- Page 1 Installation Guide Sink Strainer K-8816 K-8817 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page“ Français-1” Español, página“ Español-1” 113776-2-AB...
-
Page 2: Tools And Materials
We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems, please don’t hesitate to contact us. Our phone numbers and website are listed on the back cover. Thanks again for choosing Kohler Company. -
Page 3: Rough-In Diagram
(10.8 cm) (3.3 cm) (4.4 cm) Max. 3/4" 4-1/2" D. (1.9 cm) (11.4 cm) Max. 3-3/8" D. (8.6 cm) 2-1/2" (6.4 cm) 4-11/16" 27" (68.6 cm) (11.9 cm) Cable 4" (10.2 cm) 1-1/2" O.D. 1. Rough-In Diagram Kohler Co. 113776-2-AB... - Page 4 Thread the screw out of the control body housing and remove the drain body. 3. Prepare the Drain Control Look inside the control housing and position the actuator assembly with the outer flat toward the front of the sink. 113776-2-AB Kohler Co.
- Page 5 Right Drain Closed; Left Drain Closed Left Drain Open 4. Control Knob Indicator Positioning Familiarize yourself with the actuator assembly and the various positions. Insert and remove the control knob and compare the inside positions to those shown above. Kohler Co. 113776-2-AB...
- Page 6 Hand tighten the cable connectors to the control housing. Connect the right hand drain cable to the right hand control connection. Connect the left hand drain cable to the left hand control connection. 113776-2-AB Kohler Co.
- Page 7 8. Complete the Strainer Installation Apply thread sealant tape to the control body. Slide the nut onto the tailpiece and insert the small gasket. Thread the tailpiece to the control body and tighten the nut securely with a wrench. Kohler Co. 113776-2-AB...
- Page 8 Remove the strainer cup and stopper from the drain body. Thread the adjustment screw out of the stopper until the stopper almost touches strainer cup. Thread the knurled nut until it touches the stopper. If necessary, repeat the process until the stopper is properly adjusted. 113776-2-AB Kohler Co.
