Summary of Contents for MAXHUB V6
- Page 1 Beyond Collaboration MAXHUB V6 Classical Series (C5530, C6530, C7530, C8630) Quick Start Guide...
-
Page 2: Table Of Contents
Table of Contents Safety Warnings ....................Unboxing Checklist ..................Installation Guide ..................... Reference On Wall Mount ................ Installing the Wireless Module ............Installing the OPS/Android Module ..........Removing OPS/Android Module ............Product Appearance Introduction ..........Back Interface ..................... Interface Function .................. -
Page 3: Safety Warnings
6. Please make sure the AC is grounded. Screen 1. Please do NOT use hard or sharp objects on the screen other than the MAXHUB stylus. 2. Please unplug the power before cleaning the product. Use a soft, dustless, and dry cloth to clean the screen. - Page 4 Maintenance Please contact a MAXHUB authorized reseller for maintenance or repair. Warranty Exclusions MAXHUB does not warranty Products that match any one or few of the following descriptions: 1. Product damage caused by disregarding the user manual’s instructions. 2. Hardware damage caused by improper set up.
-
Page 5: Unboxing Checklist
3. The Warranty does not cover products with a damaged Warranty Sticker. 4. The Warranty does not cover products for which there is no certificate of purchase. 5. The Warranty does not cover regular maintenance, nor does it cover repairs or replacement of parts due to normal wear and tear. -
Page 6: Installation Guide
Installation Guide 1. Remove the panel from the box and prepare for installation. ① Place the panel on soft material like mat. ② Bracket package is placed in accessory box. 2. Confirm the panel installation position. The height and pictures are only for reference, please refer to the actual installation size on site. - Page 7 3. Take 8 pcs expansion rubber plug B and 4. Fix the wall bracket onto the 8pcs expansion screw them into the wall. It is recommended to plug B, using a combination of 8pcs screw C use a 10mm impact drill bit. and gasket D.
-
Page 8: Reference On Wall Mount
Reference for Wall Mounting The physical dimensions listed below should be taken into consideration for wall mounting. For ease of operation, maintain a proper distance between the wall and rear of the product panel. Series Classic Dimension 55" 65" 75" 86"... -
Page 9: Installing The Ops/Android Module
Step 1: Remove the Mylar on the bottom of the interactive flat panel. Step 2: Insert the wireless module SI06 into the wireless module slot and screw securely into place. Installing the OPS/Android Module Note: Please make sure the power is off before proceeding with the installation. Step 1: Unscrew and remove the cover. -
Page 10: Removing Ops/Android Module
Press up and unlock the module and take it out. Turn the MAXHUB Interactive Flat Panel on and off 1. Plug the power cable into the power socket of the product. 2. Plug the power cable to the power supply. -
Page 11: Product Appearance Introduction
Product Appearance Introduction Number Description Number Description Press briefly to start the display or to switch from On to Standby Mode. USB Type-C Press and hold for 3 seconds to shut down the product. Speaker USB 3.0 Stylus Magnet Area Microphone Infrared Receiver 48MP Camera... -
Page 12: Back Interface
Back Interface *Integrated in Interactive Flat Panel device Touch Touch signal output HDMI IN Multi-media HDMI input HDMI IN Connect to Audio input Audio Out device Connecting a central RS232 control device with an RS232 interface Connecting USB devices, USB 2.0 such as mobile hard disk, U disk, USB keyboard and mouse, etc. - Page 13 4. RS232 device connection Serial Port Cable 5. USB device connection First Start of MAXHUB Interactive Flat Panel Classic series power Press the power key to start the MAXHUB V6. Device is ready to be used with all the features.
-
Page 14: Maintenance
Warranty MAXHUB warrants its products to be free from defects in material and workmanship during the warran- ty period. If a product proves to be defective in material or workmanship during the warranty period, MAXHUB will, at its sole option, repair or replace the product with a similar product. Replacement Prod-uct or parts may include re-manufactured or refurbished parts or components. - Page 15 Beyond Collaboration https://www.facebook.com/MAXHUB.Global www.maxhub.com/en/ sales@maxhub.com https://www.linkedin.com/company/maxhub-overseas/ https://www.youtube.com/c/MAXHUB...
