Only one equalisation cycle is allowed per charge cycle.
If enabled, the charger will automatically perform the equalise function after the standard
charge has been completed.
5.5 Battery Recover Mode
If a battery is connected to the charger that is below the normal operating voltage an incor-
rect battery fault (F1) will be displayed. However, if the battery voltage is between 1 and
1.5VPC, battery recover mode is available. This mode employs a special charging technique
to recover batteries that have been stood for a long time or have been over discharged.
This mode can be enabled by pressing the pause button for 5 seconds whilst the fault is
displayed. Battery recover mode will then start; once the battery voltage has been recovered
to a normal level a standard charge will be performed.
6 Faults / Warnings
In the event of a problem occurring, the charger will display an appropriate fault / warning
code via the charge status indicator. This code will consist of a number of red flashes, as
shown in the tables below, followed by a green flash.
Faults permanently stop charge until they are rectified.
No. of RED flashes
1
2
3
4
5
6
7
8
• Fault Number 1 is critical and will prevent charging.
• Fault 2 is likely to indicate an internal charger fault.
• Faults 3 to 5 occur when a particular stage of charge takes too long. This indicates that
the battery might be at fault or have been over discharged.
5
Fault
Incorrect battery voltage
Incorrect current control
Bulk timeout
Gassing timeout
Auto-balance timeout
Charger over temperature
Configuration error
Safety disconnect system error
Faults / Warnings
