MAXHUB UC S10 Manual

QUICK START GUIDE
UC S10
UC S10 Collaboration-Soundbar:
(plus BM 21 Speakerphone)

Introduction

The UC S10 from MAXHUB is a unique and very flexible Audio & Video Collaboration Bar for a variety of
applications. The unique features are the integrated Android system, which allows to use the UC S10 as
a standalone "Terminal" (Host), the wireless access point which allows for 4 external devices to connect
via wireless screen sharing. The 6 integrated microphones (6-Mic-Array) will allow for a pick-up pattern
of up to 8m easily, and the internal 8W loudspeaker is capable, of filling up a medium sized Huddle- or
Meeting room (approx. 25-30 m2) with clear voice from the far end side. The extremely powerful noise
reduction and the accurate AEC (Acoustic Echo Cancellation) algorithms are the basis of the great sound
experience with the UC S10 in almost every Video Conference application you want to use. A unique
MAXHUB dereverberation algorithm is also on board.
The integrated 4K / 12MP Camera incorporates the Auto-Tracking and Auto-Focus functions which
allow for automatic tracking of people in the room, while the easy way to create up to 3 presets also
allows for specific positions of the camera.
To save a preset, just put the camera into the right position, then press and hold the buttons 1, 2, or 3
on the IR remote control for 5 sec. To recall a preset, just push the buttons 1, 2 or 3 once, and the
camera will move to the programmed position.
The Auto-Tracking function can be turned ON or OFF thru the IR remote, by pushing and holding
the "tracking button" for 3 sec.
