Bauknecht GSF 7297 Quick Reference Manual

GSF 7297
GB

DYNAMIC SENSE: Energy savings and optimum wash results

The two sensor-controlled "DYNAMIC SENSE" wash options are
recommended for routine washes. They use double-sensor
technology. Separate sensors gauge turbidity and particles in order to
determine the degree of soiling of the wash water. In accordance with
values measured, a microprocessor establishes optimum water,
energy and time consumption. Optimum wash results are thus
achieved using only those resources strictly required.
Water supply indicator
Check the appliance fills with water.
Lower spray arm block indicator
Release the spray arm.
"Water stop" device indicator
"Water stop" device not working.
Switch off the dishwasher and shut off the water tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add regeneration salt
immediately before starting a wash programme.
Programme Symbol
and Temperature
Recommended programme for routine washes, for crockery
Eco Normal 40 - 55° C
with little or no dried-on food.
Recommended programme for heavily soiled crockery, with
Intensive 60 - 70° C
dried-on food. Especially suitable for pans and saucepans.
Crockery to be washed later.
Pre-wash
Lightly soiled crockery with no dried-on food.
Rapid 40° C
Light soiling, especially glasses and cups.
Glasses 40° C
2)
Normally or heavily soiled crockery with dried-on food.
Bio 50° C
1) Values may vary in relation to usage, e.g.: different loads, water
temperatures - above or below 15° C - as well as water hardness and power supply voltage, etc.
2) Reference programme for Test Institute and energy-label.
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme progress indicator
Pre-rinse /
Pre-wash
Washing
Programme selection
and recommended load type
Start button
Drying
Indicator lamp lit while the dishwasher is
operating.
Programme end
Flashes when a fault occurs.
Switches off at the end of the programme.
On / Off Button
Place the detergent in the:
small large
compartment compartment
Water
(Litres)
X X
X X
- -
- X
- X
X X
(We reserve the right to make technical modifications)
1)
Consumption
Normal load
Energy Time
(kWh) (Min.)
5.0 0.02 9
13.0 0.85 30
12.0 0.82 60
16.0 1.05 120
5019 100 90307
