  • Page 1 OPERATOR’S MANUAL TIG 200 P INVERTER Part No. 9110H IMPORTANT Read this Operator’s Manual completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your distributor if you do not fully understand this manual.

  • Page 2: Table Of Contents

    CONTENT CONTENT §1 SAFETY..............................1 §2 SUMMARY ............................9 §2.1 Features ..............................9 §2.2 Brief Introduction ..........................10 §2.3 Parameters .............................. 11 §2.4 Duty cycle & Over heat ......................... 12 §2.5 Working Principle ..........................12 §2.6 Volt-Ampere Characteristic ........................ 13 §3 Installation &...

  • Page 3: Safety

    SAFETY §1 SAFETY Notice: The instructions are for reference only. The manufacturer reserves the right to explain the differences between the description and the product due to product changes and upgrades! The device is manufactured using state-of-the-art technology and according to recognised safety standards. If used incorrectly or misused, however, it can cause: ...
  • Page 4 SAFETY Excessive ambient temperature will cause the machine heat dissipation is not smooth, so that the internal components of the machine heat seriously. Usually the maximum operating temperature is 104°F (40°C). Low temperature may lead to performance degradation or damage of components inside the product, resulting in ice inside the water tank.
  • Page 5 SAFETY Many harmful phenomena, such as noise, bright light and harmful gas, will inevitably occur in the welding process. In order to avoid harmful By product phenomena causing harm to the human body, it is necessary to make corresponding preparations in advance. Arc rays from the welding process produce intense visible and invisible ultraviolet and infrared rays that can burn eyes and skin.
  • Page 6 SAFETY Welding may produce fumes and gases hazardous to health. Avoid breathing these fumes and gases.  Do not breathe the smoke and gas generated whilst welding or cutting, keep your head out of the fumes. Use enough ventilation and/or exhaust at the arc to keep fumes and gases away from the breathing zone.
  • Page 7 SAFETY Flying sparks from the welding arc, hot work piece, and hot equipment can cause fires and burns. Accidental contact of electrode to metal objects can cause sparks, explosion, overheating or fire.  Welding sparks and hot materials from welding can easily go through small cracks and openings to adjacent areas.
  • Page 8 SAFETY cylinder outlet valve and gas regulator. Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. All hoses, fittings, etc. should be suitable for the application and maintained in good condition.
  • Page 9 SAFETY maintenance. Don’t sling cables or leads around either the body or parts of the body. The electrode (rod electrode, tungsten electrode, welding wire, etc) must  Never be immersed.  Never be touched when current is flowing. When the machine is connected to the power supply, there is electricity inside the machine.
  • Page 10 SAFETY  Shield off entire welding installation. Radiation Class A Device.  Only can be used in the industrial area.  If it is used in other area, it may cause connection and radiation problems of circuit. Radiation Class B device. ...

  • Page 11: Summary

    SUMMARY §2 SUMMARY §2.1 Features  New appearance and new panel design: More trendy and humanized.  LCD screen for accurate setting & feedback of welding output.  PFC Technology: Power factor more than 0.99.  Input voltage, works with single-phase: 110V/230V. ...

  • Page 12: Brief Introduction

    SUMMARY §2.2 Brief Introduction TIG DC-series welding machine adopts the latest pulse width modulation (PWM) technology and insulated gate bipolar transistor (IGBT) power module, which can change work frequency to medium frequency so as to replace the traditional hulking work frequency transformer with the cabinet medium frequency transformer. Thus, it is characterized with portable, small size, light weight, low consumption and etc.

  • Page 13: Parameters

    SUMMARY depth of penetration is even. Be suitable for welding by one side and forming by two sides and all position welding for pipe. 4) High frequency arc can make metal for microlite fabric, eliminate blowhole and improve the mechanical performance of the joint.

  • Page 14: Duty Cycle & Over Heat

    SUMMARY §2.4 Duty cycle & Over heat The letter “X” stands for duty cycle, Relation of welding current and which is defined as the proportion of duty cycle for BT TIG 200 P the time that a machine can work continuously within a certain time (10 minutes).

  • Page 15: Volt-Ampere Characteristic

    SUMMARY §2.6 Volt-Ampere Characteristic TIG DC-series welding machine has an excellent volt-ampere characteristic, whose graph is shown as the following figure. The relation between the conventional rated loading voltage U and the conventional welding current I is as follows: When I ≤600A, U =10+0.04I (V);...

  • Page 16: Installation & Operation

    INSTALLATION & OPERATION §3 Installation & Operation §3.1 Layout for Front and Rear panel “-” Output terminal. TIG torch remote connection socket. TIG torch gas connector. “+” Output terminal. Shield gas input joint: To connect one head of the gas hose while the other head is connected to argon gas cylinder.

  • Page 17: Layout For Control Panel

    INSTALLATION & OPERATION §3.2 Layout for Control panel §3.2.1 Control panel 1. Welding mode button: Press it to select MMA/ HF TIG/ Lift TIG welding mode. 2. Trigger mode selecting button: Press it to select 2T or 4T trigger mode. * 3.
  • Page 18 INSTALLATION & OPERATION Further Controls Explained Trigger mode selecting button (2) 2T Mode The trigger is pulled and held on to activate the welding circuit, when the trigger is released, the welding circuit stops. This function without the adjustment of start current and crater current is suitable for the Re-tack welding、transient welding、thin plate welding and so on.
  • Page 19 INSTALLATION & OPERATION (7) t4～t5: Post-gas time, after the arc is turned off. You can adjust it (0.0~10s) through turnning the knob on the front panel. (8) t5: Electromagnetic gas valve turned off, the shield gas stops to flow, and welding is finished.
  • Page 20 INSTALLATION & OPERATION (7) t4: Press the torch switch again, the welding current will drop in accordance with the selected down-slope time. (8) t4～t5: The output current slopes down to the crater current. The downslope time can be adjusted; (9) t5～t6: The crater current time; (10) t6: Loosen the gun switch, stop arc and keep on argon flowing;...

  • Page 21: Mma Display Introduction

    INSTALLATION & OPERATION §3.2.2 MMA display introduction 1. Welding mode button: Press it to enter MMA welding mode. 2. Hot Start button: Press it to select Hot start. 3. Arc Force button: Press it to select Arc force. 4. Parameter adjust knob: Rotate it to adjust welding current and value of Hot start and Arc force.

  • Page 22: Hf/Lift Tig Display Introduction

    INSTALLATION & OPERATION §3.2.3 HF/LIFT TIG display introduction 1. Welding mode button: Press it to enter HF TIG or Lift TIG welding mode. 2. Trigger mode button: Press it to select 2T or 4T trigger mode. 3. Welding function button: Press it to select No Pulse/ Pulse/ Spot welding function. (Here is no Spot function in Lift TIG welding mode.) 4.

  • Page 23: Tig Pulse Display Introduction

    INSTALLATION & OPERATION parameters. Rotate it to adjust parameters’ value. 8. Current display: It displays welding current during welding operation, otherwise show current selected. 9. Welding voltage display. §3.2.4 TIG PULSE display introduction 1. Peak current: 3~200A. 2. Base current: 3~200A, but less than Peak current. 3.

  • Page 24: Job Program Introduction

    INSTALLATION & OPERATION 2. T display: 0.2~1.0s. 3. T display: off~10.0s. §3.2.6 JOB Program introduction 1. Welding mode display: Here are selected welding states. 2. Parameters display: Here are all selected parameters values. 3. JOB number: A total 1~10 JOB numbers can store or call the selected parameters by JOB button.

  • Page 25: Installation & Operation For Mma Welding

    INSTALLATION & OPERATION §3.3 Installation & Operation for MMA welding §3.3.1 Set up installation for MMA Welding Connection of Output Cables Two sockets are available on this welding machine. For MMA welding the electrode holder is shown be connected to the positive socket, while the earth lead (work piece) is connected to the negative socket, this is known as DCEP.

  • Page 26: Operation For Mma Welding

    INSTALLATION & OPERATION (5) With the corresponding input power supply terminal or socket good contact and prevent oxidation; (6) With a multi meter measure the input voltage is within the fluctuation range; (7) The power ground is well grounded. §3.3.2 Operation for MMA Welding (1) According to the above method to install is correct, rotate the power switch, so that the power switch is “ON”...

  • Page 27: Mma Welding

    INSTALLATION & OPERATION §3.3.3 MMA Welding One of the most common types of arc welding is manual metal arc welding (MMA) or stick welding. An electric current is used to strike an arc between the base material and a consumable electrode rod or ‘stick’. The electrode rod is made of a material that is compatible with the base material being welded and is covered with a flux that gives off gaseous vapours that serve as a shielding gas and providing a layer of slag, both of which protect the weld area from atmospheric contamination.

  • Page 28: Mma Welding Fundamentals

    INSTALLATION & OPERATION The Metal Wire Core works as conductor of the current that maintains the arc. The core wire melts and is deposited into the welding pool. The covering on a shielded metal arc welding electrode is called Flux. The flux on the electrode performs many different functions.

  • Page 29: Arc Length

    INSTALLATION & OPERATION  Welding Current (Amperage) Electrode Size Current Range ø mm (Amps) 2.5 mm 60~95 3.2 mm 100~130 4.0 mm 130~165 5.0 mm 165~260 Correct current selection for a particular job is an important factor in arc welding. With the current set too low, difficulty is experienced in striking and maintaining astable arc.

  • Page 30: Installation & Operation For Tig Welding

    INSTALLATION & OPERATION degrees to the work piece.  Travel Speed The electrode should be moved along in the direction of the joint being welded at a speed that will give the size of run required. At the same time, the electrode is fed downwards to keep the correct arc length at all times.

  • Page 31: Dc Tig Welding

    INSTALLATION & OPERATION (1) Insert the earth cable plug into the positive socket on the front of the machine and tighten it. (2) Plug the welding torch into the negative socket on the front panel, and tighten it. (3) Connect the gas line of TIG Gun to outlet gas connector on the front of the machine. (4) Connect the control cable of torch switch to 12 pin socket on the front of the machine.

  • Page 32: Tig Welding Fusion Technique

    INSTALLATION & OPERATION be connected to (this rule applies to all the other forms of DC welding as well). DC TIG welding is a process in which an arc is struck between a TUNGSTEN electrode and the metal work piece. The weld area is shielded by an inert gas flow to prevent contamination of the tungsten, molten pool and weld area.
  • Page 33 INSTALLATION & OPERATION hand while manipulating the welding torch in the other. However, some welds combining thin materials can be accomplished without filler metal like edge, corner, and butt joints. This is known as Fusion welding where the edges of the metal pieces are melted together using only the heat and arc force generated by the TIG arc.

  • Page 34: Tungsten Electrodes

    INSTALLATION & OPERATION §3.4.4 Tungsten Electrodes Tungsten is a rare metallic element used for manufacturing TIG welding electrodes. The TIG process relies on tungsten’s hardness and high-temperature resistance to carry the welding current to the arc. Tungsten has the highest melting point of any metal, 3,410 degrees Celsius.
  • Page 35 INSTALLATION & OPERATION E3 tungsten electrodes (AWS classification EWG) contain a minimum of 98% percent tungsten and up to 1.5 percent Lanthanum and small percentages of Zirconium and Yttrium they are called E3 Tungsten. E3 Tungsten Electrodes provide conductivity similar to that of thoriated electrodes.

  • Page 36: Tungsten Preparation

    INSTALLATION & OPERATION use with AC sine wave power sources. Lanthanated tungsten maintains a sharpened point well, which is an advantage for welding steel and stainless steel on DC or AC from square wave power sources. Zirconiated (Color Code: White) Zirconiated tungsten electrodes (AWS classification EWZr-1) contain a minimum of 99.10 percent tungsten and 0.15 to 0.40 percent zirconium.
  • Page 37 INSTALLATION & OPERATION Electrode Tip/Flat The shape of the tungsten electrode tip is an important process variable in precision arc welding. A good selection of tip/flat size will balance the need for several advantages. The bigger the flat, the more likely arc wander will occur and the more difficult it will be to arc start.

  • Page 38: Operation Environment

    INSTALLATION & OPERATION • Have a wider arc • Have a more consistent arc The included angle determines weld bead shape and size. Generally, as the included angle increases, penetration increases and bead width decreases. Tungsten Diameter at Constant Included Current Range Current Range Diameter...
  • Page 39 INSTALLATION & OPERATION output electrode with any part of your body.  Before operation, no concerned people should be left. Do not watch the arc in unprotected eyes.  Ensure good ventilation of the machine to improve duty ratio.  Turn off the engine when the operation finished to economize energy source. ...

  • Page 40: Maintenance & Troubleshooting

    MAINTENANCE & TROUBLESHOOTING §4 Maintenance & Troubleshooting §4.1 Maintenance In order to guarantee that arc welding machine works high-efficiently and in safety, it must be maintained regularly. Let customers understand the maintenance methods and means of arc welding machine more, enable customers to carry on simple examination and safeguarding by oneself, try one's best to reduce the fault rate and repair times of arc welding machine, so as to lengthen service life of arc welding machine .Maintenance items in detail are in the following table.

  • Page 41: Troubleshooting

    MAINTENANCE & TROUBLESHOOTING Observe that whether the current output cable is damaged. If it is damaged, it should be wrapped up, insulated or changed. Use the dry compressed air to clear the inside of arc welding machine. Especially for clearing up the dusts on radiator, main voltage transformer, Monthly inductance, IGBT module, the fast recover diode and PCB, etc.
  • Page 42 MAINTENANCE & TROUBLESHOOTING Troubles Reasons Solution no-load voltage Check the main circuit and the The machine is damaged output (MMA) Pr4. The welding cable is not connected Connect the welding cable to with the two output of the welder. the welder’s output. The welding cable damaged.

  • Page 43: Mma Welding - Trouble Shooting

    MAINTENANCE & TROUBLESHOOTING §4.3 MMA Welding - Trouble Shooting The following chart addresses some of the common problems of MMA welding. In all cases of equipment malfunction, the manufacturer’s recommendations should be strictly adhered to and followed. Trouble Possible Reason Suggested Remedy Check earth lead is connected.

  • Page 44: Dc Tig Welding - Trouble Shooting

    MAINTENANCE & TROUBLESHOOTING metal during Use the correct welding technique or welding Poor welding technique seek assistance for the correct technique Check the joint design and fit up, Poor joint preparation and or make sure the material is not too thick. joint design Seek assistance for the correct joint design and fit up...
  • Page 45 MAINTENANCE & TROUBLESHOOTING color restricted. Set the gas flow between 20~40 CFH (6~12 l/min). Check hoses and fittings for leaks Remove moisture and materials like Contaminated base metal paint, grease, oil and dirt from base metal Remove all grease, oil or moisture Contaminated filler wire from filler metal Check the filler wire and change if...

  • Page 46: List Of Error Code

    MAINTENANCE & TROUBLESHOOTING Check and change the size and or the Incorrect tungsten size or type tungsten if required Loose connection Check all connectors and tighten Earth clamp not connected to Connect the earth clamp directly to the work work piece wherever possible §4.5 List of error code Error Type Error code...

  • Page 47: Electrical Principle Drawing

    MAINTENANCE & TROUBLESHOOTING §4.6 Electrical principle drawing...
