Rohm BD34302EKV User Manual

32-bit, 1536 kHz Sampling Stereo Audio D/A Converter
BD34302EKV Evaluation Board (Hardware)
(BD34302EKV-EVK-001)
IC Introduction
BD34302EKV is a D/A converter for high-quality audio that incorporates ROHM's unique sound quality design technology. The
newly developed DWA improves THD performance and provides higher resolution and more natural sound quality with HD (High
Definition) monaural mode. In addition, an automatic mode switching function makes it possible to easily switch between
PCM/DSD and different sampling frequencies.
