Summary of Contents for Exide MOTION+ PREMIUM SP3
- Page 1 Operating Instructions Operating Instructions MOTION PREMIUM Charger Date Name No. V1 EN Issued: 21.02.2025 Revision: 25.03.2025 Checked:...
-
Page 2: Installation
Introduction In response to growing global environmental concerns and our commitment to sustainability, we are taking targeted measures to integrate environmentally friendly practices into all areas of our business. We are constantly striving to reduce our paper con- sumption, which is why we have provided this printed manual in English only. -
Page 3: Display And Control
Display and Control The charger is for inside use only. Before installation, check that: • The charger has not sustained any transit damage. • The rating is suitable for the intended input supply and battery (lead-acid (vented, gel, AGM) or lithium-ion) to be charged. •... -
Page 4: Operation
Operation Pause Light blue flashing Standby Constant light blue Operation Before connecting the battery, check that the battery voltage corresponds to the volt- age indicated on the charger rating plate. Charging When a battery is connected to the charger & mains applied, charge will start automatically. The charge status indicator will show yellow during bulk charge or yellow and green alter- nating during the second stage of charge. - Page 5 Faults / Warnings Only one equalisation cycle is allowed per charge cycle. If enabled, the charger will automatically perform the equalise function after the standard charge has been completed. Battery Recover Mode If a battery is connected to the charger that is below the normal operating voltage an incor- rect battery fault (F1) will be displayed.
-
Page 6: Maintenance
Repair • Fault 6 may occur if the charger is in an ambient temperature above 35°C or airflow is restricted. Charge stops under these conditions until the charger has cooled sufficiently. • Fault 7 will occur if there is a problem with the internal configuration file •... - Page 7 Guarantee Exide Technologies recommends that a yearly periodic inspection / test is performed on this equipment, contact your local agent for details. Guarantee See local conditions of sale. Specification Models SP3 / SP3+ 1PH - 230VAC 10% ONLY Input Voltage Input Frequency 45 –...
- Page 8 +31104455666 mpsalesbnl@exidegroup.com NETHERLANDS +31104455666 mpsalesbnl@exidegroup.com POLAND +48618786149 service-poland@exidegroup.com PORTUGAL +351263200800 sales-portugal@exidegroup.com SPAIN +34936803080 sales-spain@exidegroup.com SWEDEN +46108886060 info.gnb@exidegroup.com SWITZERLAND +496042810 service.de@exidegroup.com UNITED KINGDOM +448456064111 service.uk@exidegroup.com Exide Holding Europe SAS FRANCE 5, allée des Pierres Mayettes F-92636 Gennevilliers, France www.exidegroup.com March 2025...
