Bauknecht GSFS 3000 Quick Reference Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Quick reference guide
PROGRAMME
START/RESUME BUTTON
SELECTION BUTTON
Push this button to start the selected programme:
Push "Programs" button
the indicator lights up and goes off at the end of the
(repeatedly) until the indicator
programme. When the door is opened during a
of the required programme
washing cycle, the cycle is temporarely paused: the
lights up (see "Table of
Start indicator blinking. To restart the cycle close
programmes" below).
the door and push Start button again.
Table of programmes
P
Programmes
1
Quickwash
2)
2
Bio Normal
3
Intensive
1) Programme data obtained in conformity with European standard EN 50242, obtained under normal conditions
(without additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible
with sensor programmes as a result of the appliance's automatic calibration system.
2) Reference programme for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for
detailed information on the EN/Standard loading comparison test and other tests, contact the following address:
"nk_customer@whirlpool.com".
BUTTON
Push this button to switch on or switch off the control panel.
If pressed when a programme is running it cancels
the programme ongoing.
If the indicator flashes repeatedly, see page 5 -
chapter "What to do if ...".
Loading instructions
Lightly soiled crockery, with
40°C
no dried-on food.
50°C
Normally soiled crockery.
Recommended programme
for heavily soiled crockery,
70°C
especially suitable for pans
and saucepans.
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING
AUTOMATICALLY AFTER 30 SECONDS IF ANY CYCLE IS STARTED.
Consumption
Deter-
gent
1)
Litres kWh
Minutes
X
13.0
0.70
30
X
15.0
1.05
150
X
17.0
1.65
145
GSFS 3000
ANY BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
Chart
5019 496 01616
GB -1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSFS 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bauknecht GSFS 3000

Summary of Contents for Bauknecht GSFS 3000

  • Page 1 2) Reference programme for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/Standard loading comparison test and other tests, contact the following address: GSFS 3000 5019 496 01616 “nk_customer@whirlpool.com”.

  • Page 2: First Time Use

    First time use How to set water hardness in order to always assure the best cleaning results Water hardness should be set only - Press and hold together Programs and buttons for minimum 3 seconds. before the first wash or if water - Programmes LEDs will indicate the water hardness setting.

  • Page 3: Daily Use

    Daily check Adding rinse aid (not necessary when you use tablets). How to adjust the rinse aid dosage regulator Visual The rinse aid dosage can be indicator adjusted to the detergent used. The lower the setting, the less rinse aid is dispensed (factory setting: position 4).

  • Page 4: How To Load The Racks

    How to load the racks How to load UPPER RACK How to adjust upper rack height (if available). A - Glass-holder for long stem glasses: it can be (in some models only) adjusted in 2 different positions according glasses shape. C - Cutlery basket: it can be placed in the upper rack It could be useful to lift up the upper rack to have more space in lower rack or bring it down to load...

  • Page 5: Maintenance And Care

    Select programme Quick, permanent or alternating Overview of programmes The max. possible number of programmes is illustrated in the chapter “Chart”. The corresponding programmes for your appliance can be found on the panel (page 1). Choose programme according to the attached table of programmes (page 1). Duration of the programme depends on the external conditions in the apartment, temperature and pressure etc.
  • Page 6 What to do if... If a fault occurs, before contacting the After-sales Service, make the following checks to try and remedy the problem. Most faults can be remedied by taking the courses of action, quickly restoring normal appliance operation. The appliance... Possible causes...
  • Page 7 What to do if... Crockery and cutlery... Possible causes... Solutions..salt indicator lit - Use tablets for soft water. - Set “Tablet” option; if this option is not available, it is normal for the salt indicator to light up..have deposits: regeneration salt residue - Water too hard.

  • Page 8: Precautions And General Recommendations

    What to do if... Disconnect the mains plug If, after carrying out the above checks, the fault persists, disconnect the mains plug and turn off the water tap. Contact the After-sales Service (see warranty). Before contacting our After-Sales Service, take note of the following: - the description of the fault, - the appliance type and model, - the service code (the number indicated on the adhesive rating plate) inside the door on the right-hand side:...
