UeeVii CPE-453 User Manual

Hide thumbs

Advertisement

Table of Contents

WIRELESS BRIDGE
USER MANUAL
Model: CPE-453
Tips:
Thank you for ordering and using UeeVii Wireless Bridge, please read the
manual carefully before use. If there are any problems during the use,
please contact us in time.
The installation of this device requires some network knowledge.
If you can't install it, please let us know or contact a professional.
Customer Service Email: support@ueevii.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPE-453 and is the answer not in the manual?

Questions and answers

Related Manuals for UeeVii CPE-453

Summary of Contents for UeeVii CPE-453

  • Page 1 USER MANUAL Model: CPE-453 Tips: Thank you for ordering and using UeeVii Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time. The installation of this device requires some network knowledge.
  • Page 2 Introduce 1. Overview UeeVii CPE453 is a high-performance enterprise-class outdoor digital bridge that supports 802.11ac technology. It operates in the 5.8G wireless band. It has unique digital tube pairing technology, no computer configuration, easy to finish point-to-point, point-to-point (less than 8 points) equipment matching. With a 100M network interface.

  • Page 3: Package Included

    Important Certification Model: CPE-453 FCC ID: 2A6EJ-CPE450 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 Package Details Part SIG 4 SIG 3 SIG 2 SIG 1 LAN 1 LAN 2 M/S Button DC Port LAN 1/PoE Button and port description Item Description In the working mode, when the DIP switch is turned to "M", the device is in the "master bridge" mode, and when the DIP M/S Button switch is turned to "S", the device is in the "slave bridge"...

  • Page 5: Poe Power Supply

    Indicator status description Item Description In the master bridge mode, as the output power indicator, the SIG1 stronger the signal, the more lights on; SIG2 In the slave bridge mode, it indicates the signal strength of the SIG3 connection after successful pairing, the stronger the signal, SIG4 the more lights.
  • Page 6 Digital Switch Quick Pairing Point to Pint Piring: 1) Move the M/S Button to "M" as the master bridge, and the other to "S" as the slave bridge; 2) Short press the "digital switch/reset" button, the value of the digital tube will be +1 every time you press it;...
  • Page 7 Salve Bridge Salve Bridge --------------------------- Master Bridge Salve Bridge Browser Settings Bridge Note: You can work the wireless bridge without advanced settings 1. Computer Access Wireless Bridge, connect the CPE to the computer Refer to the figure left to connect the CPE to the computer through a PoE adapter and an Ethernet cable.
  • Page 8 3. Change your computer's IPv4 address to 169.254.254.xxx (169.254.254.xxx cannot be the same as the IP of the CPE), then the entry IP address is 169.254.254.xxx, the subnet mask is 255.255.255.0(Autofill), the Default gateway is 169.254.254.xxx, Preferred DDS server 169.254.254.xxx. You can use 169.254.254.3(xxx=3) in the reference picture to set.

  • Page 9: Specifications

    Language Setting: English/Chinese can be switched through the icon in the upper right corner Specifications Item Description Brand UeeVii Model CPE-453 Frequency 580MHz Wireless technology 5G, 450M, 802.11a/n/ac 1T1R technology SISO 1*10/100Mbps Adaptive Network Interface, Network interface 1*10/100Mbps Adaptive Network Interface, 24V 0.5A non-standard POE power supply,...

  • Page 10: Troubleshooting

    Built-in dual polarized high gain directional antenna Antenna (14dBi plate wave angle of 60 degrees, 60 degrees vertical wave width) Networking mode Point to point and point to multipoint (within 8 points) Product size Length 285mm*Width 98 mm*Height 98 mm Troubleshooting Solution Trouble...
  • Page 11 1. Make sure the wireless bridge is connected to the computer and the network cable is of good 1. LAN connection or quality. ethernet cable has a 2. Set the computer's local problem IPv4 address to the same Can't access from 2.
  • Page 12 4. Contact us for replacement items Technical Support and Service Thank you for your order and for using UeeVii Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time.
