Icom IC-M412 Service Manual page 24

[VR-A UNIT]
REF PARTS
NO. NO.
R1 7210003140 VAR TP96N97N-15SK-10KA-2685
J1 6510009381 CON B5B-ZR(LF)(SN)
DESCRIPTION M.
LOCATION
[SQL-A UNIT]
H/V REF PARTS
NO. NO.
R1 7210003150 VAR
J1 6510009471 CON
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 6
DESCRIPTION M.
TP96N97-15SK-10KB-2685
S3B-ZR(LF)(SN)
S.=Surface mount
H/V
LOCATION
