Page 1: Table Of Contents
Original operating instructions EN-US 3.0 465845 DualSense D Detector for activating and safeguarding automatic sliding doors in accordance with EN 16005 including emergency exits 4.1 Software configuration Description 4.2 Mechanical settings 1.1 Function 1.2 Scope of delivery Operation and maintenance 5.1 Commissioning Safety instructions 5.2 Status display Installation 5.3 Regular work...
Page 2: Description
Description Installation Function Mounting position The detector is designed for mounting above an Door requirements for the sensor: automatic pedestrian door and for connection to the door • Always position a detector above the main closing controller. To activate the door, a radar field detects the edge.
Page 3 Rain cover to protect sensors on the external facade 129.50 1 Cable aperture 2 Hole for screw Use the angle profile instead of the drilling template. 1. With the help of the angle profile, mark the positions of the cable outlet (1) and the two screws (2). 2.
Page 4 5. Pull the connection cable through the opening in the ceiling mounting kit. 6. Insert the mounting housing into the recess and screw NOTE the flange to the ceiling. Configuration-friendly mounting position The sensor is removed from the installation housing for configuration. An AIR inclination angle of ≥...
Page 5: Electrical Connection
To close the ceiling mounting kit, press the supplied cover Detector Door controller onto the flange of the mounting housing. The edge of the 1 Supply voltage, 11.5 – 32 V DC cover snaps into place on the flange. 2 Radar output, max. 34 V DC, max. 40 mA 3 Test input, 5 – 32 V DC, max. 4 mA 4 Infrared output, max. 34 V DC / 24 V AC, max. 40 mA 5 Radar voltage output,...
Page 6 Joystick action in the menu view NOTE Display value view of the parameter (exit configuration in menu item Exit) Default settings To change the value for the selected parameter, press the The detector starts with the default settings. joystick. The display switches to the value view. The value Alternative default settings can be selected in view lists the configurable values of a parameter.
Page 7: Mechanical Settings
Reset Restart teaches the detector in again. Software version Factory setting deletes all manual settings, including password. Exit Password Dialog for setting a password consisting of 4 digits. At 0000, the password protection Exit configuration Password? is inactive (factory setting). For any other 0 0 0 combination of digits, the password is Cancel...
Page 8 Align the radar module The radar module can be manually tilted at an angle of 0 to 90° and swiveled 20° to either side. 1. Adjust the swivel angle so that the radar module is aligned to the path in front of the door. 2.
Page 9: Operation And Maintenance
Set the AIR inclination angle (mm) Distance R The AIR field must be aligned to the floor with the smallest Height H possible distance to the door, but not to the door itself. 3800 +5° +4° +3° +2° +2° +1° 0°...
Page 10: Regular Work
LED display Operating status LED flashes green Detector flashes Radar hardware fault defective green flashes red a) AIR signal too strong/weak Door does not close b) AIR break (15 minutes) c) AIR hardware fault LED lights up red alternately Detector restart (9 seconds) AIR detects door ►...
Page 11: Tools
Door does not move Configuration code LEDs flash red and green simultaneously Info Exit Display: Message ► Ensure that the supply voltage is A2004 ... A2007 sufficient. If the supply voltage is guaranteed according to the technical Supply voltage too AIR sign.
Page 12: Contact
Contact If you have any questions about the device, please contact us: service@bircher.com +41 52 687 1366 Bircher Smart Access BBC Bircher AG, Wiesengasse 20, CH-8222 Beringen bircher.com 12 / 12 © 06.02.2025 Bircher Smart Access 465845 v3.0 en-us...
