If any of your wireless system components require service or calibration, please call our Customer Service Department at 1-800-622-2378 or 203-359-1660. They will assist you in arranging the return and service of your device. We can also be reached on the Internet at www.omega.com, e-mail: cservice@omega.com... -
Page 29: Section 7 Specifications
Specifications Section 7 – Transmitter Specifications 7.1 UWXL-24-TC & UWXL-24-RTD Specifications Input J, K, T, E, R, S, B, C or N thermocouple, Model UWXL-24-TC: software selectable Pt100 RTD, 0.00385 or 0.00392 curve, software Model UWXL-24-RTD: selectable Measurement Range Model UWXL-24-TC -100 to 760°C (-148 to 1400°F) -100 to 1260°C (-148 to 2300°F) -200 to 400°C (-328 to 752°F) -
Page 30: Fcc (Domestic Use: Usa & Canada)
Approvals, Regulatory Compliance & Patent Notice Section 8 – Approvals, Regulatory Compliance & Patent Notice NOTE: All approvals outlined in this manual are based on testing that was done with antennas that are supplied with your wireless Series System Components. Removing and or installing a different antea will void the product compliance demonstrated in these documents. - Page 31 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
- Page 32 Where Do I Find Everything I Need for Process Measurement and Control? OMEGA…Of Course! Shop online at omega.com TEMPERATURE M U Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies M U Wire: Thermocouple, RTD & Thermistor M U Calibrators & Ice Point References M U Recorders, Controllers &...
