- Page 1 User Manual Model ID: MAVERICKSTORM1FLEX...
-
Page 2: Edition Notes
Edition Notes The Maverick Storm 1 Flex User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the Maverick Storm 1 Flex as of the release date of this edition. Trademarks Chauvet, Chauvet Professional, the Chauvet logo, Maverick, and Maverick Storm are registered trademarks or trademarks of Chauvet &... -
Page 3: Table Of Contents
Control Panel Description ................Battery-Powered Display..................12 Home Screen ....................Control Panel Lock..................Passcode ......................12 Technician Mode................... Menu Map ..................... DMX Configuration..................Control Mode...................... 17 Control Personalities ..................17 Starting Address....................17 Maverick Storm 1 Flex User Manual Rev. 1... - Page 4 Web Server ....................Error Codes....................5. Maintenance................Product Maintenance ..................Torque Measurements .................. Vacuum Test Measurements ................ Gobo Maintenance..................Transporting on Truss or Racks..............6. Technical Specifications ............Contact Us ..................Warranty & Returns..................Maverick Storm 1 Flex User Manual Rev. 1...
-
Page 5: Before You Begin
The product has XLR sockets for DMX input and output. • Notice: This control circuit is isolated and belongs to the Class 2 data port. The control circuit has a cumulative leakage current of less than 3.5 mA. Maverick Storm 1 Flex User Manual Rev. 1... -
Page 6: Safety Notes
• In the event of a serious operating problem, stop using immediately. If a Chauvet product requires service, contact Chauvet Technical Support. Maverick Storm 1 Flex User Manual Rev. 1... -
Page 7: Fcc Statement Of Compliance
LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. Maverick Storm 1 Flex User Manual Rev. 1... -
Page 8: Introduction
Product Overview # Name 1 LCD display 2 Menu buttons 3 Antenna 4 Carry handles 5 Ethernet ports 6 DMX in/out 7 USB-C port 8 Power in 9 Fuse holder 10 Condensation valve Maverick Storm 1 Flex User Manual Rev. 1... -
Page 9: Product Dimensions
20.4 in 29 in 518 mm 738 mm 16.48 in 418.5 mm 21.23 in 539 mm 9.92 in 252 mm 15.27 in 10.41 in 388 mm 264.3 mm 24.1 in 612 mm Maverick Storm 1 Flex User Manual Rev. 1... -
Page 10: Setup
3. Setup AC Power The Maverick Storm 1 Flex has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 11: Signal Connections
Setup Signal Connections The Maverick Storm 1 Flex can receive a DMX, Art-Net™, or sACN, signal. The Maverick Storm 1 Flex has two Amphenol XLRnet through ports, and 5-pin DMX in and out ports. If using other compatible products with this product, it is possible to control each individually with a single controller. -
Page 12: Usb Software Update
Setup USB Software Update The Maverick Storm 1 Flex allows for software updates with a USB device using the built-in USB port. To update the software using a USB flash drive, do the following: 1. Power on the product, and plug the flash drive into the USB port. -
Page 13: Mounting
When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity. Procedure The Maverick Storm 1 Flex comes with 2 Omega brackets to which the user can directly attach mounting clamps (sold separately). Make sure the clamps are capable of supporting the weight of this product. Use at least two mounting points per product. -
Page 14: Gobo Wheels
Setup Gobo Wheels Gobo 1 Gobo 2 (Rotating) (Static) Gobo Dimensions 23.9 mm 20 mm Gobo 1 (Rotating) Maverick Storm 1 Flex User Manual Rev. 1... -
Page 15: Gobo Replacement
This provides a layer of protection against the high temperature from the lamp. • All custom gobos in the Maverick Storm 1 Flex gobo wheel must be aluminum or glass. Procedure Follow the recommended procedure below to remove or replace the gobos: 1. -
Page 16: Operation
The technician mode disables the pan/tilt motors, allowing the output of the product to be aimed by hand. To enable the technician mode of the Maverick Storm 1 Flex, hold <UP> and <LEFT> while the product is powering on. When the product is turned off and back on, the pan and tilt will return to normal function. -
Page 17: Menu Map
Operation Menu Map Refer to the Maverick Storm 1 Flex product page on www.chauvetprofessional.com for the latest menu map and software. Main Level Programming Levels Description Address 001–512 Sets the starting address Manual Manually set IP address IP Mode DHCP... - Page 18 USB Update Update firmware via USB C Update Other Pan/Tilt Shutter/Prism Color/CMY Reset Reset individual functions or all functions Function from start-up Gobo/Gobo Rotate Frost/Animation Factory Reset to factory default settings Settings Maverick Storm 1 Flex User Manual Rev. 1...
- Page 19 _ _ _ _ _ _ _ _ Shows current Subnet Mask _ _ _ _ _ _ _ _ Shows MAC address _ _ _ _ _ _ _ _ Shows product UID Maverick Storm 1 Flex User Manual Rev. 1...
- Page 20 Shows all current values from input signals Information Gobo Index Gobo2 Animation Animation Rotate Focus Focus Fine Focus Auto Zoom Zoom Fine Prism1 Prism1 Rotate Prism2 Prism2 Rotate Frost CMY Macro CMY Macro Speed Control Maverick Storm 1 Flex User Manual Rev. 1...
-
Page 21: Dmx Configuration
Use control configurations to operate the product with a DMX, Art-Net™, or sACN controller. Control Mode The Maverick Storm 1 Flex works with wired DMX, Lumenradio CRMX™, Art-Net™, and sACN control signals. To select which protocol to use: 1. Go to the Settings main level. -
Page 22: Control Channel Assignments And Values
049 055 CTB 056 060 White 061 187 Split color 188 219 Color scroll, fast to slow 220 223 Stop 224 255 Reverse color scroll, clockwise, slow to fast Maverick Storm 1 Flex User Manual Rev. 1... - Page 23 109 113 Gobo 1 shaking, slow to fast 114 127 Open 128 191 Gobo scroll, slow to fast 192 255 Reverse gobo scroll, slow to fast Animation 000 255 Animation effect Maverick Storm 1 Flex User Manual Rev. 1...
- Page 24 Frost 000 255 Frost effect 000 009 No function – CMY macro 010 255 CMY macro – CMY macro speed 000 255 CMY macro speed, fast to slow Maverick Storm 1 Flex User Manual Rev. 1...
- Page 25 226 230 No function 231 235 Pan/tilt swap on 236 240 Pan/tilt swap off 241 245 Minimum Zoom Focus off 246 250 Minimum Zoom Focus on 251 255 No function Maverick Storm 1 Flex User Manual Rev. 1...
-
Page 26: Configuration Settings
1. Go to the Settings main level. 2. Select the Backlight Timer option. 3. Select the length of the backlight timer, from 30S (30 seconds), 1M (1 minute), 5M (5 minutes), or ON (always on). Maverick Storm 1 Flex User Manual Rev. 1... -
Page 27: Loss Of Data
Changes to settings automatically save to the currently selected Preset. • If no Preset has been selected, changes to settings save to PRESET A. • After selecting a Preset, the product will restart. Maverick Storm 1 Flex User Manual Rev. 1... -
Page 28: Preset Synchronization
1. Connect the Maverick Storm 1 Flex products to receive the Presets by a DMX daisy chain. 2. Make the Maverick Storm 1 Flex with the Presets to transfer the first in the DMX daisy chain. 3. Power on all of the products. -
Page 29: Zero Adjust Mode
4. Adjust the “zero” position for the selected function from 000–255. Web Server The Maverick Storm 1 Flex Web Server can be accessed by any computer on the same network as the product. It allows network access to system information, settings such as control setup, manual testing of all functions, firmware updates, and the ability to change the Web Server password. -
Page 30: Error Codes
Check the magnetic rod down Check module connection Ensure nothing is blocking movement Check sensors for +/- 5V when opened Light Block Sunshield error and closed Do a factory reset Update software Maverick Storm 1 Flex User Manual Rev. 1... - Page 31 Replace Z fan 1 ZFAN1 Fan wires have poor connection Check fan wire connection ZFan 2 is damaged Replace Z fan 2 ZFAN2 Fan wires have poor connection Check fan wire connection Maverick Storm 1 Flex User Manual Rev. 1...
- Page 32 Replace Z fan 5 ZFAN5 Fan wires have poor connection Check fan wire connection ZFan 6 is damaged Replace Z fan 6 ZFAN6 Fan wires have poor connection Check fan wire connection Maverick Storm 1 Flex User Manual Rev. 1...
-
Page 33: Maintenance
Arm and head cover screws 25.4 22.0 Front lens cover 10.1 Vacuum Test Measurements Use the IP Tester from Chauvet Professional to ensure the product has been reassembled correctly by following the information below: Parameters Values Method Positive Test pressure 2.18 kPa... -
Page 34: Gobo Maintenance
This is to prevent undue stress on the tilt locks and limit the amount of off-axis bounce on internal components. Maverick Storm 1 Flex User Manual Rev. 1... -
Page 35: Technical Specifications
5-pin IP-rated XLR Seetronic IP-rated RJ45 26 or 33 Ordering Product Name Item Name Item Code UPC Number Maverick Storm 1 Flex MAVERICKSTORM1FLEX 08102629 781462229771 UL 1573 CSA C22.2 No. 166 E113093 Maverick Storm 1 Flex User Manual Rev. 1... -
Page 36: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Maverick Storm 1 Flex User Manual Rev. 1...
