Bauknecht GSF 7394 Quick Reference Manual

GB GSF 7394
DYNAMIC SENSE: Energy savings and optimum wash results
The two sensor-controlled "DYNAMIC SENSE" wash options are recommended
for routine washes. They use double-sensor technology. Separate sensors
gauge turbidity and particles in order to determine the degree of soiling of the
wash water. In accordance with values measured, a microprocessor establishes
optimum water, energy and time consumption. Optimum wash results are thus
achieved using only those resources strictly required.
Water supply indicator
Check the appliance fills with water.
Lower spray arm block indicator
Release the spray arm.
"Water stop" device indicator
"Water stop" device not working.
Switch off the dishwasher and shut off the water tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add regeneration salt
immediately before starting a wash programme.
Programme Symbol
and Temperature
Eco Normal 40 - 55° C
Intensive 60 - 70° C
Pre-wash
Rapid 40° C
Glasses 40° C
2)
Bio-Normal 50° C
1) Values may vary in relation to usage, e.g.: different loads,
water temperatures - above or below 15° C - as well as water hardness and power supply voltage.
2) Reference programme for Test Institute and energy-label.
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme progress indicator
Pre-rinse /
Pre-wash
Washing
Eco-Dry
The indicator lamp switches on during dry
cycles without fans.
Programme selection and
recommended load type
Recommended programme for routine washes, for crockery with
little or no dried-on food.
Recommended programme for heavily soiled crockery, with
dried-on food. Especially suitable for pans and saucepans.
Crockery to be washed later.
Lightly soiled crockery with no dried-on food.
Light soiling, especially glasses and cups.
Normally or heavily soiled crockery with dried-on food.
Drying
Programme end
Options
Place the detergent in the:
small
compartment
X
X
-
-
-
X
Delayed start buttons
The wash cycle can be programmed to start after 1-24 hours.
Then press the Start button. The dishwasher will start at the set time.
Time and failure display
Indicates in hours the time remaining until the start of the wash cycle.
Switches off when the programme has started. Toward the end of
the programme, during the drying cycle, the display will indicate the
time remaining in minutes.
"F1-F9" Identification of faults for service technician.
Start button
Indicator lamp lit while the dishwasher is operating. Flashes when a
fault occurs. Switches off at the end of the programme.
On / Off Button
Consumption
large
Normal load
compartment
Water
(Litres)
X
X
- 5.0
X 13.0
X 12.0
X 16.0
5019 100 90253
(We reserve the right to make technical modifications)
1)
Energy Time
(kWh) (Min.)
0.02 9
0.85 30
0.82 60
1.05 140
