Features and Benefits
Leadership 64-Bit Architecture
The Alpha 64-bit architecture was introduced with the Alpha
21064 chip in 1992 and now the 21264, builds upon that
proven architecture.
Performance
The Alpha 21264 chip, the world's fastest microprocessor, is
offered with a switch-based interconnect that supports four
processors. This switch-based system provides a memory
bandwidth of up to 5.2 Gbytes/sec (peak) using two 256-bit
memory buses running at 83 MHz.
Scalability
An entry-level system (Model 1) offers one processor, 512
MB memory, and 6 PCI slots. Model 2, can have 32 GB
memory, and 10 I/O slots. The pedestal system provides
space for another 21 disks using BA36R StorageWorks
shelves, or 28 disks using Universal StorageWorks shelves.
beyond the 12 in the chassis. The cabinet can house up to four
systems and/or additional disks. All variants support up to
four processors.
Reliability and Availability
The AlphaServer ES40 uses the latest technologies to achieve
redundancy, error correction, and fault management. The
system has redundant fans and power supplies; fans, power
supplies, and disks can be hot plugged. The remote
management console (RMC) monitors, sends alerts, and
records possible error conditions. The RMC can be accessed
even if the system is completely down.
ES40 Workstation
The system is also offered as a workstation and is called the
AlphaStation ES40.
Third-Generation Alpha Chip
The third generation of the Alpha microprocessor, the Alpha
21264, is a superscalar superpipelined implementation of the
Alpha architecture. The first offering of this chip was known
as EV6. These systems are offered with the EV67 chip (.28
micron) and the EV68 chip (.18 micron). Each chip has over
15.2 million transistors. In our discussion here, the Alpha
21264 designation applies to all variants of the chip.
Designed for performance, the 21264 achieves this goal by
carefully studied and simulated architectural and circuit
analysis. The 21264 memory system also enables the high
performance levels. On-chip and off-chip caches provide for
very low latency data access, which allows for very high
bandwidth data access. (In ES40 systems the size of the off-
chip cache is 8 MB running at 222 MHz (dual data rate cache)
for EV67 and 8 MB running at 277 MHz DDR for EV68.)
2
Internal to each chip is a 64-Kbyte instruction cache (I-cache)
and a 64-Kbyte data cache (D-cache).
I-cache. 64 Kbytes, two-way set-associative, virtually
addressed cache with 64-byte blocks
D-cache. 64 Kbytes, two-way set-associative, virtually
indexed, physically tagged, writeback cache with 64-byte
blocks
Chip Operation
Several key design choices were made in the chip architecture
to maximize performance: Four instructions are fetched each
cycle, and then how those instructions are handled boosts the
speed of execution. Register renaming assigns a unique
storage location with each write reference to a register,
avoiding register dependencies that can be a potential
bottleneck to processor performance.
Another design feature, out-of-order execution, permits
instructions to execute in an order different from the order that
the instructions are fetched. In effect, instructions execute as
quickly as possible. This allows for faster execution, since
critical path computations are started and completed as soon as
possible.
In addition, the Alpha 21264 employs speculative execution to
maximize performance. It speculatively fetches and executes
instructions even though it may not know immediately
whether the instruction will be on the final execution path.
This is particularly useful, for instance, when the 21264
predicts branch directions and speculatively executes down the
predicted path. The sophisticated branch prediction in the
21264 coupled with the speculative and dynamic execution
extracts maximum instruction parallelism from applications.
For more information about the chip, see:
http://www.compaq.com/alphaserver/download/ev6chip.pdf.
Alpha 21264 Features
Out-of-order instruction execution
Large (64 Kbyte) on-chip data and instruction caches
Improved branch prediction through intuitive execution
Register renaming
Increased bandwidth for high-speed access to second-
level cache and system memory
Motion video instructions
Square root and divide instructions
All instructions are 32 bits long and have a regular
instruction format
Floating-point unit, supports DIGITAL and IEEE
floating-point data types
80 integer registers, 64 bits wide
72 floating-point registers, 64 bits wide
