Wireless Bridge
USER MANUAL
Model: CPE-688
Tips:
Thank you for ordering the UeeVii CPE688 Wireless Bridge. Please read
this manual carefully before use. The installation of this device requires
some network knowledge.
If you encounter any problems please contact us promptly at the email
below or contact a professional.
Customer Service Email: support@ueevii.com
Advertisement
Table of Contents
Related Manuals for UeeVii CPE-688
Summary of Contents for UeeVii CPE-688
- Page 1 USER MANUAL Model: CPE-688 Tips: Thank you for ordering the UeeVii CPE688 Wireless Bridge. Please read this manual carefully before use. The installation of this device requires some network knowledge. If you encounter any problems please contact us promptly at the email below or contact a professional.
-
Page 2: Table Of Contents
8.1 Case 1: PTP extended network WiFi range 8.2 Case 2: PTP extended of surveillance cameras range 8.3 Case 3: PTMP extended surveillance cameras range 8.4 Case 4: PTP extended surveillance cameras range 9. Advanced Settings 10. Troubleshooting 11. Technical Support and Service support@ueevii.com... -
Page 3: Overview
1. Overview 1.1 Introduce UeeVii CPE688 is a long-distance 5.8G wireless transmission device. lt uses wireless communication technology to transmit network data using air as a medium to perform long-distance point-to-point or point-to-multi point interconnection. The working data link layer realizes the interconnection of local area networks. -
Page 4: Important Certification
(1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 1.4 Specifications Brand UeeVii Model CPE-688 MT7621A+MT7612EN Flash 8MByte DRAM DDR3 128MByte Interface 1000/100/10Mbps LAN *1... -
Page 5: Package Included
Box Size & Weight 13.8*9.8*2.3 inch & 2.6 lb Protection Level IP66 2. Package Included 2 * CPE688 Gigabit Bridge 2 * Gigabit PoE Adapter (24V) 2 * Cat 5e Network Cable 2 * Metal Hoop 1 * User Manual support@ueevii.com... -
Page 6: Interface Details
A-B Button: Pushing the button to "A" indicates that the bridge acts as the master bridge(transmitter), and pushing the button to "B" indicates that the bridge acts as the slave bridge (receiver). support@ueevii.com... -
Page 7: Led Indicator Details
Power indicator, the LED is on after the power is connected. Digital Digital display LED display "H" indicates manual display configuration status. Digital Digital display LED display "L" and flashing indicates display settings status. Digital Digital display LED flashing indicates edit the config or display connecting. support@ueevii.com... -
Page 8: Quick Start
PoE power supply. The PoE port of the PoE power supply is connected to the LAN port of the wireless bridge. 1.2. The LAN port of the PoE power supply is connected to the PC, router, and switch. support@ueevii.com... -
Page 9: Point To Point Pairing Step
6. Wait for 2-5 minutes to complete the pairing. When the number of the digital tube is solid and the signal light on the side turns on, it means their pairing is successful; 7. Finally connect other devices(Router, PC, Switch) and install them to the target location. support@ueevii.com... -
Page 10: Installation
fix the CPE, the bracket is not included in the package. Recommended UeeVii Universal Bracket (ASIN: B09Y56M6Z9). 2. Please, prepare a long enough network cable(Recommended within... -
Page 11: Wifi Function
1. The WiFi function is turned on by default for the master bridge. WiFi SSID: admin WiFi PWD: admin 2. You can access the wireless bridge through your computer to set the SSID and new WiFi password. Please refer to the advanced settings section. support@ueevii.com... -
Page 12: Application Case
Master Bridge Slave Bridge Router Computer Router Router device(AP mode) 6.2 Case 2: Point-to-point extended of surveillance cameras range Master Bridge Slave Bridge IP Camera Computer Switch IP Camera IP Camera support@ueevii.com... -
Page 13: Case 3: Ptmp Extended Surveillance Cameras Range
6.3 Case 3: Point-to-multiple point extended surveillance cameras range Slave Bridge IP Camera Master Bridge Computer IP Camera 60° IP Camera IP Camera 6.4 Case 4: Point-to-point extended surveillance cameras range Master Bridge Slave Bridge IP Camera Computer IP Camera IP Camera support@ueevii.com... -
Page 14: Advanced Settings
Connection" to right-click to open the network properties. Refer to the picture above to open. Step 3: Find and double-click open the "Internet Protocol Version 4 (TCP/IPv4)choose the " Use the following lP address" and enter lP address, subnet mask, Default gateway, Preferred DDS server. upport@ueevii.com... - Page 15 4. On the login screen, the default user name and login password of the wireless bridge is "admin" just entry password log in. Note: “admin” is not the password of the WiFi SSID, it is just the password for WEB access. 5. Log in successful, go to setting. support@ueevii...
- Page 16 6. In the wireless settings,turn off "Hide SSID",then modify the SSID name and WiFi password, and finally click "Apply" to complete the setting. upport@ueevii.com...
- Page 17 192.168.255.108 5GCPE_5G136 qlinkcpe123456136 192.168.255.109 192.168.255.109 192.168.255.110 192.168.255.110 5GCPE_5G140 qlinkcpe123456140 5GCPE_5G149 qlinkcpe123456149 192.168.255.111 192.168.255.111 192.168.255.112 192.168.255.112 5GCPE_5G153 qlinkcpe123456153 5GCPE_5G157 qlinkcpe123456157 192.168.255.113 192.168.255.113 192.168.255.114 5GCPE_5G161 qlinkcpe123456161 192.168.255.114 5GCPE_5G165 qlinkcpe123456165 192.168.255.115 192.168.255.115 （Ps:In this chart, SSIDs and Passwords are the default.） support@ueevii...
-
Page 18: Troubleshooting
IPad devices dress 3. LAN connection or 3. Check LAN connection Can not login WEB ethernet cable has and Ethernet cable aproblem 4. Clear cookie, run arp-d to 4. Too much cookie, clear MAC address MAC address haven't update support@ueevii.com... - Page 19 1. Make CPE or PoE adapter need a ground connection 2. Running time over 7days, 1. Static electricity reboot it Device always 2. Running time 3. After lightning, device dead toolong PoE port broken or unstable 3. Lightning stroke better to deploy lightning conductor support@ueevii...
-
Page 20: Technical Support And Service
11. Technical Support and Service A. Thank you for your order and for using UeeVii Wireless Bridge, please read the manual carefully before use. lf there are any problems during the use,please contact us in time; B. The installation of this device requires some network knowledge. lf you can't install it, please let us know or contact a professional.
