GSF 4851
GB
Water supply indicator
Check the appliance fills with water.
Lower spray arm block indicator
Release the spray arm.
"Water stop" device indicator
"Water stop" device not working. Switch off
the dishwasher and shut off the water tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add regeneration salt
immediately before starting a wash programme.
Programme Symbol
and Temperature
Pre-wash
Bio-Eco 50° C
2)
Bio-Normal 50° C
3)
Normal 65° C
Intensive 70° C
1)
Values may vary in relation to usage, e.g.: different loads, water
temperatures - above or below 15° C - as well as water hardness and power supply voltage etc.
2)
Programme recommended when using detergents of type B (enzyme-based detergents).
Reference programme for energy label.
3)
Programme recommended when using detergents of type A (non enzyme-based detergents).
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme progress indicator
Pre-rinse /
Pre-wash
Washing
Programme selection and
recommended load type
Crockery to be washed later.
Normally soiled crockery.
Normally or heavily soiled crockery with dried-on food.
Normally or heavily soiled crockery with dried-on food.
Heavily soiled pans and saucepans.
Delayed start button
Drying
The wash cycle can be programmed
to start after 3-6-9 hours.
Then press the Start button.
Programme
end
The dishwasher will start at the set time.
Start button
Indicator lamp lit while the dishwasher is operating.
Flashes when a fault occurs.
Switches off at the end of the programme.
On / Off Button
Place the detergent in the:
small
large
compartment
compartment
-
-
-
X
X
X
X
X
X
X
(We reserve the right to make technical modifications)
Option
1)
Consumption
Normal load
Water
Energy
Time
(Litres)
(kWh)
(Min.)
5.0
0.02
9
12.0
1.25
73
16.0
1.40
86
16.0
1.60
86
21.0
1.68
93
5019 100 90338
