UeeVii CPE450 User Manual

Wireless bridge
Hide thumbs Also See for CPE450:
Table of Contents

Advertisement

Quick Links

Download this manual
Wireless Bridge
User Manual
Tips:
Thank you for ordering and using UeeVii Wireless Bridge, please
read the manual carefully before use. If there are any problems
during the use, please contact us in time.
The installation of this device requires some network knowledge. If
you can't install it, please let us know or contact a professional.
Customer Service Email: support@ueevii.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPE450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UeeVii CPE450

Summary of Contents for UeeVii CPE450

  • Page 1 Wireless Bridge User Manual Tips: Thank you for ordering and using UeeVii Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time. The installation of this device requires some network knowledge. If you can't install it, please let us know or contact a professional.

  • Page 2: Table Of Contents

    Menu Basic Settings 1 . Introduce 2. Important Certification 3. Highlights 4. Package List 5. Details Part 6. Part Description 7. PoE Power Supply 8. Connection Method 9. Dial Pairing Guide 10. Installation 11. WiFi Function 12. Application Case Topology Diagram Advanced Settings 1 .

  • Page 3: Basic Settings

    Note: If you are a non-technical person, just read the basic settings 1. Introduce UeeVii CPE450 is a long-distance 5.8G wireless transmis- sion device. It uses wireless communication technology to transmit network data using air as a medium to perform long-distance point-to-point or point-to-multipoint inter- connection.

  • Page 4: Important Certification

    3. 7. Support PC browser to access and modify the device. 3. 8. 24V~48V PoE power supply, efficient power saving. 4. Package List 2 * CPE450 Wireless Bridge 2 * POE Adapter (24V ) 2 * Network Cable 2 * Metal Hoop...

  • Page 5: Details Part

    5. Details Part 6. Part Description Item Description WLAN Signal WLAN and 4 grid green signal strength display. When LAN1 and LAN2 are connected is LAN1/LAN2 flashing. Power indicator, red LED solid is normal. Digital tube display "H" indicates in manual Digital Tube configuration status.

  • Page 6: Poe Power Supply

    Digital tube display "L" and flashing Digital Tube indicates in settings status. Digital tube flashing indicates setting the Digital Tube config or connecting, solid light indicates that the pairing has been successful. A , B status lights, lighting is B mode, no Point LED lighting is A mode.

  • Page 7: Connection Method

    48V PoE Switch 24V or 48V PoE Injector 7. 1 . The LAN port of the PoE power supply is connected to the PC, router, and switch. 7. 2. According to the requirements, prepare a long enough network cable（Recommended within 20 meters, must Cat 5e or up）...

  • Page 8: Dial Pairing Guide

    Digital Bridge-B Slave Mode 8. 2. Transmission of video signals Digital Bridge-A Master Mode Digital Bridge-B Slave Mode 9.Dial Pairing Guide A. Point to Point Pairing Step: 1. Switch one unit to A (Master Bridge) and one unit to B(Slave Bridge); 2.
  • Page 9 3. Wait for them to power up, about 2 min; 4. Use the tiny reset button to click through until you get a channel with a letter. 1,2,3,..., A ,B,C,...,F, here used C; 5. Then on the other unit do the same. Both units need to be on the same channel;...

  • Page 10: Installation

    CPE, the bracket is not included in the package. Recommended UeeVii Universal Bracket (ASIN: B09Y56M6Z9). 2. Please, prepare a long enough network cable to connect the PoE adapter and CPE, the network cable is connected to the LAN port of the CPE, and the other end is connected to the PoE port of the PoE adapter.

  • Page 11: Wifi Function

    11. WiFi Function 1. The WiFi function is turned on by default for the master bridge. WiFi SSID: CPE5G-5GXXX WiFi PWD: zllinkcpe123456XXX XXX represents different channels, please refer to the com- parison table in the user manual. 2. You can access the wireless bridge through your com- puter to set the SSID and new WiFi password.
  • Page 12 Case 3: Point-to-multiple point extended surveillance cameras range Case 4: Point-to-point extended surveillance cameras range...
  • Page 13 Case 5： Work with Starlink...

  • Page 14: Advanced Settings

    Case 6: Repeater mode obstacle avoidance transmission A1 and B2 are blocked by mountains and cannot transmit directly. They can be relayed through 2 pairs of bridges. Advanced Settings Note: You can work the wireless bridge without advanced settings 1. Connect Computer and Power Supply Computer access wireless bridge, connect the CPE to the computer.

  • Page 15: How To Change Your Ip Address On Windows

    2. How to Change Your IP Address on Windows 2. 1 Modify your computer's IP address, make your computer's IP and the bridge's IP address be on the same network segment(LAN) so that you can access them. Step 1 : Find and open "Open Network and Sharing Center" on your computer.
  • Page 16 mask, Default gateway, Preferred DDS server. 2. 2 Change your computer's IP address to 192.168.255.xxx (192.168.255.xxx cannot be the same as the IP of the CPE), then the entry IP address is 192.168.255.xxx, the subnet mask is 255.255.255.0(Autofill), the Default gateway is 192.168.255.

  • Page 17: How To Change Your Ip Address On Mac

    3. How to Change Your IP Address on Mac 3. 1 Click the Apple icon in the upper-left corner of the screen, and select System Preferences. 3. 2 Click Network.
  • Page 18 3. 3 Click your current network on the left and then click Advanced in the lower-right corner of the window. 3. 4 Click the TCP/IP tab.
  • Page 19 3. 5 Click the drop-down box next to Configure IPv6 (or IPv4) and select Manually. 3. 6 Enter the IP address you want to use (enter 192.168. 255.6; Router 192.168.255.1), and click OK .

  • Page 20: Hide Wifi Ssid

    3. 7 Verify that your new local IP address is displayed and click Apply. 4. Hide WiFi SSID In the wireless settings, select "Hidden", and finally click "Apply" to complete the setting.

  • Page 21: Setting Options (Optional)

    5. Setting Options (optional) 5. 1. DIP Switch Function The function of the DIP switch is to control the pairing by dialing the digital switch, making the pairing simple ; When the DIP switch is turned on, pairing can be done through dialing, but any modified wireless bridge parameters cannot be saved when the power is turned off or restarted, and the default parameters must be used ;...

  • Page 22: Modify Bridge Mode

    5. 2. Modify Bridge Mode In "Quick Setup"-->"Bridge Setting"-->"Mode", change the mode to A (Master) or B (Slave). One of the pair of bridges must be A (Master) and the other must be B. (Slave) can be paired. 5. 3. Modify Matching ID Modify the ID (channel) in "Quick Setup"-->"Bridge Setting"...

  • Page 23: Modify Ip Address 2

    5. 4. Modify IP address Enter the custom IP address in "Quick Setup"-->"Bridge Setting"-->"Fixed IP Address". You need to modify the IP addresses of the two wireless bridges in the same network segment. For example, the main network bridge is changed to 192.168.3.104, and the slave network bridge is changed to 192.168.3.204.

  • Page 24: Modify Ssid & Password And Re-Pair

    5. 5. Modify SSID & Password and Re-pair 1. Visit the management page of the Master bridge and turn off the DIP button. After it is turned off, you will not be able to use the button to change the number. Remove the check mark and click "OK"...
  • Page 25 3. At this time, the two bridges will lose their pairing (the signal indicators on the side of the two bridges will go out). You need to pair them according to the following steps. Note: Wait for a minute, after refreshing the page, you may not be able to access it because the two wireless bridges are not paired.
  • Page 26 4. Visit the management page of the Slave bridge and turn off the DIP button. After it is turned off, you will not be able to use the button to change the number. Remove the check mark and click "OK" to save. 5.
  • Page 27 6. On the scan results page, find the Name (SSID) set for the master bridge, which is "Master_CPE450" in the legend. Click the " " button to select this master bridge.
  • Page 28 7. Enter the password set for the main bridge. The legend is "CPE450666". Click the "Apply" button at the top to save and pairing will be performed automatically.

  • Page 29: Digital & Ip & Wifi Correspondence Chart

    8. Wait for 1 minute and check that the signal indicators on the sides of the two bridges are on, which means the pairing is successful. Digital & IP & WiFi Correspondence Chart You can check the SSID and password through this chart. SSID Password A IP...

  • Page 30: Specifications

    Specifications Brand UeeVii Model CPE450 2A6EJ-CPE450 FCC ID AR9344 DRAM DDR2 64Mbyte, Flash: 8Mbyte Interface 10/100Mbps LAN*2 11a: 54M,48M,36M,24M,18M,12M,9M, 6Mbps 11n:7.2M,14.4M,21.7M,28.9M,43.3M,57.8M, Data rate 65M,72.2M,14.4M,28.9M,43.3M,57.8M, 86.7M,115.6M,130M,144.4Mbps Transfer method Direct Sequence Spread Spectrum(DSSS) Modulation OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK IEEE802.11ac IEEE802.11n,IEEE802.11a , Protocol standard IEEE802.3u CSMA/CA,TCP/IP,IPX/SPX,NetBEUI,...

  • Page 31: Troubleshooting

    Serial Support Safety WEP 64/128bits,WPA,WPA2,802.1x Temperature -30～65℃ Box Size & Weight 11.8*11.5*2.7 inch & 2.2 LB Troubleshooting Trouble Solution Reason 1. Use WiFi analysis to choose the best 1. Wireless channel, interference 2. CPE should be in 2. Distance is too the normal distance, long, or there are and avoid the wall...
  • Page 32 1. Press the "RST ” button in 10s to reset 1. Forget the the bridge, the default password password is admin. 2. Input wrong 2. Re-input the password password Wrong 3. WiFi password is 3.WEB access user Password namer and password confused with the WEB access is "admin", Please...
  • Page 33 1. Check if the PoE adapter or PoE switch 1. PoE adapter is work 2. Check if the PoE damaged 2. Damage to CPE's port of CPE is ok PoE port or LED 3. Check if Ethernet System LED part cable is loose if Ether- light off 3.
  • Page 34 1. Make CPE or PoE adapter need a ground connection 2. Running time over 7 1. Static electricity days,reboot it Device always 2. Running time too 3. After lightning, dead long device PoE port broken 3. Lightning stroke or unstable better to deploy lightning conductor 4.

  • Page 35: Technical Support And Service

    Technical Support and Service Thank you for your order and for using UeeVii Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time. Tech Service Email: support@ueevii.com e.g.
  • Page 36 WhatsAPP Facebook FaceBook_Grounp Youtube Official Website...
