- Page 1 All manuals and user guides at all-guides.com DIGI-ARC205STL IGBT INVERTER • DC MMA / LIFT TIG • WELDING MACHINE Part No. 9023 Suitable for 220~240V OPERATING INSTRUCTIONS...
-
Page 2: Safety Precautions
All manuals and user guides at all-guides.com STEALTH DIGI-ARC205STL SAFETY PRECAUTIONS Follow these precautions carefully. Improper use of any welder can result in injury or death. 1. ONLY CONNECT MACHINE TO A POWER SOURCE FOR WHICH IT WAS DESIGNED. THE SPECIFICATION PLATE ON THE MACHINE LISTS THIS INFORMATION. WHEN WELDING OUTDOORS ONLY USE AN EXTENSION CORD INTENDED FOR SUCH USE. -
Page 3: Technical Specifications
STEALTH DIGI-ARC205STL MAIN USE AND RANGE STEALTH DIGI-ARC205STL inverter arc machine is a welding machine incorporating IGBT and features performance and high efficiency. The welding current is infinitely and independently adjustable. All ferrous metal, copper and stainless steel material can be omni-bearing welded in all positions. -
Page 4: Front Panel
All manuals and user guides at all-guides.com STEALTH DIGI-ARC205STL connect the protection grounding of the welder. PRODUCT DESCRIPTION d. Welding operation should be carried out in dry and good ventilating area. T • Before welding, the operator should read the operating instructions. -
Page 5: Machine Operation
All manuals and user guides at all-guides.com .METHOD OF THE OPERATION STEALTH DIGI-ARC205STL -1. hand welding with electrode(MMA) MACHINE OPERATION ① .Put switch"2" (MMA/TIG switch) onto the position "MMA". 6.1 HAND WELDING WITH ELECTRODE (MMA) Selecting empiric formula: I=40*d ,d is dia. of the electrode. -
Page 6: Troubleshooting
All manuals and user guides at all-guides.com STEALTH DIGI-ARC205STL TROUBLESHOOTING Problems Causes Solutions Power lamp not lit 1. No electricity input 1. Check incoming line 2. Machine switch fails 2. Replace switch Fan not rotating 1. Fan power line is off 1. - Page 7 All manuals and user guides at all-guides.com STEALTH DIGI-ARC205STL Do not touch electrically live parts or Keep flammable materials away. Wear eye, ear and body protection. WARNING electrode with skin or wet clothing. Insulate yourself from work and ground. Spanish...
- Page 8 LEIA E COMPREENDA AS INSTRUÇÕES DO FABRICANTE PARA ESTE EQUIPAMENTO E AS PARTES DE USO, E SIGA AS PRÁTICAS DE SEGURANÇA DO EMPREGADOR. Specialised Welding Products Ltd Unit 1, Farringdon Industrial Centre, Farringdon, Nr Alton, Hampshire GU34 3DD, UK tel: +44 (0)1420 588180 • fax: +44 (0)1420 588184 • email: sales@swp.uk.net...
