- Page 1 NAT-108 Series Quick Installation Guide Moxa Industrial NAT Device Version 1.0, April 2025 Technical Support Contact Information www.moxa.com/support 2025 Moxa Inc. All rights reserved. P/N: 1802001081010 *1802001081010*...
-
Page 2: Package Checklist
Package Checklist The NAT-108 Series is shipped with the items listed below. If any of these items are missing or damaged, please contact your customer service representative for assistance. • 1 Industrial NAT device • 1 USB-C-to-DB9 cable • 1 Console port cover •... - Page 3 Panel Views of NAT-108 Series Front Panel Front Panel: 1. POWER LED indicator 2. STATE LED indicator 3. LEARNING LED indicator 4. LOCKDOWN LED indicator 5. 10/100 Mbps copper ports Top Panel Top Panel: 1. Grounding screw 2. Terminal block with latch for power input 3.
-
Page 4: Mounting Dimensions
DIN-rail Mounting The metal DIN-rail mounting kit is fixed to the back panel of the NAT- 108 Series by default when shipped. Mount the NAT-108 Series on a corrosion-free mounting rail that adheres to the EN 60715 standard. - 4 -... -
Page 5: Wall Mounting
108 Series on the wall, as shown in the following illustrations. STEP 1: Remove the aluminum DIN-rail attachment plate from the rear panel of the NAT-108 Series, and then attach the wall mount plates with three M3 screws. - 5 -... -
Page 6: Wiring Requirements
STEP 2: Mounting the NAT-108 Series on the wall requires two screws. Use the NAT-108 Series with the wall mount plates attached as a guide to mark the correct location of the two screws. NOTE The screws should have a screw head diameter of 3.5 to 6.0 mm, a shaft diameter of 2.5 to 3.5 mm, and a length of at least... -
Page 7: Wiring The Power Inputs
This product is intended to be mounted to a well-grounded mounting surface such as a metal panel. Wiring the Power Inputs The NAT-108 Series has one power input. The top and side views of the terminal block connector are shown below. - 7 -... -
Page 8: Communication Connections
8 10/100BaseT(X) Ethernet ports Type-C Console Port Connection The NAT-108 Series provides one TYBP-C console port located on the top panel. Connect the industrial secure router to a PC COM port using the Type-C-to-DB9 connection cable, and then launch a console terminal software, e.g. -
Page 9: 10/100Baset(X) Ethernet Port Connection
NOTE DO NOT power off the device when loading default settings. LED Indicators The front panel of the NAT-108 Series has several LED indicators. The function of each LED is described in the following table: Color State... -
Page 10: Specifications
Color State Description Device reset is in progress, blinking Blinking once per second. The system failed the self-diagnosis test on boot-up. The device lockdown learning is in Blinking LEARN progress. Amber Learning finished. The device lockdown allowlist is enabled. LOCKDOW Green The device lockdown allowlist is disabled. - Page 11 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱: 8 埠工業網路位址轉譯(NAT)裝置 型號（型式）: NAT-108 系列 (系型號參考頁) Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻 多溴聯苯 多溴二苯醚 單元 Unit 鉛 汞 鎘 Hexavalent Polybrominat Polybrominated Lead Mercury...
