IGBT INVERTER • DC MMA / LIFT TIG • WELDING MACHINE
Part No. 9021
INSTRUCTIONS
DIGI-ARC160STL
OPERATING
Suitable for
220~240V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stealth DIGI-ARC160STL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWP Stealth DIGI-ARC160STL

Summary of Contents for SWP Stealth DIGI-ARC160STL

  • Page 1 DIGI-ARC160STL IGBT INVERTER • DC MMA / LIFT TIG • WELDING MACHINE Part No. 9021 Suitable for 220~240V OPERATING INSTRUCTIONS...

  • Page 2: Safety Precautions

    STEALTH DIGI-ARC160STL SAFETY PRECAUTIONS Follow these precautions carefully. Improper use of any welder can result in injury or death. 1. ONLY CONNECT MACHINE TO A POWER SOURCE FOR WHICH IT WAS DESIGNED. THE SPECIFICATION PLATE ON THE MACHINE LISTS THIS INFORMATION. WHEN WELDING OUTDOORS ONLY USE AN EXTENSION CORD INTENDED FOR SUCH USE.

  • Page 3: Operating Condition And Work Surrounding

    STEALTH DIGI-ARC160STL MAIN USE AND RANGE STEALTH DIGI-ARC160STL inverter arc machine is a welding machine incorporating IGBT and features performance and high efficiency. The welding current is infinitely and independently adjustable. All ferrous metal, copper and stainless steel material can be omni-bearing welded in all positions.

  • Page 4: Product Description

    STEALTH DIGI-ARC160STL connect the protection grounding of the welder. PRODUCT DESCRIPTION d. Welding operation should be carried out in dry and good ventilating area. T • Before welding, the operator should read the operating instructions. surrounding objects should be not less than 0.5m away from the welder.

  • Page 5: Machine Operation

    .METHOD OF THE OPERATION STEALTH DIGI-ARC160STL -1. hand welding with electrode(MMA) MACHINE OPERATION ① .Put switch"2" (MMA/TIG switch) onto the position "MMA". 6.1 HAND WELDING WITH ELECTRODE (MMA) Selecting empiric formula: I=40*d ,d is dia. of the electrode. Put switch 2 (MMA/TIG switch) to position MMA.

  • Page 6: Troubleshooting

    STEALTH DIGI-ARC160STL TROUBLESHOOTING Problems Causes Solutions Power lamp not lit 1. No electricity input 1. Check incoming line 2. Machine switch fails 2. Replace switch Fan not rotating 1. Fan power line is off 1. Reconnect the line 2. Fan enclosure is blocked 2.
  • Page 7 STEALTH DIGI-ARC160STL Do not touch electrically live parts or Keep flammable materials away. Wear eye, ear and body protection. WARNING electrode with skin or wet clothing. Insulate yourself from work and ground. Spanish No toque las partes o los electrodos Mantenga el material combustible Protéjase los ojos, los oídos y el...
  • Page 8 LEIA E COMPREENDA AS INSTRUÇÕES DO FABRICANTE PARA ESTE EQUIPAMENTO E AS PARTES DE USO, E SIGA AS PRÁTICAS DE SEGURANÇA DO EMPREGADOR. Specialised Welding Products Ltd Unit 1, Farringdon Industrial Centre, Farringdon, Nr Alton, Hampshire GU34 3DD, UK tel: +44 (0)1420 588180 • fax: +44 (0)1420 588184 • email: sales@swp.uk.net...
