SFC4100AB Switch

User Guide

Table of Contents

Need help?

Do you have a question about the SFC4100AB and is the answer not in the manual?

Questions and answers

Summary of Contents for Soltech SFC4100AB

Page 1 SFC4100AB Switch User Guide...
Page 2: Table Of Contents
2.3. Power Input Method ....................................21 3. Installation of bracket ......................................22 4. Installation of Product ......................................23 4.1. Installation Procedure for SFC4100AB ............................23 4.2. Installation of SFP Module .................................. 24 4.3. Installation of Fiber Optic Cable ............................... 24...
Page 3 SOLTECH USER GUIDE Switch SFC4100AB 4.5. Operating System ....................................25 5. Switch Access Guide ......................................26 5.1. The Initial Defaults Values ..................................26 5.2. WEB Interface ......................................27 5.2.1. WEB Login ...................................... 27 5.3. CLI Interface ........................................ 29 5.3.1. CLI Basic Symbol ..................................29 5.3.2.
Page 4 SOLTECH USER GUIDE Switch SFC4100AB 6.1.2.4. Log ......................................66 6.1.2.5. Detailed Log ..................................70 6.2. Green Ethernet ......................................72 6.2.1. Green Ethernet Configuration ............................... 72 6.2.1.1. Port Power Savings ................................ 72 6.2.2. Green Ethernet Monitor ................................76 6.2.2.1. Port Power Savings ................................ 76 6.3.
Page 5 SOLTECH USER GUIDE Switch SFC4100AB 6.4.2.4. Snooping Table ................................119 6.4.2.5. Detailed Statistics ................................. 121 6.5. Security ........................................123 6.5.1. Switch Configuration ................................123 6.5.1.1. Users ....................................123 6.5.1.2. Privilege Levels ................................127 6.5.1.3. Auth Method .................................. 130 6.5.1.4. Telnet ....................................133 6.5.1.5.
Page 6 SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.3.1. Configuration ..............................186 6.5.2.3.2. Static Table ................................189 6.5.2.4. ARP Inspection ................................191 6.5.2.4.1. Port Configuration ............................191 6.5.2.4.2. VLAN Configuration ............................195 6.5.2.4.3. Static Table ................................197 6.5.2.4.4. Dynamic Table ..............................199 6.5.3. AAA Configuration ..................................200 6.5.3.1.
Page 7 SOLTECH USER GUIDE Switch SFC4100AB 6.6.1.4. CIST Ports ..................................230 6.6.1.5. MSTI Ports ..................................236 6.6.2. Spanning Tree Monitor ................................240 6.6.2.1. Bridge Status .................................. 240 6.6.2.2. Port Status ..................................244 6.6.2.3. Port Statistics .................................. 246 6.7. LLDP ..........................................247 6.7.1.
Page 8 SOLTECH USER GUIDE Switch SFC4100AB 6.12.2. VLAN Monitor ..................................302 6.12.2.1. Membership ................................. 302 6.12.2.2. Ports ....................................303 6.13. QoS ..........................................305 6.13.1. QoS Configuration ................................. 305 6.13.1.1. Port Classification ..............................305 6.13.1.2. Port Policing ................................. 313 6.13.1.3. Queue Policing ................................316 6.13.1.4.
Page 9 SOLTECH USER GUIDE Switch SFC4100AB 7.1. Diagnostics ........................................ 359 7.1.1. Ping ........................................359 7.1.2. Link OAM ...................................... 360 7.1.2.1. MIB Retrieval ................................... 360 7.1.3. Ping6 ....................................... 361 7.1.4. VeriPHY ......................................362 8. Switch Maintenance Guide ..................................... 363 8.1. Maintenance ......................................363 8.1.1.
Page 10 SOLTECH USER GUIDE Switch SFC4100AB 9.2.1. Google Chrome Browser ............................... 385 9.2.2. Microsoft Edge Browser ................................. 386...
Page 11: Introduction
1.1. PRODUCT INTRODUCTION 1.1.1. Product overview The SFC4100AB products are managed 10 Gigabit Ethernet switches designed for use. They feature 10/100/1000Mbps TP ports and SFP slots that support 100M/1G/2.5G/10G Base-X. The 10-Gigabit Managed Ethernet Switches can automatically identify the correct transmission speed and determine the Port's Full/Half Duplex mode.
Page 12: Product Features
SOLTECH USER GUIDE Switch SFC4100AB 1.2. PRODUCT FEATURES 1.2.1. Physical Port 1.2.1.1. SFC4100AB  4 10/100/1000BASE-T RJ45 Copper ports 4 Combo Ports (1Gbps RJ45 or 1Gbps SFP Slots)   16 100/1000BASE-X SFP Slots 8 100/1000/2500BASE-X SFP Slots  ...
Page 13: Quality Of Service
SOLTECH USER GUIDE Switch SFC4100AB - IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN - BPDU Guard Supports Link Aggregation  - 802.3ad Link Aggregation Control Protocol (LACP) - Cisco ether-channel (static trunk) - Maximum 10 trunk groups, up to 16 ports per trunk group ...
Page 14: Security
SOLTECH USER GUIDE Switch SFC4100AB 1.2.2.4. Security  Authentication - Built-in RADIUS client to co-operate with the RADIUS servers - TACACS+ login users access authentication - RADIUS / TACACS+ users access authentication - Guest VLAN assigns clients to a restricted VLAN with limited services Access Control List ...
Page 15 SOLTECH USER GUIDE Switch SFC4100AB  System Maintenance - Firmware upload/download via HTTP/TFTP - Reset button for system reboot or reset to factory default - Dual images  DHCP Relay DHCP Option82   DHCP Server User Privilege levels control ...
Page 16: Product Specification
SOLTECH USER GUIDE Switch SFC4100AB 1.3. PRODUCT SPECIFICATION Product SFC4100AB Hardware Specifications Copper Ports 4 10/100/1000Mbps RJ45 auto-MDI/MDI-X Ports Combo Port 4 RJ45 Port or 4 1G SFP Slots 16 100/1000Mbps SFP Slots Fiber Slots 8 100/1000/2500Mbps SFP Slots 4 100/1000/10000Mbps SFP Slots...
Page 17 SOLTECH USER GUIDE Switch SFC4100AB IEEE 802.3x pause frame for full duplex Flow Control Back pressure for half duplex Jumbo Frame Software Functions - Port disable / enable Port - Auto-negotiation 10/100/1000Mbps full and half duplex mode selection Configuration - Flow Control disable / enable...
Page 18: Standards Conformance
SOLTECH USER GUIDE Switch SFC4100AB RFC-2737 Entity MIB RFC-2618 RADIUS Client MIB RFC-2933 IGMP-STD_MIB RFC3411 SNMP-Frameworks-MIB LLDP MAU_MIB Ring Protocol ERPS, STP, RSTP, MSTP, S-Ring Inter-VLAN Supported Routing Static Routes 128 IPv4 Routes Standards Conformance IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX/100Base-FX Fast Ethernet IEEE 802.3z Gigabit Ethernet (SX/LX)
Page 19: Product Contents
SOLTECH USER GUIDE Switch SFC4100AB 1.4. PRODUCT CONTENTS SFC4100AB Managed 10G Ethernet Switch Rack Mount Bracket Fixed Screw AC Power Cable If any of the contents are missing or damaged and need to be repaired, please repack the product and...
Page 20: Exterior
SOLTECH USER GUIDE Switch SFC4100AB 2. Exterior 2.1. MODEL & EXTERIOR Model Exterior Port Information Product Size 10/100/1000BASE-T Port 4 Combo Port 4 (UTP or SFP) 1G SFP Slot 16 2.5G SFP Slot 8 440x225x44 SFC4100AB 10G SFP Slot 4...
Page 21: Led Condition
The front panel LED indicates the immediate status of power, system status, port link/active and PoE to monitor, diagnose and resolve potential issues with connected devices. The following diagram shows the switch LED indicators for product SFC4100AB: 2.2.1. SFC4100AB Color 상태...
Page 22: Power Input Method
SOLTECH USER GUIDE Switch SFC4100AB 2.3. POWER INPUT METHOD On the rear side of the SFC4100AB, there is a power input slot. Depending on the product, the following AC power can be supplied. - SFC4100AB : AC Power Input 100~240V/50~60Hz 1ea Power Notice: 1.
Page 23: Installation Of Bracket
Switch SFC4100AB 3. Installation of bracket In the basic accessories of the SFC4100AB product, Rack Mount brackets are included. These brackets allow for mounting the product on a 19-inch RACK. Bracket installation is completed by aligning the screw holes and...
Page 24: Installation Of Product
Managed 10G Ethernet Switch on a desktop or shelf. 4.1. INSTALLATION PROCEDURE FOR SFC4100AB Step 1 Place the SFC4100AB, near a 100 ~ 240Vac power source. Step 2 Maintain sufficient ventilation space between the Managed 10G Ethernet Switch and surrounding objects.
Page 25: Installation Of Sfp Module
SOLTECH USER GUIDE Switch SFC4100AB 4.2. INSTALLATION OF SFP MODULE SFP transceivers module(in the following sections referred to as SFP module) typically provide Hot-pluggable and Hot-swappable functionality. Users can remove or insert the module into the SFP slot of the Managed 10G Ethernet Switch without the need to power off the switch.
Page 26: Removing Transceiver Module
SOLTECH USER GUIDE Switch SFC4100AB 4.4. REMOVING TRANSCEIVER MODULE A. Check if there is current network activity on the port with the SFP module to be removed, or Disable the port through the Switch/Converter's management interface. B. Remove the Fiber cable smoothly.
Page 27: Switch Access Guide
SOLTECH USER GUIDE Switch SFC4100AB 5. Switch Access Guide Here's a brief introduction on how to access device 5.1. THE INITIAL DEFAULTS VALUES The initial values of the equipment are as follows: Items Defaults Values Note Administrator account admin Administrator password...
Page 28: Web Interface
SOLTECH USER GUIDE Switch SFC4100AB 5.2. WEB INTERFACE 5.2.1. WEB Login This page provides a brief overview of accessing the web interface. 1. Users must know IPv4 Address of device to WEB set. 2. Connect AP (LAN interface) with PC (LAN port) using enclosed LAN cable.
Page 29 SOLTECH USER GUIDE Switch SFC4100AB Sign in page appears. Enter your Username and Password, then click on "Sign in." (Default ID: admin, PW: admin) 4. Successfully connected to the equipment's web interface.
Page 30: Cli Interface
SOLTECH USER GUIDE Switch SFC4100AB 5.3. CLI INTERFACE 5.3.1. CLI Basic Symbol This page is the description of symbols commonly used in CLI(Command Line Interface) commands. Symbol Description < > The symbol indicates that you have to enter a value directly.
Page 31 SOLTECH USER GUIDE Switch SFC4100AB 2. Set Serial Port.(Set Speed 115200 like below) 3. Access Device with Console.(New Connection Alt+N) The initial ID and password are both "admin." 4. You are currently connected to the console.(Initial ID-admin, PW-admin or the password you previously set)
Page 32: Telnet
SOLTECH USER GUIDE Switch SFC4100AB 5.3.3. Telnet This page provides an explanation of Telnet connection. You should follow the same configuration steps as mentioned in item 2 of the console connection. Telnet allows for switch access from a computer within the same network.
Page 33: Ssh
SOLTECH USER GUIDE Switch SFC4100AB 5.3.4. SSH This page provides an explanation of SSH connection. You should follow the same configuration steps as mentioned in item 2 of the console connection. Click "Continue (C)" on the security warning window Enter your username and password in the SSH Authentication window.
Page 34: Cli Basic Command
SOLTECH USER GUIDE Switch SFC4100AB 5.4. CLI BASIC COMMAND This page provides an explanation of basic commands used in the Command-Line Interface (CLI). 5.4.1. CLI Basic use Key TAB key  When entering a command, pressing the TAB key will either display the next possible command or complete the existing command.
Page 35: Cli Basic Use Mode
SOLTECH USER GUIDE Switch SFC4100AB ipv6 IPv6 configuration commands link-oam Link OAM configuration logout Exit from EXEC mode more Display file Negate a command or set its defaults ping Send ICMP echo messages platform Platform configuration reload Reload system. send...
Page 36: Cli Basic Command
SOLTECH USER GUIDE Switch SFC4100AB 5.4.3. CLI Basic Command Login  Users need to input username and password when login firstly. [Console] Username: admin [Console] Password: > Logout  To log out the current user or log in as a new user, please log out.
Page 37 SOLTECH USER GUIDE Switch SFC4100AB Clear  To delete the remaining records, you can use the "Clear" command. # clear ? access Access management access-list Access list Ethernet Protection Switching. erps Ethernet Ring Protection Switching Interface Internet Protocol configuration commands...
Page 38 SOLTECH USER GUIDE Switch SFC4100AB Show  To Show running system information, you can use the "show" command. # show ? Authentication, Authorization and Accounting methods access Access management access-list Access list aggregation Aggregation port configuration audit-log System Audit Log message...
Page 39 SOLTECH USER GUIDE Switch SFC4100AB radius-server RADIUS configuration rmon RMON statistics running-config Show running system information scan-agent SCAN-AGENT Module sflow Statistics flow. snmp Display SNMP configurations spanning-tree STP Bridge sring SRING Module switchport Display switching mode characteristics system system tacacs-server...
Page 40 SOLTECH USER GUIDE Switch SFC4100AB Copy running-config startup-config  To save the running-configuration settings to the Startup-Config, you can use the “copy running-config startup-config” command. This command can only be used in Privileged mode. # copy running-config startup-config Building configuration...
Page 41: Switch Management Guide
SOLTECH USER GUIDE Switch SFC4100AB 6. Switch Management Guide 6.1. SYSTEM 6.1.1. System Configuration 6.1.1.1. Information WEB MENU Configuration>System>Information The switch system information is provided here. System Information Configuration Object Description The textual identification of the contact person for this managed node, System Contact together with information on how to contact this person.
Page 42 System Name  System Location  EXAMPLE CLI CONFIGURATION System Contact  (config)# snmp-server contact <line255> (config)# snmp-server contact SOLTECH System Name  (config)# hostname <host_name> (config)# hostname TESTSWITCH System Location  (config)# snmp-server location <line255> (config)# snmp-server location SOLTECH-LAB...
Page 43 SOLTECH USER GUIDE Switch SFC4100AB 6.1.1.2. IP WEB MENU Configuration>System>IP Configure IP basic settings, control IP interfaces and IP routes. IP Configuration Object Description Mode Configure whether the IP stack should act as a Host or a Router. DNS Server This setting controls the DNS name resolution done by the switch.
Page 44 SOLTECH USER GUIDE Switch SFC4100AB IP Routes Object Description Delete Select this option to delete an existing IP route. Network The destination IP network or host address of this route. The destination IP network or host mask, in number of bits (prefix length).
Page 45 SOLTECH USER GUIDE Switch SFC4100AB • From any DHCPv4 Interfaces • From this DHCPv4 Interfaces (VLAN1) • From any DHCPv6 Interfaces • From this DHCPv6 Interfaces (VLAN1)  DNS Proxy IP Interfaces   VLAN(This field is only available for input when creating a new interface.)
Page 46 SOLTECH USER GUIDE Switch SFC4100AB  DHCPv4 • DHCPv4 fallback not set • DHCPv4 fallback setting. (After this period expires, a configured IPv4 address will be used as IPv4 interface address.)  IPv4 IP Routes   Add Route •...
Page 47 SOLTECH USER GUIDE Switch SFC4100AB  DNS Server • Configured IPv4 or IPv6 (config)# ip name-server <0-3> <ipv4_ucast> (config)# ip name-server 0 8.8.8.8 (config)# ip name-server <0-3> <ipv6_ucast> (config)# ip name-server 0 2001:4860:4860::8888 • From any DHCPv4 Interfaces (config)# ip name-server <0-3> dhcp ipv4 (config)# ip name-server 0 dhcp ipv4 •...
Page 48 SOLTECH USER GUIDE Switch SFC4100AB (config-if-vlan)# ip address dhcp fallback <ipv4_addr> <ipv4_netmask> timeout <uint> (config-if-vlan)# ip address dhcp fallback 192.168.10.101 255.255.255.0 timeout 30  IPv4 (config)# interface vlan <vlan_list> (config-if-vlan)# ip address <ipv4_addr> <ipv4_netmask> (config-if-vlan)# ip address 192.168.10.101 255.255.255.0 IP Routes ...
Page 49: Ntp
SOLTECH USER GUIDE Switch SFC4100AB 6.1.1.3. NTP WEB MENU Configuration>System>NTP Configure NTP on this page. NTP Configuration Object Description Indicates the NTP mode operation. Possible modes are: Enabled: Enable NTP client mode operation. Mode Disabled: Disable NTP client mode operation.
Page 50 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION NTP Configuration   Mode • Enable • Disable  Server • Use the IPv4 or IPv6 address of the NTP server • Use the domain name of the NTP server...
Page 51 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION NTP Configuration   Mode • Enable(NTP client mode operation is used.) (config)# ntp • Disable (NTP client mode operation is not used.) (config)# no ntp  Server • NTP server configuration (config)# ntp server <1-5>...
Page 52: Time
SOLTECH USER GUIDE Switch SFC4100AB 6.1.1.4. Time WEB MENU Configuration>System>Time This page allows you to configure the Time Zone. Time Zone Configuration Object Description Lists various Time Zones world wide. Time Zone Select appropriate Time Zone. Number of hours offset from UTC.
Page 53 SOLTECH USER GUIDE Switch SFC4100AB Month Select the starting and ending month. Hours Select the starting and ending hour. Minutes Select the starting and ending minute. Enter the number of minutes to add during Daylight Saving Time. Offset ( Range: 1 to 1439 ) Buttons : Click to apply changes.
Page 54 SOLTECH USER GUIDE Switch SFC4100AB • Recurring • Non-Recurring...
Page 55 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Time Zone Configuration   Time Zone • (UTC+09:00) Seoul (config)# clock timezone '' <-23-23> <0-59> <0-9> (config)# clock timezone '' 9 0 1 • Manual Setting (config)# clock timezone '' <-23-23> <0-59> <0-9>...
Page 56 SOLTECH USER GUIDE Switch SFC4100AB CHECK CONFIGURATION Check Configuration  You can verify the change at Information Monitor Daylight Saving Time Monitor   You can verify the changes on the same page after saving  # show clock detail...
Page 57: Log
SOLTECH USER GUIDE Switch SFC4100AB 6.1.1.5. Log WEB MENU Configuration>System>Log Configure System Log on this page. System Log Configuration Object Description Indicates the server mode operation. When the mode operation is enabled, the syslog message will send out to syslog server.
Page 58 SOLTECH USER GUIDE Switch SFC4100AB • Enable  Server Address • IPv4 Address (PC Address)  Syslog Level • Audit • Error • Warning • Notice • Information EXAMPLE CLI CONFIGURATION System Log Configuration   Server Mode...
Page 59 SOLTECH USER GUIDE Switch SFC4100AB • Disable (config)# no logging on • Enable (config)# logging on  Server Address • IPv4 Address (PC Address) (config)# logging host <ipv4_ucast> (config)# logging host 192.168.10.130  Syslog Level • Audit (config)# logging level audit •...
Page 60: System Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.1.2. System Monitor 6.1.2.1. Information WEB MENU Monitor>System>Information The switch system information is provided here. System Information Object Description Displays system information for the switch. System Displays switch identification information. Contact Displays switch Name. Name Displays switch Location.
Page 61 MEMORY : Total=208355 KBytes, Free=181987 KBytes, Max=181905 Kbytes FLASH : 0x40000000-0x40ffffff, 256 x 0x10000 blocks MAC Address : 00-21-6d-00-00-00 Board Serial : Previous Restart : Cool System Contact : SOLTECH System Name : TESTSWITCH System Location : SOLTECH-LAB System Time : 1970-01-02T07:24:10+09:00 System Uptime...
Page 62 SOLTECH USER GUIDE Switch SFC4100AB Active Image ------------ Image : SFC4100AB.dat (primary) Version : OneImg_JAGUAR2 (standalone) build 5.0.3.0 by Soltech Corp. Date : 2023-07-21T14:21:27+09:00 Bank-Index : Bank1 Alternate Image --------------- Image : SFC4100AB.dat (backup) Version : OneImg_JAGUAR2 (standalone) build 5.0.1.0 by Soltech Corp.
Page 63: Cpu Load
SOLTECH USER GUIDE Switch SFC4100AB 6.1.2.2. CPU Load WEB MENU Monitor>System>CPU Load This page displays the CPU load, using an SVG graph. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every 3 seconds. EXAMPLE WEB MONITOR WEB MENU Monitor>System>CPU Load...
Page 64: Ip Status
SOLTECH USER GUIDE Switch SFC4100AB 6.1.2.3. IP Status WEB MENU Monitor>System>IP Status This page displays the status of the IP protocol layer. The status is defined by the IP interfaces, the IP routes and the neighbor cache (ARP cache) status.
Page 65 SOLTECH USER GUIDE Switch SFC4100AB Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every seconds. : Click to refresh the page immediately. EXAMPLE WEB MONITOR EXAMPLE CLI MONITOR IP Interfaces  # show interface vlan VLAN1 LINK: 00-21-6d-00-87-32 Mtu:1500 <UP BROADCAST RUNNING MULTICAST>...
Page 66 SOLTECH USER GUIDE Switch SFC4100AB IP Routes  # show ip route 0.0.0.0/0 via 192.168.10.1 <UP GATEWAY HW_RT> 2.2.2.0/24 via interface index 2 <UP HW_RT> 3.3.3.0/24 via 192.168.10.1 <UP GATEWAY HW_RT> 127.0.0.1/32 via 127.0.0.1 <UP HOST> 192.168.10.0/24 via interface index 1 <UP HW_RT>...
Page 67: Log
SOLTECH USER GUIDE Switch SFC4100AB 6.1.2.4. Log WEB MENU Configuration>System>Log Configure System Log on this page. System Log Information Object Description Display the information from the system logs for the selected log level. Level Delete the information from the system logs for the selected log level.
Page 68 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Configuration>System>Log System Log Information   Level • example notice Select Notice> Click (Check only Notice)  Clear Level • example notice...
Page 69 SOLTECH USER GUIDE Switch SFC4100AB Select Notice> Click (Delete only Notice) EXAMPLE CLI MONITOR System Log Information  # show logging Switch logging host mode is enabled Switch logging host address is 192.168.10.130 Switch logging level is info. Number of entries on Switch 1:...
Page 70 SOLTECH USER GUIDE Switch SFC4100AB 6 Audit 1970-01-01T00:00:02+00:00 Intf. Port:2 TEST Ok!!!, (CAP:0x0000303F) 7 Audit 1970-01-01T00:00:02+00:00 Intf. Port:3 TEST Ok!!!, (CAP:0x0000303F) 21 Audit 1970-01-01T00:00:57+00:00 User [admin] logged on HTTP 22 Audit 1970-01-01T00:15:30+00:00 User admin logouted on HTTP 23 Audit 1970-01-01T00:15:35+00:00 User [admin] logged on HTTP ...
Page 71: Detailed Log
SOLTECH USER GUIDE Switch SFC4100AB 6.1.2.5. Detailed Log WEB MENU Configuration>System>Detailed Log The switch system detailed log information is provided here. Detailed System Log Information Object Description The ID (>= 1) of the system log entry. Message The detailed message of the system log entry.
Page 72 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI MONITOR Detailed System Log Information   # show logging <1-4294967295> # show logging 1 Switch : 1 Level : Audit Time : 1970-01-01T09:00:00+09:00 Message: Audit Log Start, Image:[SFC6810BT 5.0.3.0]...
Page 73: Green Ethernet
SOLTECH USER GUIDE Switch SFC4100AB 6.2. GREEN ETHERNET 6.2.1. Green Ethernet Configuration 6.2.1.1. Port Power Savings WEB MENU Configuration>Green Ethernet>Port Power Savings This page allows the user to configure the port power savings features. Port Power Saving Configuration Object Description The option is to configure the switch to optimize EEE.
Page 74 SOLTECH USER GUIDE Switch SFC4100AB : Click to undo any changes made locally and revert to previously saved values. EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Green Ethernet>Port Power Savings Port Power Saving Configuration   Optimize EEE for • Latency •...
Page 75 SOLTECH USER GUIDE Switch SFC4100AB  PerfectReach  EEE (Energy-Efficient Ethernet)  EEE Urgent Queues...
Page 76 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Port Power Saving Configuration   Optimize EEE for • Latency (config)# no green-ethernet eee optimize-for-power • Power (config)# green-ethernet eee optimize-for-power  ActiPHY (config)# interface GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# green-ethernet energy-detect ...
Page 77: Green Ethernet Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.2.2. Green Ethernet Monitor 6.2.2.1. Port Power Savings WEB MENU Monitor>Green Ethernet>Port Power Savings This page provides the current status for EEE. Port Power Saving Status Object Description Port This is the logical port number for this row.
Page 78 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR Port Power Saving Status  EXAMPLE CLI MONITOR  Port Power Saving Status # show green-ethernet Interface Link Energy-detect Short-Reach EEE Capable EEE Enabled LP EEE Capable EEE In Power Save --------------------- --- -------- ----------- ----------- ----------- --------------- -----------------...
Page 79: Ports
SOLTECH USER GUIDE Switch SFC4100AB 6.3. PORTS 6.3.1. Ports Configuration 6.3.1.1. Ports WEB MENU Configuration>Ports Indicate general setting detail of switch and configure. Port Configuration Object Description Port This is the logical port number for this row. The description of the port. It is an ASCII string no longer Description than 256 characters .
Page 80: Flow Control
SOLTECH USER GUIDE Switch SFC4100AB When Auto Speed is selected on a port, this section indicates the flow control capability that is advertised to the link partner. When a fixed-speed setting is selected, that is what is used. The Current Rx column indicates whether pause frames on the port are obeyed, and the Current Tx column indicates whether pause frames on the port are transmitted.
Page 81 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION Port Configuration   Description  Speed Configured Auto-negotiation is the default value, and other values are fixed. (speed, duplex)  Advertise Duplex For UTP ports, only Speed Auto can be configured, and Full duplex is prioritized and communicated to the link partner.
Page 82 SOLTECH USER GUIDE Switch SFC4100AB • Speed – AUTO excluding 1G(connected as 100M full duplex based on priority) • Speed – AUTO excluding 1G, 100M(connected as 10M full duplex based on priority)  Flow Control • Flow Control Disable(default) •...
Page 83 SOLTECH USER GUIDE Switch SFC4100AB  • Enable • Priority  Maximum Frame Size (1518~10240bytes)
Page 84 SOLTECH USER GUIDE Switch SFC4100AB  Excessive Collision Mode(Apply only UTP) • Discard(default) • Restart  Frame Length Check EXAMPLE CLI CONFIGURATION Port Configuration   Description (config)# interface 10GigabitEthernet/ GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# description <line> (config-if) )# description H/W TEAM...
Page 85 SOLTECH USER GUIDE Switch SFC4100AB  Speed Configured Auto-negotiation is the default value, and other values are fixed. (speed, duplex) (config)# interface 10GigabitEthernet/ GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# speed <auto/10g/1000/100/10> (config-if)# speed auto (config-if)# speed 100 (config-if)# duplex <auto/full/half>...
Page 86 SOLTECH USER GUIDE Switch SFC4100AB  • Enable, Priority (config)# interface 10GigabitEthernet/GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# priority-flowcontrol prio <0~7> (config-if)# priority-flowcontrol prio 0-7 (config-if)# priority-flowcontrol prio 1,3,7 • Disable, Priority (config)# interface 10GigabitEthernet/GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)#no priority-flowcontrol prio <0~7>...
Page 87: Ports Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.3.2. Ports Monitor 6.3.2.1. State WEB MENU Monitor>Ports>State This page provides an overview of the current status of switch ports. State Link Link Disabled Down (non-Max Speed) (Max Speed) RJ-45 Ports SFP Ports Info. Down 100M 2.5G...
Page 88 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Monitor>Ports>State EXAMPLE CLI CONFIGURATION Port State Overview  # show interface * status Interface Mode Speed & Duplex Flow Control Max Frame Excessive Link MAC-Addr ---------------------- ------- -------------- ------------ --------- --------- --------- --------...
Page 89: Traffic Overview
SOLTECH USER GUIDE Switch SFC4100AB 6.3.2.2. Traffic Overview WEB MENU Monitor>Ports>Traffic Overview This page provides an overview of general traffic statistics for all switch ports. Port Statistics Overview Object Description Port The logical port. Click number will navigate to the Detailed Statistics.
Page 90 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI MONITOR Port Statistics Overview  # show interface GigabitEthernet 1/1-4 statistics packets Interface Rx Packets Tx Packets ---------------------- ------------------ ------------------ GigabitEthernet 1/1 4434 2280 GigabitEthernet 1/2 GigabitEthernet 1/3 GigabitEthernet 1/4 # show interface 10GigabitEthernet 1/1-4 statistics packets...
Page 91 SOLTECH USER GUIDE Switch SFC4100AB # show interface GigabitEthernet 1/1-4 statistics discards Interface Rx Discards Tx Discards ---------------------- ------------------ ------------------ GigabitEthernet 1/1 GigabitEthernet 1/2 GigabitEthernet 1/3 GigabitEthernet 1/4 # show interface 10GigabitEthernet 1/1-4 statistics discards Interface Rx Discards Tx Discards...
Page 92: Qos Statistics
SOLTECH USER GUIDE Switch SFC4100AB 6.3.2.3. QoS Statistics WEB MENU Monitor>Ports>QoS Statistics This page provides statistics for the different queues for all switch ports. Queuing Counters Object Description Port The logical port. Click number will navigate to the Detailed Statistics.
Page 93 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI MONITOR Queuing Counters  #show interface GigabitEthernet 1/1-4 statistics priority GigabitEthernet 1/1 Rx Priority queue Tx Priority queue ------------------------------------------ ------------------- ------------------ Priority 0 Priority 1 Priority 2 Priority 3 Priority 4 Priority 5...
Page 94 SOLTECH USER GUIDE Switch SFC4100AB Priority 4 Priority 5 Priority 6 Priority 7 10GigabitEthernet 1/2 Rx Priority queue Tx Priority queue ------------------------------------------ ------------------- ------------------ Priority 0 Priority 1 Priority 2 Priority 3 Priority 4 Priority 5 Priority 6 Priority 7...
Page 95: Qcl Status
SOLTECH USER GUIDE Switch SFC4100AB 6.3.2.4. QCL Status WEB MENU Monitor>Ports>QCL Status This page shows the QCL status by different QCL users. Each row describes the QCE that is defined. It is a conflict if a specific QCE is not applied to the hardware due to hardware limitations. The maximum number of QCEs is 256 on each switch.
Page 96 SOLTECH USER GUIDE Switch SFC4100AB : Click to release the resources required to add QCL entry, in case the conflict status for any QCL entry is 'yes'. : Click to refresh the page.
Page 97: Detailed Statistics
SOLTECH USER GUIDE Switch SFC4100AB 6.3.2.5. Detailed Statistics WEB MENU Monitor>Ports>Detailed Statistics This page provides detailed traffic statistics for a specific switch port. (Use the port select box to select which switch port details to display.) Detailed Port Statistics Port n...
Page 98 SOLTECH USER GUIDE Switch SFC4100AB Rx Filtered The number of received frames filtered by the forwarding process. Tx Drops The number of frames dropped due to output buffer congestion. Tx Late/Exc. The number of frames dropped due to excessive or late collisions.
Page 99 SOLTECH USER GUIDE Switch SFC4100AB Rx 128-255: Tx 128-255: Rx 256-511: Tx 256-511: Rx 512-1023: 130 Tx 512-1023: Rx 1024-1526: 0 Tx 1024-1526: Rx 1527- Tx 1527- Rx Priority 0: 2693 Tx Priority 0: Rx Priority 1: Tx Priority 1:...
Page 100: Dhcp
SOLTECH USER GUIDE Switch SFC4100AB 6.4. DHCP 6.4.1. DHCP Configuration 6.4.1.1. Server Mode WEB MENU Configuration>DHCP>Server>Mode This page configures global mode and VLAN mode to enable/disable DHCP server per system and per VLAN. DHCP Server Mode Configuration Global Mode Object...
Page 101 SOLTECH USER GUIDE Switch SFC4100AB Buttons : Click to add a new VLAN range. : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 102 SOLTECH USER GUIDE Switch SFC4100AB • Disable EXAMPLE CLI CONFIGURATION Global Mode   Mode • Disable (config)# no ip dhcp server • Enable (config)# ip dhcp server VLAN Mode   Add VLAN Range • Enable (config)# interface vlan <vlan_list>...
Page 103: Server Excluded Ip
SOLTECH USER GUIDE Switch SFC4100AB 6.4.1.2. Server Excluded IP WEB MENU Configuration>DHCP>Server>Excluded IP This page configures excluded IP addresses. DHCP server will not allocate these excluded IP addresses to DHCP client. DHCP Server Excluded IP Configuration Excluded IP Address Object Description Define the IP range to be excluded IP addresses.
Page 104 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Excluded IP Address   Add IP Range • IP Range (config)# ip dhcp excluded-address <ipv4_addr> <ipv4_addr> (config)# ip dhcp excluded-address 192.168.10.1 192.168.10.101 (config)# ip dhcp excluded-address 192.168.10.103 192.168.10.130...
Page 105: Server Pool
SOLTECH USER GUIDE Switch SFC4100AB 6.4.1.3. Server Pool WEB MENU Configuration>DHCP>Server>Pool This page manages DHCP pools. According to the DHCP pool, DHCP server will allocate IP address and deliver configuration parameters to DHCP client. DHCP Server Pool Configuration Pool Setting...
Page 106 SOLTECH USER GUIDE Switch SFC4100AB DHCP Pool Configuration Pool Object Description Name Select a pool by pool name. Setting Object Description Pool Name Display the selected pool name. Specify which type of the pool is. Network: the pool defines a pool of IP addresses to service more than Type one DHCP client.
Page 107 SOLTECH USER GUIDE Switch SFC4100AB Specify lease time that allows the client to request a lease time for the IP Lease Time address.(If all are 0's, then it means the lease time is infinite.) Specify domain name that client should use when resolving hostname Domain Name via DNS.
Page 108 SOLTECH USER GUIDE Switch SFC4100AB • Name  DHCP Pool Configuration  Type • Network...
Page 109 SOLTECH USER GUIDE Switch SFC4100AB DHCP Server Pool Configuration   Type • Network EXAMPLE CLI CONFIGURATION DHCP Server Pool Configuration   Add New Pool • Name (config)# ip dhcp pool <word32> (config)# ip dhcp pool DHCP_TEST  DHCP Pool Configuration ...
Page 110: Snooping
SOLTECH USER GUIDE Switch SFC4100AB 6.4.1.4. Snooping WEB MENU Configuration>DHCP>Snooping Configure DHCP Snooping on this page. DHCP Snooping Configuration Object Description Indicates the DHCP snooping mode operation. Enabled: Enable DHCP snooping mode operation. When DHCP snooping mode operation is enabled, the DHCP request messages will...
Page 111 SOLTECH USER GUIDE Switch SFC4100AB • Disable (Default) • Enable Port Mode Configuration   Mode • Trusted (Default)
Page 112 SOLTECH USER GUIDE Switch SFC4100AB • Untrusted EXAMPLE CLI CONFIGURATION DHCP Snooping Configuration   Snooping Mode • Disable (Default) (config)# no ip dhcp snooping • Enable (config)# ip dhcp snooping Port Mode Configuration   Mode • Trusted (Default) (config)# interface 10GigabitEthernet/GigabitEthernet <port_type_list>...
Page 113: Dhcp Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.4.2. DHCP Monitor 6.4.2.1. Server Statistics WEB MENU Monitor>DHCP>Server>Statistics This page displays the database counters and the number of DHCP messages sent and received by DHCP server. DHCP Server Statistics Database Counters Object Description Pool Number of pools.
Page 114 SOLTECH USER GUIDE Switch SFC4100AB DHCP Message Received Counters Object Description OFFER Number of DHCP OFFER messages sent. Number of DHCP ACK messages sent. Number of DHCP NAK messages sent. Buttons Auto-refresh : Check this box to refresh the page automatically.
Page 115 SOLTECH USER GUIDE Switch SFC4100AB Automatic Manual Expired ========================= Message Received Counters ========================= DISCOVER REQUEST DECLINE RELEASE INFORM ========================= Message Sent Counters ========================= OFFER =========================...
Page 116: Server Binding
SOLTECH USER GUIDE Switch SFC4100AB 6.4.2.2. Server Binding WEB MENU Monitor>DHCP>Server>Binding This page displays bindings generated for DHCP clients. DHCP Server Binding IP Binding IP Address Object Description IP address allocated to DHCP client. Click IP navigate to the detailed page.
Page 117 SOLTECH USER GUIDE Switch SFC4100AB DHCP Server Binding IP Data WEB MENU Monitor>DHCP>Server>Binding This page displays the detailed data of a binding. DHCP Server Binding IP Data Binding Object Description IP address of the selected binding. Binding IP Data Object Description IP address allocated to DHCP client.
Page 118 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Monitor>DHCP>Server>Binding WEB MENU Monitor>DHCP>Server>Binding>Click IP EXAMPLE CLI MONITOR DHCP Server Binding IP  # show ip dhcp server binding IP: 192.168.10.102 ---------------------------------------------- State is committed Binding type is automatic Pool name is DHCP_TEST Server ID is 192.168.10.101...
Page 119: Server Declined Ip
SOLTECH USER GUIDE Switch SFC4100AB 6.4.2.3. Server Declined IP WEB MENU Monitor>DHCP>Server>Declined IP This page displays declined IP addresses. DHCP Server Declined IP Declined IP Address Object Description Declined IP List of IP addresses declined. Buttons Auto-refresh : Check this box to refresh the page automatically.
Page 120: Snooping Table
SOLTECH USER GUIDE Switch SFC4100AB 6.4.2.4. Snooping Table WEB MENU Monitor>DHCP>Snooping Table This page display the dynamic IP assigned information after DHCP Snooping mode is disabled. All DHCP clients obtained the dynamic IP address from the DHCP server will be listed in this table except for local VLAN interface IP addresses.
Page 121 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Monitor>DHCP>Snooping Table EXAMPLE CLI MONITOR Dynamic DHCP Snooping Table  # show ip dhcp snooping table Entry ID MAC Address : 00-21-6d-05-f0-5c VLAN ID Source Port : GigabitEthernet 1/1 IP Address : 192.168.10.102...
Page 122: Detailed Statistics
SOLTECH USER GUIDE Switch SFC4100AB 6.4.2.5. Detailed Statistics WEB MENU Monitor>DHCP>Detailed Statistics This page provides statistics for DHCP snooping. Dynamic Detailed Statistics Port n Object Description Rx and Tx Discover The number of discover packets received and transmitted. Rx and Tx Offer The number of offer packets received and transmitted.
Page 123 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Monitor>DHCP>Detailed Statistics DHCP Detailed Statistics Port 1(Client/port1)  EXAMPLE CLI MONITOR DHCP Detailed Statistics Port 1(Client/port1)  # show ip dhcp detailed statistics client/combined/normal-forward/relay/server/snooping interface 10GigabitEthernet/GigabitEthernet <port_type_list> # show ip dhcp detailed statistics client interface GigabitEthernet 1/1...
Page 124: Security
SOLTECH USER GUIDE Switch SFC4100AB 6.5. SECURITY 6.5.1. Switch Configuration The product provides authentication capabilities for both local administrators and users, granting permissions based on account-specific privilege levels. User Accounts and Permissions: Multiple users can be created on the switch, identified by their usernames and corresponding privilege levels.
Page 125 SOLTECH USER GUIDE Switch SFC4100AB Object Description User Name The name identifying the user. This is also a link to Add/Edit User. The privilege level of the user. The allowed range is 0 to 15. If the privilege level value is 15, it can access all groups, i.e. that is granted the fully control of the device.
Page 126 SOLTECH USER GUIDE Switch SFC4100AB administrator account, privilege level 10 for a standard user account and privilege level 5 for a guest account. Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 127 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Users Configuration   Add New User • Add User / Edit User (config)# username <word31> privilege <0-15> password unencrypted (config)# username test privilege 10 password unencrypted #: Please input a new password (plain): <line31>...
Page 128: Privilege Levels
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.2. Privilege Levels WEB MENU Configuration>Security>Switch>Privilege Level This page provides an overview of the privilege levels. Privilege Level Configuration Object Description The name identifying the privilege group. In most cases, a privilege level group consists of a single module, but a few of them contains more than one.
Page 129: Privilege Level
SOLTECH USER GUIDE Switch SFC4100AB Web- Users, Privilege Levels and everything in Maintenance. Debug Only present in CLI. Every group has an authorization Privilege level for the following sub groups: configuration read-only, configuration/execute read-write, status/statistics read- Privilege Level only, status/statistics read-write (e.g. for clearing of statistics).
Page 130 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Privilege Level Configuration  (config)# web privilege group {1} level {2} <0-15> (config)# web privilege group DDMI level configRoPriv 6 Aggregation DDMI DHCP DHCPv6_Client Debug Diagnostics ERPS ETH_LINK_OAM Green_Ethernet IPMC_Snooping LACP LLDP...
Page 131: Auth Method
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.3. Auth Method WEB MENU Configuration>Security>Switch>Auth Method Authentication Method Configuration Object Description Authentication Method You can configure how a user is authenticated when they log into the Configuration switch via one of the management client interfaces.
Page 132 SOLTECH USER GUIDE Switch SFC4100AB granted access to CLI commands according to his privilege level. Authorize all commands with a privilege level higher than or equal to Cmd Lvl this level. Valid values are in the range 0 to 15.
Page 133 SOLTECH USER GUIDE Switch SFC4100AB Accounting Method Configuration  EXAMPLE CLI CONFIGURATION Authentication Method Configuration  (config)# aaa authentication login {1} {2} (config)# aaa authentication login console tacacs radius local (config)# aaa authentication login ssh tacacs local (config)# aaa authentication login http radius tacacs local...
Page 134: Telnet
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.4. Telnet WEB MENU Configuration>Security>Switch>Telnet Configure Telnet on this page. Telnet Configuration Object Description Indicates the Telnet mode operation. Mode Enabled: Enable Telnet mode operation. Disabled: Disable Telnet mode operation. Buttons : Click to apply changes.
Page 135: Ssh
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.5. SSH WEB MENU Configuration>Security>Switch>SSH Configure SSH on this page. SSH Configuration Object Description Indicates the SSH mode operation. Mode Enabled: Enable SSH mode operation. Disabled: Disable SSH mode operation. Buttons : Click to apply changes.
Page 136: Https
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.6. HTTPS WEB MENU Configuration>Security>Switch>HTTPS This page allows you to configure the HTTPS settings and maintain the current certificate on the switch. HTTPS Configuration Object Description Indicate the HTTPS mode operation. Enabled: Enabled HTTPS mode operation.
Page 137 SOLTECH USER GUIDE Switch SFC4100AB Display the current status of certificate on the switch. Switch secure HTTP certificate is presented. Certificate Status Switch secure HTTP certificate is not presented. Switch secure HTTP certificate is generating. Buttons : Click to apply changes.
Page 138 SOLTECH USER GUIDE Switch SFC4100AB  Certificate Maintain • None(default) EXAMPLE CLI CONFIGURATION HTTPS Configuration   Mode • Enable(default) (config)# ip http secure-server • Disable (config)# no ip http secure-server  Automatic Redirect • Enable(default) (config)# ip http secure-redirect •...
Page 139: Access Management
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.7. Access Management WEB MENU Configuration>Security>Switch>Access Management Configure access management table on this page. The maximum number of entries is 16. Access Management Configuration Object Description Indicates the access management mode operation. Mode Enabled: Enable access management mode operation.
Page 140 SOLTECH USER GUIDE Switch SFC4100AB • Disable(default) • Enable  Add New Entry EXAMPLE CLI CONFIGURATION Access Management Configuration   Mode • Disable(default) (config)# no access management • Enable (config)# access management  Add New Entry (config)# access management <1-16> <1-4095> <ipv4_addr> to <ipv4_addr> [1] (config)# access management 1 1 192.168.10.1 to 192.168.10.135 web telnet...
Page 141: Snmp
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8. SNMP 6.5.1.8.1. System WEB MENU Configuration>Security>SNMP>System Configure SNMP on this page SNMP System Configuration Object Description Indicates the SNMP mode operation. Mode Enabled: Enable SNMP mode operation. Disabled: Disable SNMP mode operation. Indicates the SNMP supported version.
Page 142 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>SNMP>System SNMP System Configuration   Mode • Disable(default) • Enable  Version...
Page 143 SOLTECH USER GUIDE Switch SFC4100AB  Community(v1/v2c) • Read Community • Write Community  Engine ID(v3)  Secure OS products EXAMPLE CLI CONFIGURATION  SNMP System Configuration  Mode • Disable(default) (config)# no snmp-server...
Page 144 SOLTECH USER GUIDE Switch SFC4100AB • Enable (config)# snmp-server  Version (config)# snmp-server version {1} (config)# snmp-server version v1 v1 v2c v3  Community(v1/v2c) • Read Community (config)# snmp-server community v2c <word255> ro (config)# snmp-server community v2c test123 ro •...
Page 145: Trap
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8.2. Trap WEB MENU Configuration>Security>SNMP>Trap Configure SNMP trap on this page. Trap Configuration Global Setting Object Description Indicates the trap mode operation. Mode Enabled: Enable SNMP trap mode operation. Disabled: Disable SNMP trap mode operation.
Page 146 SOLTECH USER GUIDE Switch SFC4100AB Buttons : Click to add a new user. (Clicking on the button will open the SNMP Trap Configuration window.) : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 147 SOLTECH USER GUIDE Switch SFC4100AB the first character must be an alpha character, and the first and last characters must not be a dot or a dash. Indicates the SNMP trap destination port. SNMP Agent will send SNMP Trap Destination port message via this port, the port range is 1~65535.
Page 148 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>SNMP>Trap Global Setting   Mode • Disable(default) • Enable Trap Destination Configurations   Add New Entry • Use SNMP v1...
Page 149 SOLTECH USER GUIDE Switch SFC4100AB • Use SNMP v2c EXAMPLE CLI CONFIGURATION Global Setting   Mode • Disable(default) (config)# no snmp-server trap • Enable (config)# snmp-server trap...
Page 150 SOLTECH USER GUIDE Switch SFC4100AB Trap Destination Configurations   Add New Entry • Use SNMP v1 (config)# snmp-server host <word32> (config)# snmp-server host TEST-123 (config-snmps-host)# (config-snmps-host)# shutdown (config-snmps-host)# version {v1/v2/v3} <word255> (config-snmps-host)# version v1 def_trap_pwd (config-snmps-host)# host { <v_ipv4_ucast> | <v_word> } [ <udp_port> ] [ traps | informs ] (config-snmps-host)# host 192.168.10.130 162...
Page 151: Communities
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8.3. Communities WEB MENU Configuration>Security>SNMP>Communities Configure SNMPv3 community table on this page. The entry index key is Community. SNMPv3 Community Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 152 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION SNMPv3 Community Configuration   Add New Entry (config)# snmp-server community v3 <v3_comm> [<v_ipv4_addr> <v_ipv4_netmask>] (config)# snmp-server community v3 def_ro_pwd 192.168.10.0 255.255.255.0 (config)# snmp-server community v3 def_rw_pwd 192.168.10.0 255.255.255.0...
Page 153: Users
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8.4. Users WEB MENU Configuration>Security>SNMP>Users Configure SNMPv3 user table on this page. The entry index keys are Engine ID and User Name. SNMPv3 User Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 154 SOLTECH USER GUIDE Switch SFC4100AB A string identifying the privacy password phrase. The allowed string length is Privacy Password 8 to 32, and the allowed content is ASCII characters from 33 to 126. Buttons : Click to add a new user entry.
Page 155 SOLTECH USER GUIDE Switch SFC4100AB SNMPv3 User Configuration   Add New Entry • NoAuth, NoPriv (config)# snmp-server user <username> engine-id <engineID> (config)# snmp user TEST-123 engine-id 800007e5017f000001 • Auth, NoPriv (config)# snmp-server user <username> engine-id <engineID> [ { sha | sha224 | sha256 | sha384 | sha512 } <auth_passwd>...
Page 156: Groups
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8.5. Groups WEB MENU Configuration>Security>SNMP>Groups Configure SNMPv3 group table on this page. The entry index keys are Security Model and Security Name. SNMPv3 Group Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 157 SOLTECH USER GUIDE Switch SFC4100AB • (Security Name influenced by Communities) • (Security Name influenced by Users) EXAMPLE CLI CONFIGURATION SNMPv3 Group Configuration   Add New Entry • (Security Name influenced by Communities) (config)# snmp-server security-to-group model { v1 | v2c | v3 } name <security_name>...
Page 158: Views
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8.6. Views WEB MENU Configuration>Security>SNMP>Views Configure SNMPv3 view table on this page. The entry index keys are View Name and OID Subtree. SNMPv3 View Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 159 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION SNMPv3 Group Configuration   Add New Entry • test_view(excluded SysName) (config)# snmp-server view <view_name> <oid_subtree> { include | exclude } (config)# snmp-server view test_view .1 include (config)# snmp-server view test_view .1.3.6.1.2.1.1.5.0 exclude...
Page 160: Access
SOLTECH USER GUIDE Switch SFC4100AB 6.5.1.8.7. Access WEB MENU Configuration>Security>SNMP>Access Configure SNMPv3 access table on this page. The entry index keys are Group Name, Security Model and Security Level. SNMPv3 Access Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 161 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION SNMPv3 Access Configuration   Add New Entry • default_rw_group(test_view) EXAMPLE CLI CONFIGURATION SNMPv3 Access Configuration   Add New Entry • default_rw_group(test_view) (config)# snmp-server access <group_name> model { v1 | v2c | v3 | any } level { auth | noauth | priv } [ read <view_name>...
Page 162: Network Configuration
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2. Network Configuration 6.5.2.1. Limit Control WEB MENU Configuration>Security>Network>Limit Control This page allows you to configure the Port Security Limit Control system and port settings. You can set up port security aging for each system.
Page 163 SOLTECH USER GUIDE Switch SFC4100AB Port Security Limit Control Configuration System Configuration Object Description Indicates if Limit Control is globally enabled or disabled on the switch. Mode If globally disabled limit checks and corresponding actions are disabled. If checked, secured MAC addresses are subject to aging as discussed under Aging Enabled Aging Period.
Page 164 SOLTECH USER GUIDE Switch SFC4100AB switch, 3) Click the Reopen button. Trap&Shutdown If Limit + 1 MAC addresses is seen on the port, both the "Trap" and the "Shutdown" actions described above will be taken. This column shows the current state of the port as seen from the Limit Control's point of view.
Page 165 SOLTECH USER GUIDE Switch SFC4100AB • Disabled • Enabled  Aging Period (10 ~ 9,999,999 seconds) Port Configuration   Mode • Disabled • Enabled  Limit (1 ~ 1024 MAC address)
Page 166 SOLTECH USER GUIDE Switch SFC4100AB  Action • None | Trap | Shutdown | Trap&Shutdown EXAMPLE CLI CONFIGURATION System Configuration   Mode • Disabled (config)# no port-security • Enabled (config)# port-security  Aging Enable • Disabled (config)# no port-security aging •...
Page 167 SOLTECH USER GUIDE Switch SFC4100AB (config)# port-security aging time <v_10_to_9999999> (config)# port-security aging time 9999999 Port Configuration   Mode • Disabled (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# no port-security • Enabled (config)# interface ( <port_type> [ <plist> ] )
Page 168: Acl
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.2. ACL ACL (Access Control List) is composed of ACE (Access Control Entry) entries that specify individual users or groups allowed access to specific traffic entities such as processes or programs. ACE parameters vary depending on the selected frame type.
Page 169: Ports
SOLTECH USER GUIDE Switch SFC4100AB ACEs are configured with multiple parameters, which vary depending on the selected frame type. Incoming ports must select the next frame type chosen for ACE. Different parameter options are displayed based on the chosen frame type. Supported frame types include: •...
Page 170 SOLTECH USER GUIDE Switch SFC4100AB Select which rate limiter to apply on this port. The allowed values are Rate Limiter ID Disabled or the values 1 through 16. The default value is "Disabled". Select which port frames are redirected on. The allowed values are Disabled Port Redirect or a specific port number.
Page 171 SOLTECH USER GUIDE Switch SFC4100AB  Rate Limiter ID • Disabled | 1~16  Port Redirect (Need Action Deny) • Disabled(default) | Port Number  Mirror • Disabled(default) | Enabled  Logging • Disabled(default) | Enabled  Shutdown • Disabled(default) | Enabled...
Page 172 SOLTECH USER GUIDE Switch SFC4100AB  State • Enabled(default) | Disabled EXAMPLE CLI CONFIGURATION ACL Ports Configuration   Policy ID • 0~255(default 0) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# access-list policy <policy_id>...
Page 173 SOLTECH USER GUIDE Switch SFC4100AB (config-if)# access-list redirect interface { <port_type> <port_type_id> | ( <port_type> [ <port_type_list> ] ) } (config-if)# access-list redirect interface GigabitEthernet 1/4  Mirror • Disabled(default) | Enabled (config-if)# no access-list mirror (config-if)# access-list mirror ...
Page 174: Rate Limiters
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.2.2. Rate Limiters WEB MENU Configuration>Security>Network>ACL>Rate Limiters Configure the rate limiter for the ACL of the switch. ACL Ports Configuration Object Description The rate limiter ID for the settings contained in the same row and its range is Rate Limiter ID 1 to 16.
Page 175 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION ACL Rate Limiter Configuration   Rate • 0 ~ 5,000,000pps or 0 ~ 10,000,000kbps (config)# access-list rate-limiter [ <rate_limiter_list> ] { 10pps <pps10_rate> | 25kbps <kpbs25_rate> } (config)# access-list rate-limiter <1-16> 10pps <0-500000>...
Page 176: Access Control List Configuration
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.2.3. Access Control List Configuration WEB MENU Configuration>Security>Network>ACL>Access Control List This page shows the Access Control List (ACL), which is made up of the ACEs defined on this switch. Each row describes the ACE that is defined. The maximum number of ACEs is 512 on each switch.
Page 177: Ace Configuration
SOLTECH USER GUIDE Switch SFC4100AB Counter Indicates the number of times the ACE was hit by a frame. Modification You can modify each ACE in the table using the following buttons: Inserts a new ACE before the current row. Buttons...
Page 178 SOLTECH USER GUIDE Switch SFC4100AB Specific: If you want to filter a specific policy with this ACE, choose this value. Two field for entering an policy value and bitmask appears. When "Specific" is selected for the policy filter, you can enter a specific Policy Value policy value.
Page 179: Tag Priority
SOLTECH USER GUIDE Switch SFC4100AB source MAC address. The legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that hits this ACE matches this SMAC value DMAC Filter Specify the destination MAC filter for this ACE.
Page 180 SOLTECH USER GUIDE Switch SFC4100AB Target IP Address When "Host" or "Network" is selected for the target IP filter, you can enter a specific target IP address in dotted decimal notation. Target IP Mask When "Network" is selected for the target IP filter, you can enter a specific target IP mask in dotted decimal notation.
Page 181 SOLTECH USER GUIDE Switch SFC4100AB OFFSET) field for an IPv4 frame. IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater than zero must not be able to match this entry. IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater than zero must be able to match this entry.
Page 182 SOLTECH USER GUIDE Switch SFC4100AB & sipv6_bitmask] (last 32 bits). For example, if the SIPv6 address is 2001::3 and the SIPv6 bitmask is 0xFFFFFFFE(bit 0 is "don't-care" bit), then SIPv6 address 2001::2 and 2001::3 are applied to this rule. Hop Limit Specify the hop limit settings for this ACE.
Page 183 SOLTECH USER GUIDE Switch SFC4100AB Range 0 to 65535. A frame that hits this ACE matches this TCP/UDP destination value. TCP FIN Specify the TCP "No more data from sender" (FIN) value for this ACE. TCP frames where the FIN field is set must not be able to match this entry.
Page 184 SOLTECH USER GUIDE Switch SFC4100AB : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. : Return to the previous page. EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>Network>ACL>Access Control List...
Page 185 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Example) Deny frames based on the source MAC address from PORT1. (config)# access-list ace <ace_id> [1] (config)# access-list ace 1 ingress interface GigabitEthernet 1/1 frame-type etype smac 00-21-6d-05-f0-5c action deny action dmac-type...
Page 186 SOLTECH USER GUIDE Switch SFC4100AB { <sportv4_tcp_start> [ to <sportv4_tcp_end> ] | any } ] [ dport { <dportv4_tcp_start> [ to <dportv4_tcp_end> ] | any } ] [ ip-flag [ ip-ttl { <ip_flag_tcp_ttl> | any } ] [ ip-options { <ip_flag_tcp_options> | any } ] [ ip-fragment { <ip_flag_tcp_fragment> | any } ] ] [ tcp- flag [ tcp-fin { <tcpv4_flag_fin>...
Page 187: Ip Source Guard
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.3. IP Source Guard 6.5.2.3.1. Configuration WEB MENU Configuration>Security>Network>IP Source Guard>Configuration This page provides IP Source Guard related configuration. IP Source Guard Configuration Object Description Mode of IP Source Enable the Global IP Source Guard or disable the Global IP Source Guard.
Page 188 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION IP Source Guard Configuration   Mode • Disable | Enable Port Mode Configuration   Mode • Disable | Enable  Max Dynamic Clients • 0 | 1 | 2 | Unlimited EXAMPLE CLI CONFIGURATION ...
Page 189 SOLTECH USER GUIDE Switch SFC4100AB • Disable | Enable (config)# no ip verify source (config)# ip verify source Port Mode Configuration   Mode • Disable | Enable (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1...
Page 190: Static Table
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.3.2. Static Table WEB MENU Configuration>Security>Network>IP Source Guard>Static Table This page shows the static IP Source Guard rules. The maximum number of rules is 112 on the switch. Static IP Source Guard Table Object Description Delete Check to delete the entry.
Page 191 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Static IP Source Guard Table   Add New Entry • Port | VLAN ID(Port VLAN) | IP Address | MAC address (config)# ip source binding interface <port_type> <in_port_type_id> <vlan_var> <ipv4_var> <mac_var>...
Page 192: Arp Inspection
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.4. ARP Inspection 6.5.2.4.1. Port Configuration WEB MENU Configuration>Security>Network>ARP Inspection>Port Configuration This page provides ARP Inspection related configuration. ARP Inspection Configuration Object Description Mode Enable the Global ARP Inspection or disable the Global ARP Inspection.
Page 193 SOLTECH USER GUIDE Switch SFC4100AB Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. : Click to translate all dynamic entries to static entries.
Page 194 SOLTECH USER GUIDE Switch SFC4100AB  Log Type • None | Deny | Permit | All EXAMPLE CLI CONFIGURATION ARP Inspection Configuration   Mode • Disable | Enable (config)# no ip arp inspection (config)# ip arp inspection Port Mode Configuration ...
Page 195 SOLTECH USER GUIDE Switch SFC4100AB (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# no ip arp inspection logging (config-if)# ip arp inspection logging { deny | permit | all } (config-if)# ip arp inspection logging deny...
Page 196: Vlan Configuration
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.4.2. VLAN Configuration WEB MENU Configuration>Security>Network>ARP Inspection>VLAN Configuration This page provides ARP Inspection related configuration. VLAN Mode Configuration Object Description Specify ARP Inspection is enabled on which VLANs. First, you have to enable the port setting on Port configuration.
Page 197 SOLTECH USER GUIDE Switch SFC4100AB • Log Type( None | Deny | Permit | All ) EXAMPLE CLI CONFIGURATION VLAN Mode Configuration   Add New Entry • VLAN ID(1~4095) (config)# ip arp inspection vlan <in_vlan_list> (config)# ip arp inspection vlan 4095 •...
Page 198: Static Table
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.4.3. Static Table WEB MENU Configuration>Security>Network>ARP Inspection>Static Table This page shows the static ARP Inspection rules. The maximum number of rules is 256 on the switch. Static ARP Inspection Table Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 199 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Static ARP Inspection Table   Add New Entry • Example (config)# ip arp inspection entry interface <port_type> <in_port_type_id> <vlan_var> <mac_var> <ipv4_var> (config)# ip arp inspection entry interface GigabitEthernet 1/4 1 00-21-6d-05-f0-5c...
Page 200: Dynamic Table
SOLTECH USER GUIDE Switch SFC4100AB 6.5.2.4.4. Dynamic Table WEB MENU Configuration>Security>Network>ARP Inspection>Dynamic Table Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic ARP Inspection Table contains up to 256 entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address.
Page 201: Aaa Configuration
SOLTECH USER GUIDE Switch SFC4100AB 6.5.3. AAA Configuration AAA allows for common server configurations including Timeout, Retransmit, Secret Key, NAS IP Address, NAS IPv6 Address, NAS Identifier, and Dead Time parameters. The software supports configuration of RADIUS and TACACS+ servers.
Page 202 SOLTECH USER GUIDE Switch SFC4100AB Global Configuration Object Description Timeout is the number of seconds, in the range 1 to 1000, to wait for a reply Timeout from a RADIUS server before retransmitting the request. Retransmit is the number of times, in the range 1 to 1000, a RADIUS request Retransmit is retransmitted to a server that is not responding.
Page 203 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>AAA>RADIUS Global Configuration   Timeout(3sec)  Retransmit(5times)  Deadtime(2minutes)  Key (Radius server secret key)  Add New Server...
Page 204 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Global Configuration   Timeout(3sec) (config)# radius-server timeout <seconds> (config)# radius-server timeout 3  Retransmit(5times) (config)# radius-server retransmit <retries> (config)# radius-server retransmit 5  Deadtime(2minutes) (config)# radius-server deadtime <minutes> (config)# radius-server deadtime 2 ...
Page 205: Tacacs
SOLTECH USER GUIDE Switch SFC4100AB 6.5.3.2. TACACS+ WEB MENU Configuration>Security>AAA>TACACS+ This page allows you to configure the TACACS+ servers. TACACS+ Server Configuration Global Configuration Object Description Timeout is the number of seconds, in the range 1 to 1000, to wait for a reply Timeout from a TACACS+ server before it is considered to be dead.
Page 206 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>AAA>TACACS+ Global Configuration   Timeout(3sec)  Deadtime(2minutes)  Key (Tacacs+ server secret key)  Add New Server EXAMPLE CLI CONFIGURATION  Global Configuration  Timeout(3sec) (config)# tacacs-server timeout <seconds>...
Page 207 SOLTECH USER GUIDE Switch SFC4100AB  Key (Tacacs+ server secret key) (config)# tacacs-server key [ <key> ] (config)# tacacs-server key tacacs11  Add New Server (config)# tacacs-server host <host_name> [ port <port> ] [ timeout <seconds> ] [ key <key> ]...
Page 208: Access Management Statistics Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.5.4. Access Management Statistics Monitor WEB MENU Monitor>Security>Access Management Statistics This page provides statistics for access management. Access Management Statistics Object Description Interface The interface type through which the remote host can access the switch.
Page 209 SOLTECH USER GUIDE Switch SFC4100AB Access Management Statistics: ----------------------------- HTTP Receive: Allow: Discard: HTTPS Receive: Allow: Discard: SNMP Receive: Allow: Discard: TELNET Receive: Allow: Discard: Receive: Allow: Discard:...
Page 210: Network Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.5.5. Network Monitor 6.5.5.1. Port Security 6.5.5.1.1. Switch WEB MENU Monitor>Security>Network>Port Security>Switch This page shows the Port Security status. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 211: Mac Count
SOLTECH USER GUIDE Switch SFC4100AB Each of the user modules has a column that shows whether that module has enabled Port Security or not. A '-' means that the corresponding user module Users is not enabled, whereas a letter indicates that the user module abbreviated by that letter (see Abbr) has enabled port security.
Page 212 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Monitor>Security>Network>Port Security>Switch Port Security Switch Status  EXAMPLE CLI MONITOR Port Security Switch Status  # show port-security switch [ interface ( <port_type> [ <v_port_type_list> ] ) ] # show port-security switch...
Page 213: Port
SOLTECH USER GUIDE Switch SFC4100AB 6.5.5.1.2. Port WEB MENU Monitor>Security>Network>Port Security>Port This page shows the MAC addresses secured by the Port Security module. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 214 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Monitor>Security>Network>Port Security>Switch Port Security Switch Status  EXAMPLE CLI MONITOR Port Security Switch Status  # show port-security port [ interface ( <port_type> [ <v_port_type_list> ] ) ] # show port-security port interface GigabitEthernet 1/1...
Page 215: Acl Status
SOLTECH USER GUIDE Switch SFC4100AB 6.5.5.2. ACL Status WEB MENU Monitor>Security>Network>ACL Status This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific ACE is not applied to the hardware due to hardware limitations. The maximum number of ACEs is 512 on each switch.
Page 216 SOLTECH USER GUIDE Switch SFC4100AB : The select box determines which ACL user is affected by clicking the buttons. EXAMPLE WEB MONITOR WEB MENU Monitor>Security>Network>ACL Status EXAMPLE CLI MONITOR ACL Status  # show access-list ace-status [ static ] [ link-oam ] [ loop-protect ] [ dhcp ] [ arp-...
Page 217: Arp Inspection
SOLTECH USER GUIDE Switch SFC4100AB 6.5.5.3. ARP Inspection WEB MENU Monitor>Security>Network>ARP Inspection Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic ARP Inspection Table contains up to 256 entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address.
Page 218: Ip Source Guard
SOLTECH USER GUIDE Switch SFC4100AB 6.5.5.4. IP Source Guard WEB MENU Monitor>Security>Network>IP Source Guard Entries in the Dynamic IP Source Guard Table are shown on this page. The Dynamic IP Source Guard Table is sorted first by port, then by VLAN ID, then by IP address, and then by MAC address.
Page 219: Aaa Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.5.6. AAA Monitor 6.5.6.1. RADIUS Overview WEB MENU Monitor>Security>AAA>RADIUS Overview This page provides an overview of the status of the RADIUS servers configurable on the Authentication configuration page. RADIUS Server Status Overview Object Description The RADIUS server number. Click to navigate to detailed statistics for this server.
Page 220: Radius Details
SOLTECH USER GUIDE Switch SFC4100AB 6.5.6.2. RADIUS Details WEB MENU Monitor>Security>AAA>RADIUS Details This page provides detailed statistics for a particular RADIUS server. RADIUS Authentication Statistics for Server #n Object Description RADIUS The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client Authentication MIB.
Page 221: Other Info
SOLTECH USER GUIDE Switch SFC4100AB This section contains information about the state of the server and the latest round-trip time. IP Address IP address and UDP port for the authentication server in question. Other Info The number of RADIUS Access-Reject packets (valid or invalid) State received from the server.
Page 222: Spanning Tree
SOLTECH USER GUIDE Switch SFC4100AB 6.6. SPANNING TREE 6.6.1. Spanning Tree Configuration 6.6.1.1. Bridge Setting WEB MENU Configuration>Spanning Tree>Bridge Setting This page allows you to configure STP system settings. The settings are used by all STP Bridge instances in the Switch .
Page 223 SOLTECH USER GUIDE Switch SFC4100AB Filtering Edge Port BPDU Control whether a port explicitly configured as Edge will disable itself upon reception of a BPDU. The port will enter the error-disabled state, and will be removed from the active Guard topology.
Page 224 SOLTECH USER GUIDE Switch SFC4100AB • Forward Delay(Default 15, 4~30sec) • Max Age (Default 20, 6~40sec) • Maximum Hop Count(Default 20, 6~40sec) • Transmit Hold Count(Default 6, 1~10sec)  Advanced Settings • Edge Port BPDU Filtering • Edge Port BPDU Guard •...
Page 225 SOLTECH USER GUIDE Switch SFC4100AB (config)# spanning-tree mst forward-time <fwdtime> (config)# spanning-tree mst forward-time 15 • Max Age (Default 20, 6~40sec) (config)# spanning-tree mst max-age <maxage> (config)# spanning-tree mst max-age 20 • Maximum Hop Count(Default 20, 6~40sec) (config)# spanning-tree mst max-hops <maxhops>...
Page 226: Msti Mapping
SOLTECH USER GUIDE Switch SFC4100AB 6.6.1.2. MSTI Mapping WEB MENU Configuration>Spanning Tree>MSTI Mapping This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. MSTI Configuration Configuration Identification Object Description...
Page 227 SOLTECH USER GUIDE Switch SFC4100AB Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. EXAMPLE WEB CONFIGURATION MSTI Configuration   Configuration Identification •...
Page 228 SOLTECH USER GUIDE Switch SFC4100AB • Configuration Name | Revision(0~65535) (config)# spanning-tree mst name <name> revision <v_0_to_65535> (config)# spanning-tree mst name MSTP1 revision 65535  MSTI Mapping • VLANs Mapped (config)# spanning-tree mst <instance> vlan <v_vlan_list> (config)# spanning-tree mst 1 vlan 1-10,4094...
Page 229: Msti Priorities
SOLTECH USER GUIDE Switch SFC4100AB 6.6.1.3. MSTI Priorities WEB MENU Configuration>Spanning Tree>MSTI Priorities This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. MSTI Configuration MSTI Priority Configuration Object...
Page 230 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION MSTI Configuration   MSTI Priority Configuration • MSTI(0-7) • Priority(Default 32768) (config)# spanning-tree mst <instance> priority <prio> (config)# spanning-tree mst 1 priority 0 (config)# spanning-tree mst 1 priority 61440...
Page 231: Cist Ports
SOLTECH USER GUIDE Switch SFC4100AB 6.6.1.4. CIST Ports WEB MENU Configuration>Spanning Tree>CIST Ports This page allows the user to inspect the current STP CIST port configurations, and possibly change them as well. This page contains settings for physical and aggregated ports.
Page 232 SOLTECH USER GUIDE Switch SFC4100AB If enabled, causes the port not to propagate received topology change notifications and topology changes to other ports. If set it can cause temporary loss of connectivity after changes in a spanning tree's active topology as a result of persistently incorrect learned Restricted TCN station location information.
Page 233 SOLTECH USER GUIDE Switch SFC4100AB  Priority • 0|16|32|48|64|80|96|112|128|144|160|176|192|208|224|240  Admin Edge • Non-Edge | Edge  Auto Edge • Enable | Disable  Restricted Role • Enable | Disable  Restricted TCN • Enable | Disable...
Page 234 SOLTECH USER GUIDE Switch SFC4100AB  BPDU Guard • Enable | Disable  Point-to-Point • Forced True | Forced False | Auto EXAMPLE CLI CONFIGURATION CIST Aggregated Port Configuration   CIST Normal Port Configuration  STP Enabled • Enable | Disable...
Page 235 SOLTECH USER GUIDE Switch SFC4100AB  Priority • 0|16|32|48|64|80|96|112|128|144|160|176|192|208|224|240 (config-stp-aggr)# spanning-tree mst 0 port-priority <prio> (config-stp-aggr)# spanning-tree mst 0 port-priority 128 (config-if)# spanning-tree mst 0 port-priority <prio> (config-if)# spanning-tree mst 0 port-priority 128  Admin Edge • Non-Edge | Edge...
Page 236 SOLTECH USER GUIDE Switch SFC4100AB  BPDU Guard • Enable | Disable (config-stp-aggr)# spanning-tree bpdu-guard (config-stp-aggr)# no spanning-tree bpdu-guard (config-if)# spanning-tree bpdu-guard (config-if)# no spanning-tree bpdu-guard  Point-to-Point • Forced True | Forced False | Auto (config-stp-aggr)# spanning-tree link-type point-to-point...
Page 237: Msti Ports
SOLTECH USER GUIDE Switch SFC4100AB 6.6.1.5. MSTI Ports WEB MENU Configuration>Spanning Tree>MSTI Ports This page allows the user to inspect the current STP MSTI port configurations, and possibly change them as well. An MSTI port is a virtual port, which is instantiated separately for each active CIST (physical) port for each MSTI instance configured on and applicable to the port.
Page 238 SOLTECH USER GUIDE Switch SFC4100AB MSTn MSTI Port Configuration MSTI Aggregated Ports Configuration MSTI Normal Ports Configuration Object Description Port The switch port number of the corresponding STP CIST (and MSTI) port. Controls the path cost incurred by the port. The Auto setting will set the path cost as appropriate by the physical link speed, using the 802.1D recommended values.
Page 239 SOLTECH USER GUIDE Switch SFC4100AB • Auto | Specific(1~200,000,000)  Priority • 0|16|32|48|64|80|96|112|128|144|160|176|192|208|224|240 EXAMPLE CLI CONFIGURATION  MSTI Port Configuration • Select MSTI mst <instance> (CIST=0, MSTI1=1, MSTI2=2, …, MSTI7=7) MSTn MSTI Port Configuration  MSTI Aggregated Ports Configuration ...
Page 240 SOLTECH USER GUIDE Switch SFC4100AB (config-stp-aggr)# spanning-tree mst 1 cost 200000000 (config)# interface ( <port_type> [ <plist> ] ) (config)# interface * (config-if)# spanning-tree mst <instance> cost { <cost> | auto } (config-if)# spanning-tree mst 1 cost auto (config-if)# spanning-tree mst 1 cost 200000000 ...
Page 241: Spanning Tree Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.6.2. Spanning Tree Monitor 6.6.2.1. Bridge Status WEB MENU Monitor>Spanning Tree>Bridge Status This page provides a status overview of all STP bridge instances. The displayed table contains a row for each STP bridge instance, where the column displays the following...
Page 242 SOLTECH USER GUIDE Switch SFC4100AB STP Detailed Bridge Status Object Description STP Bridge Status This entry shows the state of the STP bridge instance. Bridge Instance The Bridge instance - CIST, MST1, ... Bridge ID The Bridge ID of this Bridge instance.
Page 243 SOLTECH USER GUIDE Switch SFC4100AB WEB MENU Monitor>Spanning Tree>Bridge Status STP Bridges  When you click on MSTI, the STP Detailed Bridge Status window will open. STP Detailed Bridge Status  CIST Ports & Aggregations State  EXAMPLE CLI MONITOR STP Bridges ...
Page 244 SOLTECH USER GUIDE Switch SFC4100AB Port Port Role State Pri PathCost Edge P2P Uptime --------- -------------- ---------- --- -------- ---- --- ------------- Gi 1/2 DesignatedPort Forwarding 128 20000 Yes Yes 0d 01:32:52 MSTI1 Bridge STP Status Bridge ID : 32769.00-21-6D-00-00-00 Root ID : 32769.00-21-6D-00-00-00...
Page 245: Port Status
SOLTECH USER GUIDE Switch SFC4100AB 6.6.2.2. Port Status WEB MENU Monitor>Spanning Tree>Port Status This page displays the STP CIST port status for physical ports of the switch. STP Port Status Object Description Port The switch port number of the logical STP port.
Page 246 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI MONITOR STP Port Status  # show spanning-tree mst 0 int * Port Port Role State Pri PathCost Edge P2P Uptime ----- --------- -------------- ---------- --- -------- ---- --- ------------- CIST Gi 1/2...
Page 247: Port Statistics
SOLTECH USER GUIDE Switch SFC4100AB 6.6.2.3. Port Statistics WEB MENU Monitor>Spanning Tree>Port Statistics This page displays the STP port statistics counters of bridge ports in the switch. STP Statistics Object Description Port The switch port number of the logical STP port.
Page 248: Lldp
SOLTECH USER GUIDE Switch SFC4100AB 6.7. LLDP 6.7.1. LLDP Configuration 6.7.1.1. LLDP WEB MENU Configuration>LLDP>LLDP This page allows the user to inspect and configure the current LLDP interface settings. LLDP Configuration LLDP Parameters Object Description The switch periodically transmits LLDP frames to its neighbors for having the network Tx Interval discovery information up-to-date.
Page 249 SOLTECH USER GUIDE Switch SFC4100AB Tx only The switch will drop LLDP information received from neighbors, but will send out LLDP information. Disabled The switch will not send out LLDP information, and will drop LLDP information received from neighbors. Enabled The switch will send out LLDP information, and will analyze LLDP information received from neighbors.
Page 250 SOLTECH USER GUIDE Switch SFC4100AB • 2~10 times(4times)  Tx Delay • 1~8192 sec(2sec)  Tx Delay • 1~10 sec(2sec) LLDP Interface Configuration   Mode • Disabled | Enabled(default) | Rx Only | Tx Only  CDP aware •...
Page 251 SOLTECH USER GUIDE Switch SFC4100AB  Port Descr • Disabled | Enabled(default)  Sys Name • Disabled | Enabled(default)  Sys Descr • Disabled | Enabled(default)  Sys Capa • Disabled | Enabled(default)
Page 252 SOLTECH USER GUIDE Switch SFC4100AB  Mgmt Addr • Disabled | Enabled(default) EXAMPLE CLI CONFIGURATION LLDP Configuration  LLDP Parameters   Tx Interval • 5~32768 sec(30sec) (config)# lldp timer <val> (config)# lldp timer 30  Tx Hold • 2~10 times(4times) (config)# lldp holdtime <val>...
Page 253 SOLTECH USER GUIDE Switch SFC4100AB • 1~8192 sec(2sec) (config)# lldp transmission-delay <val> (config)# lldp transmission-delay 2  Tx Delay • 1~10 sec(2sec) (config)# lldp transmission-delay <val> (config)# lldp reinit 2 LLDP Interface Configuration   Mode • Disabled | Enabled(default) | Rx Only | Tx Only (config)# interface ( <port_type>...
Page 254 SOLTECH USER GUIDE Switch SFC4100AB  Sys Name • Disabled | Enabled(default) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# lldp tlv-select system-name  Sys Descr • Disabled | Enabled(default) (config)# interface ( <port_type> [ <plist> ] )
Page 255: Lldp-Med
SOLTECH USER GUIDE Switch SFC4100AB 6.7.1.2. LLDP-MED WEB MENU Configuration>LLDP>LLDP-MED This page allows you to configure the LLDP-MED. This function applies to VoIP devices which support LLDP-MED. LLDP-MED Configuration Fast Start Repeat Count Object Description Rapid startup and Emergency Call Service Location Identification Discovery of endpoints is a critically important aspect of VoIP systems in general.
Page 256 SOLTECH USER GUIDE Switch SFC4100AB in an LLDPDU. Only after an LLDP-MED Endpoint Device is detected, will an LLDP- MED capable Network Connectivity Device start to advertise LLDP-MED TLVs in outgoing LLDPDUs on the associated interface. The LLDP-MED application will...
Page 257: Map Datum
SOLTECH USER GUIDE Switch SFC4100AB represents ground level at the given latitude and longitude. Inside a building, 0.0 represents the floor level associated with ground level at the main entrance. The Map Datum is used for the coordinates given in these options: WGS84: (Geographical 3D) - World Geodesic System 1984, CRS Code 4327, Prime Meridian Name: Greenwich.
Page 258 SOLTECH USER GUIDE Switch SFC4100AB Room no. Room number - Example: 450F. Place type Place type - Example: Office. Postal community Postal community name - Example: Leonia. name P.O. Box Post office box (P.O. BOX) - Example: 12345. Additional code Additional code - Example: 1320300003.
Page 259: Application Type
SOLTECH USER GUIDE Switch SFC4100AB ID for the policy. This is auto generated and shall be used when selecting the policies Policy ID that shall be mapped to the specific interfaces. Intended use of the application types: 1. Voice - for use by dedicated IP Telephony handsets and other similar appliances supporting interactive voice services.
Page 260 SOLTECH USER GUIDE Switch SFC4100AB DSCP value to be used to provide Diffserv node behavior for the specified application type as defined in IETF RFC 2474. DSCP may contain one of 64 code point values (0 DSCP through 63). A value of 0 represents use of the default DSCP value as defined in RFC 2475.
Page 261: Lldp Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.7.2. LLDP Monitor 6.7.2.1. Neighbors WEB MENU Monitor>LLDP>Neighbors This page provides a status overview for all LLDP neighbors. LLDP Neighbor Information The displayed table contains a row for each interface on which an LLDP neighbor is detected. The columns hold the following information.
Page 262 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Monitor>LLDP>Neighbors LLDP Neighbor Information  EXAMPLE CLI CONFIGURATION LLDP Neighbor Information  # show lldp neighbors Local Interface : GigabitEthernet 1/8 Chassis ID : 00-21-6D-01-02-03 Port ID Port Description : GigabitEthernet 1/5...
Page 263: Lldp-Med Neighbors
SOLTECH USER GUIDE Switch SFC4100AB 6.7.2.2. LLDP-MED Neighbors WEB MENU Monitor>LLDP>LLDP-MED Neighbors This page provides a status overview of all LLDP-MED neighbors. LLDP-MED Neighbor Information The displayed table contains a row for each interface on which an LLDP neighbor is detected. This function applies to VoIP devices which support LLDP-MED.
Page 264 SOLTECH USER GUIDE Switch SFC4100AB particular end user. Capabilities include all of the capabilities defined for the previous Generic Endpoint Class (Class I), and are extended to include aspects related to media streaming. Example product categories expected to adhere to this class include (but are not limited to) Voice / Media Gateways, Conference Bridges, Media Servers, and similar.
Page 265 SOLTECH USER GUIDE Switch SFC4100AB Priority is the Layer 2 priority to be used for the specified application type. One of the Priority eight priority levels (0 through 7). DSCP is the DSCP value to be used to provide Diffserv node behavior for the specified DSCP application type as defined in IETF RFC 2474.
Page 266: Eee
SOLTECH USER GUIDE Switch SFC4100AB 6.7.2.3. EEE WEB MENU Monitor>LLDP>EEE By using EEE power savings can be achieved at the expense of traffic latency. This latency occurs due to that the circuits EEE turn off to save power, need time to boot up before sending traffic over the link. This time is called "wakeup time".
Page 267 SOLTECH USER GUIDE Switch SFC4100AB Green - Switch and link partner have agreed on wakeup times. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every 3 seconds. : Click to refresh the page. EXAMPLE WEB CONFIGURATION WEB MENU Monitor>LLDP>EEE...
Page 268: Port Statistics
SOLTECH USER GUIDE Switch SFC4100AB 6.7.2.4. Port Statistics WEB MENU Monitor>LLDP>Port Statistics This page provides an overview of all LLDP traffic. LLDP Global Counters Object Description Global Counters Global counters are counters that refer to the whole switch Clear global counters If checked the global counters are cleared when CLEAR is pressed.
Page 269 SOLTECH USER GUIDE Switch SFC4100AB the Chassis ID or Remote Port ID is not already contained within the table. Entries are removed from the table when a given interface's link is down, an LLDP shutdown frame is received, or when the entry ages out.
Page 270 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION  LLDP Global Counters LLDP Statistics Local Counters  # show lldp statistics LLDP global counters Neighbor entries was last changed at 1970-01-01T13:44:54+09:00 (90116 secs. ago). Total Neighbors Entries Added Total Neighbors Entries Deleted 22.
Page 271: Mep
SOLTECH USER GUIDE Switch SFC4100AB 6.8. MEP 6.8.1. MEP Configuration WEB MENU Configuration>MEP The Maintenance Entity Point instances are configured here. Maintenance Entity Point Object Description Delete This box is used to mark a MEP for deletion in next Save operation.
Page 272 SOLTECH USER GUIDE Switch SFC4100AB MEP Configuration This page allows the user to inspect and configure the current MEP Instance. Instance Data Object Description MEP Instance The ID of the MEP. Domain See help on MEP create WEB. Mode See help on MEP create WEB.
Page 273 SOLTECH USER GUIDE Switch SFC4100AB This is the IEEE Maintenance Domain Name and is only used in case of 'IEEE String' Domain Name format. This string can be empty giving Maintenance Domain Name Format 1 - Not present. This can be max 16 char.
Page 274 SOLTECH USER GUIDE Switch SFC4100AB The priority to be inserted as PCP bits in TAG (if any). In case of enable of Continuity Priority Check and Loss Measurement both implemented on SW based CCM, 'Priority' has to be the same.
Page 275 SOLTECH USER GUIDE Switch SFC4100AB Specific - OUI First - OUI Second The last received second value in the OS TLV OUI field. - OUI Third The last received third value in the OS TLV OUI field. - Sub-Type The last received value in the OS TLV Sub-Type field.
Page 276 SOLTECH USER GUIDE Switch SFC4100AB Fault Management - Instance 1 - MEP id 1 This page allows the user to inspect and configure the Fault Management of the current MEP Instance. Loop Back Object Description Loop Back based on transmitting/receiving LBM/LBR PDU can be enabled/disabled.
Page 277 SOLTECH USER GUIDE Switch SFC4100AB Selection of LBM PDU transmitted unicast or multi-cast. The unicast MAC will be Cast configured through 'Peer MEP' or 'Unicast Peer MAC'. To-wards MIP only unicast Loop Back is possible. This is only used if the 'Unicast MAC' is configured to all zero. The LBM unicast MAC Peer MEP will be taken from the 'Unicast Peer MAC' configuration of this peer.
Page 278 SOLTECH USER GUIDE Switch SFC4100AB This is only used if NOT configured to all zero. This will be used as the Link Trace Target Unicast MAC MAC. This is the only way to configure a MIP as Target MAC. This is the LTM PDU TTL value as described in Y.1731. This value is decremented each Time To Live time forwarded by a MIP.
Page 279 SOLTECH USER GUIDE Switch SFC4100AB Warning will be given if selected frame size exceeds the CPU RX frame MAX size Frame MIN Size is 64 Bytes. The 'empty' TEST PDU has the size of 12 bytes. In order to achieve the configured frame size a data TLV will be added with a pattern.
Page 280 SOLTECH USER GUIDE Switch SFC4100AB LOCK Object Description Insertion of LOCK signal (LCK PDU transmission) in client layer flows, can be Enable enable/disabled. Selecting the frame rate of LCK PDU. This is the inverse of transmission period as Frame Rate described in Y.1731.:...
Page 281 SOLTECH USER GUIDE Switch SFC4100AB Performance Monitor - Instance 1 - MEP id 1 You can use this page to inspect and configure the performance monitor of the current MEP instance.
Page 282 SOLTECH USER GUIDE Switch SFC4100AB Performance Monitoring Data Set Object Description When enabled this MEP instance will contribute to the 'PM Data Set' gathered by the Enable PM Session. Loss Measurement Object Description Loss Measurement initiator is enabled/disabled. Initiator is transmitting/receiving CCM or LMM/LMR or SLM/SLR/1SL PDUs - see 'Synthetic' and 'Ended'.
Page 283 SOLTECH USER GUIDE Switch SFC4100AB This is the interval in number of measurement intervals where the interval Frame Loss FLR Interval Ratio is calculated. This is the 'synthetic' LM measurement interval in milliseconds. This must be a whole number of the LM PDU transmission interval (inverse 'Rate'). This is the interval in time where the loss and FLR is calculated based on the counted number of SL OAM PDUs.
Page 284 SOLTECH USER GUIDE Switch SFC4100AB Maintenance Enable/disable of loss measurement availability maintenance. Loss Measurement Availability Status Object Description The number of measurements performed while the near end has been in the "Avail" Near Avail Count state. Far Avail Count The number of measurements performed while the far end has been in the "Avail" state.
Page 285 SOLTECH USER GUIDE Switch SFC4100AB FLR Threshold Signal Degraded frame loss ratio threshold in per mille. Bad Threshold Number of consecutive bad interval measurements required to set degrade state. Good Threshold Number of consecutive good interval measurements required to clear degrade state.
Page 286 SOLTECH USER GUIDE Switch SFC4100AB Av Delay last N The average delay of the last n packets - since last 'clear'. Delay Min. The minimum delay - since last 'clear'. Delay Max. The maximum delay - since last 'clear'. Av Delay-Var Tot The average total delay variation - since last 'clear'.
Page 287 SOLTECH USER GUIDE Switch SFC4100AB Delay Measurement Bins for IFDV A Measurement Bin is a counter that stores the number of delay measurements falling within a specified range, during a Measurement Interval. If the measurement threshold is 5000 us and the total number of Measurement Bins is four, we can give an example as follows.
Page 288: Erps
SOLTECH USER GUIDE Switch SFC4100AB 6.9. ERPS 6.9.1.1 ERPS Configuration WEB MENU Configuration>ERPS The ERPS instances are configured here. Ethernet Ring Protection Switching Object Description Delete This box is used to mark an ERPS for deletion in next Save operation.
Page 289 SOLTECH USER GUIDE Switch SFC4100AB Buttons : Click to add a new Protection group entry. : Click to refresh the page immediately. : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 290 SOLTECH USER GUIDE Switch SFC4100AB Guard timeout value to be used to prevent ring nodes from receiving outdated R-APS messages. Guard Time The period of the guard timer can be configured in 10 ms steps between 10 ms and 2 seconds, with a default value of 500 ms The Wait To Restore timing value to be used in revertive switching.
Page 291 SOLTECH USER GUIDE Switch SFC4100AB OK: State of West port is ok Port 1 SF: State of West port is Signal Fail Transmit APS The transmitted APS according to State Transition Tables in G.8032. Port 0 Receive APS The received APS on Port 0 according to State Transition Tables in G.8032.
Page 292: S-Ring
SOLTECH USER GUIDE Switch SFC4100AB 6.10. S-RING 6.10.1. S-Ring Configuration WEB MENU Configuration>S-Ring S-Ring is a protocol within the Ring Protocol that manages the Ring by determining whether packets transmitted from the 2nd Port of the Master node are received by the 1st Port.
Page 293 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>S-Ring S-Ring Configuration & Status   Mode • Disable | Slave | Master • 1st Port | 2nd Port • Example Configuration EXAMPLE CLI CONFIGURATION S-Ring Configuration & Status...
Page 294 SOLTECH USER GUIDE Switch SFC4100AB  Mode • Disable | Slave | Master  1st Port | 2nd Port  Robustness • 1~10 (config)# sring id <v_id> [ mode { disable | { master | slave } 1st-port <v_ingressPort> 2nd-port <v_egressPort> } ] [ robustness <v_robustnessValue> ]...
Page 295: Mac Table
SOLTECH USER GUIDE Switch SFC4100AB 6.11. MAC TABLE 6.11.1. MAC Table Configuration WEB MENU Configuration>MAC Table The MAC Address Table is configured on this page. Set timeouts for entries in the dynamic MAC Table and configure the static MAC table here.
Page 296 SOLTECH USER GUIDE Switch SFC4100AB The MAC table is sorted first by VLAN ID and then by MAC address. Object Description Delete Check to delete the entry. It will be deleted during the next save. VLAN ID The VLAN ID of the entry.
Page 297 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION Aging Configuration   Disable Automatic Aging (config)# mac address-table aging-time <v_0_10_to_1000000> (config)# mac address-table aging-time 0  Aging Time(Enable Automatic Aging | Aging Time 300) (config)# mac address-table aging-time <v_0_10_to_1000000> (config)# mac address-table aging-time 300 ...
Page 298: Mac Table Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.11.2. MAC Table Monitor WEB MENU Monitor>MAC Table Entries in the MAC Table are shown on this page. The MAC Table contains up to 8192 entries, and is sorted first by VLAN ID, then by MAC address.
Page 299 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Monitor>MAC Table MAC Address Table  EXAMPLE CLI CONFIGURATION MAC Address Table  # show mac address-table Type MAC Address Ports Static 00:21:6d:00:00:01 GigabitEthernet 1/3 Static 33:33:00:00:00:01 GigabitEthernet 1/1-4 10GigabitEthernet 1/1-4 CPU...
Page 300: Vlans
SOLTECH USER GUIDE Switch SFC4100AB 6.12. VLANS 6.12.1. VLAN Configuration WEB MENU Configuration>VLANs This page allows for controlling VLAN configuration on the switch. The page is divided into a global section and a per-port configuration section. Global VLAN Configuration Object Description This field shows the allowed Access VLANs, i.e.
Page 301 SOLTECH USER GUIDE Switch SFC4100AB 3. Discards all frames not classified to the Access VLAN 4. On egress all frames are transmitted untagged Trunk ports can carry traffic on multiple VLANs simultaneously, and are normally used to connect to other switches. Trunk ports have the following characteristics: 1.
Page 302 SOLTECH USER GUIDE Switch SFC4100AB If the port is configured to accept Tagged Only frames (see Ingress Acceptance below), frames without this TPID are dropped. S-Custom-Port: On egress, if frames must be tagged, they will be tagged with the custom S-tag.
Page 303: Vlan Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.12.2. VLAN Monitor 6.12.2.1. Membership WEB MENU Monitor>VLANs>Membership This page provides an overview of membership status of VLAN users. VLAN Membership Status for Combined users Object Description Various internal software modules may use VLAN services to configure VLAN memberships on the fly.
Page 304: Ports
SOLTECH USER GUIDE Switch SFC4100AB 6.12.2.2. Ports WEB MENU Monitor>VLANs>Ports This page provides VLAN Port Status. VLAN Port Status for Combined users Object Description Various internal software modules may use VLAN services to configure VLAN port configuration on the fly.
Page 305 SOLTECH USER GUIDE Switch SFC4100AB Since both users cannot win, this gives rise to a conflict, which is solved in a prioritized way. The Administrator has the least priority. Other software modules are prioritized according to their position in the drop-down list: The higher in the list, the higher priority.
Page 306: Qos
SOLTECH USER GUIDE Switch SFC4100AB 6.13. QOS 6.13.1. QoS Configuration 6.13.1.1. Port Classification WEB MENU Configuration>QoS>Port Classification This page allows you to configure the basic QoS Ingress Classification settings for all switch ports. QoS Ingress Port Classification Object Description Port The port number for which the configuration below applies.
Page 307 SOLTECH USER GUIDE Switch SFC4100AB Disabled: Use default CoS and DPL for tagged frames. Enabled: Use mapped versions of PCP and DEI for tagged frames. Click on the mode in order to configure the mode and/or mapping. Note: This setting has no effect if the port is VLAN unaware. Tagged frames received on VLAN unaware ports are always classified to the default CoS and DPL.
Page 308 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>QoS>Port Classification QoS Ingress Port Classification   • 0~7 (0 – The Lowest Priority)  • 0~3 (0 – Low drop probability)
Page 309 SOLTECH USER GUIDE Switch SFC4100AB  • 0~7 (0 - The Lowest Priority)  • 0~1 (0 – Low drop probability)  Tag Class • Disabled QoS Ingress Port Tag Classification Port n Tagged Frames Settings • Tag Classification ...
Page 310 SOLTECH USER GUIDE Switch SFC4100AB (PCP, DEI) to (QoS class, DP level) Mapping • QoS class  0~7 (0 - The Lowest Priority) • DP level  0~3 (0 – Low drop probability)
Page 311 SOLTECH USER GUIDE Switch SFC4100AB  DSCP Based • Enabled | Disabled  WRED Group • 1~3 ( WRED group...
Page 312 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION  QoS Ingress Port Classification  • 0~7 (0 – The Lowest Priority) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# qos cos <cos> (config-if)# qos cos 0 ...
Page 313 SOLTECH USER GUIDE Switch SFC4100AB  Tag Class • Disabled QoS Ingress Port Tag Classification Port n Tagged Frames Settings • Tag Classification  Disabled | Enabled (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# qos trust tag (PCP, DEI) to (QoS class, DP level) Mapping •...
Page 314: Port Policing
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.2. Port Policing WEB MENU Configuration>QoS>Port Policing This page allows you to configure the Policer settings for all switch ports. QoS Ingress Port Policers Object Description Port The port number for which the configuration below applies.
Page 315 SOLTECH USER GUIDE Switch SFC4100AB  Rate • 10-13128147(kbps, fps) or 1-13128(Mbps, kfps)  Unit • kbps, Mbps, fps, kfps  Flow Control • Enabled | Disabled...
Page 316 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION QoS Ingress Port Policers   Enable • Enabled | Disabled  Rate • 10-13128147(kbps, fps) or 1-13128(Mbps, kfps)  Unit • kbps, Mbps, fps, kfps  Flow Control • Enabled | Disabled (config)# interface ( <port_type>...
Page 317: Queue Policing
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.3. Queue Policing WEB MENU Configuration>QoS>Queue Policing This page allows you to configure the Queue Policer settings for all switch ports. QoS Ingress Queue Policers Object Description Port The port number for which the configuration below applies.
Page 318 SOLTECH USER GUIDE Switch SFC4100AB  Rate • 25-13128147(kbps) or 1-13128(Mbps)  Unit • kbps, Mbps...
Page 319 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION  QoS Ingress Queue Policers  Queue n (n, 0~7)  Enable (E) • Enabled | Disabled  Rate • 25-13128147(kbps) or 1-13128(Mbps)  Unit • kbps, Mbps (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# qos queue-policer queue <queue>...
Page 320: Port Scheduler
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.4. Port Scheduler WEB MENU Configuration>QoS>Port Scheduler This page provides an overview of QoS Egress Port Schedulers for all switch ports. QoS Egress Port Schedulers Object Description The logical port for the settings contained in the same row.
Page 321 SOLTECH USER GUIDE Switch SFC4100AB QoS Egress Port Schedulers and Shapers Port n Object Description Controls how many of the queues are scheduled as strict and how many are scheduled Scheduler Mode as weighted on this switch port. Queue Shaper Enable Controls whether the queue shaper is enabled for this queue on this switch port.
Page 322 SOLTECH USER GUIDE Switch SFC4100AB QoS Egress Port Schedulers and Shapers Port n   Scheduler Mode • Strict Priority | Queues Weighted...
Page 323 SOLTECH USER GUIDE Switch SFC4100AB  Queue Shaper Enable • Enabled | Disabled  Queue Shaper Rate • 100-13107100(kbps) or 1-13107(Mbps)  Queue Shaper Unit • kbps or Mbps...
Page 324 SOLTECH USER GUIDE Switch SFC4100AB  Queue Scheduler Weight • 1~100(Scheduler Mode should be set to ‘Weighted’)  Port Shaper Enable • Enabled | Disabled...
Page 325 SOLTECH USER GUIDE Switch SFC4100AB  Port Shaper Rate • 100-13107100(kbps) or 1-13107(Mbps)  Port Shaper Unit • kbps or Mbps...
Page 326 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI CONFIGURATION QoS Egress Port Schedulers   Port (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 QoS Egress Port Schedulers and Shapers Port n   Scheduler Mode •...
Page 327 SOLTECH USER GUIDE Switch SFC4100AB (config-if)# qos queue-shaper queue <queue> <rate> [ kbps | mbps ] [ excess ] [ rate-type { line | data } ] (config-if)# no qos queue-shaper queue 0 (config-if)# qos queue-shaper queue 0 1 mbps (config-if)# qos queue-shaper queue 0 100 kbps ...
Page 328: Port Shaping
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.5. Port Shaping WEB MENU Configuration>QoS>Port Shaping This page provides an overview of QoS Egress Port Shapers for all switch ports. QoS Egress Port Shapers Object Description The logical port for the settings contained in the same row.
Page 329: Port Tag Remarking
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.6. Port Tag Remarking WEB MENU Configuration>QoS>Port Tag Remarking This page provides an overview of QoS Egress Port Tag Remarking for all switch ports. QoS Egress Port Tag Remarking Object Description The logical port for the settings contained in the same row.
Page 330 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB CONFIGURATION WEB MENU Configuration>QoS>Port Tag Remarking QoS Egress Port Tag Remarking   Port( Click on the port number in order to configure tag remarking. QoS Egress Port Tag Remarking Port n ...
Page 331 SOLTECH USER GUIDE Switch SFC4100AB PCP/DEI Configuration  The following items are displayed when the mode is set to "Default".  Default PCP •  Default DEI • (QoS class, DP level) to (PCP, DEI) Mapping  When the Mode is set to 'Mapped' you will see the following entries ...
Page 332 SOLTECH USER GUIDE Switch SFC4100AB  • EXAMPLE CLI CONFIGURATION QoS Egress Port Tag Remarking   Port (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 QoS Egress Port Tag Remarking Port n   Tag Remarking Mode...
Page 333 SOLTECH USER GUIDE Switch SFC4100AB • Classified (config-if)# no qos tag-remark • Default (config-if)# qos tag-remark { pcp <pcp> dei <dei> | mapped } (config-if)# qos tag-remark pcp <pcp> dei <dei> • Mapped (config-if)# qos tag-remark { pcp <pcp> dei <dei> | mapped }...
Page 334: Port Dscp
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.7. Port DSCP WEB MENU Configuration>QoS>Port DSCP This page allows you to configure the basic QoS Port DSCP Configuration settings for all switch ports. QoS Port DSCP Configuration Object Description The Port column shows the list of ports for which you can configure DSCP ingress and Port egress settings.
Page 335: Dscp-Based Qos
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.8. DSCP-Based QoS WEB MENU Configuration>QoS>DSCP-Based QoS This page allows you to configure the basic QoS DSCP based QoS Ingress Classification settings for all switches. DSCP-Based QoS Ingress Classification Object Description DSCP Maximum number of supported DSCP values are 64.
Page 336: Dscp Translation
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.9. DSCP Translation WEB MENU Configuration>QoS>DSCP Translation This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in Ingress or Egress. DSCP Translation Object Description...
Page 337: Dscp Classification
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.10. DSCP Classification WEB MENU Configuration>QoS>DSCP Classification This page allows you to configure the mapping of QoS class and Drop Precedence Level to DSCP value. DSCP Classification Object Description QoS Class Actual QoS class. DSCP DP0 Select the classified DSCP value (0-63) for Drop Precedence Level 0.
Page 338: Qos Control List
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.11. QoS Control List WEB MENU Configuration>QoS>QoS Control List This page shows the QoS Control List(QCL), which is made up of the QCEs. Each row describes a QCE that is defined. The maximum number of QCEs is 256 on each switch.
Page 339: Qce Configuration
SOLTECH USER GUIDE Switch SFC4100AB CoS: Classify Class of Service. DPL: Classify Drop Precedence Level. DSCP: Classify DSCP value. PCP: Classify PCP value. DEI: Classify DEI value. Policy: Classify ACL Policy number. You can modify each QCE (QoS Control Entry) in the table using the following buttons: : Inserts a new QCE before the current row.
Page 340 SOLTECH USER GUIDE Switch SFC4100AB Value of Inner Tag field can be Inner Tag 'Untagged', 'Tagged', 'C-Tagged', 'S-Tagged' or 'Any'. Valid value of Inner VLAN ID can be any value in the range Inner VID 1-4095 or 'Any'; user can enter either a specific value or a range of VIDs.
Page 341 SOLTECH USER GUIDE Switch SFC4100AB DSCP DSCP (0-63, BE, CS1-CS7, EF or AF11-AF43) or 'Default'. PCP: (0-7) or 'Default'. Note: PCP and DEI cannot be set individually. DEI: (0-1) or 'Default'. Policy ACL Policy number: (0-255) or 'Default' (empty field).
Page 342: Storm Policing
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.12. Storm Policing WEB MENU Configuration>QoS>Storm Policing Global storm policers for the switch are configured on this page. Global Storm Policer Configuration There is a unicast storm policer, multicast storm policer, and a broadcast storm policer.
Page 343: Wred
SOLTECH USER GUIDE Switch SFC4100AB 6.13.1.13. WRED WEB MENU Configuration>QoS>WRED This page allows you to configure the Random Early Detection (RED) settings. Weighted Random Early Detection Configuration Through different RED configuration for the queues (QoS classes) it is possible to obtain Weighted Random Early Detection (WRED) operation between queues.
Page 344 SOLTECH USER GUIDE Switch SFC4100AB RED Drop Probability Function The following illustration shows the drop probability versus fill level function with associated parameters. Min is the fill level where the queue randomly start dropping frames marked with Drop Precedence Level > 0 (yellow frames).
Page 345: Mirroring
SOLTECH USER GUIDE Switch SFC4100AB 6.14. MIRRORING 6.14.1. Mirroring Configuration WEB MENU Configuration>Mirroring Mirroring is a feature for switched port analyzer. The administrator can use the Mirroring to debug network problems. The selected traffic can be mirrored or copied on a destination port where a network analyzer can be attached to analyze the network traffic.
Page 346 SOLTECH USER GUIDE Switch SFC4100AB on this switch. The switch is a forwarding node for monitor flow and the switch is an option node. Intermediate The object is to forward traffic from source switch to destination switch. The intermediate ports are located on this switch.
Page 347 SOLTECH USER GUIDE Switch SFC4100AB Configuration Guideline for All Features When the switch is running on Remote Mirroring mode, the administrator also needs to check whether or not other features are enabled or disabled. For example, the administrator is not disabled the MSTP on reflector port. All monitor traffic will be blocked on reflector port.
Page 348 SOLTECH USER GUIDE Switch SFC4100AB  Reflector Port Only “Source(RMirror)” type can configuration Source VLAN(s) Configuration   Source VLANs Only “Mirror, Source(RMirror)” type can configuration • 1~4095(This can affect the Source in Port Configuration.)  Port Configuration  Source •...
Page 349 SOLTECH USER GUIDE Switch SFC4100AB Only “Source | Intermediate | Destination(RMirror) type can configuration  Destination Only “Mirror, Destination(RMirror) type can configuration EXAMPLE CLI CONFIGURATION Mirroring & Remote Mirroring Configuration   Mode • Disabled | Enabled (config)# no monitor session 1 (config)# monitor session 1 ...
Page 350 SOLTECH USER GUIDE Switch SFC4100AB  VLAN ID Only “Source | Intermediate | Destination(RMirror) type can configuration • 1~4095  Reflector Port Only “Source(RMirror)” type can configuration (config)# monitor session <session_number> [ destination { interface ( <port_type> [ <di_list> ] ) | remote vlan <drvid> reflector-port <port_type> <rportid> } | source { interface ( <port_type>...
Page 351 SOLTECH USER GUIDE Switch SFC4100AB (config)# monitor session <session_number> [ destination { interface ( <port_type> [ <di_list> ] ) | remote vlan <drvid> reflector-port <port_type> <rportid> } | source { interface ( <port_type> [ <si_list> ] ) [ both | rx | tx ] | remote vlan <srvid> | vlan <source_vlan_list>...
Page 352: Ddmi
SOLTECH USER GUIDE Switch SFC4100AB 6.15. DDMI 6.15.1. DDMI Configuration WEB MENU Configuration>DDMI Configure DDMI on this page. DDMI Configuration Object Description Indicates the DDMI mode operation. Possible modes are: Mode Enabled Enable DDMI mode operation. Disabled Disable DDMI mode operation.
Page 353: Ddmi Monitor
SOLTECH USER GUIDE Switch SFC4100AB 6.15.2. DDMI Monitor 6.15.2.1. Overview WEB MENU Configuration>DDMI>Overview Display DDMI overview information on this page. DDMI Configuration Object Description Port DDMI port. (Navigating to the Detail page by clicking on the port number.) Vendor Indicates Vendor name SFP vendor name.
Page 354 SOLTECH USER GUIDE Switch SFC4100AB ------------------------------ Transceiver Information ========================================================== Vendor : Soltech Part Number : GP-3148-L2CD Serial Number : S2005136619 Revision : 1.0 Data Code : 2020-05-19 Transceiver : 2G5 DDMI Information ++ : high alarm, + : high warning, - : low warning, -- : low alarm.
Page 355 SOLTECH USER GUIDE Switch SFC4100AB Tx: transmit, Rx: receive, mA: milliamperes, mW: milliwatts. ========================================================== current High Alarm High Warn Low Warn Low Alarm Threshold Threshold Threshold Threshold ------------- -------- ---------- ---------- ---------- -------- Temperature(C) Voltage(V) Tx Bias(mA) Tx Power(mW) Rx Power(mW)
Page 356: Detailed
SOLTECH USER GUIDE Switch SFC4100AB 6.15.2.2. Detailed WEB MENU Configuration>DDMI>Detailed Transceiver Information Display DDMI detailed information on this page. Object Description Vendor Indicates Vendor name SFP vendor name. Part Number Indicates Vendor PN Part number provided by SFP vendor. Serial Number Indicates Vendor SN Serial number provided by vendor.
Page 357 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB MONITOR WEB MENU Configuration>DDMI>Detailed Transceiver Information   DDMI Information EXAMPLE CLI MONITOR Transceiver Information  DDMI Information  # show interface ( <port_type> [ <plist> ] ) transceiver # show interface 10GigabitEthernet 1/1-4 transceiver...
Page 358 SOLTECH USER GUIDE Switch SFC4100AB Rx Power(mW) 10GigabitEthernet 1/2 ------------------------------ Tranceiver Information ========================================================== Vendor : OEM Part Number : SFP-LX Serial Number : S1231240320176 Revision : A0 Data Code : 2014-03-09 Transceiver : 1000BASE_LX DDMI Information ++ : high alarm, + : high warning, - : low warning, -- : low alarm.
Page 359 SOLTECH USER GUIDE Switch SFC4100AB Transceiver : 100BASE_LX DDMI Information ++ : high alarm, + : high warning, - : low warning, -- : low alarm. Tx: transmit, Rx: receive, mA: milliamperes, mW: milliwatts. ========================================================== % SFP module doesn't support DDMI...
Page 360: Switch Diagnostics Guide
SOLTECH USER GUIDE Switch SFC4100AB 7. Switch Diagnostics Guide 7.1. DIAGNOSTICS 7.1.1. Ping WEB MENU Diagnostics>Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. ICMP Ping After you press Start, ICMP packets are transmitted, and the sequence number and round trip time are displayed upon reception of a reply.
Page 361: Link Oam
SOLTECH USER GUIDE Switch SFC4100AB 7.1.2. Link OAM 7.1.2.1. MIB Retrieval WEB MENU Diagnostics>Link OAM>MIB Retrieval This page allows you to retrieve the local or remote OAM MIB variable data on a particular port. Link OAM MIB Retrieval Select the appropriate radio button and enter the port number of the switch to retrieve the content of interest.
Page 362: Ping6
SOLTECH USER GUIDE Switch SFC4100AB 7.1.3. Ping6 WEB MENU Diagnostics>Ping6 This page allows you to issue ICMPv6 PING packets to troubleshoot IPv6 connectivity issues. ICMPv6 Ping After you press ‘Start’, ICMPv6 packets are transmitted, and the sequence number and round trip time are displayed upon reception of a reply.
Page 363: Veriphy
SOLTECH USER GUIDE Switch SFC4100AB 7.1.4. VeriPHY WEB MENU Diagnostics>VeriPHY This page is used for running the VeriPHY Cable Diagnostics for 10/100 and 1G copper ports. VeriPHY Cable Diagnostics Press ‘Start’ to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds.
Page 364: Switch Maintenance Guide
SOLTECH USER GUIDE Switch SFC4100AB 8. Switch Maintenance Guide 8.1. MAINTENANCE 8.1.1. Restart Device WEB MENU Maintenance>Restart Device You can restart the switch on this page. After restart, the switch will boot normally. When restarting, the startup-config will be loaded. (If not saved, the configuration will be lost upon restart.)
Page 365 SOLTECH USER GUIDE Switch SFC4100AB After waiting for a few minutes, the initial screen (Port State) will be displayed, and the restart will be completed. EXAMPLE CLI Restart Device(Load Startup-Config and Restart)  # reload cold % Cold reload in progress, please stand by.
Page 366: Factory Defaults
SOLTECH USER GUIDE Switch SFC4100AB 8.1.2. Factory Defaults WEB MENU Maintenance>Factory Defaults You can reset the configuration of the switch on this page. Only the IP configuration is retained. The new configuration is available immediately, which means that no restart is necessary.
Page 367 SOLTECH USER GUIDE Switch SFC4100AB (This means that the IP configuration of the device can change upon reboot.)  Clicking 'No' will return you to the initial screen. EXAMPLE CLI Factory Defaults   Defaults Executing "Defaults" in the CLI will reset the device, including IP configurations, to their default settings.
Page 368: Software
SOLTECH USER GUIDE Switch SFC4100AB 8.1.3. Software 8.1.3.1. Firmware Download On this page provide instructions for downloading the firmware for the Devices. Access the company website at www.solmate.net. SUPPORT>Software>Switch Firmware>Please Search Product Name. You can search for the latest firmware of the product by entering its product name.
Page 369: Upload
SOLTECH USER GUIDE Switch SFC4100AB 8.1.3.2.Upload WEB MENU Maintenance>Software>Upload This page facilitates an update of the firmware controlling the switch. Buttons Click this button, you can find the software image to upload. Click this button, upload the selected software image.
Page 370 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI The method for software upgrade using console (utilizing TFTP) Software Upload  1. Run the Tftpd32 program. 2. Click on "Browse" to locate the file you want to update. 3. Click on "Show Dir" to select the file, then click "Copy." and click "Close" to close the window.
Page 371: Image Select
SOLTECH USER GUIDE Switch SFC4100AB 8.1.3.3. Image Select WEB MENU Maintenance>Software>Image Select This page provides information about the active and alternate (backup) firmware images in the device, and allows you to revert to the alternate image. The web page displays two tables with information about the active and alternate firmware images.
Page 372 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB WEB MENU Maintenance>Software>Image Select Clicking on will activate the alternative image. Use it if there are issues with the existing image. EXAMPLE CLI Software Image Selection  # firmware swap ... Erase from 0x40fd0000-0x40fdffff: .
Page 373: Configuration
SOLTECH USER GUIDE Switch SFC4100AB 8.1.4. Configuration The switch stores its configuration in a number of text files in CLI format. The files are either virtual (RAM-based) or stored in flash on the switch. 1. running-config: A virtual file that represents the currently active configuration on the switch.
Page 374: Save Startup-Config
SOLTECH USER GUIDE Switch SFC4100AB 8.1.4.2. Save startup-config WEB MENU Maintenance>Configuration>Save startup-config This copies running-config to startup-config, thereby ensuring that the currently active configuration will be used at the next reboot. Buttons : Click "Save configuration" to copy the running-config to the startup-config.
Page 375: Download
SOLTECH USER GUIDE Switch SFC4100AB 8.1.4.3. Download WEB MENU Maintenance>Configuration>Download It is possible to download any of the files on the switch to the web browser. Select the file and Click ‘Download Configuration’. Download of running-config may take a little while to complete, as the file must be prepared for download.
Page 376 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI Download Configuration  Run Tftpd32 and choose the destination to save the file. Click on "Browse" to set the location where the file will be saved. Subsequently, enter the CLI command. # copy flash-filename tftp://PC IPv4 Address/save-filename # copy running-config tftp://192.168.10.130/running-config...
Page 377: Upload
SOLTECH USER GUIDE Switch SFC4100AB 8.1.4.4. Upload WEB MENU Maintenance>Configuration>Upload It is possible to upload a file from the web browser to all the files on the switch, except default-config which is read-only. Select the file to upload, select the destination file on the target, then click Upload Configuration.
Page 378 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE WEB WEB Menu Maintenance>Configuration>Upload 1. Click on to load the saved configuration. 2. After selecting the desired file, click the "Open" button. 3. Select the desired Destination File and click on "Upload Configuration". (For the Running-config, you can choose to Replace or Merge.)
Page 379 SOLTECH USER GUIDE Switch SFC4100AB The screen will appear, and the configuration will be uploaded. EXAMPLE CLI  Upload Configuration Since direct uploading to the Running-Config is currently unavailable, let me introduce an alternative method. 1. Click on “Browse” in tftp32 to set the path.
Page 380 SOLTECH USER GUIDE Switch SFC4100AB 2. Click on "show Dir" to select the file, then click on "Copy", and finally click "Close" to close the window. 3. Return to the console window and enter the following. # copy tftp://<PC IPv4 Address>/<upload_filename> startup-config # copy tftp://192.168.10.130/running-config startup-config...
Page 381: Activate
SOLTECH USER GUIDE Switch SFC4100AB 8.1.4.5. Activate WEB MENU Maintenance>Configuration>Activate Activate Configuration Select configuration file to activate. The previous configuration will be completely replaced, potentially leading to loss of management connectivity. Please note: The activated configuration file will not be saved to startup-config automatically.
Page 382 SOLTECH USER GUIDE Switch SFC4100AB EXAMPLE CLI Activate Configuration  # copy <flash file> running-config # copy flash:default-config running-config...
Page 383: Delete
SOLTECH USER GUIDE Switch SFC4100AB 8.1.4.6. Delete WEB MENU Maintenance>Configuration>Delete It is possible to delete any of the writable files stored in flash, including startup-config. If this is done and the switch is rebooted without a prior Save operation, this effectively resets the switch to default configuration.
Page 384 SOLTECH USER GUIDE Switch SFC4100AB startup-config successfully deleted. (Delete is complete. The device will go to default settings upon restart.) EXAMPLE CLI Delete Configuration File  # delete <url_file> # delete flash:startup-config...
Page 385: Fault Recovery Method
SOLTECH USER GUIDE Switch SFC4100AB 9. Fault Recovery Method 9.1. EMERGENCY RECOVERY 9.1.1. 3seconds Reset If the device is not functioning or the settings are incorrect, there is a hardware button for quick equipment reset. It is labeled "Reset" on the front panel. To perform the reset, use a thin and long clip or pen to press and hold it for about 3 seconds until the Port LEDs blink.
Page 386: Web Interface Connectivity Problem
SOLTECH USER GUIDE Switch SFC4100AB 9.2. WEB INTERFACE CONNECTIVITY PROBLEM If you are experiencing intermittent login failures or difficulty maintaining the login during WEB access, please follow the steps below. Typically, closing and reopening all web browsers resolves the issue.
Page 387 SOLTECH USER GUIDE Switch SFC4100AB 9.2.2. Microsoft Edge Browser 1. Click on the 'Not secure' next to the equipment's URL. Click on 'Cookies,' remove the cookies, then restart the web browser. Click on the permissions for this site. After verifying the equipment's IP, 'Reset Permissions.'...
