- Page 1 User Manual Envertech Corporation Ltd. Tel: +86 21 6858 0086 Web: www.envertec.com Email: info@envertec.com Address: No.138, Xinjunhuan road, Minhang District, Shanghai, China USM-2024-V04...
-
Page 2: Table Of Contents
Content Important Safety Information ....... 1 Read It First ............... 1 Safety Instructions ............ 1 Envertech Microinverter System ......2 How it Works ............4 Monitoring Device EnverBridge ........ 5 Optimal Reliability ............ 5 Simple Design............5 Product Information ..........5 Overview .............. -
Page 3: Important Safety Information
Please be kindly note that the Envertech microinverter itself is a heat sink. DANGER indicates a hazardous situation which, if not Under normal operating conditions, its temperature is 20°C above ambient, avoided, will result in death or serious injury. -
Page 4: How It Works
2.1 How it Works The Envertech microinverter maximizes energy production from your photovoltaic (PV) array. Each Envertech microinverter is individually connected to one PV module in your array. This unique conjuration means that an individual Maximum Peak Power Point Tracker (MPPT) controls each PV module. -
Page 5: Monitoring Device Enverbridge
Envertech (Shanghai) Corporation Ltd. declares that this microinverter (Wi-Fi integrated) complies with the essential requirements and other relevant PV systems using Envertech microinverters are very simple to design and install. provisions of Directive 2014/53/EU. Following Article 10(2) and Article 10(10), You can install a combination of PV modules of any type, at any orientation, products with CE certification are allowed to be used in all EU member states. -
Page 6: Datasheet
3.2 Datasheet Model EVT300 EVT350 EVT360 Model EVT400 EVT500 EVT560 Input Data（DC） Input Data（DC） Recommended Module Power Range (W) 180W～450W+ 180W～550W+ 180W～500W+ Recommended Module Power Range (W) 180W～550W+ 250W～650W+ (180W～450W+)*2 Maximum Input Voltage (V) Maximum Input Voltage (V) Minimum Start Voltage (V) Minimum Start Voltage (V) Maximum Continuous Input Current (A) Maximum Continuous Input Current (A) - Page 7 Model EVT720 EVT800SE EVT800 Model EVT1600SE EVT1800SE EVT2000SE Input Data（DC） Input Data（DC） Recommended Module Power Range (W) (180W～500W+)*2 (180W～550W+)*2 (180W～550W+)*2 Recommended Module Power Range (W) (250W～650W+)*4 Maximum Input Voltage (V) Maximum Input Voltage (V) Minimum Start Voltage (V) Minimum Start Voltage (V) Maximum Continuous Input Current (A) 20*4 Maximum Continuous Input Current (A)
- Page 8 Model EVT500_L EVT800_L EVT1000_L Input Data（DC） MPPT Voltage Range(V) 22V-50V 22V-50V 22V-50V Recommended Module Power Range (W) 250W～650W+ (180W～550W+)*2 (250W～650W+)*2 Maximum Input Voltage (V) Minimum Start Voltage (V) Maximum Continuous Input Current (A) 14*2 20*2 Maximum Input Short Circuit Current (A) 25*2 25*2 Number of MPPT...
-
Page 9: Preparation
4.1 Packing Checklist Symbol Description After you receive the Envertech microinverter, please check if there is any Dangerous electrical voltage damage on the carton, and then check the inside completeness for any visible This device is directly connected to the public grid, thus external damage on the microinverter and accessories. -
Page 10: Accessories
AC Extension microinverters in the Cable system. Installing Envertech microinverter system involves several key steps. Each step listed here is elaborated on the following pages. For connecting the Step 1. Verify voltage microinverter's AC T-Connector Step 2. - Page 11 Mark out the estimated center of PV modules on the rack to mount the microinverter. Insert the end cap directly into the unused end connector and make sure it is inserted in place. (For EVT2500/ EVT2000/ EVT2000SE series) End cap Envertech(Shanghai)Corporation LTD.
- Page 12 1) Connect the AC connector of the micro-inverter to the female connector of the AC extension cable plug, then insert the plug into the socket. Option b. Put the open parts of the extension cable into the plug and use the plug to connect to the socket (For B version balcony installation) b.
- Page 13 Step 9. (Optional) For the monitoring device (EnverBridge) installation, scan this QR code EnverBridge Installation Step 10. Wi-Fi configuration (For microinverter that has built-in Wi-Fi module. The SN after CN2310.) Option 1. Use Bluetooth to configure Wi-Fi Note: Please position the microinverter as close as possible to the router. b.
- Page 14 Note: If the Bluetooth doesn't open successfully. You will receive the above c. Click NEXT and wait for success. Please allow EnverView to access your local reminders. Please turn on Bluetooth. network. If not, it will cause configuration failure. Option 2. Use EVT to configure Wi-Fi Note: Please position the microinverter as close as possible to the router.
- Page 15 b. Select a 2.4GHz Wi-Fi network, and return to the app. Enter Wi-Fi password. Allow EnverView to use your location, or you will fail to configure Wi-Fi. Note: When configuring Wi-Fi, make sure you keep staying on the current network. Note: 1.
- Page 16 d. Click Configuration and wait for success. Note: If the setting is not successful, wait for 5 more seconds. Click Configuration again and check that the microinverter is as close to the router Fields marked with an asterisk (*) are required. as possible.
- Page 17 3) Checking data Login to your account to check data. c. Click “Confirm” to finish adding the microinverter. Note: Please ensure that both the microinverter and your phone are in the same router network. Option 2. Use EnverPortal to bind MI a.
-
Page 18: Debugging And Operating
6.2 Microinverter Operation The Envertech microinverter is powered on when there is sufficient DC voltage from the PV module. The LED light of each microinverter will blink green to indicate normal start-up operation approximately 1 minute after DC power is applied. -
Page 19: Troubleshoot An Inoperable Microinverter
Envertech microinverter. one minute). WARNING: Envertech microinverters are powered by DC power from the PV 9. Attach an ammeter clamp to one conducting wire of the DC cables from the modules. Please disconnect and reconnect DC power to check the LED blinks 1 PV module to measure the microinverter’s current. -
Page 20: Disconnect Microinverters From Pv Modules
T emperature ( ℃): 800W -40 ℃ to +65 ℃ OVC II ( PV) Envertech (Sh ang hai) C orp oratio n L TD. w w w .envertec.com Pow er (Max. C ontinuous) (W): T emperature ( ℃ ): 800W -40℃... - Page 21 3.63A 50Hz/60Hz +/-0.90 OVC III (AC Main) OVC II ( PV) Class I Envertech (Shanghai) Corporation LTD. MPPT Voltage Range (Vdc): Max. DC Input (Vdc): Max. Input Continuous Current (A): Max. Input Short-Circuit Current (A): Ingress Protection (IP): Power (Max. Continuous) (W): Temperature ( ℃...
-
Page 22: Recycling And Disposal
User I dent i f i cat i on Number WARNING: c. BC05-C Do not attempt to repair the Envertech microinverter. It contains no user-serviceable parts. If the microinverter fails, contact your direct supplier or Envertech customer service to obtain an RMA (return merchandise authorization) number and start the replacement process.
