SFC8100 Series Switch

User Guide

Need help?

Do you have a question about the SFC8100 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Soltech SFC8100 Series

Page 1 SFC8100 Series Switch User Guide...
Page 2 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Contents 1. Introduction ..........................................12 1.1. Product Introduction ....................................12 1.1.1. Product overview ..................................12 1.2. Product Features ...................................... 13 1.2.1. Physical Port ....................................13 1.2.1.1. SFC8100 ....................................13 1.2.1.2. SFC8100-BP_2x2 ................................13 1.2.1.3.
Page 3 2.5.2. SFC8100-BP (4x4), SFC8100BT-BP (4x4) ..........................32 3. Installation of bracket ......................................33 4. Installation of Product ......................................35 4.1. Installation Procedure for SFC8100 SERIES ..........................35 4.2. Installation of SFP Module .................................. 36 4.3. Installation of Fiber Optic Cable ............................... 36 4.4.
Page 4 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.4.1. CLI Basic use Key ..................................45 5.4.2. CLI Basic use Mode ..................................46 5.4.3. CLI Basic Command ................................... 47 6. Switch Management Guide ....................................52 6.1. System ........................................... 52 6.1.1. System Configuration ................................52 6.1.1.1.
Page 5 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3.2. Ports Monitor ....................................100 6.3.2.1. State ....................................100 6.3.2.2. Traffic Overview ................................102 6.3.2.3. QoS Statistics .................................. 105 6.3.2.4. QCL Status ..................................108 6.3.2.5. Detailed Statistics ................................. 110 6.4. DHCP ..........................................113 6.4.1.
Page 6 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.7. Access Management ..............................155 6.5.1.8. SNMP ....................................157 6.5.1.8.1. System ................................... 157 6.5.1.8.2. Trap..................................161 6.5.1.8.3. Communities ..............................167 6.5.1.8.4. Users ..................................169 6.5.1.8.5. Groups .................................. 172 6.5.1.8.6. Views ..................................174 6.5.1.8.7. Access ................................... 176 6.5.2.
Page 7 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.4. Access Management Statistics Monitor .......................... 224 6.5.5. Network Monitor ..................................226 6.5.5.1. Port Security ................................... 226 6.5.5.1.1. Switch ..................................226 6.5.5.1.2. Port ..................................229 6.5.5.2. ACL Status ..................................231 6.5.5.3. ARP Inspection ................................233 6.5.5.4.
Page 8 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.1.3. MSTI Priorities ................................263 6.8.1.4. CIST Ports ..................................265 6.8.1.5. MSTI Ports ..................................271 6.8.2. Spanning Tree Monitor ................................275 6.8.2.1. Bridge Status .................................. 275 6.8.2.2. Port Status ..................................279 6.8.2.3. Port Statistics .................................. 281 6.9.
Page 9 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11.2.3. EEE ....................................323 6.11.2.4. Port Statistics ................................325 6.12. PoE ..........................................328 6.12.1. PoE Configuration................................... 328 6.12.2. Power off Scheduler ................................337 6.12.3. PoE Monitor ....................................339 6.13. EPS ..........................................341 6.13.1. EPS Configuration ................................... 341 6.14.
Page 10 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.1. Port Classification ..............................396 6.20.1.2. Port Policing ................................. 404 6.20.1.3. Queue Policing ................................407 6.20.1.4. Port Scheduler ................................410 6.20.1.5. Port Shaping ................................418 6.20.1.6. Port Tag Remarking ..............................419 6.20.1.7. Port DSCP ..................................424 6.20.1.8.
Page 11 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 7.1. Diagnostics ........................................ 475 7.1.1. Ping ........................................475 7.1.2. Link OAM ...................................... 476 7.1.2.1. MIB Retrieval ................................... 476 7.1.3. Ping6 ....................................... 477 7.1.4. VeriPHY ......................................478 8. Switch Maintenance Guide ..................................... 479 8.1. Maintenance ......................................479 8.1.1.
Page 12 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 9.2.2. Microsoft Edge Browser ................................. 502...
Page 13 1.1. Product Introduction 1.1.1. Product overview The SFC8100 Series products are managed 10 Gigabit Ethernet switches designed for industrial use. They feature 10/100/1000Mbps TP ports and SFP slots that support 100M/1G/10G Base-X. The 10-Gigabit Managed Industrial Ethernet Switches can automatically identify the correct transmission speed and determine the Port's Full/Half Duplex mode.
Page 14 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.2. Product Features 1.2.1. Physical Port 1.2.1.1. SFC8100  8 10/100/1000BASE-T RJ45 Copper ports with LED 4 100/1000/10GBASE-X SFP+ slot   SFP Slot status LED Console interface for basic managements and setup ...
Page 15 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.2.1.4. SFC8100BT  8 10/100/1000BASE-T RJ45 Copper ports with LED IEEE 802.3af/at 4 Port(5~8 Port) + IEEE 802.3af/at/bt 4 Port(1~4 Port)   PoE Budget : 240W 4 100/1000/10GBASE-X/SFP+ slot   SFP Slot status LED Console interface for basic managements and setup ...
Page 16 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.2.1.7. SFC8100G-1U  SFC8100G-1U : Supports 2-slot operation with SFC8100G Module Dual power redundancy support and power LED   SFC8100G Module - 4 10/100/1000BASE-T RJ45 Copper ports with LED - 4 100/1000/10GBASE-X/SFP+ slots...
Page 17 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.2.2. Common features 1.2.2.1. Layer2 Features High performance of Store-and-Forward architecture and runt/CRC filtering eliminates erroneous  packets to optimize the network bandwidth  Storm Control support - Broadcast / Multicast / Unknown unicast Supports VLAN ...
Page 18 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.2.2.2. Power over Ethernet (*SFC8100BT, SFC8100BT-BP)  Complies with IEEE 802.3af / at / bt Power over Ethernet PSE Selectable PoE mode : IEEE 802.3af/at/bt   Ports 1 to 4 support up to Max. 90 watts; port 5 to 8 support up to Max. 30 watts Each port supports 56V DC power to PoE powered device ...
Page 19 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.2.2.5. Security  Authentication - Built-in RADIUS client to co-operate with the RADIUS servers - TACACS+ login users access authentication - RADIUS / TACACS+ users access authentication - Guest VLAN assigns clients to a restricted VLAN with limited services Access Control List ...
Page 20 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  System Maintenance - Firmware upload/download via HTTP/TFTP - Reset button for system reboot or reset to factory default - Dual images  DHCP Relay DHCP Option82   DHCP Server User Privilege levels control ...
Page 21 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1.3. Product Specification SFC8100-BP_2x2 SFC8100BT-BP_2x2 SFC8100G-1U Product SFC8100 SFC8100BT SFC8100-BP_4x4 SFC8100BT-BP_4x4 SFC8100G-4U Hardware Specifications 4 10/100/1000Mbps Copper Ports 8 10/100/1000Mbps RJ45 auto-MDI/MDI-X Ports RJ45 auto-MDI/MDI-X Ports Fiber Slots 4 100/1000/10000Mbps SFP Slots Console 1 x RJ45 serial port (Baud Rate : 115200) <...
Page 22 SOLTECH USER GUIDE Industrial Switch SFC8100 Series IEEE 802.3x pause frame for full duplex Flow Control Back pressure for half duplex Jumbo Frame 2 relay output with current carrying Alarm Contact 1 relay output with current carrying capacity of 12~24Vdc @ 1A...
Page 23 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Port Mirror One to Multi-port and the monitor mode is RX RFC-1213 MIB-II IF-MIB RFC-1493 Bridge MIB RFC-1643 Ethernet MIB RFC-2863 Interface MIB RFC-2665 Ether-Like MIB SNMP MIBs RFC-2819 RMON MIB (Group 1,2,3,9)
Page 24 SOLTECH USER GUIDE Industrial Switch SFC8100 Series RFC 1112 IGMP version 1 RFC 2236 IGMP version 2 RFC 3376 IGMP version 3 RFC3590 MLDv1 RFC4604 MLDv2 ITU-T G.8032 Ethernet Ring Protection Switching 1.4. Product Contents SFC8100 Series SFC8100-1U SFC8100-1U(DC) SFC8100-4U...
Page 25 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2. Exterior 2.1. Model & Exterior Model Exterior Port Information Product Size 10/100/1000BASE-T Port 8 1G/10G SFP Slot 4 74x130x166.5 SFC8100 Console Port 1 (mm) RESET Switch 1 (for Default-config) 10/100/1000BASE-T Port 8 1G/10G SFP Slot 4 74x130x166.5...
Page 26 The front panel LED indicates the immediate status of power, system status, port link/active and PoE to monitor, diagnose and resolve potential issues with connected devices. The following diagram shows the switch LED indicators for each product in the SFC8100 Series. 2.2.1. SFC8100 / SFC8100BP...
Page 27 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2.2.2. SFC8100BT / SFC8100BT-BP Color Status Status Description POWER Green Switch Power On System PWR1 Green Power Input 1 PWR2 Green Power Input 2 S-Ring ID 1 Slave Mode RING1 Green Flashing S-Ring ID 1 Master Mode...
Page 28 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2.2.3. SFC8100G / SFC8100G-1U / SFC8100G-4U Color Status Status Description POWER Green Switch Power On System PWR1 Green Power Input 1 PWR2 Green Power Input 2 S-Ring ID 1 Slave Mode RING1 Green...
Page 29 Industrial Switch SFC8100 Series 2.3. Power Input Method At the top of the SFC8100 Series products (SFC8100, SFC8100BP, SFC8100BT, SFC8100BT-BP), there are two power input slots labeled as "Power1" and "Power2". Depending on the product, the following DC power can be supplied.
Page 30 Industrial Switch SFC8100 Series Power Notice: 1. The SFC8100 Series products provide reverse voltage protection. If the polarity of the input voltage is reversed, the product will not function. 2. The device requires power to operate. It will not function until power is supplied. If the user's network needs to be active at all times, consider using an Uninterrupted Power Supply (UPS) device.
Page 31 Industrial Switch SFC8100 Series 2.5. BYPASS Connection Method In the SFC8100 Series, the front panel of SFC8100-BP(2x2), SFC8100-BP(4x4), SFC8100BT-BP(2x2), and SFC8100BT- BP(4x4) models features LC-type BYPASS ports. The 2x2 port is appropriate for Wavelength Division Multiplexing (WDM), while the 4x4 port is appropriate for the 2Core method.
Page 32 SOLTECH USER GUIDE Industrial Switch SFC8100 Series The followings are data flow examples for the BYPASS product during connection and power on/off. 2.5.1. SFC8100-BP (2x2), SFC8100BT-BP (2x2) #2 SFC8100-BP(2X2) POWER ON #2 SFC8100-BP(2X2) POWER OFF...
Page 33 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2.5.2. SFC8100-BP (4x4), SFC8100BT-BP (4x4) #2 SFC8100-BP(4X4) POWER ON #2 SFC8100-BP(4X4) POWER OFF...
Page 34 Industrial Switch SFC8100 Series 3. Installation of bracket In the basic accessories of the SFC8100 Series products (SFC8100, SFC8100BP, SFC8100BT, SFC8100BT-BP), Wall Mount brackets and DIN-Rail Mount brackets are included. These brackets can be used for mounting the product on walls or DIN-Rails. Bracket installation is completed by aligning the screw holes and assembling the included screws, as shown in the diagram below.
Page 35 SOLTECH USER GUIDE Industrial Switch SFC8100 Series The basic accessories of the SFC8100G-1U and SFC8100G-4U products include Rack Mount brackets. These brackets allow for mounting on a 19-inch Rack. Bracket installation is completed by aligning the screw holes and fixing them to the 19-inch Rack, as shown in the diagram below.
Page 36 Please follow the steps provided below in the given order to install the Industrial Managed 10G Ethernet Switch on a desktop or shelf. 4.1. Installation Procedure for SFC8100 SERIES Step 1 Place the SFC8100/SFC8100-BP near a 36 ~ 56VDC 60W-rated power source.
Page 37 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 4.2. Installation of SFP Module SFP transceivers module(in the following sections referred to as SFP module) typically provide Hot-pluggable and Hot-swappable functionality. Users can remove or insert the module into the SFP slot of the Industrial Managed 10G Ethernet Switch without the need to power off the switch.
Page 38 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 4.4. Removing Transceiver Module A. Check if there is current network activity on the port with the SFP module to be removed, or Disable the port through the Switch/Converter's management interface. B. Remove the Fiber cable smoothly.
Page 39 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5. Switch Access Guide Here's a brief introduction on how to access device 5.1. The Initial Defaults Values The initial values of the equipment are as follows: Items Defaults Values Note Administrator account...
Page 40 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.2. WEB Interface 5.2.1. WEB Login This page provides a brief overview of accessing the web interface. 1. Users must know IPv4 Address of device to WEB set. 2. Connect AP (LAN interface) with PC (LAN port) using enclosed LAN cable.
Page 41 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Sign in page appears. Enter your Username and Password, then click on "Sign in." (Default ID: admin, PW: admin) 4. Successfully connected to the equipment's web interface.
Page 42 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.3. CLI Interface 5.3.1. CLI Basic Symbol This page is the description of symbols commonly used in CLI(Command Line Interface) commands. Symbol Description < > The symbol indicates that you have to enter a value directly.
Page 43 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2. Set Serial Port.(Set Speed 115200 like below) 3. Access Device with Console.(New Connection Alt+N) The initial ID and password are both "admin." 4. You are currently connected to the console.(Initial ID-admin, PW-admin or the password you previously set)
Page 44 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.3.3. Telnet This page provides an explanation of Telnet connection. You should follow the same configuration steps as mentioned in item 2 of the console connection. Telnet allows for switch access from a computer within the same network.
Page 45 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.3.4. SSH This page provides an explanation of SSH connection. You should follow the same configuration steps as mentioned in item 2 of the console connection. Click "Continue (C)" on the security warning window Enter your username and password in the SSH Authentication window.
Page 46 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.4. CLI Basic Command This page provides an explanation of basic commands used in the Command-Line Interface (CLI). 5.4.1. CLI Basic use Key TAB key  When entering a command, pressing the TAB key will either display the next possible command or complete the existing command.
Page 47 SOLTECH USER GUIDE Industrial Switch SFC8100 Series ipv6 IPv6 configuration commands link-oam Link OAM configuration logout Exit from EXEC mode more Display file Negate a command or set its defaults ping Send ICMP echo messages platform Platform configuration reload Reload system.
Page 48 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 5.4.3. CLI Basic Command Login  Users need to input username and password when login firstly. [Console] Username: admin [Console] Password: > Logout  To log out the current user or log in as a new user, please log out.
Page 49 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Clear  To delete the remaining records, you can use the "Clear" command. # clear ? access Access management access-list Access list Ethernet Protection Switching. erps Ethernet Ring Protection Switching Interface Internet Protocol configuration commands...
Page 50 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Show  To Show running system information, you can use the "show" command. # show ? Authentication, Authorization and Accounting methods access Access management access-list Access list aggregation Aggregation port configuration audit-log System Audit Log message...
Page 51 SOLTECH USER GUIDE Industrial Switch SFC8100 Series radius-server RADIUS configuration rmon RMON statistics running-config Show running system information scan-agent SCAN-AGENT Module sflow Statistics flow. snmp Display SNMP configurations spanning-tree STP Bridge sring SRING Module switchport Display switching mode characteristics system...
Page 52 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Copy running-config startup-config  To save the running-configuration settings to the Startup-Config, you can use the “copy running-config startup-config” command. This command can only be used in Privileged mode. # copy running-config startup-config Building configuration...
Page 53 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6. Switch Management Guide 6.1. System 6.1.1. System Configuration 6.1.1.1. Information WEB MENU Configuration>System>Information The switch system information is provided here. System Information Configuration Object Description The textual identification of the contact person for this managed node, System Contact together with information on how to contact this person.
Page 54 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION System Contact  System Name  System Location  EXAMPLE CLI CONFIGURATION System Contact  (config)# snmp-server contact <line255> (config)# snmp-server contact SOLTECH System Name  (config)# hostname <host_name> (config)# hostname TESTSWITCH System Location ...
Page 55 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.1.2. IP WEB MENU Configuration>System>IP Configure IP basic settings, control IP interfaces and IP routes. IP Configuration Object Description Mode Configure whether the IP stack should act as a Host or a Router.
Page 56 SOLTECH USER GUIDE Industrial Switch SFC8100 Series IP Routes Object Description Delete Select this option to delete an existing IP route. Network The destination IP network or host address of this route. The destination IP network or host mask, in number of bits (prefix length).
Page 57 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • From any DHCPv4 Interfaces • From this DHCPv4 Interfaces (VLAN1) • From any DHCPv6 Interfaces • From this DHCPv6 Interfaces (VLAN1)  DNS Proxy IP Interfaces   VLAN(This field is only available for input when creating a new interface.)
Page 58 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  DHCPv4 • DHCPv4 fallback not set • DHCPv4 fallback setting. (After this period expires, a configured IPv4 address will be used as IPv4 interface address.)  IPv4 IP Routes   Add Route •...
Page 59 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  DNS Server • Configured IPv4 or IPv6 (config)# ip name-server <0-3> <ipv4_ucast> (config)# ip name-server 0 8.8.8.8 (config)# ip name-server <0-3> <ipv6_ucast> (config)# ip name-server 0 2001:4860:4860::8888 • From any DHCPv4 Interfaces (config)# ip name-server <0-3>...
Page 60 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config-if-vlan)# ip address dhcp fallback <ipv4_addr> <ipv4_netmask> timeout <uint> (config-if-vlan)# ip address dhcp fallback 192.168.10.101 255.255.255.0 timeout 30  IPv4 (config)# interface vlan <vlan_list> (config-if-vlan)# ip address <ipv4_addr> <ipv4_netmask> (config-if-vlan)# ip address 192.168.10.101 255.255.255.0 IP Routes ...
Page 61 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.1.3. System Time WEB MENU Configuration>System>NTP This page allows you to configure the Time. System Time Status Object Description NTP Mode Indicates NTP status. System time Indicates the current time on the switch * When 'NTP Mode' is enable, 'Time Setting' will be disabled.
Page 62 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION System Time Configuration   Time Setting • Year(2000~2037) • Month(1~12) • Date(1~31) • Hours(0~23) • Minutes(0~59) Click the Apply button EXAMPLE CLI CONFIGURATION System Time Configuration   Time Setting •...
Page 63 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.1.4. NTP WEB MENU Configuration>System>NTP Configure NTP on this page. NTP Configuration Object Description Indicates the NTP mode operation. Possible modes are: Enabled: Enable NTP client mode operation. Mode Disabled: Disable NTP client mode operation.
Page 64 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION NTP Configuration   Mode • Enable • Disable  Server • Use the IPv4 or IPv6 address of the NTP server • Use the domain name of the NTP server...
Page 65 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION NTP Configuration   Mode • Enable (NTP client mode operation is used.) (config)# ntp • Disable (NTP client mode operation is not used.) (config)# no ntp  Server •...
Page 66 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.1.5. Time WEB MENU Configuration>System>Time This page allows you to configure the Time Zone. Time Zone Configuration Object Description Lists various Time Zones world wide. Time Zone Select appropriate Time Zone. Number of hours offset from UTC.
Page 67 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Month Select the starting and ending month. Hours Select the starting and ending hour. Minutes Select the starting and ending minute. Enter the number of minutes to add during Daylight Saving Time. Offset...
Page 68 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Recurring • Non-Recurring...
Page 69 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Time Zone Configuration   Time Zone • (UTC+09:00) Seoul (config)# clock timezone '' <-23-23> <0-59> <0-9> (config)# clock timezone '' 9 0 1 • Manual Setting (config)# clock timezone '' <-23-23> <0-59> <0-9>...
Page 70 SOLTECH USER GUIDE Industrial Switch SFC8100 Series CHECK CONFIGURATION Check Configuration  You can verify the change at Information Monitor Daylight Saving Time Monitor   You can verify the changes on the same page after saving  # show clock detail...
Page 71 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.1.6. Log WEB MENU Configuration>System>Log Configure System Log on this page. System Log Configuration Object Description Indicates the server mode operation. When the mode operation is enabled, the syslog message will send out to syslog server.
Page 72 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Enable  Server Address • IPv4 Address (PC Address)  Syslog Level • Audit • Error • Warning • Notice • Information EXAMPLE CLI CONFIGURATION System Log Configuration   Server Mode...
Page 73 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Disable (config)# no logging on • Enable (config)# logging on  Server Address • IPv4 Address (PC Address) (config)# logging host <ipv4_ucast> (config)# logging host 192.168.10.130  Syslog Level • Audit (config)# logging level audit •...
Page 74 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.2. System Monitor 6.1.2.1. Information WEB MENU Monitor>System>Information The switch system information is provided here. System Information Object Description Displays system information for the switch. System Displays switch identification information. Contact Displays switch Name.
Page 75 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Displays the current intenal templature of switch. Current Displays the minimum intenal templature of switch. Minimum Displays the maximum intenal templature of switch. Maximum Displays the average intenal templature of switch. Average EXAMPLE WEB MONITOR WEB MENU Monitor>System>Information...
Page 76 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Active Image ------------ Image : SFC8100BT.dat (primary) Version : OneImg_JAGUAR2 (standalone) build 5.0.3.0 by Soltech Corp. Date : 2023-07-21T14:21:27+09:00 Bank-Index : Bank1 Alternate Image --------------- Image : SFC8100BT.dat (backup) Version : OneImg_JAGUAR2 (standalone) build 5.0.1.0 by Soltech Corp.
Page 77 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.2.2. CPU Load WEB MENU Monitor>System>CPU Load This page displays the CPU load, using an SVG graph. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every 3 seconds.
Page 78 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.2.3. IP Status WEB MENU Monitor>System>IP Status This page displays the status of the IP protocol layer. The status is defined by the IP interfaces, the IP routes and the neighbor cache (ARP cache) status.
Page 79 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every seconds. : Click to refresh the page immediately. EXAMPLE WEB MONITOR EXAMPLE CLI MONITOR IP Interfaces  # show interface vlan VLAN1 LINK: 00-21-6d-00-87-32 Mtu:1500 <UP BROADCAST RUNNING MULTICAST>...
Page 80 SOLTECH USER GUIDE Industrial Switch SFC8100 Series IP Routes  # show ip route 0.0.0.0/0 via 192.168.10.1 <UP GATEWAY HW_RT> 2.2.2.0/24 via interface index 2 <UP HW_RT> 3.3.3.0/24 via 192.168.10.1 <UP GATEWAY HW_RT> 127.0.0.1/32 via 127.0.0.1 <UP HOST> 192.168.10.0/24 via interface index 1 <UP HW_RT>...
Page 81 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.2.4. Log WEB MENU Configuration>System>Log Configure System Log on this page. System Log Information Object Description Display the information from the system logs for the selected log level. Level Delete the information from the system logs for the selected log level.
Page 82 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Configuration>System>Log System Log Information   Level • example notice Select Notice> Click (Check only Notice)  Clear Level • example notice...
Page 83 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Select Notice> Click (Delete only Notice) EXAMPLE CLI MONITOR System Log Information  # show logging Switch logging host mode is enabled Switch logging host address is 192.168.10.130 Switch logging level is info.
Page 84 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6 Audit 1970-01-01T00:00:02+00:00 Intf. Port:2 TEST Ok!!!, (CAP:0x0000303F) 7 Audit 1970-01-01T00:00:02+00:00 Intf. Port:3 TEST Ok!!!, (CAP:0x0000303F) 21 Audit 1970-01-01T00:00:57+00:00 User [admin] logged on HTTP 22 Audit 1970-01-01T00:15:30+00:00 User admin logouted on HTTP 23 Audit 1970-01-01T00:15:35+00:00 User [admin] logged on HTTP ...
Page 85 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.1.2.5. Detailed Log WEB MENU Configuration>System>Detailed Log The switch system detailed log information is provided here. Detailed System Log Information Object Description The ID (>= 1) of the system log entry. Message The detailed message of the system log entry.
Page 86 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR Detailed System Log Information   # show logging <1-4294967295> # show logging 1 Switch : 1 Level : Audit Time : 1970-01-01T09:00:00+09:00 Message: Audit Log Start, Image:[SFC8100BT 5.0.3.0]...
Page 87 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.2. Green Ethernet 6.2.1. Green Ethernet Configuration 6.2.1.1. Port Power Savings WEB MENU Configuration>Green Ethernet>Port Power Savings This page allows the user to configure the port power savings features. Port Power Saving Configuration...
Page 88 SOLTECH USER GUIDE Industrial Switch SFC8100 Series : Click to undo any changes made locally and revert to previously saved values. EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Green Ethernet>Port Power Savings Port Power Saving Configuration   Optimize EEE for •...
Page 89 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  PerfectReach  EEE (Energy-Efficient Ethernet)  EEE Urgent Queues...
Page 90 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Port Power Saving Configuration   Optimize EEE for • Latency (config)# no green-ethernet eee optimize-for-power • Power (config)# green-ethernet eee optimize-for-power  ActiPHY (config)# interface GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# green-ethernet energy-detect ...
Page 91 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.2.2. Green Ethernet Monitor 6.2.2.1. Port Power Savings WEB MENU Monitor>Green Ethernet>Port Power Savings This page provides the current status for EEE. Port Power Saving Status Object Description Port This is the logical port number for this row.
Page 92 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR Port Power Saving Status  EXAMPLE CLI MONITOR  Port Power Saving Status # show green-ethernet Interface Link Energy-detect Short-Reach EEE Capable EEE Enabled LP EEE Capable EEE In Power Save...
Page 93 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3. Ports 6.3.1. Ports Configuration 6.3.1.1. Ports WEB MENU Configuration>Ports Indicate general setting detail of switch and configure. Port Configuration Object Description Port This is the logical port number for this row. The description of the port. It is an ASCII string no longer Description than 256 characters.
Page 94 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Ports in AMS mode with 1000-X speed has Cu port preferred. Ports in AMS mode with 1000-X speed has fiber port preferred. Ports in AMS mode with 100-FX speed has fiber port preferred.
Page 95 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION  Port Configuration  Description  Speed Configured Auto-negotiation is the default value, and other values are fixed. (speed, duplex)  Advertise Duplex For UTP ports, only Speed Auto can be configured, and Full duplex is prioritized and communicated to the link partner.
Page 96 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Speed – AUTO excluding 1G(connected as 100M full duplex based on priority) • Speed – AUTO excluding 1G, 100M(connected as 10M full duplex based on priority)  Flow Control • Flow Control Disable(default) •...
Page 97 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  • Enable • Priority  Maximum Frame Size (1518~10240bytes)
Page 98 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Excessive Collision Mode(Apply only UTP) • Discard(default) • Restart  Frame Length Check EXAMPLE CLI CONFIGURATION  Port Configuration  Description (config)# interface 10GigabitEthernet/ GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# description <line>...
Page 99 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Speed Configured Auto-negotiation is the default value, and other values are fixed. (speed, duplex) (config)# interface 10GigabitEthernet/ GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# speed { 10g | 2500 | 1000-c37 | 1000 | 100 | 10 | auto { [ 10 ] [ 100 ]...
Page 100 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  • Enable, Priority (config)# interface 10GigabitEthernet/GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)# priority-flowcontrol prio <0~7> (config-if)# priority-flowcontrol prio 0-7 (config-if)# priority-flowcontrol prio 1,3,7 • Disable, Priority (config)# interface 10GigabitEthernet/GigabitEthernet <port_type_list> (config)# interface GigabitEthernet 1/1 (config-if)#no priority-flowcontrol prio <0~7>...
Page 101 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3.2. Ports Monitor 6.3.2.1. State WEB MENU Monitor>Ports>State This page provides an overview of the current status of switch ports. State Link Link Disabled Down (non-Max Speed) (Max Speed) RJ-45 Ports SFP Ports Info.
Page 102 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Monitor>Ports>State EXAMPLE CLI CONFIGURATION Port State Overview  # show interface GigabitEthernet 1/1-4 status Interface Mode Speed & Duplex Flow Control Max Frame Excessive Link MAC-Addr ---------------------- ------- -------------- ------------ --------- --------- --------- --------...
Page 103 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3.2.2. Traffic Overview WEB MENU Monitor>Ports>Traffic Overview This page provides an overview of general traffic statistics for all switch ports. Port Statistics Overview Object Description Port The logical port. Click number will navigate to the Detailed Statistics.
Page 104 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR Port Statistics Overview  # show interface GigabitEthernet 1/1-4 statistics packets Interface Rx Packets Tx Packets ---------------------- ------------------ ------------------ GigabitEthernet 1/1 4434 2280 GigabitEthernet 1/2 GigabitEthernet 1/3 GigabitEthernet 1/4 # show interface 10GigabitEthernet 1/1-4 statistics packets...
Page 105 SOLTECH USER GUIDE Industrial Switch SFC8100 Series # show interface GigabitEthernet 1/1-4 statistics discards Interface Rx Discards Tx Discards ---------------------- ------------------ ------------------ GigabitEthernet 1/1 GigabitEthernet 1/2 GigabitEthernet 1/3 GigabitEthernet 1/4 # show interface 10GigabitEthernet 1/1-4 statistics discards Interface Rx Discards...
Page 106 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3.2.3. QoS Statistics WEB MENU Monitor>Ports>QoS Statistics This page provides statistics for the different queues for all switch ports. Queuing Counters Object Description Port The logical port. Click number will navigate to the Detailed Statistics.
Page 107 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR Queuing Counters  #show interface GigabitEthernet 1/1-4 statistics priority GigabitEthernet 1/1 Rx Priority queue Tx Priority queue ------------------------------------------ ------------------- ------------------ Priority 0 Priority 1 Priority 2 Priority 3 Priority 4...
Page 108 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Priority 4 Priority 5 Priority 6 Priority 7 10GigabitEthernet 1/2 Rx Priority queue Tx Priority queue ------------------------------------------ ------------------- ------------------ Priority 0 Priority 1 Priority 2 Priority 3 Priority 4 Priority 5 Priority 6...
Page 109 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3.2.4. QCL Status WEB MENU Monitor>Ports>QCL Status This page shows the QCL status by different QCL users. Each row describes the QCE that is defined. It is a conflict if a specific QCE is not applied to the hardware due to hardware limitations. The maximum number of QCEs is 256 on each switch.
Page 110 SOLTECH USER GUIDE Industrial Switch SFC8100 Series : Click to release the resources required to add QCL entry, in case the conflict status for any QCL entry is 'yes'. : Click to refresh the page.
Page 111 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.3.2.5. Detailed Statistics WEB MENU Monitor>Ports>Detailed Statistics This page provides detailed traffic statistics for a specific switch port. (Use the port select box to select which switch port details to display.) Detailed Port Statistics Port n...
Page 112 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Rx Filtered The number of received frames filtered by the forwarding process. Tx Drops The number of frames dropped due to output buffer congestion. Tx Late/Exc. The number of frames dropped due to excessive or late collisions.
Page 113 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Rx 128-255: Tx 128-255: Rx 256-511: Tx 256-511: Rx 512-1023: 130 Tx 512-1023: Rx 1024-1526: 0 Tx 1024-1526: Rx 1527- Tx 1527- Rx Priority 0: 2693 Tx Priority 0: Rx Priority 1: Tx Priority 1:...
Page 114 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4. DHCP 6.4.1. DHCP Configuration 6.4.1.1. Server Mode WEB MENU Configuration>DHCP>Server>Mode This page configures global mode and VLAN mode to enable/disable DHCP server per system and per VLAN. DHCP Server Mode Configuration Global Mode...
Page 115 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to add a new VLAN range. : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 116 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Disable EXAMPLE CLI CONFIGURATION Global Mode   Mode • Disable (config)# no ip dhcp server • Enable (config)# ip dhcp server VLAN Mode   Add VLAN Range • Enable (config)# interface vlan <vlan_list>...
Page 117 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.1.2. Server Excluded IP WEB MENU Configuration>DHCP>Server>Excluded IP This page configures excluded IP addresses. DHCP server will not allocate these excluded IP addresses to DHCP client. DHCP Server Excluded IP Configuration Excluded IP Address...
Page 118 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Excluded IP Address   Add IP Range • IP Range (config)# ip dhcp excluded-address <ipv4_addr> <ipv4_addr> (config)# ip dhcp excluded-address 192.168.10.1 192.168.10.101 (config)# ip dhcp excluded-address 192.168.10.103 192.168.10.130...
Page 119 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.1.3. Server Pool WEB MENU Configuration>DHCP>Server>Pool This page manages DHCP pools. According to the DHCP pool, DHCP server will allocate IP address and deliver configuration parameters to DHCP client. DHCP Server Pool Configuration...
Page 120 SOLTECH USER GUIDE Industrial Switch SFC8100 Series DHCP Pool Configuration Pool Object Description Name Select a pool by pool name. Setting Object Description Pool Name Display the selected pool name. Specify which type of the pool is. Network: the pool defines a pool of IP addresses to service more than Type one DHCP client.
Page 121 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Specify lease time that allows the client to request a lease time for the Lease Time IP address.(If all are 0's, then it means the lease time is infinite.) Specify domain name that client should use when resolving hostname Domain Name via DNS.
Page 122 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Name  DHCP Pool Configuration  Type • Network...
Page 123 SOLTECH USER GUIDE Industrial Switch SFC8100 Series DHCP Server Pool Configuration   Type • Network EXAMPLE CLI CONFIGURATION DHCP Server Pool Configuration   Add New Pool • Name (config)# ip dhcp pool <word32> (config)# ip dhcp pool DHCP_TEST ...
Page 124 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.1.4. Snooping WEB MENU Configuration>DHCP>Snooping Configure DHCP Snooping on this page. DHCP Snooping Configuration Object Description Indicates the DHCP snooping mode operation. Enabled: Enable DHCP snooping mode operation. When DHCP snooping mode operation is enabled, the DHCP request messages will...
Page 125 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Disable (Default) • Enable Port Mode Configuration   Mode • Trusted (Default)
Page 126 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Untrusted EXAMPLE CLI CONFIGURATION DHCP Snooping Configuration   Snooping Mode • Disable (Default) (config)# no ip dhcp snooping • Enable (config)# ip dhcp snooping Port Mode Configuration   Mode •...
Page 127 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.2. DHCP Monitor 6.4.2.1. Server Statistics WEB MENU Monitor>DHCP>Server>Statistics This page displays the database counters and the number of DHCP messages sent and received by DHCP server. DHCP Server Statistics Database Counters Object...
Page 128 SOLTECH USER GUIDE Industrial Switch SFC8100 Series DHCP Message Received Counters Object Description OFFER Number of DHCP OFFER messages sent. Number of DHCP ACK messages sent. Number of DHCP NAK messages sent. Buttons Auto-refresh : Check this box to refresh the page automatically.
Page 129 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Automatic Manual Expired ========================= Message Received Counters ========================= DISCOVER REQUEST DECLINE RELEASE INFORM ========================= Message Sent Counters ========================= OFFER =========================...
Page 130 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.2.2. Server Binding WEB MENU Monitor>DHCP>Server>Binding This page displays bindings generated for DHCP clients. DHCP Server Binding IP Binding IP Address Object Description IP address allocated to DHCP client. Click IP navigate to the detailed page.
Page 131 SOLTECH USER GUIDE Industrial Switch SFC8100 Series DHCP Server Binding IP Data WEB MENU Monitor>DHCP>Server>Binding This page displays the detailed data of a binding. DHCP Server Binding IP Data Binding Object Description IP address of the selected binding. Binding IP Data...
Page 132 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Monitor>DHCP>Server>Binding WEB MENU Monitor>DHCP>Server>Binding>Click IP EXAMPLE CLI MONITOR DHCP Server Binding IP  # show ip dhcp server binding IP: 192.168.10.102 ---------------------------------------------- State is committed Binding type is automatic Pool name is DHCP_TEST Server ID is 192.168.10.101...
Page 133 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.2.3. Server Declined IP WEB MENU Monitor>DHCP>Server>Declined IP This page displays declined IP addresses. DHCP Server Declined IP Declined IP Address Object Description Declined IP List of IP addresses declined. Buttons Auto-refresh : Check this box to refresh the page automatically.
Page 134 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.2.4. Snooping Table WEB MENU Monitor>DHCP>Snooping Table This page display the dynamic IP assigned information after DHCP Snooping mode is disabled. All DHCP clients obtained the dynamic IP address from the DHCP server will be listed in this table except for local VLAN interface IP addresses.
Page 135 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Monitor>DHCP>Snooping Table EXAMPLE CLI MONITOR Dynamic DHCP Snooping Table  # show ip dhcp snooping table Entry ID MAC Address : 00-21-6d-05-f0-5c VLAN ID Source Port : GigabitEthernet 1/1 IP Address : 192.168.10.102...
Page 136 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.4.2.5. Detailed Statistics WEB MENU Monitor>DHCP>Detailed Statistics This page provides statistics for DHCP snooping. Dynamic Detailed Statistics Port n Object Description Rx and Tx Discover The number of discover packets received and transmitted.
Page 137 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Monitor>DHCP>Detailed Statistics DHCP Detailed Statistics Port 1(Client/port1)  EXAMPLE CLI MONITOR DHCP Detailed Statistics Port 1(Client/port1)  # show ip dhcp detailed statistics client/combined/normal-forward/relay/server/snooping interface 10GigabitEthernet/GigabitEthernet <port_type_list> # show ip dhcp detailed statistics client interface GigabitEthernet 1/1...
Page 138 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5. Security 6.5.1. Switch Configuration The product provides authentication capabilities for both local administrators and users, granting permissions based on account-specific privilege levels. User Accounts and Permissions: Multiple users can be created on the switch, identified by their usernames and corresponding privilege levels.
Page 139 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Users Configuration Object Description User Name The name identifying the user. This is also a link to Add/Edit User. The privilege level of the user. The allowed range is 0 to 15. If the privilege level value is 15, it can access all groups, i.e.
Page 140 SOLTECH USER GUIDE Industrial Switch SFC8100 Series privilege level 15. Generally, the privilege level 15 can be used for an administrator account, privilege level 10 for a standard user account and privilege level 5 for a guest account. Buttons : Click to apply changes.
Page 141 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Users Configuration   Add New User • Add User / Edit User (config)# username <word31> privilege <0-15> password unencrypted (config)# username test privilege 10 password unencrypted #: Please input a new password (plain): <line31>...
Page 142 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.2. Privilege Levels WEB MENU Configuration>Security>Switch>Privilege Level This page provides an overview of the privilege levels. Privilege Level Configuration Object Description The name identifying the privilege group. In most cases, a privilege level group consists of a single module, but a few of them contains more than one.
Page 143 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Web- Users, Privilege Levels and everything in Maintenance. Debug Only present in CLI. Every group has an authorization Privilege level for the following sub groups: configuration read-only, configuration/execute read-write, status/statistics read- Privilege Level only, status/statistics read-write (e.g.
Page 144 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# web privilege group {1} level {2} <0-15> (config)# web privilege group DDMI level configRoPriv 6 Aggregation DDMI DHCP DHCPv6_Client Debug Diagnostics ERPS ETH_LINK_OAM Green_Ethernet IPMC_Snooping LACP LLDP Loop_Protect MAC_Table Maintenance Ports Private_VLANs...
Page 145 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.3. Auth Method WEB MENU Configuration>Security>Switch>Auth Method Authentication Method Configuration Object Description Authentication Method You can configure how a user is authenticated when they log into the Configuration switch via one of the management client interfaces.
Page 146 SOLTECH USER GUIDE Industrial Switch SFC8100 Series granted access to CLI commands according to his privilege level. Authorize all commands with a privilege level higher than or equal to Cmd Lvl this level. Valid values are in the range 0 to 15.
Page 147 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Accounting Method Configuration  EXAMPLE CLI CONFIGURATION Authentication Method Configuration  (config)# aaa authentication login {1} {2} (config)# aaa authentication login console tacacs radius local (config)# aaa authentication login ssh tacacs local (config)# aaa authentication login http radius tacacs local...
Page 148 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.4. Telnet WEB MENU Configuration>Security>Switch>Telnet Configure Telnet on this page. Telnet Configuration Object Description Indicates the Telnet mode operation. Mode Enabled: Enable Telnet mode operation. Disabled: Disable Telnet mode operation.(Default) Port(TCP) Enter the TCP port for Telnet access.
Page 149 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Fail Blocking Time(s) • 10~3600sec EXAMPLE CLI CONFIGURATION Telnet Configuration   Mode • Enable | Disable (config)# ip telnet (config)# no ip telnet  Port(TCP) • Default 23 (config)# ip telnet port { <port> | default }...
Page 150 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.5. SSH WEB MENU Configuration>Security>Switch>SSH Configure SSH on this page. SSH Configuration Object Description Indicates the SSH mode operation. Mode Enabled: Enable SSH mode operation. Disabled: Disable SSH mode operation. Port(TCP) TCP port number for SSH Service Max Connection Number of clients accessible to the switch.
Page 151 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Fail Blocking Time(s) • 10~3600sec EXAMPLE CLI CONFIGURATION  SSH Configuration  Mode • Enable | Disable (config)# ip ssh (config)# no ip ssh  Port(TCP) • 1~65534 | 22(default) (config)# ip ssh port { <port> | default }...
Page 152 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.6. HTTPS WEB MENU Configuration>Security>Switch>HTTPS This page allows you to configure the HTTPS settings and maintain the current certificate on the switch. HTTPS Configuration Object Description Indicate the HTTPS mode operation. Enabled: Enabled HTTPS mode operation.
Page 153 SOLTECH USER GUIDE Industrial Switch SFC8100 Series allowed. Display the current status of certificate on the switch. Switch secure HTTP certificate is presented. Certificate Status Switch secure HTTP certificate is not presented. Switch secure HTTP certificate is generating. Max Connection Number of clients accessible to the switch.
Page 154 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Max Connection • 1 | 2 | 3 | 4  Fail Blocking Time(s) • 10~3600sec  Certificate Upload • Web Browser | URL  File Upload | URL...
Page 155 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION  HTTPS Configuration  Mode • Enable(default) | Disable (config)# ip http secure-server (config)# no ip http secure-server  Automatic Redirect • Enable(default) | Disable (config)# ip http secure-redirect (config)# no ip http secure-redirect ...
Page 156 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.7. Access Management WEB MENU Configuration>Security>Switch>Access Management Configure access management table on this page. The maximum number of entries is 16. Access Management Configuration Object Description Indicates the access management mode operation. Mode Enabled: Enable access management mode operation.
Page 157 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Disable(default) • Enable  Add New Entry EXAMPLE CLI CONFIGURATION Access Management Configuration   Mode • Disable(default) (config)# no access management • Enable (config)# access management  Add New Entry (config)# access management <1-16> <1-4095> <ipv4_addr> to <ipv4_addr> [1] (config)# access management 1 1 192.168.10.1 to 192.168.10.135 web telnet...
Page 158 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8. SNMP 6.5.1.8.1. System WEB MENU Configuration>Security>SNMP>System Configure SNMP on this page SNMP System Configuration Object Description Indicates the SNMP mode operation. Mode Enabled: Enable SNMP mode operation. Disabled: Disable SNMP mode operation.
Page 159 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>SNMP>System SNMP System Configuration   Mode • Disable(default) • Enable  Version...
Page 160 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Community(v1/v2c) • Read Community • Write Community  Engine ID(v3)  Secure OS products EXAMPLE CLI CONFIGURATION SNMP System Configuration   Mode • Disable(default) (config)# no snmp-server...
Page 161 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Enable (config)# snmp-server  Version (config)# snmp-server version {1} (config)# snmp-server version v1 v1 v2c v3  Community(v1/v2c) • Read Community (config)# snmp-server community v2c <word255> ro (config)# snmp-server community v2c test123 ro •...
Page 162 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8.2. Trap WEB MENU Configuration>Security>SNMP>Trap Configure SNMP trap on this page. Trap Configuration Global Setting Object Description Indicates the trap mode operation. Mode Enabled: Enable SNMP trap mode operation. Disabled: Disable SNMP trap mode operation.
Page 163 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to add a new user. (Clicking on the button will open the SNMP Trap Configuration window.) : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 164 SOLTECH USER GUIDE Industrial Switch SFC8100 Series the first character must be an alpha character, and the first and last characters must not be a dot or a dash. Indicates the SNMP trap destination port. SNMP Agent will send SNMP Trap Destination port message via this port, the port range is 1~65535.
Page 165 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>SNMP>Trap Global Setting   Mode • Disable(default) • Enable Trap Destination Configurations   Add New Entry • Use SNMP v1...
Page 166 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Use SNMP v2c EXAMPLE CLI CONFIGURATION Global Setting   Mode • Disable(default) (config)# no snmp-server trap • Enable (config)# snmp-server trap...
Page 167 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Trap Destination Configurations   Add New Entry • Use SNMP v1 (config)# snmp-server host <word32> (config)# snmp-server host TEST-123 (config-snmps-host)# (config-snmps-host)# shutdown (config-snmps-host)# version {v1/v2/v3} <word255> (config-snmps-host)# version v1 def_trap_pwd (config-snmps-host)# host { <v_ipv4_ucast> | <v_word> } [ <udp_port> ] [ traps | informs ] (config-snmps-host)# host 192.168.10.130 162...
Page 168 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8.3. Communities WEB MENU Configuration>Security>SNMP>Communities Configure SNMPv3 community table on this page. The entry index key is Community. SNMPv3 Community Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 169 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION SNMPv3 Community Configuration   Add New Entry (config)# snmp-server community v3 <v3_comm> [<v_ipv4_addr> <v_ipv4_netmask>] (config)# snmp-server community v3 def_ro_pwd 192.168.10.0 255.255.255.0 (config)# snmp-server community v3 def_rw_pwd 192.168.10.0 255.255.255.0...
Page 170 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8.4. Users WEB MENU Configuration>Security>SNMP>Users Configure SNMPv3 user table on this page. The entry index keys are Engine ID and User Name. SNMPv3 User Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 171 SOLTECH USER GUIDE Industrial Switch SFC8100 Series A string identifying the privacy password phrase. The allowed string length is Privacy Password 8 to 32, and the allowed content is ASCII characters from 33 to 126. Buttons : Click to add a new user entry.
Page 172 SOLTECH USER GUIDE Industrial Switch SFC8100 Series SNMPv3 User Configuration   Add New Entry • NoAuth, NoPriv (config)# snmp-server user <username> engine-id <engineID> (config)# snmp user TEST-123 engine-id 800007e5017f000001 • Auth, NoPriv (config)# snmp-server user <username> engine-id <engineID> [ { sha | sha224 | sha256 | sha384 | sha512 } <auth_passwd>...
Page 173 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8.5. Groups WEB MENU Configuration>Security>SNMP>Groups Configure SNMPv3 group table on this page. The entry index keys are Security Model and Security Name. SNMPv3 Group Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 174 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • (Security Name influenced by Communities) • (Security Name influenced by Users) EXAMPLE CLI CONFIGURATION SNMPv3 Group Configuration   Add New Entry • (Security Name influenced by Communities) (config)# snmp-server security-to-group model { v1 | v2c | v3 } name <security_name>...
Page 175 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8.6. Views WEB MENU Configuration>Security>SNMP>Views Configure SNMPv3 view table on this page. The entry index keys are View Name and OID Subtree. SNMPv3 View Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 176 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION SNMPv3 Group Configuration   Add New Entry • test_view(excluded SysName) (config)# snmp-server view <view_name> <oid_subtree> { include | exclude } (config)# snmp-server view test_view .1 include (config)# snmp-server view test_view .1.3.6.1.2.1.1.5.0 exclude...
Page 177 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.1.8.7. Access WEB MENU Configuration>Security>SNMP>Access Configure SNMPv3 access table on this page. The entry index keys are Group Name, Security Model and Security Level. SNMPv3 Access Configuration Object Description Delete Check to delete the entry. It will be deleted during the next save.
Page 178 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION SNMPv3 Access Configuration   Add New Entry • default_rw_group(test_view) EXAMPLE CLI CONFIGURATION SNMPv3 Access Configuration   Add New Entry • default_rw_group(test_view) (config)# snmp-server access <group_name> model { v1 | v2c | v3 | any } level { auth | noauth | priv } [ read <view_name>...
Page 179 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2. Network Configuration 6.5.2.1. Limit Control WEB MENU Configuration>Security>Network>Limit Control This page allows you to configure the Port Security Limit Control system and port settings. You can set up port security aging for each system.
Page 180 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Port Security Limit Control Configuration System Configuration Object Description Indicates if Limit Control is globally enabled or disabled on the switch. Mode If globally disabled limit checks and corresponding actions are disabled. If checked, secured MAC addresses are subject to aging as discussed under Aging Enabled Aging Period.
Page 181 SOLTECH USER GUIDE Industrial Switch SFC8100 Series switch, 3) Click the Reopen button. Trap&Shutdown If Limit + 1 MAC addresses is seen on the port, both the "Trap" and the "Shutdown" actions described above will be taken. This column shows the current state of the port as seen from the Limit Control's point of view.
Page 182 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Disabled • Enabled  Aging Period (10 ~ 9,999,999 seconds) Port Configuration   Mode • Disabled • Enabled  Limit (1 ~ 1024 MAC address)
Page 183 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Action • None | Trap | Shutdown | Trap&Shutdown EXAMPLE CLI CONFIGURATION System Configuration   Mode • Disabled (config)# no port-security • Enabled (config)# port-security  Aging Enable • Disabled (config)# no port-security aging •...
Page 184 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# port-security aging time <v_10_to_9999999> (config)# port-security aging time 9999999 Port Configuration   Mode • Disabled (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# no port-security •...
Page 185 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.2. ACL ACL (Access Control List) is composed of ACE (Access Control Entry) entries that specify individual users or groups allowed access to specific traffic entities such as processes or programs. ACE parameters vary depending on the selected frame type.
Page 186 SOLTECH USER GUIDE Industrial Switch SFC8100 Series ACEs are configured with multiple parameters, which vary depending on the selected frame type. Incoming ports must select the next frame type chosen for ACE. Different parameter options are displayed based on the chosen frame type. Supported frame types include: •...
Page 187 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Select which rate limiter to apply on this port. The allowed values are Rate Limiter ID Disabled or the values 1 through 16. The default value is "Disabled". Select which port frames are redirected on. The allowed values are Disabled Port Redirect or a specific port number.
Page 188 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Rate Limiter ID • Disabled | 1~16  Port Redirect (Need Action Deny) • Disabled(default) | Port Number  Mirror • Disabled(default) | Enabled  Logging • Disabled(default) | Enabled  Shutdown •...
Page 189 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  State • Enabled(default) | Disabled EXAMPLE CLI CONFIGURATION ACL Ports Configuration   Policy ID • 0~255(default 0) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# access-list policy <policy_id>...
Page 190 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config-if)# access-list redirect interface { <port_type> <port_type_id> | ( <port_type> [ <port_type_list> ] ) } (config-if)# access-list redirect interface GigabitEthernet 1/4  Mirror • Disabled(default) | Enabled (config-if)# no access-list mirror (config-if)# access-list mirror ...
Page 191 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.2.2. Rate Limiters WEB MENU Configuration>Security>Network>ACL>Rate Limiters Configure the rate limiter for the ACL of the switch. ACL Ports Configuration Object Description The rate limiter ID for the settings contained in the same row and its range is Rate Limiter ID 1 to 16.
Page 192 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION ACL Rate Limiter Configuration   Rate • 0 ~ 5,000,000pps or 0 ~ 10,000,000kbps (config)# access-list rate-limiter [ <rate_limiter_list> ] { 10pps <pps10_rate> | 25kbps <kpbs25_rate> } (config)# access-list rate-limiter <1-16> 10pps <0-500000>...
Page 193 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.2.3. Access Control List Configuration WEB MENU Configuration>Security>Network>ACL>Access Control List This page shows the Access Control List (ACL), which is made up of the ACEs defined on this switch. Each row describes the ACE that is defined. The maximum number of ACEs is 512 on each switch.
Page 194 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Counter Indicates the number of times the ACE was hit by a frame. Modification You can modify each ACE in the table using the following buttons: Inserts a new ACE before the current row.
Page 195 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Specific: If you want to filter a specific policy with this ACE, choose this value. Two field for entering an policy value and bitmask appears. When "Specific" is selected for the policy filter, you can enter a specific Policy Value policy value.
Page 196 SOLTECH USER GUIDE Industrial Switch SFC8100 Series source MAC address. The legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that hits this ACE matches this SMAC value DMAC Filter Specify the destination MAC filter for this ACE.
Page 197 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Target IP Address When "Host" or "Network" is selected for the target IP filter, you can enter a specific target IP address in dotted decimal notation. Target IP Mask When "Network" is selected for the target IP filter, you can enter a specific target IP mask in dotted decimal notation.
Page 198 SOLTECH USER GUIDE Industrial Switch SFC8100 Series OFFSET) field for an IPv4 frame. IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater than zero must not be able to match this entry. IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater than zero must be able to match this entry.
Page 199 SOLTECH USER GUIDE Industrial Switch SFC8100 Series means this bit is "don't-care". The real matched pattern is [sipv6_address & sipv6_bitmask] (last 32 bits). For example, if the SIPv6 address is 2001::3 and the SIPv6 bitmask is 0xFFFFFFFE(bit 0 is "don't-care" bit), then SIPv6 address 2001::2 and 2001::3 are applied to this rule.
Page 200 SOLTECH USER GUIDE Industrial Switch SFC8100 Series TCP/UDP Destination When "Range" is selected for the TCP/UDP destination filter, you can enter a specific TCP/UDP destination range value. The allowed range is Range 0 to 65535. A frame that hits this ACE matches this TCP/UDP destination value.
Page 201 SOLTECH USER GUIDE Industrial Switch SFC8100 Series this ACE matches this EtherType value. Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 202 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Example) Deny frames based on the source MAC address from PORT1. (config)# access-list ace <ace_id> [1] (config)# access-list ace 1 ingress interface GigabitEthernet 1/1 frame-type etype smac 00-21-6d-05-f0-5c action deny...
Page 203 SOLTECH USER GUIDE Industrial Switch SFC8100 Series { <sportv4_tcp_start> [ to <sportv4_tcp_end> ] | any } ] [ dport { <dportv4_tcp_start> [ to <dportv4_tcp_end> ] | any } ] [ ip-flag [ ip-ttl { <ip_flag_tcp_ttl> | any } ] [ ip-options { <ip_flag_tcp_options>...
Page 204 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.3. IP Source Guard 6.5.2.3.1. Configuration WEB MENU Configuration>Security>Network>IP Source Guard>Configuration This page provides IP Source Guard related configuration. IP Source Guard Configuration Object Description Mode of IP Source Enable the Global IP Source Guard or disable the Global IP Source Guard.
Page 205 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION IP Source Guard Configuration   Mode • Disable | Enable  Port Mode Configuration  Mode • Disable | Enable  Max Dynamic Clients • 0 | 1 | 2 | Unlimited...
Page 206 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Disable | Enable (config)# no ip verify source (config)# ip verify source Port Mode Configuration   Mode • Disable | Enable (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1...
Page 207 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.3.2. Static Table WEB MENU Configuration>Security>Network>IP Source Guard>Static Table This page shows the static IP Source Guard rules. The maximum number of rules is 112 on the switch. Static IP Source Guard Table...
Page 208 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Static IP Source Guard Table   Add New Entry • Port | VLAN ID(Port VLAN) | IP Address | MAC address (config)# ip source binding interface <port_type> <in_port_type_id> <vlan_var>...
Page 209 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.4. ARP Inspection 6.5.2.4.1. Port Configuration WEB MENU Configuration>Security>Network>ARP Inspection>Port Configuration This page provides ARP Inspection related configuration. ARP Inspection Configuration Object Description Mode Enable the Global ARP Inspection or disable the Global ARP Inspection.
Page 210 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. : Click to translate all dynamic entries to static entries.
Page 211 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Log Type • None | Deny | Permit | All EXAMPLE CLI CONFIGURATION ARP Inspection Configuration   Mode • Disable | Enable (config)# no ip arp inspection (config)# ip arp inspection Port Mode Configuration ...
Page 212 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# no ip arp inspection logging (config-if)# ip arp inspection logging { deny | permit | all } (config-if)# ip arp inspection logging deny...
Page 213 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.4.2. VLAN Configuration WEB MENU Configuration>Security>Network>ARP Inspection>VLAN Configuration This page provides ARP Inspection related configuration. VLAN Mode Configuration Object Description Specify ARP Inspection is enabled on which VLANs. First, you have to enable the port setting on Port configuration.
Page 214 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Log Type( None | Deny | Permit | All ) EXAMPLE CLI CONFIGURATION VLAN Mode Configuration   Add New Entry • VLAN ID(1~4095) (config)# ip arp inspection vlan <in_vlan_list> (config)# ip arp inspection vlan 4095 •...
Page 215 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.4.3. Static Table WEB MENU Configuration>Security>Network>ARP Inspection>Static Table This page shows the static ARP Inspection rules. The maximum number of rules is 256 on the switch. Static ARP Inspection Table Object Description Delete Check to delete the entry.
Page 216 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Static ARP Inspection Table   Add New Entry • Example (config)# ip arp inspection entry interface <port_type> <in_port_type_id> <vlan_var> <mac_var> <ipv4_var> (config)# ip arp inspection entry interface GigabitEthernet 1/4 1 00-21-6d-05-f0-5c...
Page 217 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.2.4.4. Dynamic Table WEB MENU Configuration>Security>Network>ARP Inspection>Dynamic Table Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic ARP Inspection Table contains up to 256 entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address.
Page 218 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.3. AAA Configuration AAA allows for common server configurations including Timeout, Retransmit, Secret Key, NAS IP Address, NAS IPv6 Address, NAS Identifier, and Dead Time parameters. The software supports configuration of RADIUS and TACACS+ servers.
Page 219 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Global Configuration Object Description Timeout is the number of seconds, in the range 1 to 1000, to wait for a reply Timeout from a RADIUS server before retransmitting the request. Retransmit is the number of times, in the range 1 to 1000, a RADIUS request Retransmit is retransmitted to a server that is not responding.
Page 220 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>AAA>RADIUS Global Configuration   Timeout(3sec)  Retransmit(5times)  Deadtime(2minutes)  Key (Radius server secret key)  Add New Server...
Page 221 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Global Configuration   Timeout(3sec) (config)# radius-server timeout <seconds> (config)# radius-server timeout 3  Retransmit(5times) (config)# radius-server retransmit <retries> (config)# radius-server retransmit 5  Deadtime(2minutes) (config)# radius-server deadtime <minutes> (config)# radius-server deadtime 2 ...
Page 222 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.3.2. TACACS+ WEB MENU Configuration>Security>AAA>TACACS+ This page allows you to configure the TACACS+ servers. TACACS+ Server Configuration Global Configuration Object Description Timeout is the number of seconds, in the range 1 to 1000, to wait for a reply Timeout from a TACACS+ server before it is considered to be dead.
Page 223 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Security>AAA>TACACS+ Global Configuration   Timeout(3sec)  Deadtime(2minutes)  Key (Tacacs+ server secret key)  Add New Server EXAMPLE CLI CONFIGURATION  Global Configuration  Timeout(3sec) (config)# tacacs-server timeout <seconds>...
Page 224 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Key (Tacacs+ server secret key) (config)# tacacs-server key [ <key> ] (config)# tacacs-server key tacacs11  Add New Server (config)# tacacs-server host <host_name> [ port <port> ] [ timeout <seconds> ] [ key <key>...
Page 225 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.4. Access Management Statistics Monitor WEB MENU Monitor>Security>Access Management Statistics This page provides statistics for access management. Access Management Statistics Object Description Interface The interface type through which the remote host can access the switch.
Page 226 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Access Management Statistics: ----------------------------- HTTP Receive: Allow: Discard: HTTPS Receive: Allow: Discard: SNMP Receive: Allow: Discard: TELNET Receive: Allow: Discard: Receive: Allow: Discard:...
Page 227 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.5. Network Monitor 6.5.5.1. Port Security 6.5.5.1.1. Switch WEB MENU Monitor>Security>Network>Port Security>Switch This page shows the Port Security status. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 228 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Each of the user modules has a column that shows whether that module has enabled Port Security or not. A '-' means that the corresponding user module Users is not enabled, whereas a letter indicates that the user module abbreviated by that letter (see Abbr) has enabled port security.
Page 229 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Monitor>Security>Network>Port Security>Switch Port Security Switch Status  EXAMPLE CLI MONITOR Port Security Switch Status  # show port-security switch [ interface ( <port_type> [ <v_port_type_list> ] ) ]...
Page 230 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.5.1.2. Port WEB MENU Monitor>Security>Network>Port Security>Port This page shows the MAC addresses secured by the Port Security module. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 231 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Monitor>Security>Network>Port Security>Switch Port Security Switch Status  EXAMPLE CLI MONITOR Port Security Switch Status  # show port-security port [ interface ( <port_type> [ <v_port_type_list> ] ) ]...
Page 232 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.5.2. ACL Status WEB MENU Monitor>Security>Network>ACL Status This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific ACE is not applied to the hardware due to hardware limitations. The maximum number of ACEs is 512 on each switch.
Page 233 SOLTECH USER GUIDE Industrial Switch SFC8100 Series : The select box determines which ACL user is affected by clicking the buttons. EXAMPLE WEB MONITOR WEB MENU Monitor>Security>Network>ACL Status EXAMPLE CLI MONITOR ACL Status  # show access-list ace-status [ static ] [ link-oam ] [ loop-protect ] [ dhcp ] [ arp-...
Page 234 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.5.3. ARP Inspection WEB MENU Monitor>Security>Network>ARP Inspection Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic ARP Inspection Table contains up to 256 entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address.
Page 235 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.5.4. IP Source Guard WEB MENU Monitor>Security>Network>IP Source Guard Entries in the Dynamic IP Source Guard Table are shown on this page. The Dynamic IP Source Guard Table is sorted first by port, then by VLAN ID, then by IP address, and then by MAC address.
Page 236 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.6. AAA Monitor 6.5.6.1. RADIUS Overview WEB MENU Monitor>Security>AAA>RADIUS Overview This page provides an overview of the status of the RADIUS servers configurable on the Authentication configuration page. RADIUS Server Status Overview Object Description The RADIUS server number.
Page 237 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.5.6.2. RADIUS Details WEB MENU Monitor>Security>AAA>RADIUS Details This page provides detailed statistics for a particular RADIUS server. RADIUS Authentication Statistics for Server #n Object Description RADIUS The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client Authentication MIB.
Page 238 SOLTECH USER GUIDE Industrial Switch SFC8100 Series This section contains information about the state of the server and the latest round-trip time. IP Address IP address and UDP port for the authentication server in question. Other Info The number of RADIUS Access-Reject packets (valid or invalid) State received from the server.
Page 239 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.6. Aggregation 6.6.1. Static Configuration WEB MENU Configuration>Aggregation>Static This page is used to configure the Aggregation hash mode and the aggregation group. Aggregation Mode Configuration Hash Code Contributors Object Description The Source MAC address can be used to calculate the destination port for the frame.
Page 240 SOLTECH USER GUIDE Industrial Switch SFC8100 Series : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Aggregation>Static Aggregation Mode Configuration   Hash Code Contributors •...
Page 241 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Aggregation Mode Configuration   Hash Code Contributors • Source MAC Address(Check) • Destination MAC Address(Uncheck) • IP Address(Check) • TCP/UDP Port Number(Check) (config)# aggregation mode { [ smac ] [ dmac ] [ ip ] [ port ] }*1...
Page 242 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.6.2. LACP Configuration WEB MENU Configuration>Aggregation>LACP This page allows the user to inspect the current LACP port configurations, and possibly change them as well. LACP Port Configuration Object Description Port The switch port number.
Page 243 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>Aggregation>LACP LACP Port Configuration   LACP Enable • Enable(1~2 Port)  • Auto | Specific(1~65535)
Page 244 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Role • Active | Passive  Timeout • Fast | Slow  Prio • 1~65535...
Page 245 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION LACP Port Configuration   LACP Enable • Enable(1~2 Port) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1-2 (config-if)# lacp  • Auto | Specific(1~65535) (config-if)# lacp key { <v_1_to_65535> | auto }...
Page 246 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.6.3. Static Monitor WEB MENU Monitor>Aggregation>Static This page is used to see the staus of ports in Aggregation group. Aggregation Status Object Description Aggr ID The Aggregation ID associated with this aggregation instance.
Page 247 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.6.4. LACP Monitor 6.6.4.1. System Status WEB MENU Monitor>Aggregation>LACP>System Status This page provides a status overview for all LACP instances. LACP System Status Object Description The Aggregation ID associated with this aggregation instance. For LLAG the id is shown...
Page 248 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.6.4.2. Port Status WEB MENU Monitor>Aggregation>LACP>Port Status This page provides a status overview for LACP status for all ports. LACP Status Object Description Port The switch port number. 'Yes' means that LACP is enabled and the port link is up. 'No' means that LACP is not enabled or that the port link is down.
Page 249 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR LACP Status  # show lacp neighbor Aggr ID Partner System ID Partner Prio Partner Key Last Changed ------- ----------------- ------------ ----------- ------------ 00:21:6d:00:00:00 32768 00:35:08 Port State Aggr ID Partner Port Partner Port Prio...
Page 250 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR LACP Statistics  # show lacp statistics Port Rx Frames Tx Frames Rx Unknown Rx Illegal -------------------- ---------- ---------- ---------- ---------- Gi 1/1 Gi 1/2...
Page 251 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.7. Loop Protection 6.7.1. Loop Protection Configuration WEB MENU Configuration>Loop protection This page allows the user to inspect the current Loop Protection configurations, and possibly change them as well. Loop Protection Configuration General Settings...
Page 252 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Controls whether the port is actively generating loop protection PDU's, or whether it is Tx Mode just passively looking for looped PDU's. Buttons : Click to apply changes. : Click to apply and save changes.
Page 253 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Action • Shudown Port(default) | Shutdown Port and Log | Log Only  Tx Mode • Enable(default) | Disable...
Page 254 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION General Settings  Global Configuration   Enable Loop Protection • Disable | Enable (config)# no loop-protect (config)# loop-protect  Transmission Time • 5sec (1~10) (config)# loop-protect transmit-time <t> (config)# loop-protect transmit-time 5 ...
Page 255 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.7.2. Loop Protection Monitor WEB MENU Configuration>Loop Protection This page displays the loop protection port status the ports of the switch. Loop Protection Status Object Description Port The switch port number of the logical port.
Page 256 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR Loop Protection Status  # show loop-protect interface * Loop Protection Configuration ====================================== Loop Protection : Enable Transmission Time : 5 sec Shutdown Time : 180 sec GigabitEthernet 1/1 ------------------------------ Loop protect mode is enabled.
Page 257 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8. Spanning Tree 6.8.1. Spanning Tree Configuration 6.8.1.1. Bridge Setting WEB MENU Configuration>Spanning Tree>Bridge Setting This page allows you to configure STP system settings. The settings are used by all STP Bridge instances in the Switch .
Page 258 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Filtering Edge Port BPDU Control whether a port explicitly configured as Edge will disable itself upon reception of a BPDU. The port will enter the error-disabled state, and will be removed from the active Guard topology.
Page 259 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Forward Delay(Default 15, 4~30sec) • Max Age (Default 20, 6~40sec) • Maximum Hop Count(Default 20, 6~40sec) • Transmit Hold Count(Default 6, 1~10sec)  Advanced Settings • Edge Port BPDU Filtering • Edge Port BPDU Guard •...
Page 260 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# spanning-tree mst forward-time <fwdtime> (config)# spanning-tree mst forward-time 15 • Max Age (Default 20, 6~40sec) (config)# spanning-tree mst max-age <maxage> (config)# spanning-tree mst max-age 20 • Maximum Hop Count(Default 20, 6~40sec) (config)# spanning-tree mst max-hops <maxhops>...
Page 261 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.1.2. MSTI Mapping WEB MENU Configuration>Spanning Tree>MSTI Mapping This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. MSTI Configuration Configuration Identification...
Page 262 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. EXAMPLE WEB CONFIGURATION MSTI Configuration ...
Page 263 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Configuration Name | Revision(0~65535) (config)# spanning-tree mst name <name> revision <v_0_to_65535> (config)# spanning-tree mst name MSTP1 revision 65535  MSTI Mapping • VLANs Mapped (config)# spanning-tree mst <instance> vlan <v_vlan_list> (config)# spanning-tree mst 1 vlan 1-10,4094...
Page 264 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.1.3. MSTI Priorities WEB MENU Configuration>Spanning Tree>MSTI Priorities This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. MSTI Configuration MSTI Priority Configuration...
Page 265 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION MSTI Configuration   MSTI Priority Configuration • MSTI(0-7) • Priority(Default 32768) (config)# spanning-tree mst <instance> priority <prio> (config)# spanning-tree mst 1 priority 0 (config)# spanning-tree mst 1 priority 61440...
Page 266 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.1.4. CIST Ports WEB MENU Configuration>Spanning Tree>CIST Ports This page allows the user to inspect the current STP CIST port configurations, and possibly change them as well. This page contains settings for physical and aggregated ports.
Page 267 SOLTECH USER GUIDE Industrial Switch SFC8100 Series If enabled, causes the port not to propagate received topology change notifications and topology changes to other ports. If set it can cause temporary loss of connectivity after changes in a spanning tree's active topology as a result of persistently incorrect learned Restricted TCN station location information.
Page 268 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Priority • 0|16|32|48|64|80|96|112|128|144|160|176|192|208|224|240  Admin Edge • Non-Edge | Edge  Auto Edge • Enable | Disable  Restricted Role • Enable | Disable  Restricted TCN • Enable | Disable...
Page 269 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  BPDU Guard • Enable | Disable  Point-to-Point • Forced True | Forced False | Auto EXAMPLE CLI CONFIGURATION CIST Aggregated Port Configuration   CIST Normal Port Configuration  STP Enabled •...
Page 270 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Priority • 0|16|32|48|64|80|96|112|128|144|160|176|192|208|224|240 (config-stp-aggr)# spanning-tree mst 0 port-priority <prio> (config-stp-aggr)# spanning-tree mst 0 port-priority 128 (config-if)# spanning-tree mst 0 port-priority <prio> (config-if)# spanning-tree mst 0 port-priority 128  Admin Edge • Non-Edge | Edge...
Page 271 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  BPDU Guard • Enable | Disable (config-stp-aggr)# spanning-tree bpdu-guard (config-stp-aggr)# no spanning-tree bpdu-guard (config-if)# spanning-tree bpdu-guard (config-if)# no spanning-tree bpdu-guard  Point-to-Point • Forced True | Forced False | Auto (config-stp-aggr)# spanning-tree link-type point-to-point...
Page 272 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.1.5. MSTI Ports WEB MENU Configuration>Spanning Tree>MSTI Ports This page allows the user to inspect the current STP MSTI port configurations, and possibly change them as well. An MSTI port is a virtual port, which is instantiated separately for each active CIST (physical) port for each MSTI instance configured on and applicable to the port.
Page 273 SOLTECH USER GUIDE Industrial Switch SFC8100 Series MSTn MSTI Port Configuration MSTI Aggregated Ports Configuration MSTI Normal Ports Configuration Object Description Port The switch port number of the corresponding STP CIST (and MSTI) port. Controls the path cost incurred by the port. The Auto setting will set the path cost as appropriate by the physical link speed, using the 802.1D recommended values.
Page 274 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Auto | Specific(1~200,000,000)  Priority • 0|16|32|48|64|80|96|112|128|144|160|176|192|208|224|240 EXAMPLE CLI CONFIGURATION  MSTI Port Configuration • Select MSTI mst <instance> (CIST=0, MSTI1=1, MSTI2=2, …, MSTI7=7) MSTn MSTI Port Configuration  MSTI Aggregated Ports Configuration ...
Page 275 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config-stp-aggr)# spanning-tree mst 1 cost 200000000 (config)# interface ( <port_type> [ <plist> ] ) (config)# interface * (config-if)# spanning-tree mst <instance> cost { <cost> | auto } (config-if)# spanning-tree mst 1 cost auto (config-if)# spanning-tree mst 1 cost 200000000 ...
Page 276 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.2. Spanning Tree Monitor 6.8.2.1. Bridge Status WEB MENU Monitor>Spanning Tree>Bridge Status This page provides a status overview of all STP bridge instances. The displayed table contains a row for each STP bridge instance, where the column displays the following...
Page 277 SOLTECH USER GUIDE Industrial Switch SFC8100 Series STP Detailed Bridge Status Object Description STP Bridge Status This entry shows the state of the STP bridge instance. Bridge Instance The Bridge instance - CIST, MST1, ... Bridge ID The Bridge ID of this Bridge instance.
Page 278 SOLTECH USER GUIDE Industrial Switch SFC8100 Series WEB MENU Monitor>Spanning Tree>Bridge Status STP Bridges  When you click on MSTI, the STP Detailed Bridge Status window will open. STP Detailed Bridge Status  CIST Ports & Aggregations State  EXAMPLE CLI MONITOR STP Bridges ...
Page 279 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Port Port Role State Pri PathCost Edge P2P Uptime --------- -------------- ---------- --- -------- ---- --- ------------- Gi 1/2 DesignatedPort Forwarding 128 20000 Yes Yes 0d 01:32:52 MSTI1 Bridge STP Status Bridge ID : 32769.00-21-6D-00-00-00...
Page 280 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.2.2. Port Status WEB MENU Monitor>Spanning Tree>Port Status This page displays the STP CIST port status for physical ports of the switch. STP Port Status Object Description Port The switch port number of the logical STP port.
Page 281 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR STP Port Status  # show spanning-tree mst 0 int * Port Port Role State Pri PathCost Edge P2P Uptime ----- --------- -------------- ---------- --- -------- ---- --- ------------- CIST Gi 1/2...
Page 282 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.8.2.3. Port Statistics WEB MENU Monitor>Spanning Tree>Port Statistics This page displays the STP port statistics counters of bridge ports in the switch. STP Statistics Object Description Port The switch port number of the logical STP port.
Page 283 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.9. IPMC Profile 6.9.1. Profile Table Configuration WEB MENU Configuration>IPMC Profile>Profile Table This page provides IPMC Profile related configurations. The IPMC profile is used to deploy the access control on IP multicast streams. It is allowed to create at maximum 64 Profiles with at maximum 128 corresponding rules for each.
Page 284 SOLTECH USER GUIDE Industrial Switch SFC8100 Series IPMC Profile Rule Settings Table Clicking the button will bring up the list page. Clicking the button will bring up the settings page. This page provides the filtering rule settings for a specific IPMC profile. It displays the configured rule entries in precedence order.
Page 285 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Global Profile Mode • Enable | Disable IPMC Profile Table Setting   Add New IPMC Profile  Profile Name • Maximum 16 alphabetic and numeric characters.  Profile Description • Maximum 64 alphabetic and numeric characters.
Page 286 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Disable | Enable • Click button to commit rule changes for the designated profile. to view Click button Profile [Profile Name] Rule EXAMPLE CLI CONFIGURATION IPMC Profile Configuration   Global Profile Mode •...
Page 287 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config-ipmc-profile)# description <line64> (config-ipmc-profile)# description Test-Profile_Name IPMC Profile [Profile Name] Rule Settings (In precedence Order)   Add Last Rule  Entry Name Select Entry (Settings required in the Address Entry.) • ...
Page 288 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.9.2. Address Entry Configuration WEB MENU Configuration>IPMC Profile>Address Entry This page provides address range settings used in IPMC profile. The address entry is used to specify the address range that will be associated with IPMC Profile.
Page 289 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Maximum 16 alphabetic and numeric characters  Start Address • IPv4/IPv6 Multicast Group Address(ex IPv4-224.0.0.0~239.255.255.255)  End Address • IPv4/IPv6 Multicast Group Address(ex IPv4-224.0.0.0~239.255.255.255) EXAMPLE CLI CONFIGURATION IPMC Profile Address Configuration ...
Page 290 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.10. IPMC 6.10.1. IGMP Snooping Configuration 6.10.1.1. Basic Configuration WEB MENU Configuration>IPMC>IGMP Snooping>Basic Configuration This page provides IGMP Snooping related configuration. IGMP Snooping Configuration Global Configuration Object Description Snooping Enabled Enable the Global IGMP Snooping.
Page 291 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Port Related Configuration Object Description Specify which ports act as router ports. A router port is a port on the Ethernet switch that leads towards the Layer 3 multicast device or IGMP querier.
Page 292 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Port Related Configuration   Router Port • Checked | Unchecked  Fast Leave • Checked | Unchecked  Throttling • Unlimited(default) | 1~10 EXAMPLE CLI CONFIGURATION IGMP Snooping Configuration  Global Configuration ...
Page 293 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# ip igmp unknown-flooding (config)# no ip igmp unknown-flooding  IGMP SSM Range • 224.0.0.0~239.255.255.255 / 4~32 (config)# ip igmp ssm-range <v_ipv4_mcast> <ipv4_prefix_length> (config)# ip igmp ssm-range 232.0.0.0 8  Leave Proxy Enable •...
Page 294 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.10.1.2. VLAN Configuration WEB MENU Configuration>IPMC>IGMP Snooping>VLAN Configuration IGMP Snooping VLAN Configuration Navigating the IGMP Snooping VLAN Table Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries per page"...
Page 295 SOLTECH USER GUIDE Industrial Switch SFC8100 Series inserted into the periodic General Queries. The allowed range is 0 to 31744 in tenths of seconds, default query response interval is 100 in tenths of seconds (10 seconds). Last Member Query Interval.
Page 296 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • 0.0.0.0(no setting) | 192.168.10.1(setting)  Compatibility • IGMP-Auto | Forced IGMPv1 | Forced IGMPv2 | Forced IGMPv3  • 0(0~7)  • 2(1~255)  QI(sec) • 125(1~31744)  QRI(0.1sec) • 100(0~31744) ...
Page 297 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION IGMP Snooping VLAN Configuration   VLAN ID • VLAN ID 1(1~4095) (config)# ip igmp snooping vlan <v_vlan_list> (config)# ip igmp snooping vlan 1  Snooping Enabled • Enable | Disable (config)# interface vlan <vlist>...
Page 298 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  • 2(1~255) (config-if-vlan)# ip igmp snooping robustness-variable <ipmc_rv> (config-if-vlan)# ip igmp snooping robustness-variable 2  QI(sec) • 125(1~31744) (config-if-vlan)# ip igmp snooping query-interval <ipmc_qi> (config-if-vlan)# ip igmp snooping query-interval 125  QRI(0.1sec) •...
Page 299 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.10.1.3. Port Filtering Profile WEB MENU Configuration>IPMC>IGMP Snooping>Port Filtering Profile IGMP Snooping Port Filtering Profile Configuration Object Description Port The logical port for the settings. Select the IPMC Profile as the filtering condition for the specific port. Summary about...
Page 300 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Profile Management Button to view • button Profile [Profile Name] Rule Click EXAMPLE CLI CONFIGURATION IGMP Snooping VLAN Configuration   Filtering Profile • Select the IPMC Profile (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# ip igmp snooping filter <profile_name>...
Page 301 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.10.2. IGMP Snooping Monitor 6.10.2.1. Status WEB MENU Monitor>IPMC>IGMC Snooping>Status This page provides IGMP Snooping status. IGMP Snooping Status Statistics Object Description VLAN ID The VLAN ID of the entry. Querier Version Working Querier Version currently.
Page 302 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Status Indicate whether specific port is a router port or not. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every 3 seconds. : Click to refresh the page immediately.
Page 303 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.10.2.2. Groups Information WEB MENU Monitor>IPMC>IGMC Snooping>Groups Information Entries in the IGMP Group Table are shown on this page. The IGMP Group Table is sorted first by VLAN ID, and then by group.
Page 304 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.10.2.3. IPv4 SFM Information WEB MENU Monitor>IPMC>IGMC Snooping>IPv4 SFM Information Entries in the IGMP SFM Information Table are shown on this page. The IGMP SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information.
Page 305 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI MONITOR IGMP SFM Information  # show ip igmp snooping group-database sfm-information detail IGMP Snooping is enabled to start snooping IGMP control plane. (IGMP proxy for LEAVE mechanism is active) Multicast streams destined to unregistered IGMP groups will be flooding.
Page 306 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11. LLDP 6.11.1. LLDP Configuration 6.11.1.1. LLDP WEB MENU Configuration>LLDP>LLDP This page allows the user to inspect and configure the current LLDP interface settings. LLDP Configuration LLDP Parameters Object Description The switch periodically transmits LLDP frames to its neighbors for having the network Tx Interval discovery information up-to-date.
Page 307 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Tx only The switch will drop LLDP information received from neighbors, but will send out LLDP information. Disabled The switch will not send out LLDP information, and will drop LLDP information received from neighbors.
Page 308 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • 2~10 times(4times)  Tx Delay • 1~8192 sec(2sec)  Tx Delay • 1~10 sec(2sec) LLDP Interface Configuration   Mode • Disabled | Enabled(default) | Rx Only | Tx Only  CDP aware •...
Page 309 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Port Descr • Disabled | Enabled(default)  Sys Name • Disabled | Enabled(default)  Sys Descr • Disabled | Enabled(default)  Sys Capa • Disabled | Enabled(default)
Page 310 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Mgmt Addr • Disabled | Enabled(default) EXAMPLE CLI CONFIGURATION LLDP Configuration  LLDP Parameters   Tx Interval • 5~32768 sec(30sec) (config)# lldp timer <val> (config)# lldp timer 30  Tx Hold •...
Page 311 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • 1~8192 sec(2sec) (config)# lldp transmission-delay <val> (config)# lldp transmission-delay 2  Tx Delay • 1~10 sec(2sec) (config)# lldp transmission-delay <val> (config)# lldp reinit 2 LLDP Interface Configuration   Mode • Disabled | Enabled(default) | Rx Only | Tx Only (config)# interface ( <port_type>...
Page 312 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Sys Name • Disabled | Enabled(default) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# lldp tlv-select system-name  Sys Descr • Disabled | Enabled(default) (config)# interface ( <port_type> [ <plist> ] )
Page 313 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11.1.2. LLDP-MED WEB MENU Configuration>LLDP>LLDP-MED This page allows you to configure the LLDP-MED. This function applies to VoIP devices which support LLDP-MED. LLDP-MED Configuration Fast Start Repeat Count Object Description Rapid startup and Emergency Call Service Location Identification Discovery of endpoints is a critically important aspect of VoIP systems in general.
Page 314 SOLTECH USER GUIDE Industrial Switch SFC8100 Series in an LLDPDU. Only after an LLDP-MED Endpoint Device is detected, will an LLDP- MED capable Network Connectivity Device start to advertise LLDP-MED TLVs in outgoing LLDPDUs on the associated interface. The LLDP-MED application will...
Page 315 SOLTECH USER GUIDE Industrial Switch SFC8100 Series represents the floor level associated with ground level at the main entrance. The Map Datum is used for the coordinates given in these options: WGS84: (Geographical 3D) - World Geodesic System 1984, CRS Code 4327, Prime Meridian Name: Greenwich.
Page 316 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Place type Place type - Example: Office. Postal community Postal community name - Example: Leonia. name P.O. Box Post office box (P.O. BOX) - Example: 12345. Additional code Additional code - Example: 1320300003.
Page 317 SOLTECH USER GUIDE Industrial Switch SFC8100 Series that shall be mapped to the specific interfaces. Intended use of the application types: 1. Voice - for use by dedicated IP Telephony handsets and other similar appliances supporting interactive voice services. These devices are typically deployed on a separate VLAN for ease of deployment and enhanced security by isolation from data applications.
Page 318 SOLTECH USER GUIDE Industrial Switch SFC8100 Series through 63). A value of 0 represents use of the default DSCP value as defined in RFC 2475. Adding a new policy Object Description Click Add New Policy to add a new policy. Specify the Application type, Tag, VLAN ID, Adding a new policy L2 Priority and DSCP for the new policy.
Page 319 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11.2. LLDP Monitor 6.11.2.1. Neighbors WEB MENU Monitor>LLDP>Neighbors This page provides a status overview for all LLDP neighbors. LLDP Neighbor Information The displayed table contains a row for each interface on which an LLDP neighbor is detected. The columns hold the following information.
Page 320 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Monitor>LLDP>Neighbors LLDP Neighbor Information  EXAMPLE CLI CONFIGURATION LLDP Neighbor Information  # show lldp neighbors Local Interface : GigabitEthernet 1/8 Chassis ID : 00-21-6D-01-02-03 Port ID Port Description...
Page 321 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11.2.2. LLDP-MED Neighbors WEB MENU Monitor>LLDP>LLDP-MED Neighbors This page provides a status overview of all LLDP-MED neighbors. LLDP-MED Neighbor Information The displayed table contains a row for each interface on which an LLDP neighbor is detected. This function applies to VoIP devices which support LLDP-MED.
Page 322 SOLTECH USER GUIDE Industrial Switch SFC8100 Series particular end user. Capabilities include all of the capabilities defined for the previous Generic Endpoint Class (Class I), and are extended to include aspects related to media streaming. Example product categories expected to adhere to this class include (but are not limited to) Voice / Media Gateways, Conference Bridges, Media Servers, and similar.
Page 323 SOLTECH USER GUIDE Industrial Switch SFC8100 Series eight priority levels (0 through 7). DSCP is the DSCP value to be used to provide Diffserv node behavior for the specified DSCP application type as defined in IETF RFC 2474. Contain one of 64 code point values (0 through 63).
Page 324 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11.2.3. EEE WEB MENU Monitor>LLDP>EEE By using EEE power savings can be achieved at the expense of traffic latency. This latency occurs due to that the circuits EEE turn off to save power, need time to boot up before sending traffic over the link. This time is called "wakeup time".
Page 325 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Green - Switch and link partner have agreed on wakeup times. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh every 3 seconds. : Click to refresh the page.
Page 326 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.11.2.4. Port Statistics WEB MENU Monitor>LLDP>Port Statistics This page provides an overview of all LLDP traffic. LLDP Global Counters Object Description Global Counters Global counters are counters that refer to the whole switch Clear global counters If checked the global counters are cleared when CLEAR is pressed.
Page 327 SOLTECH USER GUIDE Industrial Switch SFC8100 Series the Chassis ID or Remote Port ID is not already contained within the table. Entries are removed from the table when a given interface's link is down, an LLDP shutdown frame is received, or when the entry ages out.
Page 328 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION  LLDP Global Counters LLDP Statistics Local Counters  # show lldp statistics LLDP global counters Neighbor entries was last changed at 1970-01-01T13:44:54+09:00 (90116 secs. ago). Total Neighbors Entries Added Total Neighbors Entries Deleted 22.
Page 329 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.12. PoE 6.12.1. PoE Configuration WEB MENU Configuration>PoE This page allows the user to inspect and configure the current PoE port settings. 1. AF/AT supported model 2. AF/AT/BT supported model...
Page 330 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Power Over Ethernet Configuration Object Description There are two modes for configuring how the ports/PDs may reserve power. Class In this mode each port automatically determines how much power to reserve according to the class the connected PD belongs to, and reserves the power accordingly.
Page 331 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Object Description 2. AF/AT/BT Model PoE mode terminology Model utilizing 4Pair Matrix Model utilizing 2Pair Matrix The maximum power wattage that the switch can provide. Type Type1 - Class1~3(Class 3 PDs limited to 15.4W) Type2 - Class4(Class 4 PDs limited to 30W) Type3 –...
Page 332 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. EXAMPLE WEB CONFIGURATION WEB MENU Configuration>PoE>Configuration ...
Page 333 SOLTECH USER GUIDE Industrial Switch SFC8100 Series PoE Port Configuration  AF/AT Model  Enable | Disable  PoE Mode • PoE | PoE+  Priority • Low | High | Critical...
Page 334 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  PD Alive  PD Reset AF/AT/BT Model  Enable | Disable  PoE Mode • AF/AT/BT Port...
Page 335 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • AF/AT Port  Priority(Low | High | Critical)  PD Alive(Enable | Disable)  PD Reset(Enable | Disable)  PSE Detect(Enable | Disable) EXAMPLE CLI CONFIGURATION Power Over Ethernet Configuration  ...
Page 336 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# poe management mode class-consumption (config)# poe management mode class-reserved-power (config)# poe management mode lldp-consumption (config)# poe management mode lldp-reserved-power  Capacitor Detection • Disabled(default) | Enabled (config)# no poe capacitor-detect (config)# poe capacitor-detect PoE Power Supply Configuration ...
Page 337 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 0x24:4P_4_FIN_60W_2P_3_FIN_30W_L_DET 0x25:BT_4P_POH_LIKE_90W_2P_POE_LIKE_45W_L_DET 0x26:4P_90W_2P_45W_POE_L_DET 0x27:BT_4P_60W_2P_30W_L_DET_SP_C4 0x30:BT_4P_90W_2P_45W_L_DET  Priority • Low | High | Critical (config-if)# poe priority { low | high | critical } (config-if)# poe priority low (config-if)# poe priority high (config-if)# poe priority critical ...
Page 338 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.12.2. Power off Scheduler WEB MENU Configuration>PoE>Power off scheduler This page allows users to configure time slots during which PoE will not be utilized for each port. After setting up system time or NTP, use PoE Power Off Scheduler. If not set, the PoE Power Off Scheduler will not function correctly.
Page 339 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Every, Sun, Mon, Tue, Wed, Thu, Fri, Sat  Start Time, End Time • 00:00~23:59 EXAMPLE CLI CONFIGURATION PoE Power Off Scheduler   Enable  Every, Sun, Mon, Tue, Wed, Thu, Fri, Sat ...
Page 340 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.12.3. PoE Monitor WEB MENU Monitor>PoE This page allows the user to inspect the current status for all PoE ports. Power Over Ethernet Status Object Description Local Port This is the logical port number. The last row displays the sum of all ports.
Page 341 SOLTECH USER GUIDE Industrial Switch SFC8100 Series exceeding its maximum power limit. The PoE port is turned off due to the PoE turned OFF - PD overload power usage exceeding the available allocation for the port. The PoE port is turned off due to high...
Page 342 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.13. EPS 6.13.1. EPS Configuration WEB MENU Configuration>EPS The Ethernet (Linear) Protection Switch instances are configured here. Ethernet Protection Switching Object Description Delete This box is used to mark an EPS for deletion in next Save operation.
Page 343 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EPS Configuration Instance Data Object Description EPS ID The ID of the EPS. Domain See help on EPS create WEB. Architecture See help on EPS create WEB. W Flow See help on EPS create WEB.
Page 344 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Manual Switch W Manual switch to working. This is only allowed in case of 'non-revertive' mode Exercise Exercise of the protocol - not traffic effecting. This is only allowed in case of 'Bidirectional' protection type Freeze This EPS is locally freezed - ignoring all input.
Page 345 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • P Flow(MEP instance number) • W SF MEP(MEP instance number) • P SF MEP(MEP instance number) • APS MEP(MEP instance number | Not W Flow) • Alarm Click EPS ID  EPS Configuration Instance Data ...
Page 346 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Instance State  • Protection State • W Flow • P Flow • Transmit APS r/b • Receive APS r/b • Architecture Mismatch • APS On Working • Switching Incomplete • No APS Received...
Page 347 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 1+1 Unidirectional 1+1 Bidirectional • (config)# eps <inst> 1plus1 { bidirectional | { unidirectional [ aps ] } } (config)# eps 1 1plus1 bidirectional (config)# eps 1 1plus1 unidirectional (config)# eps 1 1plus1 unidirectional aps •...
Page 348 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.14. MEP 6.14.1. MEP Configuration WEB MENU Configuration>MEP The Maintenance Entity Point instances are configured here. Maintenance Entity Point Object Description Delete This box is used to mark a MEP for deletion in next Save operation.
Page 349 SOLTECH USER GUIDE Industrial Switch SFC8100 Series MEP Configuration This page allows the user to inspect and configure the current MEP Instance. Instance Data Object Description MEP Instance The ID of the MEP. Domain See help on MEP create WEB.
Page 350 SOLTECH USER GUIDE Industrial Switch SFC8100 Series format. This string can be empty giving Maintenance Domain Name Format 1 - Not present. This can be max 16 char. This is either ITU MEG ID or IEEE Short MA Name - depending on 'Format'. See MEG Id 'Format'.
Page 351 SOLTECH USER GUIDE Industrial Switch SFC8100 Series the same. Selecting the frame rate of CCM PDU. This is the inverse of transmission period as described in Y.1731. This value has the following uses: * The transmission rate of the CCM PDU.
Page 352 SOLTECH USER GUIDE Industrial Switch SFC8100 Series - OUI Second The last received second value in the OS TLV OUI field. - OUI Third The last received third value in the OS TLV OUI field. - Sub-Type The last received value in the OS TLV Sub-Type field.
Page 353 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Fault Management - Instance 1 - MEP id 1 This page allows the user to inspect and configure the Fault Management of the current MEP Instance. Loop Back Object Description Loop Back based on transmitting/receiving LBM/LBR PDU can be enabled/disabled.
Page 354 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Selection of LBM PDU transmitted unicast or multi-cast. The unicast MAC will be Cast configured through 'Peer MEP' or 'Unicast Peer MAC'. To-wards MIP only unicast Loop Back is possible. This is only used if the 'Unicast MAC' is configured to all zero. The LBM unicast MAC Peer MEP will be taken from the 'Unicast Peer MAC' configuration of this peer.
Page 355 SOLTECH USER GUIDE Industrial Switch SFC8100 Series This is only used if NOT configured to all zero. This will be used as the Link Trace Target Unicast MAC MAC. This is the only way to configure a MIP as Target MAC.
Page 356 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Warning will be given if selected frame size exceeds the CPU RX frame MAX size Frame MIN Size is 64 Bytes. The 'empty' TEST PDU has the size of 12 bytes. In order to achieve the configured frame size a data TLV will be added with a pattern.
Page 357 SOLTECH USER GUIDE Industrial Switch SFC8100 Series LOCK Object Description Insertion of LOCK signal (LCK PDU transmission) in client layer flows, can be Enable enable/disabled. Selecting the frame rate of LCK PDU. This is the inverse of transmission period as Frame Rate described in Y.1731.:...
Page 358 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Performance Monitor - Instance 1 - MEP id 1 You can use this page to inspect and configure the performance monitor of the current MEP instance.
Page 359 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Performance Monitoring Data Set Object Description When enabled this MEP instance will contribute to the 'PM Data Set' gathered by the Enable PM Session. Loss Measurement Object Description Loss Measurement initiator is enabled/disabled. Initiator is transmitting/receiving CCM or LMM/LMR or SLM/SLR/1SL PDUs - see 'Synthetic' and 'Ended'.
Page 360 SOLTECH USER GUIDE Industrial Switch SFC8100 Series This is the interval in number of measurement intervals where the interval Frame Loss FLR Interval Ratio is calculated. This is the 'synthetic' LM measurement interval in milliseconds. This must be a whole number of the LM PDU transmission interval (inverse 'Rate').
Page 361 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Maintenance Enable/disable of loss measurement availability maintenance. Loss Measurement Availability Status Object Description The number of measurements performed while the near end has been in the "Avail" Near Avail Count state. Far Avail Count The number of measurements performed while the far end has been in the "Avail"...
Page 362 SOLTECH USER GUIDE Industrial Switch SFC8100 Series FLR Threshold Signal Degraded frame loss ratio threshold in per mille. Bad Threshold Number of consecutive bad interval measurements required to set degrade state. Good Threshold Number of consecutive good interval measurements required to clear degrade state.
Page 363 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Av Delay last N The average delay of the last n packets - since last 'clear'. Delay Min. The minimum delay - since last 'clear'. Delay Max. The maximum delay - since last 'clear'.
Page 364 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Delay Measurement Bins for IFDV A Measurement Bin is a counter that stores the number of delay measurements falling within a specified range, during a Measurement Interval. If the measurement threshold is 5000 us and the total number of Measurement Bins is four, we can give an example as follows.
Page 365 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Click Instance number MEP Configuration  Instance Data  Instance Configuration   Level(0~7)  Format(ITU ICC | IEEE String | ITU CC ICC)  Domain Name(Use only IEEE String) • This string can be empty or max 16 characters.
Page 366 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Entering the Unicast Peer MAC, manually Functional Configuration   Continuity Check • Enable • Priority(0~7) • Frame rate(300f/sec | 100f/sec | 10f/sec | 1f/sec | 6f/min | 1f/min | 6f/hour) •...
Page 367 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Link State Tracking   Enable MEP Status Alarm   Instance Configuration • cLevel, cMEG, cMEP, cAIS, cLCK, cLoop, cConfig, cSSF, aBLK, aTSD, aTSF  Peer MEP Configuration • cLOC, cRDI, cPeriod, cPriority, cDEG TLV Status ...
Page 368 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Level(0~7) • Flow Instance • Tagged VID (config)# mep <inst> [ mip ] { up | down } domain { port | evc | vlan | tp-link | tunnel-tp | pw | lsp } [ vid <vid>...
Page 369 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# mep <inst> syslog (config)# mep 1 syslog Peer MEP Configuration   Peer MEP ID (Input Peer MEP ID)  Unicast Peer MAC (Auto | Manual) • Entering the MEP ID, the MAC is automatically retrieved •...
Page 370 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Sub-Type(0-0xff) • Value(0-0xff) (config)# mep os-tlv oui <oui> sub-type <subtype> value <value> (config)# mep os-tlv oui 0xffffff sub-type 0xff value 0xff (config)# mep os-tlv oui 0xC sub-type 0x1 value 0x2 Link State Tracking ...
Page 371 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.15. ERPS 6.15.1. ERPS Configuration WEB MENU Configuration>ERPS The ERPS instances are configured here. Ethernet Ring Protection Switching Object Description Delete This box is used to mark an ERPS for deletion in next Save operation.
Page 372 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to add a new Protection group entry. : Click to refresh the page immediately. : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values.
Page 373 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Guard timeout value to be used to prevent ring nodes from receiving outdated R-APS messages. Guard Time The period of the guard timer can be configured in 10 ms steps between 10 ms and 2 seconds, with a default value of 500 ms The Wait To Restore timing value to be used in revertive switching.
Page 374 SOLTECH USER GUIDE Industrial Switch SFC8100 Series OK: State of West port is ok Port 1 SF: State of West port is Signal Fail Transmit APS The transmitted APS according to State Transition Tables in G.8032. Port 0 Receive APS The received APS on Port 0 according to State Transition Tables in G.8032.
Page 375 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>ERPS Ethernet Ring Protection Switching   Add New Protection Group • ERPS ID(1~64) • Port 0(Enter Port Number) • Port 1(Enter Port Number) • Port 0 APS MEP(Enter MEP Instance Number) •...
Page 376 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Instance Configuration   Configured  Guard Time • 10~2000(msec)  WTR Time • 1min | 2min | 3min | 4min | 5min | 6min | 7min | 8min | 9min | 10min | 11min | 12min ...
Page 377 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Instance Command   Command • None | Manual Switch | Forced Switch | Clear  Port • None | Port0 | Port1 Instance State   Protection State | Port 0 | Port 1 | Transmit APS | Port 0 Receive APS | Port 1 Receive APS |...
Page 378 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Major Ring ID(can be set when it is both an Interconnected Node and a sub ring) (config)# erps <group> major port0 interface <port_type> <port0> port1 interface <port_type> <port1> [ interconnect ] (config)# erps 1 major port0 interface GigabitEthernet 1/1 port1 interface GigabitEthernet 1/2...
Page 379 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# erps <group> version { 1 | 2 } (config)# erps 1 version 1 (config)# erps 1 version 2 RPL Configuration   RPL Role • None | RPL_Owner | RPL_Neighbour  RPL Port •...
Page 380 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Version ERPSv2 Administrative Command :None FSM State :IDLE Port 0 Link Status :Link Down Port 1 Link Status :Link Down Port 0 Block Status :BLOCKED Port 1 Block Status :UNBLOCKED R-APS Transmission :NR RB DNF BPR 0...
Page 381 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.16. Q-ERPS 6.16.1.Q-ERPS Configuration WEB MENU Configuration>Q-ERPS This page is configured to make it quick and easy to configure a single major ERPS. The values set on this page are automatically applied to MEP and ERPS. It is configured to allow basic configuration (operation of a single major ring of the ERPS protocol), and detailed settings can be changed in the MEP and ERPS settings.
Page 382 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • RPL Role(None | RPL_Owner) • Control VLAN(1~4095) • Protected VLAN(1~4095) Click ERPS ID(Check on the ERPS Configuration page.) Click VLAN Config(Check on the ERPS Configuration page.) EXAMPLE CLI CONFIGURATION Quick ERPS Configuration ...
Page 383 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.17. S-Ring 6.17.1. S-Ring Configuration WEB MENU Configuration>S-Ring S-Ring is a protocol within the Ring Protocol that manages the Ring by determining whether packets transmitted from the 2nd Port of the Master node are received by the 1st Port.
Page 384 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Buttons : Click to apply changes. : Click to apply and save changes. : Click to undo any changes made locally and revert to previously saved values. : Click to refresh the page.
Page 385 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Reordering • Refresh EXAMPLE CLI CONFIGURATION S-Ring Configuration & Status   Mode • Disable | Slave | Master  1st Port | 2nd Port  Robustness • 1~10 (config)# sring id <v_id> [ mode { disable | { master | slave } 1st-port <v_ingressPort>...
Page 386 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.18. MAC Table 6.18.1. MAC Table Configuration WEB MENU Configuration>MAC Table The MAC Address Table is configured on this page. Set timeouts for entries in the dynamic MAC Table and configure the static MAC table here.
Page 387 SOLTECH USER GUIDE Industrial Switch SFC8100 Series The MAC table is sorted first by VLAN ID and then by MAC address. Object Description Delete Check to delete the entry. It will be deleted during the next save. VLAN ID The VLAN ID of the entry.
Page 388 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION Aging Configuration   Disable Automatic Aging (config)# mac address-table aging-time <v_0_10_to_1000000> (config)# mac address-table aging-time 0  Aging Time(Enable Automatic Aging | Aging Time 300) (config)# mac address-table aging-time <v_0_10_to_1000000>...
Page 389 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.18.2. MAC Table Monitor WEB MENU Monitor>MAC Table Entries in the MAC Table are shown on this page. The MAC Table contains up to 8192 entries, and is sorted first by VLAN ID, then by MAC address.
Page 390 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Monitor>MAC Table MAC Address Table  EXAMPLE CLI CONFIGURATION MAC Address Table  # show mac address-table Type MAC Address Ports Static 00:21:6d:00:00:01 GigabitEthernet 1/3 Static 33:33:00:00:00:01 GigabitEthernet 1/1-4 10GigabitEthernet 1/1-4 CPU...
Page 391 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.19. VLANs 6.19.1. VLAN Configuration WEB MENU Configuration>VLANs This page allows for controlling VLAN configuration on the switch. The page is divided into a global section and a per-port configuration section. Global VLAN Configuration...
Page 392 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 3. Discards all frames not classified to the Access VLAN 4. On egress all frames are transmitted untagged Trunk ports can carry traffic on multiple VLANs simultaneously, and are normally used to connect to other switches. Trunk ports have the following characteristics: 1.
Page 393 SOLTECH USER GUIDE Industrial Switch SFC8100 Series If the port is configured to accept Tagged Only frames (see Ingress Acceptance below), frames without this TPID are dropped. S-Custom-Port: On egress, if frames must be tagged, they will be tagged with the custom S-tag.
Page 394 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.19.2. VLAN Monitor 6.19.2.1. Membership WEB MENU Monitor>VLANs>Membership This page provides an overview of membership status of VLAN users. VLAN Membership Status for Combined users Object Description Various internal software modules may use VLAN services to configure VLAN memberships on the fly.
Page 395 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.19.2.2. Ports WEB MENU Monitor>VLANs>Ports This page provides VLAN Port Status. VLAN Port Status for Combined users Object Description Various internal software modules may use VLAN services to configure VLAN port configuration on the fly.
Page 396 SOLTECH USER GUIDE Industrial Switch SFC8100 Series way. The Administrator has the least priority. Other software modules are prioritized according to their position in the drop-down list: The higher in the list, the higher priority. If conflicts exist, it will be displayed as "Yes" for the "Combined" user and the offending software module.
Page 397 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20. QoS 6.20.1. QoS Configuration 6.20.1.1. Port Classification WEB MENU Configuration>QoS>Port Classification This page allows you to configure the basic QoS Ingress Classification settings for all switch ports. QoS Ingress Port Classification Object...
Page 398 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Disabled: Use default CoS and DPL for tagged frames. Enabled: Use mapped versions of PCP and DEI for tagged frames. Click on the mode in order to configure the mode and/or mapping. Note: This setting has no effect if the port is VLAN unaware. Tagged frames received on VLAN unaware ports are always classified to the default CoS and DPL.
Page 399 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>QoS>Port Classification QoS Ingress Port Classification   • 0~7 (0 – The Lowest Priority)  • 0~3 (0 – Low drop probability)
Page 400 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  • 0~7 (0 - The Lowest Priority)  • 0~1 (0 – Low drop probability)  Tag Class • Disabled QoS Ingress Port Tag Classification Port n Tagged Frames Settings • Tag Classification ...
Page 401 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (PCP, DEI) to (QoS class, DP level) Mapping • QoS class  0~7 (0 - The Lowest Priority) • DP level  0~3 (0 – Low drop probability)
Page 402 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  DSCP Based • Enabled | Disabled  WRED Group • 1~3 ( WRED group...
Page 403 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION  QoS Ingress Port Classification  • 0~7 (0 – The Lowest Priority) (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# qos cos <cos> (config-if)# qos cos 0 ...
Page 404 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Tag Class • Disabled QoS Ingress Port Tag Classification Port n Tagged Frames Settings • Tag Classification  Disabled | Enabled (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1...
Page 405 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.2. Port Policing WEB MENU Configuration>QoS>Port Policing This page allows you to configure the Policer settings for all switch ports. QoS Ingress Port Policers Object Description Port The port number for which the configuration below applies.
Page 406 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Rate • 10-13128147(kbps, fps) or 1-13128(Mbps, kfps)  Unit • kbps, Mbps, fps, kfps  Flow Control • Enabled | Disabled...
Page 407 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION QoS Ingress Port Policers   Enable • Enabled | Disabled  Rate • 10-13128147(kbps, fps) or 1-13128(Mbps, kfps)  Unit • kbps, Mbps, fps, kfps  Flow Control •...
Page 408 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.3. Queue Policing WEB MENU Configuration>QoS>Queue Policing This page allows you to configure the Queue Policer settings for all switch ports. QoS Ingress Queue Policers Object Description Port The port number for which the configuration below applies.
Page 409 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Rate • 25-13128147(kbps) or 1-13128(Mbps)  Unit • kbps, Mbps...
Page 410 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION  QoS Ingress Queue Policers  Queue n (n, 0~7)  Enable (E) • Enabled | Disabled  Rate • 25-13128147(kbps) or 1-13128(Mbps)  Unit • kbps, Mbps (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# qos queue-policer queue <queue>...
Page 411 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.4. Port Scheduler WEB MENU Configuration>QoS>Port Scheduler This page provides an overview of QoS Egress Port Schedulers for all switch ports. QoS Egress Port Schedulers Object Description The logical port for the settings contained in the same row.
Page 412 SOLTECH USER GUIDE Industrial Switch SFC8100 Series QoS Egress Port Schedulers and Shapers Port n Object Description Controls how many of the queues are scheduled as strict and how many are scheduled Scheduler Mode as weighted on this switch port.
Page 413 SOLTECH USER GUIDE Industrial Switch SFC8100 Series QoS Egress Port Schedulers and Shapers Port n   Scheduler Mode • Strict Priority | Queues Weighted...
Page 414 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Queue Shaper Enable • Enabled | Disabled  Queue Shaper Rate • 100-13107100(kbps) or 1-13107(Mbps)  Queue Shaper Unit • kbps or Mbps...
Page 415 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Queue Scheduler Weight • 1~100(Scheduler Mode should be set to ‘Weighted’)  Port Shaper Enable • Enabled | Disabled...
Page 416 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Port Shaper Rate • 100-13107100(kbps) or 1-13107(Mbps)  Port Shaper Unit • kbps or Mbps...
Page 417 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION QoS Egress Port Schedulers   Port (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 QoS Egress Port Schedulers and Shapers Port n   Scheduler Mode •...
Page 418 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config-if)# qos queue-shaper queue <queue> <rate> [ kbps | mbps ] [ excess ] [ rate-type { line | data } ] (config-if)# no qos queue-shaper queue 0 (config-if)# qos queue-shaper queue 0 1 mbps (config-if)# qos queue-shaper queue 0 100 kbps ...
Page 419 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.5. Port Shaping WEB MENU Configuration>QoS>Port Shaping This page provides an overview of QoS Egress Port Shapers for all switch ports. QoS Egress Port Shapers Object Description The logical port for the settings contained in the same row.
Page 420 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.6. Port Tag Remarking WEB MENU Configuration>QoS>Port Tag Remarking This page provides an overview of QoS Egress Port Tag Remarking for all switch ports. QoS Egress Port Tag Remarking Object Description The logical port for the settings contained in the same row.
Page 421 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>QoS>Port Tag Remarking QoS Egress Port Tag Remarking   Port( Click on the port number in order to configure tag remarking. QoS Egress Port Tag Remarking Port n ...
Page 422 SOLTECH USER GUIDE Industrial Switch SFC8100 Series PCP/DEI Configuration  The following items are displayed when the mode is set to "Default".  Default PCP •  Default DEI • (QoS class, DP level) to (PCP, DEI) Mapping  When the Mode is set to 'Mapped' you will see the following entries ...
Page 423 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  • EXAMPLE CLI CONFIGURATION QoS Egress Port Tag Remarking   Port (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 QoS Egress Port Tag Remarking Port n ...
Page 424 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Default DEI • (config-if)# qos tag-remark pcp <pcp> dei <dei> (config-if)# qos tag-remark pcp 0 dei 0 (QoS class, DP level) to (PCP, DEI) Mapping   •  • (config-if)# qos map cos-tag cos <cos> dpl <dpl> pcp <pcp> dei <dei>...
Page 425 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.7. Port DSCP WEB MENU Configuration>QoS>Port DSCP This page allows you to configure the basic QoS Port DSCP Configuration settings for all switch ports. QoS Port DSCP Configuration Object Description The Port column shows the list of ports for which you can configure DSCP ingress and Port egress settings.
Page 426 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB CONFIGURATION WEB MENU Configuration>QoS>Port DSCP QoS Port DSCP Configuration   Ingress Translate • Enable | Disable  Ingress Classify • Disable | DSCP=0 | Slected | All  Egress Rewrite •...
Page 427 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Egress Rewrite • Disable | Enable | Remap DP Unaware | Remap DP Aware • Disable | Enable | Remap (config-if)# qos dscp-remark { rewrite | remap | remap-dp } (config-if)# no qos dscp-remark...
Page 428 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.8. DSCP-Based QoS WEB MENU Configuration>QoS>DSCP-Based QoS This page allows you to configure the basic QoS DSCP based QoS Ingress Classification settings for all switches. DSCP-Based QoS Ingress Classification Object Description DSCP Maximum number of supported DSCP values are 64.
Page 429 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  DSCP  Trust • Trusted | Untrusted  QoS Class •  • EXAMPLE CLI CONFIGURATION DSCP-Based QoS Ingress Classification   DSCP  Trust • Trusted | Untrusted  QoS Class •...
Page 430 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.9. DSCP Translation WEB MENU Configuration>QoS>DSCP Translation This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in Ingress or Egress. DSCP Translation...
Page 431 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  DSCP  Ingress Translate • 0~63  Ingress Classify • Enable | Disable  Egress Remap • 0~63 EXAMPLE CLI CONFIGURATION  DSCP Translation  DSCP  Ingress Translate • 0~63 (config)# qos map dscp-ingress-translation { <dscp_num> | { be | af11 | af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } } to { <dscp_num_tr>...
Page 432 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# qos map dscp-classify { <dscp_num> | { be | af11 | af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } }...
Page 433 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.10. DSCP Classification WEB MENU Configuration>QoS>DSCP Classification This page allows you to configure the mapping of QoS class and Drop Precedence Level to DSCP value. DSCP Classification Object Description QoS Class Actual QoS class.
Page 434 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION DSCP Classification   QoS Class •  • 0~1, 0~3  DSCP • 0~63 (config)# qos map cos-dscp <cos> dpl <dpl> dscp { <dscp_num> | { be | af11 | af12 | af13 | af21 | af22 |...
Page 435 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.11. QoS Control List WEB MENU Configuration>QoS>QoS Control List This page shows the QoS Control List(QCL), which is made up of the QCEs. Each row describes a QCE that is defined. The maximum number of QCEs is 256 on each switch.
Page 436 SOLTECH USER GUIDE Industrial Switch SFC8100 Series CoS: Classify Class of Service. DPL: Classify Drop Precedence Level. DSCP: Classify DSCP value. PCP: Classify PCP value. DEI: Classify DEI value. Policy: Classify ACL Policy number. You can modify each QCE (QoS Control Entry) in the table using the following buttons: : Inserts a new QCE before the current row.
Page 437 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Value of Inner Tag field can be Inner Tag 'Untagged', 'Tagged', 'C-Tagged', 'S-Tagged' or 'Any'. Valid value of Inner VLAN ID can be any value in the range Inner VID 1-4095 or 'Any'; user can enter either a specific value or a range of VIDs.
Page 438 SOLTECH USER GUIDE Industrial Switch SFC8100 Series DSCP DSCP (0-63, BE, CS1-CS7, EF or AF11-AF43) or 'Default'. PCP: (0-7) or 'Default'. Note: PCP and DEI cannot be set individually. DEI: (0-1) or 'Default'. Policy ACL Policy number: (0-255) or 'Default' (empty field).
Page 439 SOLTECH USER GUIDE Industrial Switch SFC8100 Series QCE Configuration   Port Members • Select Port Key Parameters   DMAC • Any | Unicast | Multicast | Broadcast  SMAC • Any | Specific(Selecting this option will generate additional configuration options.) ...
Page 440 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  • Any | 0 | 1  Frame Type (additional configuration options.) • Any | EtherType | LLC | SNAP | IPv4 | IPv6 EtherType Parameters   Ether Type • Any | Specific(0x600-0x7ff,0x801-0x86dc,0x86de-0xffff) LLC Parameters ...
Page 441 SOLTECH USER GUIDE Industrial Switch SFC8100 Series SNAP Parameters   • Any | Specific(<0-0xffff>) IPv4 Parameters   Protocol (additional configuration options.) • Any | UDP | TCP | Other  • Any | Specific(additional configuration options.)  IP Fragment •...
Page 442 SOLTECH USER GUIDE Industrial Switch SFC8100 Series UDP Parameters   Sport • Any | Specific(additional configuration options.) | Range(additional configuration options.)  Dport • Any | Specific(additional configuration options.) | Range(additional configuration options.) TCP Parameters   Sport •...
Page 443 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Default | 0~63  • Default | 0~7  • Default | 0~1  Policy • Default(empty field) | 0~255 EXAMPLE CLI CONFIGURATION QCE Configuration  (config)# qos qce { [ update ] } <qce_id> [ { next <qce_id_next> } | last ] [ interface (<port_type>...
Page 444 SOLTECH USER GUIDE Industrial Switch SFC8100 Series | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } | any } ] fragment { yes | no | any } ] [ sport { <sp4>...
Page 445 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# qos qce 1 tag dei any (config)# qos qce 1 tag dei 0 (config)# qos qce 1 tag dei 1  Frame Type • Any | EtherType | LLC | SNAP | IPv4 | IPv6...
Page 446 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Any | Yes | No (config)# qos qce 1 frame-type ipv4 fragment any (config)# qos qce 1 frame-type ipv4 fragment yes (config)# qos qce 1 frame-type ipv4 fragment no  DSCP •...
Page 447 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# qos qce 1 frame-type ipv4 proto tcp sport any (config)# qos qce 1 frame-type ipv4 proto tcp sport 100 (config)# qos qce 1 frame-type ipv4 proto tcp sport 0-65535 (config)# qos qce 1 frame-type ipv6 proto tcp sport any...
Page 448 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.12. Storm Policing WEB MENU Configuration>QoS>Storm Policing Global storm policers for the switch are configured on this page. Global Storm Policer Configuration There is a unicast storm policer, multicast storm policer, and a broadcast storm policer.
Page 449 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Controls the rate for the port storm policer. This value is restricted to 10-13128147 when Rate "Unit" is fps or kbps, and 1-13128 when "Unit" is kfps or Mbps. The rate is internally rounded up to the nearest value supported by the port storm policer.
Page 450 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Unit • fps | kfps | kbps | Mbps EXAMPLE CLI CONFIGURATION Global Storm Policer Configuration   Frame Type • Unknown Unicast | Multicast | Broadcast  Enable • Enable | Disable ...
Page 451 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • 10-13128147(fps|kbps) • 1-13128(kfps|Mbps)  Unit • fps | kfps | kbps | Mbps (config)# interface interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# qos storm { unicast | multicast | broadcast } <rate> [ fps | kfps | kbps | mbps ]...
Page 452 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.20.1.13. WRED WEB MENU Configuration>QoS>WRED This page allows you to configure the Random Early Detection (RED) settings. Weighted Random Early Detection Configuration Through different RED configuration for the queues (QoS classes) it is possible to obtain Weighted Random Early Detection (WRED) operation between queues.
Page 453 SOLTECH USER GUIDE Industrial Switch SFC8100 Series RED Drop Probability Function The following illustration shows the drop probability versus fill level function with associated parameters. Min is the fill level where the queue randomly start dropping frames marked with Drop Precedence Level > 0 (yellow frames).
Page 454 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.21. Mirroring 6.21.1. Mirroring Configuration WEB MENU Configuration>Mirroring Mirroring is a feature for switched port analyzer. The administrator can use the Mirroring to debug network problems. The selected traffic can be mirrored or copied on a destination port where a network analyzer can be attached to analyze the network traffic.
Page 455 SOLTECH USER GUIDE Industrial Switch SFC8100 Series on this switch. The switch is a forwarding node for monitor flow and the switch is an option node. Intermediate The object is to forward traffic from source switch to destination switch. The intermediate ports are located on this switch.
Page 456 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Configuration Guideline for All Features When the switch is running on Remote Mirroring mode, the administrator also needs to check whether or not other features are enabled or disabled. For example, the administrator is not disabled the MSTP on reflector port. All monitor traffic will be blocked on reflector port.
Page 457 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Reflector Port Only “Source(RMirror)” type can configuration Source VLAN(s) Configuration   Source VLANs Only “Mirror, Source(RMirror)” type can configuration • 1~4095(This can affect the Source in Port Configuration.) Port Configuration ...
Page 458 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Only “Source | Intermediate | Destination(RMirror) type can configuration  Destination Only “Mirror, Destination(RMirror) type can configuration EXAMPLE CLI CONFIGURATION Mirroring & Remote Mirroring Configuration   Mode • Disabled | Enabled (config)# no monitor session 1 (config)# monitor session 1 ...
Page 459 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  VLAN ID Only “Source | Intermediate | Destination(RMirror) type can configuration • 1~4095  Reflector Port Only “Source(RMirror)” type can configuration (config)# monitor session <session_number> [ destination { interface ( <port_type> [ <di_list> ] ) | remote vlan <drvid> reflector-port <port_type> <rportid> } | source { interface ( <port_type>...
Page 460 SOLTECH USER GUIDE Industrial Switch SFC8100 Series (config)# monitor session <session_number> [ destination { interface ( <port_type> [ <di_list> ] ) | remote vlan <drvid> reflector-port <port_type> <rportid> } | source { interface ( <port_type> [ <si_list> ] ) [ both | rx | tx ] | remote vlan <srvid> | vlan <source_vlan_list>...
Page 461 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.22. GVRP 6.22.1. Global config WEB MENU Configuration>GVRP>Global config This page allows you to configure the global GVRP configuration settings that are commonly applied to all GVRP enabled ports. GVRP Configuration Object Description...
Page 462 SOLTECH USER GUIDE Industrial Switch SFC8100 Series • Leave All-time(1000~5000csec)  Max number of VLANs • 1~4095(The change requires GVRP to be disabled.) EXAMPLE CLI CONFIGURATION GVRP Configuration   Enable GVRP • Enable | Disable (config)# gvrp (config)# no gvrp ...
Page 463 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.22.2. Port config WEB MENU Configuration>GVRP>Port config This page allows you to configure the global GVRP configuration settings that are commonly applied to all GVRP enabled ports. GVRP Port Configuration Object Description Port The logical port that is to be configured.
Page 464 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI CONFIGURATION GVRP Port Configuration   Mode • Disabled | GVRP Enabled (config)# interface ( <port_type> [ <plist> ] ) (config)# interface GigabitEthernet 1/1 (config-if)# gvrp...
Page 465 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.23. DDMI 6.23.1. DDMI Configuration WEB MENU Configuration>DDMI Configure DDMI on this page. DDMI Configuration Object Description Indicates the DDMI mode operation. Possible modes are: Mode Enabled Enable DDMI mode operation. Disabled Disable DDMI mode operation.
Page 466 SOLTECH USER GUIDE Industrial Switch SFC8100 Series  Check Polling Count • OFF | 1~10 EXAMPLE CLI CONFIGURATION DDMI Configuration   Mode • Enabled | Disabled (config)# ddmi (config)# no ddmi  Update Interval Time(s) • 1~12 (config)# ddmi update-interval <interval_time>...
Page 467 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.23.2. DDMI Monitor 6.23.2.1. Overview WEB MENU Configuration>DDMI>Overview Display DDMI overview information on this page. DDMI Configuration Object Description Port DDMI port. (Navigating to the Detail page by clicking on the port number.) Vendor Indicates Vendor name SFP vendor name.
Page 468 SOLTECH USER GUIDE Industrial Switch SFC8100 Series ------------------------------ Transceiver Information ========================================================== Vendor : Soltech Part Number : GP-3148-L2CD Serial Number : S2005136619 Revision : 1.0 Data Code : 2020-05-19 Transceiver : 2G5 DDMI Information ++ : high alarm, + : high warning, - : low warning, -- : low alarm.
Page 469 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Tx: transmit, Rx: receive, mA: milliamperes, mW: milliwatts. ========================================================== current High Alarm High Warn Low Warn Low Alarm Threshold Threshold Threshold Threshold ------------- -------- ---------- ---------- ---------- -------- Temperature(C) Voltage(V) Tx Bias(mA) Tx Power(mW)
Page 470 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.23.2.2. Detailed WEB MENU Configuration>DDMI>Detailed Transceiver Information Display DDMI detailed information on this page. Object Description Vendor Indicates Vendor name SFP vendor name. Part Number Indicates Vendor PN Part number provided by SFP vendor.
Page 471 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB MONITOR WEB MENU Configuration>DDMI>Detailed Transceiver Information   DDMI Information EXAMPLE CLI MONITOR Transceiver Information  DDMI Information  # show interface ( <port_type> [ <plist> ] ) transceiver # show interface 10GigabitEthernet 1/1-4 transceiver...
Page 472 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Rx Power(mW) 10GigabitEthernet 1/2 ------------------------------ Tranceiver Information ========================================================== Vendor : OEM Part Number : SFP-LX Serial Number : S1231240320176 Revision : A0 Data Code : 2014-03-09 Transceiver : 1000BASE_LX DDMI Information ++ : high alarm, + : high warning, - : low warning, -- : low alarm.
Page 473 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Transceiver : 100BASE_LX DDMI Information ++ : high alarm, + : high warning, - : low warning, -- : low alarm. Tx: transmit, Rx: receive, mA: milliamperes, mW: milliwatts. ========================================================== % SFP module doesn't support DDMI...
Page 474 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 6.24. Digital I/O 6.24.1. Digital I/O Configuration WEB MENU Configuration>Digital I/O This page is used to configure the Digital Input/Output group Digital Input/Output Control Configuration Digital Output Configuration Object Description Digital Output It is the name of Digital Output.(Digital Output is OUT1 and Digital Output is OUT 2) Mode Set the mode of the Digital Output.
Page 475 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Status It shows the status of the Digital Output. System Power Configuration Object Description Power It is the name of the power. Status It shows the status of the Power. (Normal : green, Fail: dark gray) Mode Set the mode of the Power.
Page 476 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 7. Switch Diagnostics Guide 7.1. Diagnostics 7.1.1. Ping WEB MENU Diagnostics>Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. ICMP Ping After you press Start, ICMP packets are transmitted, and the sequence number and round trip time are displayed upon reception of a reply.
Page 477 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 7.1.2. Link OAM 7.1.2.1. MIB Retrieval WEB MENU Diagnostics>Link OAM>MIB Retrieval This page allows you to retrieve the local or remote OAM MIB variable data on a particular port. Link OAM MIB Retrieval Select the appropriate radio button and enter the port number of the switch to retrieve the content of interest.
Page 478 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 7.1.3. Ping6 WEB MENU Diagnostics>Ping6 This page allows you to issue ICMPv6 PING packets to troubleshoot IPv6 connectivity issues. ICMPv6 Ping After you press ‘Start’, ICMPv6 packets are transmitted, and the sequence number and round trip time are displayed upon reception of a reply.
Page 479 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 7.1.4. VeriPHY WEB MENU Diagnostics>VeriPHY This page is used for running the VeriPHY Cable Diagnostics for 10/100 and 1G copper ports. VeriPHY Cable Diagnostics Press ‘Start’ to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds.
Page 480 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8. Switch Maintenance Guide 8.1. Maintenance 8.1.1. Restart Device WEB MENU Maintenance>Restart Device You can restart the switch on this page. After restart, the switch will boot normally. When restarting, the startup-config will be loaded. (If not saved, the configuration will be lost upon restart.)
Page 481 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2. Restart with delay Click the “Restart” button(The Delayed Restart value is 1~300) After waiting for a few minutes, the Login page will be displayed, and the restart will be completed. EXAMPLE CLI Restart Device(Load Startup-Config and Restart) ...
Page 482 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.2. Factory Defaults WEB MENU Maintenance>Factory Defaults You can reset the configuration of the switch on this page. Only the IP configuration is retained. The new configuration is available immediately, which means that no restart is necessary.
Page 483 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI Factory Defaults   Defaults Executing "Defaults" in the CLI will reset the device, including IP configurations, to their default settings. (Startup-config initialization) # reload defaults % Reloading defaults (Update startup-config). Please stand by.
Page 484 SOLTECH USER GUIDE Industrial Switch SFC8100 Series Config Factory-Default applied! (By CLI) ###: Press ENTER to get started #: Please input a new admin password:********** #: Please input the new password AGAIN:********** #: Save admin password to flash now ?
Page 485 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.3. Software 8.1.3.1. Upload WEB MENU Maintenance>Software>Upload This page facilitates an update of the firmware controlling the switch. Buttons Click this button, you can find the software image to upload. Click this button, upload the selected software image.
Page 486 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI The method for software upgrade using console (utilizing TFTP) Software Upload  1. Run the Tftpd32 program. 2. Click on "Browse" to locate the file you want to update. 3. Click on "Show Dir" to select the file, then click "Copy." and click "Close" to close the window.
Page 487 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.3.2. Image Select WEB MENU Maintenance>Software>Image Select This page provides information about the active and alternate (backup) firmware images in the device, and allows you to revert to the alternate image. The web page displays two tables with information about the active and alternate firmware images.
Page 488 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB WEB MENU Maintenance>Software>Image Select Clicking on will activate the alternative image. Use it if there are issues with the existing image. EXAMPLE CLI Software Image Selection  # firmware swap ... Erase from 0x40fd0000-0x40fdffff: .
Page 489 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.4. Configuration The switch stores its configuration in a number of text files in CLI format. The files are either virtual (RAM-based) or stored in flash on the switch. 1. running-config: A virtual file that represents the currently active configuration on the switch.
Page 490 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.4.2. Save startup-config WEB MENU Maintenance>Configuration>Save startup-config This copies running-config to startup-config, thereby ensuring that the currently active configuration will be used at the next reboot. Buttons : Click "Save configuration" to copy the running-config to the startup-config.
Page 491 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.4.3. Download WEB MENU Maintenance>Configuration>Download It is possible to download any of the files on the switch to the web browser. Select the file and Click ‘Download Configuration’. Download of running-config may take a little while to complete, as the file must be prepared for download.
Page 492 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI Download Configuration  Run Tftpd32 and choose the destination to save the file. Click on "Browse" to set the location where the file will be saved. Subsequently, enter the CLI command.
Page 493 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.4.4. Upload WEB MENU Maintenance>Configuration>Upload It is possible to upload a file from the web browser to all the files on the switch, except default-config which is read-only. Select the file to upload, select the destination file on the target, then click Upload Configuration.
Page 494 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE WEB WEB Menu Maintenance>Configuration>Upload 1. Click on to load the saved configuration. 2. After selecting the desired file, click the "Open" button. 3. Select the desired Destination File and click on "Upload Configuration".
Page 495 SOLTECH USER GUIDE Industrial Switch SFC8100 Series The screen will appear, and the configuration will be uploaded. EXAMPLE CLI  Upload Configuration Since direct uploading to the Running-Config is currently unavailable, let me introduce an alternative method. 1. Click on “Browse” in tftp32 to set the path.
Page 496 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 2. Click on "show Dir" to select the file, then click on "Copy", and finally click "Close" to close the window. 3. Return to the console window and enter the following. # copy tftp://<PC IPv4 Address>/<upload_filename> startup-config # copy tftp://192.168.10.130/running-config startup-config...
Page 497 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.4.5. Activate WEB MENU Maintenance>Configuration>Activate Activate Configuration Select configuration file to activate. The previous configuration will be completely replaced, potentially leading to loss of management connectivity. Please note: The activated configuration file will not be saved to startup-config automatically.
Page 498 SOLTECH USER GUIDE Industrial Switch SFC8100 Series EXAMPLE CLI Activate Configuration  # copy <flash file> running-config # copy flash:default-config running-config...
Page 499 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 8.1.4.6. Delete WEB MENU Maintenance>Configuration>Delete It is possible to delete any of the writable files stored in flash, including startup-config. If this is done and the switch is rebooted without a prior Save operation, this effectively resets the switch to default configuration.
Page 500 SOLTECH USER GUIDE Industrial Switch SFC8100 Series startup-config successfully deleted. (Delete is complete. The device will go to default settings upon restart.) EXAMPLE CLI Delete Configuration File  # delete <url_file> # delete flash:startup-config...
Page 501 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 9. Fault Recovery Method 9.1. Emergency Recovery 9.1.1. 3seconds Reset If the device is not functioning or the settings are incorrect, there is a hardware button for quick equipment reset. It is labeled "Reset" on the front panel. To perform the reset, use a thin and long clip or pen to press and hold it for about 3 seconds until the Port LEDs blink.
Page 502 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 9.2. WEB Interface Connectivity Problem If you are experiencing intermittent login failures or difficulty maintaining the login during WEB access, please follow the steps below. Typically, closing and reopening all web browsers resolves the issue.
Page 503 SOLTECH USER GUIDE Industrial Switch SFC8100 Series 9.2.2. Microsoft Edge Browser 1. Click on the 'Not secure' next to the equipment's URL. Click on 'Cookies,' remove the cookies, then restart the web browser. Click on the permissions for this site.
