Envertech EVT300 User Manual
Hide thumbs
Also See for EVT300:
- User manual (11 pages) ,
- Quick installation manual (3 pages) ,
- Quick installation manual (2 pages)
Subscribe to Our Youtube Channel
Related Manuals for Envertech EVT300
Summary of Contents for Envertech EVT300
- Page 1 User Manual Envertech Corporation Ltd. Tel: +86 21 6858 0086 Web: www.envertec.com Email: info@envertec.com Address: No.138, Xinjunhuan road, Minhang District, Shanghai, China USM-2024-V03...
-
Page 2: Table Of Contents
Content Important Safety Information ....... 1 Read It First ............... 1 Safety Instructions ............ 1 Envertech Microinverter System ......2 How it Works ............4 Monitoring Device EnverBridge ........ 5 Optimal Reliability ............ 5 Simple Design............5 Product Information ..........5 Overview .............. -
Page 3: Important Safety Information
Please be kindly note that the Envertech microinverter itself is a heat sink. DANGER indicates a hazardous situation which, if not Under normal operating conditions, its temperature is 20°C above ambient, avoided, will result in death or serious injury. -
Page 4: How It Works
2.1 How it Works The Envertech microinverter maximizes energy production from your photovoltaic (PV) array. Each Envertech microinverter is individually connected to one PV module in your array. This unique conjuration means that an individual Maximum Peak Power Point Tracker (MPPT) controls each PV module. -
Page 5: Monitoring Device Enverbridge
Envertech (Shanghai) Corporation Ltd. declares that this microinverter (Wi-Fi integrated) complies with the essential requirements and other relevant PV systems using Envertech microinverters are very simple to design and install. provisions of Directive 2014/53/EU. Following Article 10(2) and Article 10(10), You can install a combination of PV modules of any type, at any orientation, this product is allowed to be used in all EU member states. -
Page 6: Datasheet
3.2 Datasheet Model EVT300 EVT350 EVT360 Model EVT400 EVT500 EVT560 Input Data（DC） Input Data（DC） Recommended Module Power Range (W) 180W～450W+ 180W～550W+ 180W～500W+ Recommended Module Power Range (W) 180W～550W+ 250W～650W+ (180W～450W+)*2 Maximum Input Voltage (V) Maximum Input Voltage (V) Minimum Start Voltage (V) - Page 7 Model EVT720 EVT800SE EVT800 Model EVT1600SE EVT1800SE EVT2000SE Input Data（DC） Input Data（DC） Recommended Module Power Range (W) (180W～500W+)*2 (180W～550W+)*2 (180W～550W+)*2 Recommended Module Power Range (W) (250W～650W+)*4 Maximum Input Voltage (V) Maximum Input Voltage (V) Minimum Start Voltage (V) Minimum Start Voltage (V) Maximum Continuous Input Current (A) 20*4 Maximum Continuous Input Current (A)
-
Page 8: Preparation
4. Preparation 4.1 Packing Checklist After you receive the Envertech microinverter, please check if there is any damage on the carton, and then check the inside completeness for any visible external damage on the microinverter and accessories. Contact your dealer if anything is damaged or missing. -
Page 9: Symbols On Inverter
For microinverter with BC01 connector Any unauthorized perforations or modifications are strictly forbidden. If any defect or damage PV Module Module (device/person) is occurred, Envertech shall not take any responsibility for it. To connect the AC side to AC Extension Cable the grid. -
Page 10: Microinverter System Installation
Envertech (Shanghai) Corporation LTD. www.envertec.com Mount all microinverters under modules to avoid rain and sun. Make sure Installing Envertech microinverter system involves several key steps. Each you can see the LED light. step listed here is elaborated on the following pages. - Page 11 Insert the end cap directly into the unused end connector and make sure it remove the skin of internal wires by x=14mm. Set the metal terminals is inserted in place. (For EVT2500) onto the open parts and clamp them to tighten the connection; End cap Step 6.
- Page 12 a. Open EnverView and click WIFI. Select Bluetooth. Select the same Wi-Fi name as the EVT SN. Step 8. Switch on the PV system Ensure all connection is completed. Turn on the air switch. In a short time, you shall see the signal light blinking in green. Step 9.
- Page 13 Note: When configuring Wi-Fi, make sure you keep staying on the current network. c. Click NEXT and wait for success. Please allow EnverView to access your local Note: If the Bluetooth doesn't open successfully. You will receive the above network. If not, it will cause configuration failure. reminders.
- Page 14 a. Open EnverView and click Wi-Fi. Select EVT. Note: 1. Ensure that the Wi-Fi name does not contain , ; = or other special characters. 2. Check the Wi-Fi password, including spaces and special characters. 3. Ensure the Wi-Fi your phone connected to is 2.4GHz, and the connection between the router and the Internet is in good condition.
- Page 15 Note: When configuring Wi-Fi, make sure you keep staying on the current network. d. Click Configuration and wait for success.
- Page 16 Option 2. Use the app “EnverView” to register Note: If the setting is not successful, wait for 5 more seconds. Click Configuration again and check that the microinverter is as close to the router as possible. Fields marked with an asterisk (*) are required. Step 11.
- Page 17 b. Under “Device Management”, click “+” and enter the SN of the microinverter. Please check the SN to make sure it’s correct. 3) Checking data Login to your account to check data. c. Click “Confirm” to finish adding the microinverter. Note: Please ensure that both the microinverter and your phone are in the same router network.
-
Page 18: Debugging And Operating
6.2 Microinverter Operation The Envertech microinverter is powered on when there is sufficient DC voltage from the PV module. The LED light of each microinverter will blink green to indicate normal start-up operation approximately 1 minute after DC power is applied. -
Page 19: Troubleshoot An Inoperable Microinverter
Envertech microinverter. range. WARNING: Envertech microinverters are powered by DC power from the PV 7.3 Disconnect Microinverters from PV Modules modules. Please disconnect and reconnect DC power to check the LED blinks 1 minute after DC is applied. -
Page 20: System Diagram
+/-0.90 C l ass I T em perature ( ℃): -40℃ to +65 ℃ Envertech (Sh ang hai) C orp oratio n L TD. w w w .envertec.com T em perature ( ℃ ): -40 ℃ to +65 ℃ Envertech (Sh ang hai) C orp oratio n L TD. -
Page 21: Three Phase
Protect ive Class: +/-0.90 OVC III (AC Main) OVC II ( PV) Class I Envertech (Shanghai ) Corporation LTD. www. envertec.com Max. Input Cont inuous Current (A): Max. Input Short-Circuit Current (A): I ngress Protect ion (IP): Power (Max. Continuous) (W): Temperature ( ℃... -
Page 22: Recycling And Disposal
WARNING: Do not attempt to repair the Envertech microinverter. It contains no user-serviceable parts. If the microinverter fails, contact your direct supplier or Envertech customer service to obtain an RMA (return merchandise authorization) number and start the replacement process. PV Microinverter...
