SENKO SP-MGTP User Manual
Portable multi gas detector with pump
Hide thumbs
Also See for SP-MGTP:
- User manual (26 pages) ,
- User manual (25 pages) ,
- User manual (25 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SENKO SP-MGTP
Summary of Contents for SENKO SP-MGTP
- Page 1 PORTABLE MULTI GAS DETECTIOR WITH PUMP USER MANUAL www.senko-detection.com...
-
Page 3: Table Of Contents
CONTENTS SAFETY WARNING PRODUCT OVERVIEW Product Introduction Specification LCD Display Symbols ACTIVATION Switch On Switch Off PUMP Pump Test Filter Replacement Regulator DISPLAY Measuring Mode Display Mode Battery Display Alarm Display SETTING AND OPERATION Alam Menu Calibration Menu Zero Calibration Span Calibration Test(Inspection) Menu Set Menu... -
Page 4: Safety Warning
㧚 Do not use any other charging adapter. 㧚 Do not calibrate the device while or immediately after charging the battery. 㧚 Do not calibrate if exposed to the condition representative of the IP rating. 4 I www.senko-detection.com... - Page 5 Um = 6.3 Vdc. The ambient temperature during charging shall be in the range 0 °C to 40 °C. 㧚 The battery and sensors should only be replaced by SENKO authorized service providers in a safe zone, free of hazardous gases.
-
Page 6: Product Overview
PRODUCT OVERVIEW PRODUCT INTRODUCTION SPECIFICATION Model Name SP-MGTP (Pump) Electrochemical for toxic gases and O2 / PID for VOCs gas / Sensor Type Catalytic and NDIR for combustible gases Measuring Type Sampling Type (Built-in Pump) Display Segment LCD Display, LCD Backlight, Indicator LED... -
Page 7: Lcd Display Symbols
High Alarm High(2nd) Alarm Alarm Warning Alarm Condition STEL STEL Alarm TWA Alarm Zero Calibration Fresh Air Calibration Calibration or Device Stabilization, Configuration View, Test Success Calibration Succeeded Span Calibration Standard Gas Calibration Battery Remaining Battery SP-MGTP USER MANUAL I 7... -
Page 8: Activation
ACTIVATION SWITCH ON SWITCH OFF 8 I www.senko-detection.com... -
Page 9: Pump
O2 + Toxic + LEL(IR) + CO2(IR) + PID ≥40h N2 Type : PID, LEL(IR-CH4/CO2) O2 + Toxic + LEL(IR) + CO2(IR) ≥52h O2 + Toxic + PID ≥57h 00 Type : PID O2 + Toxic ≥72h SP-MGTP USER MANUAL I 9... -
Page 10: Display
A low gas alarm has been triggered. *In an ambient air, the Oxygen level normally indicates 20.9%vol. Measure Value (Max) A high gas alarm has been triggered. *In an ambient air, the Oxygen level normally indicates 20.9%vol. 10 I www.senko-detection.com... - Page 11 8 hours average exposure has been exceeded. Alarm Value (1st/Low Alarm) Display the preset low alarm levels. Alarm Value (2nd/High Alarm) Display the preset high alarm levels. Alarm Value (STEL) Display the preset STEL levels. SP-MGTP USER MANUAL I 11...
- Page 12 LCD Display Details Alarm Value (TWA) Display the preset TWA levels. Version / Battery / Temperature Firmware Version, Current battery voltage, Current temperature(Celsius) Date / Time Calibration Concentration Value Last Calibration Date 01.01 = January 1st (mm dd) 12 I www.senko-detection.com...
-
Page 13: Battery Display
Remaining time to next calibration date when the calibration interval is configured. (Default: N/A) Bump Remain Day Remaining time to next bump test date when the bump interval is configured. (Default : N/A) BATTERY DISPLAY SP-MGTP USER MANUAL I 13... -
Page 14: Alarm Display
Stops after Calibration is due to be performed icon & Gas Title completed successfully Calibration Blinking Exceeding the Over LImit overrange Limit for a sensor Sensor is reading a Stops after Zero Under Limit below Zero value Calibration 14 I www.senko-detection.com... - Page 15 Notices the user on a regular basis to check the device. Calibration Interval Notices the user on a regular basis to calibrate the sensor. Self-Test Interval Notices the user on a regular basis to Self-Test SP-MGTP USER MANUAL I 15...
-
Page 16: Setting And Operation
Sets the alarm to Latch (where the device stays in alarm when a gas ModE SET alarm is triggered until the button is pressed to accept it) or Auto where the alarm stops when the reading returns to normal levels. 16 I www.senko-detection.com... -
Page 17: Calibration Menu
CALIBRATION MENU Zero Calibration Span Calibration Function Function ZERO CALIBRATION (FRESH AIR CALIBRATION) Sensor On / Off Countdown Success / Fail SP-MGTP USER MANUAL I 17... -
Page 18: Span Calibration
SETTING AND OPERATION SPAN CALIBRATION (STANDARD GAS CALIBRATION) 18 I www.senko-detection.com... -
Page 19: Test(Inspection) Menu
TEST(INSPECTION) MENU Self Test Bump Test (Including Pump Test) Sensor On / Off Countdown Pass / Fail SP-MGTP USER MANUAL I 19... -
Page 20: Set Menu
Motor ON / OFF Setting PUMP SET Pump Low/Mid/High Setting Response LEL factor 0.00~99.99 Setting RSPF LEL SET (Only when LEL Sensor operating) Response VOCs factor 0.00~99.99 Setting RSPF VOCs SET (Only when VOCs sensor operating) INIT SET Setting initialize 20 I www.senko-detection.com... -
Page 21: Log
Serial Number. Test date, Pass/non-pass, Calibration Gas Concentration, BUMP TEST Log Detected Concentration. Date of the Calibration, Type, Calibration Gas Concentration, Calibration Log Detected Concentration. Time, Date of executing IR-LINK, Concentration, Alarm Types, Data Log Options. SP-MGTP USER MANUAL I 21... -
Page 22: Certification
CERTIFICATION Certifications Standards IECEx IECEx CSA SP-MGTP-P0 Series IEC60079-0: 2017 Ed. 7 Ex da ia IIC T4 Ga 23.0016X IEC60079-1: 2014-06 Ed. 7 or Ex da ia IIB T4 Ga IEC60079-11: 2011 Ed. 6 SP-MGTP-00/N0 Series Ex ia IIC T4 Ga... - Page 23 2987X Ex da ia IIB T4 Ga SP-MGTP-00/N0 Series Ex ia IIC T4 Ga Ex ia IIB T4 Ga SP-MGTP-N1/N2 Series Ex db ia IIC T4 Gb Ex db ia IIB T4 Gb Direct 2014/30/EU SP-MGTP USER MANUAL I 23...
-
Page 24: Failure / Escape
PID Oscillator overloaded Replace the PID Sensor PID Sensor Operation Error, Power OFF->ON, Err - 9 PID Oscillator not working Replace the PID Sensor PID Sensor Operation Error, Power OFF->ON, Err - 10 PID Lamp not illuminated Lamp Cleaning 24 I www.senko-detection.com... -
Page 25: Trouble-Shooting
Battery will Charger error or there is a Change battery or not charge Device error Check charger connection Continuous charging, Turn off the power before charging device will not Charging battery the device charge to 100% SP-MGTP USER MANUAL I 25... -
Page 26: Maintenance And Replacement
MAINTENANCE AND REPLACEMENT CHARGING GAS CYLINDER BATTERY PUMP 26 I www.senko-detection.com... -
Page 27: Filter
FILTER STANDARD ACCESSORIES Quick Discounnector Dust Filter & Charger & 1m tube PTFE Filter SP-MGTP USER MANUAL I 27... -
Page 28: Limited Warranty
LIMITED WARRANTY SENKO Co., Ltd. www.senko-detection.com T. +82-31-492-0445 | F. +82-31-492-0446 | E. sales@senko.co.kr 445, Doksanseong-ro, Osan-si, Gyeonggi-do, 18111, Republic of Korea...
