Bauknecht GSF 7397 Quick Reference Manual

GSF 7397
GB
DYNAMIC SENSE: Energy savings and optimum wash results
The two sensor-controlled "DYNAMIC SENSE" wash options are
recommended for routine washes. They use double-sensor
technology. Separate sensors gauge turbidity and particles in order to
determine the degree of soiling of the wash water. In accordance with
values measured, a microprocessor establishes optimum water,
energy and time consumption. Optimum wash results are thus
achieved using only those resources strictly required.
Water supply indicator
Check the appliance fills with water.
Lower spray arm block indicator
Release the spray arm.
"Water stop" device indicator
"Water stop" device not working.
Switch off the dishwasher and
shut off the water tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add
regeneration salt immediately before
starting a wash programme.
Programme Symbol
and Temperature
Eco Normal 40 - 55° C
Intensive 60 - 70° C
Pre-wash
Rapid 40° C
Glasses 40° C
2)
Bio 50° C
1) Values may vary in relation to usage, e.g.: different loads, water
temperatures - above or below 15° C - as well as water hardness and power supply voltage etc.
2) Reference programme for Test Institute and energy-label.
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme progress indicator
Pre-rinse /
Pre-wash
Washing
Options
Delayed start buttons
The wash cycle can be programmed to
start after 1-24 hours. Then press the
Start button. The dishwasher will
start at the set time.
Programme selection and
recommended load type
Recommended programme for routine washes, for crockery with
little or no dried-on food.
Recommended programme for heavily soiled crockery, with
dried-on food. Especially suitable for pans and saucepans.
Crockery to be washed later.
Lightly soiled crockery with no dried-on food.
Light soiling, especially glasses and cups.
Normally or heavily soiled crockery with dried-on food.
Time and failure display
Indicates in hours the time remaining until the start
Drying
of the wash cycle.
Switches off when the programme has started.
Programme
Toward the end of the programme, during the drying cycle,
the display will indicate the time remaining in minutes.
end
"F1--F9" Identification of faults for service technician.
Start button
Indicator lamp lit while the dishwasher is operating.
Flashes when a fault occurs.
Switches off at the end of the programme.
On / Off Button
Place the detergent in the:
small
compartment compartment
X
X
-
-
-
X
(We reserve the right to make technical modifications)
Consumption
large
Normal load
Water Energy
(Litres) (kWh)
X
X
- 5.0 0.02
X 13.0 0.85
X 12.0 0.82
X 16.0 1.05
5019 100 90306
1)
Time
(Min.)
9
30
60
120
