CLiC-iT EASY User Manual

CLiC-iT EASY
USER MANUAL
1. Components
MCD CONTINUOUS BELAY SYSTEM
1.1 Hook
Ref: DAS670
Maximal load: 22 kN
Opening for passage
on plates
Clip point
1.2 Plates
Manufactured from 316L stainless steel, the plates allow the workshops to be linked together without breaking the lifeline.
a) Start and finish plate
To be used at the start of each course
to engage the hook safely from the
ground.
Weight: 1340g
Ref: DAS671
Ref: DAS671_US*
c) Element connection plates
Workshop up to 20 metres
Maximum load: 10 kN
Ref: DAS673S
Weight: 460g
Dimensions:
Ø18 mm
190 mm
Ref: DAS673L*
Weight: 800g
Dimensions:
CLiC-iT / SARL DEHONDT //
Rev. B - 19/03/2025
Made of forged aluminium
Ø23 mm
170 mm
Ref: DAS673S_US*
Weight: 460g
Dimensions:
Ø18 mm
190 mm
Ø18 mm
354 mm
5 rue des Terres (Cellule 7) 51420 CERNAY-LES-REIMS // contact@clic-it.eu // 03.26.47.11.34
0082
Weight: 250g
Dimensions:
Wear indicator
Ribbed for
grip
b) Positioner
Positioners are an option
to guide the safety line
Ø11 mm
cable at points where the
structural strength provi-
ded by an anchor is not
required.
Ref: DAS675
Workshop or zip line up to 150 metres
Maximal load (2 cables): 10kN
Ref: DAS672
Weight: 800g
Dimensions:
Ref: DAS672_US*
Weight: 800g
Dimensions:
d) Bifurcation and evacuation cross
Maximal load > 17 kN
Used to bypass an obstacle
or evacuate. It behaves like a
switch, but does not require
any handling.
EN 17109:2020
7 mm
Ø 14 mm
110 mm
Ø23 mm
Ø11 mm
55 mm
Ø18 mm
394 mm
Ø18 mm
414 mm
Ø 18 mm
Ref: DAS674
Weight: 710g
Dimensions:
