ProLoop Lite
Loop detector for industrial doors and gates and car parks
Original instructions
General
1
Safety instructions
– These devices and their accessories may only be operated in accordance
with the operating instructions (intended use).
– These devices and their accessories may only be placed in operation by
trained and qualified personnel.
– These devices may only be operated with the operating voltages and
parameters intended for them.
2
Mechanical mounting in the switch cabinet
The 11-pin version of the ProLoop Lite is mounted onto a mounting rail base (ES 12). This base is ordered and delivered separately as it is not included
in the scope of delivery.
3
Electrical connection
The loop connection wiring to the loop detector must be twisted at least 20 times per meter.
i
Please wire the device in accordance with the terminal assignment. Make sure the terminals are assigned correctly.
3.1
Terminal connection diagram, ES 12 base assignment
Check the electrical connection (base assignment) when exchanging a loop detector from another manufacturer.
A:
Supply voltage
connection
AC
A1 (2)
11 (1)
AC
1.S
Info LED
LCD display
"Mode" key
"Data" key
Plug-in connection, 11-pin
Type plate
B:
D:
Loop connection
Relay connection
output 1
(6) 21
24 (7)
1
A2
32 (8)
(5) 22
– If malfunctions occur that cannot be eliminated, place the device out of
operation and send it in for repair.
– These devices may only be repaired by the manufacturer. Tampering and
alterations are not permitted. This will invalidate all guarantee and war-
ranty claims.
E:
Relay connection
output 2
common
common
(4) 12
nc
nc
31
(3) 14
no
no
373635B
02/19
1
