Tony Ray's AeroModel Minimoa 2025 Building Instructions

1/6

Hide thumbs

page of 45

/ 45
Bookmarks

Quick Links

Download this manual

Minimoa 2025

1/6

Building Instructions

Specifications

Wingspan

2844 mm / 112 INCH

Wing Area

54,8 sq dm / 5.89 sq ft

Flying weight

1900 g / 67.02 oz.

Fuselage length

1158 mm / 45.59 INCH

Scale

1:6

Requires

RC Transmitter with at least 7 Channels

6 x Servos (approx. 15 g)

Motor with approx. 1500 g thrust

Need help?

Do you have a question about the Minimoa 2025 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tony Ray's AeroModel Minimoa 2025

Page 1 Minimoa 2025 Building Instructions Specifications Wingspan 2844 mm / 112 INCH Wing Area 54,8 sq dm / 5.89 sq ft Flying weight 1900 g / 67.02 oz. Fuselage length 1158 mm / 45.59 INCH Scale Requires RC Transmitter with at least 7 Channels 6 x Servos (approx.
Page 2 INDEX BEFORE YOU BEGIN-------------------------------------------------------------------------------------------P.3 KIT INVENTORY-------------------------------------------------------------------------------------------P.4~P.5 ASSEMBLY-Fuselage I-----------------------------------------------------------------------------------P6~P.11 ASSEMBLY-Canopy------------------------------------------------------------------------------------P.12~P.13 ASSEMBLY-Fuselage II--------------------------------------------------------------------------------P.14~P.24 ASSEMBLY-Vertical & Horizontal Tail-------------------------------------------------------------P.25~P.29 ASSEMBLY-Centre Wing Section-------------------------------------------------------------------P.30~P.32 ASSEMBLY-Outer Wing Section--------------------------------------------------------------------P.33~P.36 ASSEMBLY-Wing Covering---------------------------------------------------------------------------P.37~P.39 ASSEMBLY-Seats and Details-----------------------------------------------------------------------P.40~P.41 ASSEMBLY-Electronics--------------------------------------------------------------------------------P.41~P.43 BEFORE YOU FLY---------------------------------------------------------------------------------------P.44~P.45 © Sebastian Hansen...
Page 3: Before You Begin
BEFORE YOU BEGIN Tips and Tricks 1. Read through the manual before you begin, thus you will have an overall idea of what to do. 2. Check all parts in the scope of delivery list. If you find any serious defects or missing parts, please contact Tony and Sebastian directly.
Page 4 KIT INVENTORY Wood Sheets Scope of Delivery Item: Marking Quantity 1.5 mm Balsa A series: A1-A25 1.5 mm Paulownia A series: A26-A27 1.5 mm Plywood A series: A28 2.0 mm balsa B series: B1-B9 2.0 mm Paulownia B series: B10-B11 2.0 mm Plywood B series: B12-B19 3.0 mm Plywood...
Page 5 Hardware Parts Scope of Delivery 1.Hardware in Strips Bag PVC-Tube (Outer Diameter: 12 mm, Inner Diameter: 10 mm) PVC-Tube (Outer Diameter: 3 mm, Inner Diameter: 2 mm) Steel Push Rod (Diameter1.2 mm) 2.Hardware in Plastic Bag Laser cut PVC sheet Paper Hinges Leather Strips 3.Hardware in Plastic Box...
Page 9 Step 23 Step 24 Step 25 Step 26 Step 27 Step 28 Step 29 Step 30: 2 x 8 mm Paulownia strips, located on B12. © Sebastian Hansen...
Page 11 Step 39: 3 x 3 mm Balsa Strips. Step 40 Step 41 Step 42 Step 43 Step 44: Before covering the fuselage, you need reinforce the central wing box. My Notes: © Sebastian Hansen...
Page 13 Step 7: 2 x 2 mm balsa strips. Step 8 Step 9 Step 10: Fill the gap. Step 11: Sand this edge. Step 12: Sand this edge. Step 13 Step 14: Remove this part. © Sebastian Hansen...
Page 14 Part 3: Fuselage II Step 1 Step 2: Install PVC tube before cover the fuselage (Outer diameter: 3 mm inner diameter: 2 mm). Step 3 Step 4: Cut off the excess according to the centerline. Central line. Step 5 Step 6 ©...
Page 16 Step 15 Step 16: It is not easy to distinguish the direction. If there is a dot on a corner of a part, it means that the corner is: top & front. Step 17 Step 18 Step 19 Step 20 Step 21 Step 22 ©...
Page 19 Step 39: Sand this edge. Step 40 Step 41 Step 42 Step 43 Step 44 Step 45 Step 46: Sand the bottom edge to a bevel. © Sebastian Hansen...
Page 22 Step 63 Step 64 Step 65: Step 66 Sand the front part of bottom edge to a bevel. Step 67 Step 68 Step 69 Step 70 © Sebastian Hansen...
Page 23 Step 71 Step 72: 6 x 6 mm Balsa strips. 1,5 mm balsa, width: 17 mm located in A7. Step 73 Step 74: Top view. Step 75 Step 76: Sand the edge to a bevel, bevel width: 5 mm. Step 77 Step 78 ©...
Page 25 Part 4: Vertical & Horizontal Tail Step 1 Step 2 Step 3 Step 4 Step 5 Step 6: A gap of 2 mm. © Sebastian Hansen...
Page 28 Step 23 Step 24 Step 25: Polish the edges. Step 26 Step 27 Step 28 Step 29 Step 30: Polish the edges. © Sebastian Hansen...
Page 30 Part 5: Center Wing Section Step 1: 2 x 8 mm Pine Strips. Step 2: Install R1 - R14. 6 x 6 balsa strips. Step 3: Install R1.5 - R13.5. Step 4 Step 5: Mark of ribs, Sand this edge to a bevel, Step 6 bevel width: 5 mm.
Page 31 Step 7 Step 8 Step 9: Step 10: 3 x 3 mm Pine Strips. Pay attention to the orientation of W3, it is asymmetrical and marked “outer side” towards the outer wing. Step 11 Step 12 Step 13 Step 14 ©...
Page 33 Part 6: Outer Wing Section Step 1 Step 2: There is a 2 mm gap between W11 and the mounting surface. When installing, put 2 mm thick wood chips under W11 temporarily. Step 3: 6 x 6 mm balsa strips. Step 4 Step 5 Step 6: 2 x 8 mm pine strips.
Page 34 Step 7 Step 8 Step 9: 3 mm pine in C5. Step 10 Step 11: Fill this space and using epoxy glue. Step 12 Step 13: Step 14 Sand the edge to a bevel, bevel width: 5 mm. © Sebastian Hansen...
Page 35 Step 15 Step 16: Install the top 2 x 8 mm pine strips. Step 17 Step 18 Step 19 Step 20 Step 21 Step 22 © Sebastian Hansen...
Page 36 Step 23: Install R16.5 - R32.5. Step 24 Step 25 Step 26: Install A1 - A26. Step 27 Step 28: Sand the edge. Step 29 Step 30 © Sebastian Hansen...
Page 38 Step 7 Step 8 Step 9 Step 10 Step 11 Step 12 Step 13 Step 14: Please pay attention to distinguish these parts, they look similar but cannot be used universally. © Sebastian Hansen...
Page 39 Step 15: Step 16 Please assemble the brake pads strictly according to the combination and position shown in the picture. Step 17: Step 18 “BR 4,5,6” is placed on top. “BR 1,2,3” is placed at the bottom. Steel Push rod Length: 170 mm. My Notes: ©...
Page 42 Part 9: Electronics (Reference example is motored version) Step 1: M2 Steel push rod, Bend it 20 - 25 Step 2 degrees at the end. Step 3: Reinforce here with epoxy resin, Step 4: Drill an additional 1,5 mm hole near the fiberglass cloth, and wrap Kevlar or carbon top.
Page 43 Step 7 Step 8: Examples of Motors.. Step 9: Step 10: Aileron Servo (example). Airbrake Servos (example). Steel wire adapter. Step 11 Step 12: Drill holes and install a screw to connect the fuselage and wings. My Notes: © Sebastian Hansen...
Page 44: Before You Fly
BEFORE YOU FLY 1. CG: 2. Horizontal stabilizer mounting angle: Horizontal stabilizer mounting adjustment: Add 0.5 – 1 mm spacers to the rear screw position. © Sebastian Hansen...
